Intercoax MCP-501T User manual

Package
MCP-501T
MCP-501R
MCP-501TL
MCP-501RL
Quick Start
Guide
Grounding Method
ÎWhen connecting the product to the ground, connect it to
the dedicated ground line. DO NOT connect the ground to
water pipes, gas piping or heating piping.
Hardware Overview
Top
Power
Eth. Link
Join Link
PoE
Right
Left
상태 표시등ETHERNET
M12 D-code 4P
제품 고정 나사용 홀
접지단자용 홀
COAX : BNC (No Analog camera)
Status LED Indicators
ÎConnect only PoE-supported products to Ethernet(M12) port
of the MCP-501T. If it is not a PoE product, the product may
be damaged due to electric shock.
Top
Power
Eth. Link
Join Link
PoE
Right
Left
상태 표시등ETHERNET
M12 D-code 4P
제품 고정 나사용 홀
접지단자용 홀
COAX : BNC (No Analog camera)
Ground Terminal Hole
Mounting Screw Hole
Overview
MCP-501 is Ethernet / PoE over Coax converter that
transmits the network data and PoE power over coaxial cable
simultaneously.
It is cost-effective and time saving solution to migrate existing
analog system to IP based system utilizing the existing coax
cable infrastructure.
This is an industrial product made in accordance with the IP65
standard of waterproofing and railway certification standards.
Features
Long range Ethernet over Coax communication following
IEEE1901 Standard
Network data and PoE over Coax (PoC, PoE)
Max. 95Mbps Bandwidth (Max. 270Mbps between MCP-501)
10/100 Full Duplex Ethernet Communication
M12 4 pin standard interface
IEEE802.3 at/af standard PD(Rx only)/PSE(Tx only).
Reliability based on railway certification standards and
industrial environments
IP65 water resistance
MCP-501T / MCP-501R
MCP-501TL / MCP-501RL
Quick Start Guide
Please read carefully the instruction manual before use.
Depending on the model, the image
and the actual look of the product may vary.
[Rev.1.0]

Caution
Please install the device following the installation guide.
Do not touch the device and cable with wet hands.
Keep away from moisture and shock.
Do not install near any heat sources such as radiators, heat
registers, stoves or other apparatus that produce heat.
Indoor use only.
Do not use for other purposes.
Do not disassemble or modify this device.
Do not put any sticker or paint on it.
If this device is defective or malfunctioning, please unplug
the power adapter immediately and contact dealer or service
center.
Warranty
This device has passed the quality control and product
inspection.
Please install and use according to the installation guide.
The warranty period for this product is 24 months from the
date of purchase.
If this device is defective or malfunctioning, please unplug
the power adapter immediately and contact dealer or service
center.
Any damages or breakage from user’s abuse, accident,
modification or natural disasters will not be covered
manufacturer’s warranty.
EN50155
Installation Guide
1. Set the IP address on the camera following the instruction
manual of the camera.
ÎIf the camera IP is automatically assigned (DHCP, etc.), there
is no need to set the camera IP separately.
2. Connect BNC of the coaxial cable to each MCP-501T and
MCP-501R.
3. Connect M12 D-Code 4P(Male) cable from the PoE Switching
Hub or NVR to Ethernet port(M12)of the MCP-501R.
4. When the connection is completed, check Power / Eth.Link /
Join Link LED is turned on properly.
ÎIn case of 7W camera, the device supports long distance PoE
transmission up to 1,000m over RG6 coaxial cable.
PoE transmission distance can be varied depending on cable
type and Camera's power consumption(W).
5. Connect PoE IP Camera to MCP-501T and Eth.Link LED is
turned on after camera operates properly.
ÎMCP-501T and R transmit Ethernet data and power
simultaneously over Coaxial (BNC) cable.
ÎMCP-501T/R are products without DC-Jack.
MCP-501T is powered by MCP-501R through the Coaxial
cable and outputs PoE to camera via Ethernet (M12) port.
MCP-501R is powered by PoE through Ethernet (M12) port.
6. Ping test is recommended to confirm the whole network
after installation.
7. Check the video signal on the monitor.
LED Indicators
Indicator Color Function
Power Power on LED
Eth. Link Ethernet Link/Act LED
Join Link Join/Link LED
PoE PoE LED
Applications
MCP-501R
AC/DC
Adapter(12V)
PoE NVR /
PoE Switch
MCP-501T
Non-PoE IP
Camera
MCP-501T
PoE IP
Camera
Coaxial Cable
10/100 Ethernet
10/100 Ethernet
PoE
Coaxial Cable
MCP-501R
MCP-501RL
MCP-501TL
MCP-501TL
MCP-501RL
Please visit below website for more detailed information.
http://www.intercoax.com
TEL : [phone]~4 FAX : [phone]
E-mail : [email protected]
