Intermec CK30 User manual

ii CK30 Handheld Computer User’s Manual
Intermec Technologies Corporation
Corporate Headquarters
6001 36th Ave. W.
Everett, WA 98203
U.S.A.
www.intermec.com
The information contained herein is proprietary and is provided solely for the purpose
of allowing customers to operate and service Intermec-manufactured equipment and is
not to be released, reproduced, or used for any other purpose without written
permission of Intermec.
Information and specifications contained in this document are subject to change
without prior notice and do not represent a commitment on the part of Intermec
Technologies Corporation.
2003 by Intermec Technologies Corporation. All rights reserved.
The word Intermec, the Intermec logo, Norand, ArciTech, CrossBar, Data Collection
Browser, dcBrowser, Duratherm, EasyCoder, EasyLAN, Enterprise Wireless LAN,
EZBuilder, Fingerprint, i-gistics, INCA (under license), InterDriver, Intermec Printer
Network Manager, IRL, JANUS, LabelShop, Mobile Framework, MobileLAN,
Nor*Ware, Pen*Key, Precision Print, PrintSet, RoutePower, TE 2000, Trakker
Antares, UAP, Universal Access Point, and Virtual Wedge are either trademarks or
registered trademarks of Intermec Technologies Corporation.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
This product includes software developed by the OpenSSL Project for use in the
OpenSSL Toolkit. (http://www.openssl.org/)
This product includes cryptographic software written by Eric Young.
([e-mail])
Throughout this manual, trademarked names may be used. Rather than put a
trademark (or ) symbol in every occurrence of a trademarked name, we state that
we are using the names only in an editorial fashion, and to the benefit of the trademark
owner, with no intention of infringement.
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and/or other countries.
Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A.

Contents
CK30 Handheld Computer User’s Manual iii
Contents
Before You Begin.....................................................................................................vi
Safety Summary.........................................................................................vi
Safety Icons ..............................................................................................vii
Global Services and Support.....................................................................vii
Who Should Read This Document? ..........................................................ix
Related Documents ...................................................................................ix
Patent Information....................................................................................ix
Using the CK30 Handheld Computer.................................................1
Introducing the CK30 Handheld Computer.............................................................2
Understanding the CK30 Models and Options...........................................3
Using the CK30 Battery ...........................................................................................4
Maximizing Battery Life .............................................................................5
Checking the Battery Status........................................................................6
Charging and Installing the Battery ............................................................6
Using the Keypad .....................................................................................................7
Using the 42-Key Large Numeric and Function Keypad.............................8
Using the 50-Key Full Alphanumeric Keypad.............................................9
Using the 52-key Full Alphanumeric Keypad............................................10
Understanding How to Use the Keypad....................................................11
Capitalizing All Characters .......................................................................12
Using the International Keypad................................................................12
Using the TE 2000 Keypad ......................................................................13
Understanding the Power Key ..................................................................13
Using the Screen.....................................................................................................14
Navigating on the Screen..........................................................................14
Understanding the Screen Icons ...............................................................14
Rotating the Screen ..................................................................................15
Using the Mouse Pointer..........................................................................16
Understanding the LEDs ........................................................................................17
Understanding the CK30 Beeps..............................................................................18
Scanning Bar Codes................................................................................................19
Scanning With the Integrated Laser Scanner and 1D Linear Imager .........20
1

Contents
iv CK30 Handheld Computer User’s Manual
Scanning Bar Codes With the 2D Area Imager.........................................21
Attaching a Tethered Scanner...................................................................22
Using the SD Card .................................................................................................23
Configuring the CK30...................................................................................25
How to Configure the CK30 ..................................................................................26
Configuring the CK30 With the Setup Assistant ......................................27
Configuring the CK30 With the Configuration Utility.............................28
Configuring the CK30 With Commands Through the Network ..............31
Configuring the CK30 With the Intermec Configuration Utility (ICU) ...31
Configuring the CK30 by Scanning Bar Codes.........................................31
How the CK30 Fits Into Your Network..................................................................32
Using Serial Communications on the CK30 .............................................33
Using RF Communications on the CK30.................................................34
Using Ethernet Communications on the CK30 ........................................38
Configuring the CK30 for BluetoothWireless Printing ..........................39
Configuring Security on the CK30 .........................................................................40
Managing the CK30........................................................................................43
Accessing the System Main Menu...........................................................................44
Using File Manager ................................................................................................45
Using Task Manager...............................................................................................47
Using ActiveSync on the CK30...............................................................................48
Installing ActiveSync and Establishing a Partnership.................................48
Using ActiveSync to Copy Files and Install Applications...........................51
Installing Applications Using AutoCab ...................................................................52
Changing the Password...........................................................................................52
Saving Your Configuration or Application to Flash.................................................53
Upgrading the Firmware.........................................................................................53
2
3

