Intermec 70 User manual

Model 70 Pocket PC
P/N 961-054-025
Edition A
March 2001
User’s Guide

Intermec Technologies Corporation
6001 36th Avenue West
P.O. Box 4280
Everett, WA 98203-9280
U.S. service and technical support: 1-800-755-5505
U.S. media supplies ordering information: 1-800-227-9947
Canadian service and technical support: 1-800-668-7043
Canadian media supplies ordering information: 1-800-268-6936
Outside U.S.A. and Canada: Contact your local Intermec service supplier.
The information contained herein is proprietary and is provided solely for the purpose of allowing customers
to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for
any other purpose without written permission of Intermec.
Information and specifications in this manual are subject to change without notice.
2001 by Intermec Technologies Corporation
All Rights Reserved
The word Intermec, the Intermec logo, INCA (under license), JANUS, IRL, Trakker Antares, Adara,
EZBuilder, TE 2000, Data Collection Browser, dcBrowser, Universal Access Point, UAP, Duratherm,
EasyCoder, Precision Print, PrintSet, Virtual Wedge, and CrossBar are either trademarks or registered
trademarks of Intermec.
Microsoft, ActiveSync, Outlook, Pocket Outlook, Windows, Windows NT, and the Windows logo are either
registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Microsoft products are licensed to OEMs by Microsoft Licensing, Inc., a wholly owned subsidiary of
Microsoft Corporation.
Throughout this manual, trademarked names may be used. Rather than put a trademark (or ) symbol in
every occurrence of a trademarked name, we state that we are using the names only in an editorial fashion, and
to the benefit of the trademark owner, with no intention of infringement.

1233
Contents
iii
Contents
Before You Begin ix
Warranty Information ix
Safety Summary ix
Warnings, Cautions, and Notes x
About This Manual xi
Other Intermec Manuals xi
Learning About the Pocket PC
Welcome 1-3
Pocket PC Description 1-3
Front Panel View 1-3
Back Panel View 1-5
Left Edge View 1-6
Top Edge View 1-7
About the Batteries 1-8
Charging the Batteries 1-9
Monitoring the Batteries 1-10
Managing the Batteries 1-11
Using the AC Adapters and Cradles 1-13
Using the Stylus 1-15
Where to Find Information 1-16
Using the Pocket PC
Turning the Pocket PC On and Off 2-3
Opening the Today Screen 2-3
Opening Programs 2-4
Using the Navigation Bar and the Command Bar 2-6
Using Pop-up Menus 2-7
1
2

Model 70 Pocket PC User’s Guide
iv
Entering Information on the Pocket PC 2-8
Using the Input Panel 2-8
Writing on the Screen 2-10
Drawing on the Screen 2-12
Recording a Message 2-13
Finding and Organizing Information 2-14
Using Compact Flash Cards 2-15
Guidelines 2-15
Backing Up and Restoring Data 2-16
Backing Up Data to a Compact Flash Card 2-16
Restoring Data From a Compact Flash Card 2-18
Customizing Your Pocket PC 2-19
Setting a Password 2-20
Adding or Removing Programs 2-20
Customizing the Start Menu 2-22
Setting Notifications 2-22
Adjusting the Backlight 2-24
Using Your Desktop 2-25
Adding Program Icons to Your Desktop 2-26
Deleting Program Icons From Your Desktop 2-27
Managing Programs in Your Desktop 2-28
Microsoft Pocket Outlook
Using Calendar 3-3
Entering Appointments 3-4
About the Calendar Summary Screen 3-5
Creating Meeting Requests 3-5
Using Contacts 3-6
Creating Contacts 3-7
About the Contacts Summary Screen 3-8
Using Tasks 3-9
Creating Tasks 3-10
About the Tasks Summary Screen 3-11
Using Notes 3-12
3

