Inter-m VRC-1104T User manual

MADE IN KOREA
9007982810
Inter-M, Ltd. (Korea) began operations in 1983.
Since then, Inter-M has grown to become one of the largest manufacturers
of professional audio and commercial sound electronics equipment in the world.
Inter-M has gained worldwide recognition for its own branded products,
as well as private label manufacturing of electronics sold under other names (OEM).
The company is no longer just a Korean company, but rather a global company
that is truly international in scope, with factories and offices in Korea and China,
and sales and marketing operations located in Japan, Europe, and the U.S.A.
With more than 850 employees around the globe,
Inter-M is well-poised for further growth and expansion.
Inter-M Americas, INC.
13875 ARTESIA BLVD. CERRITOS, CA 90703 USA
TEL : [phone], FAX : [phone]
Home Page : http://www.inter-m.net, E-mail : [email protected]
Inter-M Corporation
SEOUL OFFICE:653-5 BANGHAK-DONG, DOBONG-KU, SEOUL, KOREA
TEL : [phone]~8, FAX : [phone]
Home Page : http://www.inter-m.com, E-mail : [email protected]

VRC-1104T Pan/Tilt Zoom Controller
VRC-1104T
PAN/TILT ZOOM CONTROLLER
ZOOM FOCUS
LENS
CHANNEL QUAD
CH 2 CH 3 CH 4CH 1
WIDETELE NEARFAR AUTO PAN
UP
LEFT RIGHT
DOWN
PAN/TILT
ON
OFF
POWER

Contents
Contents
1. Unpacking and Installation.....................................................................................................1
2. Definition ..............................................................................................................................2
3. Features ................................................................................................................................2
4. Front Panel Controls...............................................................................................................3
5. Rear Panel Controls ...............................................................................................................4
6. Installation and Wiring ..........................................................................................................5
7. Block Diagram.......................................................................................................................9
8. Specifications.......................................................................................................................10

1
VRC-1104T
PAN/TILT ZOOM CONTROLLER
Unpacking and Installation
Unpacking and Installation
Although it is neither complicated to install nor difficult to operate your Pan/Tilt Zoom Controller, a
few minutes of your time is required to read this manual for a properly wired installation and
becoming familiar with its many features and how to use them. Please take a great care in unpack-
ing your set and do not discard the carton and other packing materials. They may be needed when
moving your set and are required if it ever becomes necessary to return your set for service.
Never place the unit near radiators, in front of heating vents, in excessively humid or dusty location
to avoid early damage and for your years of quality use. Connect your complementary components
as illustrated in the following page.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of suf-
ficient magnitude to constitute a risk of electric
shock to persons.
This symbol is intended to alert the user to the
presence of important operation and mainte-
nance (servicing) instructions in the literature
accompanying the appliance.
Caution: To prevent electric shock do not use this (polarized) plug
with an extension cord, receptacle or other outlet unless
the blades can be fully inserted to prevent blade expo-
sure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de
courant on une autre sortie de courant, sauf si les
lames peuvent étre insérées à fond sans en laisser
aucune partie à découvert.
* Do not install this apparatus in a confined space such as a book case or similar unit.
* The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be place on the apparatus.

2VRC-1104T
PAN/TILT ZOOM CONTROLLER
Definition
Definition
Power AC 24V and multi channel pan/tilt controller.
Features
- TABLE TYPE PAN/TILT CONTROLLER
Table type pan/tilt controller of up/down/left/right and zoom.
- MAXIMUM CH14 PAN/TILT CONTROL FUNCTION
Possible to connect maximum 4CH pan/tilt/zoom.
- LINKAGE OPERATION
Allows syncronous video and pan/tilt/zoom operation with VQD-1204 & VSW-1208.
- VARIOUS VOLTAGE CONTROL FOR ZOOM SPEEDD
External ±6V/±9V voltage selection allows various lens zoom speed.
- MICOM CONTROL TYPE
Very stable operation designed MICOM ic.

Front Panel Controls
Front Panel Controls
1. POWER SWITCH
Power on/off switch.
2. CHANNEL SELECT SWITCH
Remote pan/tilt/zoom control among four channels.
3. CONTROL LEVER
Pan/tilt driver control by lever.
4. AUTO PAN SWITCH
Automatic pan/tilt control switch.
5. QUAD SWITCH
Quad screen display linkage with VQD-1204/VQD-1305.
3
VRC-1104T
PAN/TILT ZOOM CONTROLLER
VRC-1104T
PAN/TILT ZOOM CONTROLLER
ZOOM FOCUS
LENS
CHANNEL QUAD
CH 2 CH 3 CH 4CH 1
WIDETELE NEARFAR AUTO PAN
UP
LEFT RIGHT
DOWN
PAN/TILT
ON
OFF
POWER
132 5
4

4VRC-1104T
PAN/TILT ZOOM CONTROLLER
Rear Panel Controls
Rear Panel Controls
1. AC INPUT
AC input cord terminal.
2. CONTROL SIGNAL OUTPUT TERMINAL
The signal controlled from front is transmitted to pan/tilt driver through these terminals.
3. EXT SELECT OUTPUT TERMINAL
It is for external channel selection connection with VSW-1208 or VQD-1204/VQD-1305. This
allows direct or binary output.
4. LENS VOLTAGE CONTROL SWITCH
External ±6V/±9V voltage selection for various zoom speed change.
9V6V
43 2 1
www.inter-m.com
EXT
SELECT OUT
LENS
CONTROL
SELECTOR
CHANNEL
SN
~AC INPUT
230V 50Hz, 10W
CAUTION;TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
AVIS;RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR.
MADE IN KOREA
MODEL NO. VRC-1104T
PAN/TILT ZOOM CONTROLLER
23
14