Contents
CK30 Handheld Computer User’s Manual v
Troubleshooting and Maintaining the CK30.............................55
Problems and Solutions ..........................................................................................56
Problems While Operating the Terminal..................................................57
Problems While Configuring the Terminal...............................................57
Problems While Configuring 802.1x Security...........................................58
Problems With RF Connectivity...............................................................61
Problems Transmitting Data Through the Serial Port...............................63
Problems Transmitting Data Through the DCS 30X or G4000 ...............63
Problems While Scanning Bar Codes........................................................64
Booting the CK30 ..................................................................................................66
Warm Booting the CK30 .........................................................................66
Cold Booting the CK30 ...........................................................................67
Cleaning the Scanner Window and CK30 Screen ...................................................67
Appendix................................................................................................................69
Physical and Environmental Specifications..............................................................70
Accessories for the CK30 ........................................................................................71
Using Hidden Key Sequences .................................................................................73
4
A

Before You Begin
vi CK30 Handheld Computer User’s Manual
Before You Begin
This section provides you with safety information, technical
support information, and sources for additional product
information.
Safety Summary
Your safety is extremely important. Read and follow all warnings
and cautions in this document before handling and operating
Intermec equipment. You can be seriously injured, and
equipment and data can be damaged if you do not follow the
safety warnings and cautions.
Do not repair or adjust alone
Do not repair or adjust energized equipment alone under any
circumstances. Someone capable of providing first aid must
always be present for your safety.
First aid
Always obtain first aid or medical attention immediately after an
injury. Never neglect an injury, no matter how slight it seems.
Resuscitation
Begin resuscitation immediately if someone is injured and stops
breathing. Any delay could result in death. To work on or near
high voltage, you should be familiar with approved industrial
first aid methods.
Energized equipment
Never work on energized equipment unless authorized by a
responsible authority. Energized electrical equipment is
dangerous. Electrical shock from energized equipment can cause
death. If you must perform authorized emergency work on
energized equipment, be sure that you comply strictly with
approved safety regulations.

Before You Begin
CK30 Handheld Computer User’s Manual vii
Safety Icons
This section explains how to identify and understand dangers,
warnings, cautions, and notes that are in this document. You
may also see icons that tell you when to follow ESD procedures
and when to take special precautions for handling optical parts.
A warning alerts you of an operating procedure, practice,
condition, or statement that must be strictly observed to
avoid death or serious injury to the persons working on
the equipment.
Avertissement: Un avertissement vous avertit d’une
procédure de fonctionnement, d’une méthode, d’un état
ou d’un rapport qui doit être strictement respecté pour
éviter l’occurrence de mort ou de blessures graves aux
personnes manupulant l’équipement.
A caution alerts you to an operating procedure, practice,
condition, or statement that must be strictly observed to
prevent equipment damage or destruction, or corruption
or loss of data.
Attention: Une précaution vous avertit d’une procédure de
fonctionnement, d’une méthode, d’un état ou d’un
rapport qui doit être strictement respecté pour empêcher
l’endommagement ou la destruction de l’équipement, ou
l’altération ou la perte de données.
Note: Notes either provide extra information about a topic or
contain special instructions for handling a particular condition
or set of circumstances.
Global Services and Support
Warranty Information
To understand the warranty for your Intermec product, visit the
Intermec web site at http://www.intermec.com, click Support,
and then click Warranty.