1233
Contents
v
Using Inbox 3-13
Synchronizing E-Mail Messages 3-13
Connecting Directly to an E-Mail Server 3-13
Understanding Received E-Mail Messages 3-14
Composing and Sending E-Mail Messages 3-16
Managing E-Mail Messages and Folders 3-17
Folder Behavior With ActiveSync 3-17
Folder Behavior With A Direct Connection To An E-Mail Server 3-18
Microsoft Pocket Internet Explorer
Setting Up Pocket Internet Explorer 4-3
About the Mobile Favorites Folder 4-3
Creating Mobile Favorites 4-3
About Channels 4-5
Using AvantGo Channels 4-5
Using Mobile Channels 4-5
Using Pocket Internet Explorer 4-6
Companion Programs
Pocket Word 5-3
Typing Mode 5-4
Writing Mode 5-5
Drawing Mode 5-5
Recording Mode 5-5
Pocket Excel 5-6
Tips for Working in Pocket Excel 5-7
Expenses 5-8
Creating Records 5-8
Calculating and Viewing Expenditure Totals 5-10
Printing a List of Records 5-11
Microsoft Money 5-13
Creating Accounts 5-13
Viewing the Account Register 5-14
Entering Transactions 5-15
Entering and Tracking Investments 5-16
4
5

Model 70 Pocket PC User’s Guide
vi
Windows Media Player for Pocket PC 5-18
Using Windows Media Manager for the Pocket PC 5-19
What is Packaged Content? 5-20
Using the Playlist Manager 5-20
Microsoft Reader 5-21
Getting Books on Your Device 5-21
Using the Library 5-21
Reading a Book 5-22
Using Reader Features 5-23
Getting Connected
Connecting the Pocket PC 6-3
Transferring Data Using Infrared 6-4
Connecting to an ISP Through a Modem 6-5
Connecting to a Network 6-7
Creating a Modem Connection 6-7
Creating an Ethernet Connection 6-8
Connecting Directly to an E-mail Server 6-9
Ending a Connection 6-9
Get Help on Connecting 6-10
Troubleshooting
Resetting the Pocket PC 7-3
Performing a Soft Reset 7-3
Clearing Memory (Resetting to Factory Defaults) 7-3
Tips for Extending Battery Charge 7-4
Use External Power Whenever Possible 7-4
Shorten Auto-Suspend Time 7-4
Turn Off Sounds You Don’t Need 7-5
Turn Off Notification Light 7-5
Managing Memory 7-5
Adjusting Storage Memory 7-5
Adjusting Program Memory 7-6
6
7

1233
Contents
vii
Fixing Screen Problems 7-7
Screen Is Blank 7-7
Screen Is Dark 7-7
Screen Is Hard to Read 7-7
Stylus Problems 7-8
Fixing Connection Problems 7-8
Cable and Cradle Connection Problems 7-8
Infrared (IR) Connection Problems 7-8
Modem Connection Problems 7-9
Can’t Dial Out 7-9
Can Dial Out but Cannot Make a Proper Connection 7-9
Connection Is Unreliable 7-10
Network Connection Problems 7-10
Specifications and Other Helpful Information
Specifications A-3
Using Character Recognizer A-4
How to Transfer Palm-Size PC Data to a Pocket PC A-6
A

Model 70 Pocket PC User’s Guide
viii

Before You Begin
ix
Before You Begin
This section introduces you to standard warranty provisions, safety precautions,
warnings and cautions, document formatting conventions, and sources of additional
product information. A documentation roadmap is also provided to guide you in finding
the appropriate information.
Warranty Information
To receive a copy of the standard warranty provision for this product, contact your local
Intermec support services organization. In the U.S.A. call 1-800-755-5505, and in
Canada call 1-800-668-7043. If you live outside the U.S.A or Canada, you can find your
local Intermec support services organization on the Intermec Web site at
www.intermec.com.
Safety Summary
Your safety is extremely important. Read and follow all warnings and cautions in this
book before handling and operating Intermec equipment. You can be seriously injured,
and equipment and data can be damaged if you do not follow the safety warnings and
cautions.
Do not repair or adjust alone Do not repair or adjust energized equipment alone
under any circumstances. Someone capable of providing first aid must always be
present for your safety.
First aid Always obtain first aid or medical attention immediately after an injury.
Never neglect an injury, no matter how slight it seems.
Resuscitation Begin resuscitation immediately if someone is injured and stops
breathing. Any delay could result in death. To work on or near high voltage, you should
be familiar with approved industrial first aid methods.
Energized equipment Never work on energized equipment unless authorized by a
responsible authority. Energized electrical equipment is dangerous. Electrical shock
from energized equipment can cause death. If you must perform authorized emergency
work on energized equipment, be sure that you comply strictly with approved safety
regulations.