5
VRC-1104T
PAN/TILT ZOOM CONTROLLER
Installation and Wiring
Installation and Wiring
- INSTALLATION AND WIRING
1. In case of using VSW-1208, please set the switch to EXT-SEL ON to control VSW-1208.
2. In case of using VSW-1208, please set the switch to CH-SEL ON to control full 8CH.
3. You may change the speed of zoom controlling the switch that is in rear panel to 6V tap.
4. Duration of relay is 100,000 times.
You would better replace over due relay for proper operation.
VSW-1208
CHANNEL 4
9V6V
43 2 1
www.inter-m.com
EXT
SELECT OUT LENS
CONTROL
SELECTOR
CHANNEL
SN
~AC INPUT
230V 50Hz, 10W CAUTION;TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOTREMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
AVIS;RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR.
MADE IN KOREA
MODEL NO. VRC-1104T
PAN/TILT ZOOM CONTROLLER
VQD-1204 VQD-1305
CHANNEL 3
CHANNEL 2
CHANNEL 1

6VRC-1104T
- CHANNEL OUTPUT SIGNAL
- EXT SELECT OUT OUTPUT SIGNAL
PAN/TILT ZOOM CONTROLLER
CHANNEL OUTPUT SPEC
PIN OUTPUT PIN OUTPUT
1 P/T COM (Brown) 6 DOWN (Blue)
2 LEFT (Red) 7 AUTO (Violet)
3 RIGHT (Orange Color) 8 ZOOM (Grey)
4 GND (Yellow) 9 LENS COM (GND) (White)
5 UP (Green) 10 FOCUS (Black)
PIN SIGNAL NAME
1 GND
2 EXT SEL OUTPUT (DIRECT OR BINARY)
3 EXT SEL OUTPUT (DIRECT OR BINARY)
4 EXT SEL OUTPUT (DIRECT OR BINARY)
5 EXT SEL OUTPUT (DIRECT)
6NC
7NC
8NC
9 QUAD OUTPUT

7
VRC-1104T
PAN/TILT ZOOM CONTROLLER
- LINKAGE CONNECTION
1. With VQD-1204 (VQD-1305)
* You must turn off the power of VRC-1104T to set the MENU of VQD-1204.
GND
( )
SNREMOTE
ALARM IN
1VCR
IN
MON 2 3 4
COM 1234NC COM NO G S
4
2
3
1
AC INPUT 100V~230V,50/60Hz 6W
~ALARM OUT
OUT
RELAY TRIG
9V6V
43 2 1
www.inter-m.com
EXT
SELECT OUT LENS
CONTROL
SELECTOR
CHANNEL
SN
~AC INPUT
230V 50Hz, 10W CAUTION;TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOTREMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
AVIS;RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR.
MADE IN KOREA
MODEL NO. VRC-1104T
PAN/TILT ZOOM CONTROLLER
REMOTE
EXT SELECT OUT
VRC-1104T VQD-1204/VQD-1304
EXT SELECT PIN REMOTE
19
24
35
46
57
98
(D-SUB 9PIN FOR CONNECTION)

8VRC-1104T
PAN/TILT ZOOM CONTROLLER
2. With VSW-1208 (VQD-1304)
* Please choice alarm input to EXT in VSW-1208 set MENU(2) and make alarm condition to binary.
2 / 10
SN
GND TIMER (IN / OUT) ALARM INPUT SPOT SELECT IN
SELECT OUT
AUTO
OUT
1 / 9 3 / 11 4 / 12 5 / 13 6 / 14 7 / 15 8 / 16
~AC INPUT
100V~230V,50/60Hz
4W SPOT
OUT
CAMERA INPUT
( )
ALARM
EFX SELECT OUT
9V6V
43 2 1
www.inter-m.com
EXT
SELECT OUT
LENS
CONTROL
SELECTOR
CHANNEL
SN
~AC INPUT
230V 50Hz, 10W
CAUTION;TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
AVIS;RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR.
MADE IN KOREA
MODEL NO. VRC-1104T
PAN/TILT ZOOM CONTROLLER
VRC-1104T VSW-1208*
EXT SELECT PIN ALARM PIN
19
21
32
43

9
VRC-1104T
PAN/TILT ZOOM CONTROLLER
Block Diagram
Block Diagram

10 VRC-1104T
PAN/TILT ZOOM CONTROLLER
Specifications
Specifications .........................................................0dB=0.775Vrms
- ELECTRICAL
PAN/TILT Control Voltage................................................................................................AC 24V
LENS Control Voltage ..............................................................................................DC 6V or 9V
Output Terminal...................................................................................Wire to Board Type 10 pin
- GENERAL
Power Source .....................................................................................AC 100V–240V, 50/60Hz
Power Consumption .............................................................................................................10W
Weight...............................................................................................................................2.4kg
Dimensions.......................................................................................322(W)×65(H)×200(D)mm
* Specifications and design subject to change without notice for improvements.