Before You Begin
viii CK30 Handheld Computer User’s Manual
Disclaimer of warranties: The sample code included in this
document is presented for reference only. The code does not
necessarily represent complete, tested programs. The code is
provided “as is with all faults.” All warranties are expressly
disclaimed, including the implied warranties of merchantability
and fitness for a particular purpose.
Web Support
Visit the Intermec web site at http://www.intermec.com to
download many of our current manuals in PDF format. To
order printed versions of the Intermec manuals, contact your
local Intermec representative or distributor.
Visit the Intermec technical knowledge base (Knowledge
Central) at http://intermec.custhelp.com to review technical
information or to request technical support for your Intermec
product.
Telephone Support
These services are available from Intermec by calling
1-800-755-5505 and choosing an option.
Service Description Option
Factory Repair and
On-site Repair
Request a return authorization
number for authorized service center
repair, or request an on-site repair
technician.
1
Technical Support Get technical support on your
Intermec product.
2
Service Contract
Status
Inquire about an existing contract,
renew a contract, or ask invoicing
questions.
3
Schedule Site
Surveys or
Installations
Schedule a site survey, or request a
product or system installation.
4
Ordering Products Talk to sales administration, place an
order, or check the status of your
order.
5

Before You Begin
CK30 Handheld Computer User’s Manual ix
Who Should Read This Document?
The CK30 Handheld Computer User’s Manual provides you with
information about the features of the CK30, and how to install,
operate, maintain, and troubleshoot them.
Before you install and configure the CK30, you should be
familiar with your network and general networking terms, such
as IP address.
Related Documents
The Intermec web site at http://www.intermec.com contains
many of our documents that you can download in PDF format.
To order printed versions of the Intermec manuals, contact your
local Intermec representative or distributor.
Patent Information
Product is covered by one or more of the following patents:
4,455,523; 5,627,360; 4,553,081; 5,657,317; 4,709,202; 5,671,436;
4,845,419; 5,684,290; 4,961,043; 5,777,309; 5,195,183; 5,793,604;
5,216,233; 5,805,807; 5,218,187; 5,818,027; 5,218,188; 5,821,523;
5,227,614; 5,828,052; 5,241,488; 5,831,819; 5,278,487; 5,834,753;
5,322,991; 5,841,121; 5,331,136; 5,844,222; 5,331,580; 5,883,492;
5,349,678; 5,883,493; 5,397,885; 5,886,338; 5,371,858; 5,889,386;
5,373,478; 5,898,162; 5,410,141; 5,969,328; 5,488,575; 5,986,435;
5,500,516; 6,075,340; 5,504,367; 6,109,528; 5,508,599; 6,158,661;
5,530,619; 6,234,395; 5,567,925; 6,244,512; 5,568,645; 6,330,975;
5,592,512; 6,431,451; 5,598,007, 6,497,368; 5,617,343; 6,538,413.
There may be other U.S. and foreign patents pending.

Before You Begin
x CK30 Handheld Computer User’s Manual

Using the CK30 Handheld
Computer
Use this chapter to familiarize yourself with the CK30 Handheld
Computer. In this chapter you will find these sections:
• Introducing the CK30 Handheld Computer
• Using the CK30 Battery
• Using the Keypad
• Using the Screen
• Understanding the LEDs
• Understanding the Beeps
• Scanning Bar Codes
• Using the SD Card
1

Chapter 1 — Using the CK30 Handheld Computer
2 CK30 Handheld Computer User’s Manual
Introducing the CK30 Handheld Computer
The Intermec CK30 is the first in a new line of ergonomically
designed handheld computers built on the Microsoft®
Windows® CE .NET operating system. It is a lightweight, easy-
to-use, reliable computer that enables you to use legacy
applications as well as develop applications based on the latest
technologies. The CK30 supports programming tools such as
VB.NET, C#, JavaScript, and XML.
Use this table to understand the features included with each
model of the CK30. For a complete list of accessories, see the
Appendix.
Feature Model A Model B Model C
Batch only 9
.Net Compact Framework 9
Color Display 9
Monochrome Display 9 9
32M/32M Memory 99
64M/64M Memory 9
200 MHz Processor 99
400 MHz Processor 9
IBrowse 999