Model 70 Pocket PC User’s Guide
x
Warnings, Cautions, and Notes
The warnings, cautions, and notes in this manual use the following format.
Warning
A warning alerts you of an operating procedure, practice, condition, or statement
that must be strictly observed to avoid death or serious injury to the persons working
on the equipment.
Avertissement
Un avertissement vous avertit d’une procédure de fonctionnement, d’une méthode,
d’un état ou d’un rapport qui doit être strictement respecté pour éviter l’occurrence
de mort ou de blessures graves aux personnes manupulant l’équipement.
Caution
A caution alerts you to an operating procedure, practice, condition, or statement that
must be strictly observed to prevent equipment damage or destruction, or corruption
or loss of data.
Conseil
Une précaution vous avertit d’une procédure de fonctionnement, d’une méthode,
d’un état ou d’un rapport qui doit être strictement respecté pour empêcher
l’endommagement ou la destruction de l’équipement, ou l’altération ou la perte de
données.
Note: Notes are statements that either provide extra information about a topic or
contain special instructions for handling a particular condition or set of circumstances.

Before You Begin
xi
About This Manual
This manual contains all of the information necessary to install, operate, configure,
troubleshoot, and maintain the Model 70 Pocket PC.
This manual was written for analysts and programmers who operate, program, and
connect the Pocket PC to a network or system. A basic understanding of DOS,
programming, and data communications is necessary.
Terms
You should be aware of how these terms are being used in this manual:
Term Description
Pocket PC The Intermec Model 70 Pocket PC.
PC cards “PC cards” are also known as “PCMCIA cards.”
Format Conventions for Input From a Keyboard or Keypad
This table describes the formatting conventions for input from PC or host computer
keyboards and reader keypads:
Convention Description
Special text Shows the command as you should enter it into the reader. See
“Format Conventions for Commands” later in this chapter.
Italic text Indicates that you must replace the parameter with a value. See
“Format Conventions for Commands” later in this chapter.
Bold text Indicates the keys you must press on a PC or host computer
keyboard. For example, “press Enter” means you press the key
labeled “Enter” on the PC or host computer keyboard.
Other Intermec Manuals
You may need additional information when working with the Pocket PC in a data
collection system. Please visit our Web site at www.intermec.com to download many of
our current manuals in PDF format. To order printed versions of the Intermec manuals,
contact your local Intermec representative or distributor.

Model 70 Pocket PC User’s Guide
xii

Learning About the Pocket PC
1

Model 70 Pocket PC User’s Guide
1-2

Learning About the Pocket PC
1-3
1
This chapter describes the features of the Intermec Model 70 Pocket PC. It also
explains how to maintain the batteries and use the AC adapters, cradles, and stylus.
Welcome
Congratulations on purchasing an Intermec Model 70 Pocket PC powered by Microsoft®
Windows®CE. This Pocket PC is the most convenient way to manage your business
and personal information. Microsoft ActiveSync increases the power of your Pocket PC
by allowing you to synchronize the information with your desktop or laptop computer.
To get your Pocket PC up and running
1. Activate the backup battery and charge the main battery pack.
2. Turn on the Pocket PC.
3. Follow the setup wizard.
4. Use ActiveSync to establish a partnership with your desktop or laptop computer.
For help, see the Model 70 Pocket PC Quick Start Guide (Part No. 962-054-034).
Pocket PC Description
Here are four views of the Pocket PC that describe its features.
Front Panel View
1
2
3
4
5
6
7
M70PPG006.eps

Model 70 Pocket PC User’s Guide
1-4
Front Panel View
Item Component Function
nBattery Charge and Alarm
Light
This light serves as both a battery charge
indicator and a visual alarm indicator.
•Flashing green: Notification alarm signal.
•Flashing amber: Battery is charging.
•Solid amber: Battery is fully charged.
oWindows Key Displays the Start menu.
pDC Jack Accommodates the DC connector of the AC
adapter.
➍Power and Backlight Button Turns on and off your Pocket PC. Press and
release the button to turn on or off the Pocket
PC. Press and hold the button to turn on or off
the backlight.
These buttons open some of the most frequently
used applications.
Opens the Tasks application.
Opens the Contacts application.
Opens the Notes application.
➎Program Buttons
Opens the Calendar application.
➏Display Interprets stylus taps and displays information
onscreen.
tMicrophone The small hole at the top of the Pocket PC is the
microphone for the recorder.

Learning About the Pocket PC
1-5
1
Back Panel View
1
2
3
4
5
M70PPG007.eps
Item Component Function
➊Reset Button This button is recessed inside the Pocket PC.
Occasionally, some hardware or software
malfunctions can prevent the Pocket PC from
responding. To get it working again, use the tip
of the stylus to press the Reset button.
➋Backup Battery Compartment To open the backup battery cover, carefully press
your stylus under the semi-circular extension
resting in the indented shelf to the left of the
actual cover, then lift up the backup battery
cover with the stylus.
➌Speaker Through the speaker you can hear alarms and
sound recordings.
➍Communications Port This port establishes a hardware connection with
your desktop computer. You can connect the
Pocket PC to a desktop computer by using a
cradle or an auto-sync cable.
➎Main Battery Compartment This compartment holds the rechargeable main
battery pack. To open this cover, use your
thumbs to carefully slide the door horizontally
until it unlatches and then lift the door up and
away from the Pocket PC.

Model 70 Pocket PC User’s Guide
1-6
Left Edge View
123
M70PPG008.eps
Item Component Function
➊System Manager Button Press to go to Your Desktop, which contains
your most essential programs.
➋Action Button/Scroll Wheel This wheel has three actions.
•Press the center of the dial to use it as an
action button, like the Enter key on a full-
sized PC keyboard.
•Rotate the dial up to scroll upwards from
right to left through the desktop, or to scroll
up while you are using an application.
•Rotate the dial down to scroll downwards
from left to right through the desktop, or to
scroll down while you are using an
application.
➌Record Button Hold down this button to record brief notes and
messages while speaking into the built-in
microphone. For more information, see Chapter
2, “Using the Pocket PC.”

Learning About the Pocket PC
1-7
1
Top Edge View
2
1
4
3
M70PPG009.eps
Item Component Function
➊Infrared Port This port lets the Pocket PC exchange data with
other infrared-equipped devices. The infrared
port can transmit at speeds up to 115 Kbps For
more information, see Chapter 6, “Getting
Connected.”
➋Stylus Compartment The stylus compartment stores the stylus. When
you are finished using the stylus, insert it back
into the compartment. For help on using the
stylus, see “Using the Stylus”later in this
chapter.
➌Compact Flash Card Slot This slot is protected by a removable cover. It
supports Compact Flash Type I cards.
➍Audio Jack This jack lets you connect an audio headset to
your Pocket PC.

Model 70 Pocket PC User’s Guide
1-8
About the Batteries
Warning
Your computer contains a rechargeable lithium-ion battery pack. There is a risk of
fire and burns if the battery pack is handled improperly. Do not disassemble, crush,
puncture, short external contacts, or dispose of in fire or water. Do not attempt to
open or service the battery pack. Replace only with the battery pack designated for
this product. Discard used batteries according to the manufacturer's instructions.
Avertissement
Votre ordinateur est muni d'un bloc-batterie au lithium-ion. Le bloc-batterie présente
un risque d'incendie et de brûlures en cas de manipulation incorrecte. Ne pas
désassembler, écraser, trouer, court-circuiter les contacts externes, ou jeter dans un
feu ou dans de l'eau. Ne pas essayer d'ouvrir ou de réparer le bloc-batterie.
Remplacer uniquement par un bloc-batterie conçu pour ce produit. Jeter les batteries
usées conformément aux instructions du fabricant.
Warning
Your computer contains a coin-cell lithium battery. There is a danger of explosion
and risk of personal injury if the battery is incorrectly replaced or mistreated. Do not
attempt to recharge the battery, disassemble it, or immerse it in water or dispose of in
fire. Replace only with the battery designated for this product. Discard used batteries
according to the manufacturer's instructions.
Avertissement
Votre ordinateur est muni d'une batterie au lithium en forme de pièce. Le bloc-
batterie présente un danger d'explosion et un risque de blessures corporelles en cas
de manipulation ou de remplacement incorrect. Ne pas essayer de recharger le bloc-
batterie, de le désassembler, ou de l'immerger dans de l'eau ou de le jeter dans un feu.
Remplacer uniquement par un bloc-batterie conçu pour ce produit. Jeter les batteries
usées conformément aux instructions du fabricant.
Note: If you take out your main battery for any reason, do not turn on your Pocket PC
until you have replaced the battery cover and locked it securely back into place.