Chapter 1 — Using the CK30 Handheld Computer
CK30 Handheld Computer User’s Manual 3
Understanding the CK30 Models and Options
The CK30 computer is available in three different models that
consist of different options. To find out which model of the
CK30 you have, locate the configuration label on the back of the
computer. The first five letters of the configuration number
indicate the model of CK30 you ordered. For example, the label
in the following illustration is for a CK30 model A (CK30A).
CK30AA0301000
CK30AA0301000
Configuration
number
This option is available for model A of the CK30:
• 10/100 base T Ethernet interface
These options are available for models B and C of the CK30:
• TE 2000 including 3270, 5250, and VT/ANSI as well as
third-party TE applications
• WiFi certified 802.11b radio
• DcBrowser application
• Java™ platform
• 1D linear imager
• Bluetooth™ compatible module from Socket
Communications
These options are for the CK30 Model C only:
• 2D area imager

Chapter 1 — Using the CK30 Handheld Computer
4 CK30 Handheld Computer User’s Manual
™
CK30 Handheld Computers with an IEEE 802.11b radio
installed are Wi-Fi certified for interoperability with other
802.11b wireless LAN devices.
Use this manual to understand how to use the features and
options available on the CK30. For additional help using
terminal emulation, see the appropriate TE 2000 guide:
• TE 2000 5250 Terminal Emulation Programmer’s Guide
(P/N 977-055-004)
• TE 2000 3270 Terminal Emulation Programmer’s Guide
(P/N 977-055-003)
• TE 2000 VT/ANSI Terminal Emulation Programmer’s
Guide (P/N 977-055-005
For additional help using dcBrowser, see the documentation that
ships with your G4000, the dcBrowser gateway software, or the
Data Collection Browser Client User’s Guide (P/N 070011).
IBrowse is a locked-down web browser for Intermec devices that
is compatible with Microsoft's Internet Explorer but does not
allow the user to exit out of the browser or key in a URL to
access a non-work related website. For additional help using
IBrowse, see ??????
Using the CK30 Battery
The CK30 uses an AB1 lithium-ion battery as its main power
source. You must fully charge the main battery before you can
use the CK30.
If you fail to replace the battery immediately, you may lose
important data or applications.
Attention: Si la batterie n’est pas remplacée immédiatement,
des données ou applications importantes risquent d’être
perdues.

Chapter 1 — Using the CK30 Handheld Computer
CK30 Handheld Computer User’s Manual 5
The lithium-ion battery pack that is used in this device may
present a fire or chemical burn hazard if it is mistreated. Do
not disassemble it, heat it above 100° C (212° F) or
incinerate it.
Avertissement: Le paquet de piles d’ions de lithium qui est
utilisé dans cet appareil peut presenter un risque feu ou un
risque chimique de brûlure s’il est maltraité. Il ne faut pas le
désassembler, le réchauffer à une température plus élevée que
100° C (212° F) ou l’incinérer.
Dispose of used battery packs promptly. Keep away from
children. Contact your local Intermec sales representative for
replacement batteries.
Several factors determine the life of your battery such as extreme
temperatures, input devices, and your usage. For example, if you
use a tethered scanner every day, you will need to replace your
battery more often than someone who uses an internal scanner.
Maximizing Battery Life
To prolong the life of your battery, follow these guidelines.
When You Want To: Do This to Save Battery Power:
Operate the CK30 and
the Low Battery status
icon appears or the
Battery light comes on.
1Press Power to turn off the CK30.
2Remove the battery and insert another fully
charged battery within 10 minutes or you may
lose data.
Or, you can insert the CK30 into a powered
AC1, AC2, AD1, or AD2.
Stop using the CK30
for 5 minutes or longer.
1Make sure the Low Battery icon is not on the
screen and that the Battery light is not turned
on.
2Press Power to turn of f the CK30.
Store the CK30 for
more than a day.
1Save your data and end your computer session.
2Press Power to turn off the CK30.
3Insert a fully charged battery.

Chapter 1 — Using the CK30 Handheld Computer
6 CK30 Handheld Computer User’s Manual
Checking the Battery Status
The easiest way to tell the status of your battery is to look at the
battery icon in the status bar of your CK30.
Icon Status
Battery has a full charge.
Battery has a medium charge. You should be able to
work for several more hours before changing batteries.
Battery is low. You need to replace the battery now.
If you cannot see a status bar on your screen, you can also check
the battery status by looking at the Battery Status light on the
front of the CK30. See “Understanding the LEDs” later in this
chapter for more information.
Charging and Installing the Battery
Make sure you fully charge the AB1battery before you install it
in your CK30.
To charge the battery
• Either insert the battery into the AC1 4-slot battery charger
or place the CK30 with battery installed in the AC2, AD1, or
AD2.
Use the following table to understand how long it will take to
charge your batteries in each of the CK30 charging or
communications dock accessories.
CK30 Accessory Charging Time
AC1 4-Slot Battery Charger 5 hours
AC2 4-Bay Charging Dock 5 hours
AD1 1-Bay Communications Dock 3 hours
AD2 4-Bay Communications Dock 5 hours

Chapter 1 — Using the CK30 Handheld Computer
CK30 Handheld Computer User’s Manual 7
To install the battery
• Insert the tabs on the bottom of the charged battery into the
CK30 and snap the battery into place.
AB1
battery
Battery
latch
Using the Keypad
Your CK30 has one of the following keypad overlay options:
• 42-key large numeric and function
• 50-key full alphanumeric
• 52-key full alphanumeric
Each of these keypads also comes in an International version.
The International keypads support French, German, Italian,
Portuguese, and Spanish. Although the keypads are smaller than
standard PC or terminal keyboards, you can use special keys to
access all of the keys and functions you need.
In addition, there are keypad overlays available for each type of
TE 2000 supported: 3270, 5250, and VT/ANSI. You receive the
appropriate TE overlay when you order your TE 2000
application. Each TE 2000 keypad overlay is almost identical to
the standard keypad overlay, but it contains additional keys that
are available on an IBM 3270, IBM 5250, or VT/ANSI
keyboard. For help using your terminal emulation keypad
overlay, see your specific TE 2000 guide.

Chapter 1 — Using the CK30 Handheld Computer
8 CK30 Handheld Computer User’s Manual
Using the 42-Key Large Numeric and Function Keypad
Enter
Enter
Home
\
/
CAPS
Sp
Del
[
<
]
>
Ins
PROG
Green keyOrange key
Power key
Backlight key
Scan button
42-key large numeric and function keypad: Use this keypad to easily
print numbers (0-9) and access function keys F1 through F12. You can also
print the entire alphabet and special characters by pressing color-coded key
sequences.

Chapter 1 — Using the CK30 Handheld Computer
CK30 Handheld Computer User’s Manual 9
Using the 50-Key Full Alphanumeric Keypad
?
“‘
+
Power key
Green key
Orange key
Backlight key
50-key full alphanumeric keypad: Use this keypad to easily print numbers
(0-9) and the entire alphabet. You can access Function keys (F1-F9) and
special characters, symbols, and functions by pressing color-coded key
sequences.
Note: The 50-key keypad does not have a scan key because it
was designed to work with the AH1 handle that has a built-in
scanner trigger.

Chapter 1 — Using the CK30 Handheld Computer
10 CK30 Handheld Computer User’s Manual
Using the 52-key Full Alphanumeric Keypad
Alt
Tab
Enter
Enter
Home
+
&
^
\/
[],
*
F9
F10 F11 F12
F7
F8
F5
F6
Shift
CAPS
Sp
XZ
Ctl Del
Ins
><
F21 F23
F17 F18 F19
F14
F15 F16
F13
F22F20 F24
Power key
Green key
Orange key
Backlight key
Scan button
52-key full alphanumeric keypad: Use this keypad to easily print numbers
(0-9) and the entire alphabet. You can access Function keys (F5-F24) and
special characters, symbols, and functions by pressing color-coded key
sequences.
