Interra ITR640-0001 User manual

@2022 INTERRA Version 1.1
Outdoor Intercom Unit with Linux OS
Product Manual

Outdoor Intercom Unit with Linux OS
2
@2022 INTERRA PM220621055BEN
IT
Product Manual
CONTENTS
1. CONTENT OF THE DOCUMENT.....................................................................................................5
2. PRODUCT DESCRIPTION............................................................................................................... 6
2.1. Technical Information .................................................................................................................................... 7
2.2. Connection Diagram & Features..................................................................................................................... 8
2.3. Troubleshooting ............................................................................................................................................14
2.4. Safety Instructions.........................................................................................................................................15
3. BASIC OPERATIONS.................................................................................................................... 17

Outdoor Intercom Unit with Linux OS
3
©2022 INTERRA PM220621055BEN
IT
Product Manual
Information contained in this publication regarding
device applications and the like is provided only for
your convenience and may be superseded versions
by updates. It is your responsibility to ensure that
your application meets your specifications.
INTERRA MAKES NO REPRESENTATIONS OR
WARRANTIES OF ANY KIND WHETHER
EXPRESS OR IMPLIED, WRITTEN OR ORAL,
STATUTORY OR NONSTATUTORY, RELATED
TO THE INFORMATION INCLUDING BUT NOT
LIMITED TO ITS CONDITION, QUALITY,
PERFORMANCE, MERCHANTABILITY OR
FITNESS FOR PURPOSE.
Interra disclaims all liability arising from this
information and its use. Use of Interra devices in life
support and/or safety applications is entirely at the
buyer’s risk, and the buyer agrees to defend,
indemnify and hold harmless Interra from any
damages, claims, suits, or expenses resulting from
such use. No licences are conveyed, implicitly or
otherwise, under any Interra intellectual rights.
Trademarks
The Interra name, logo and the Interra ITR640-0001
& ITR641-0001 Outdoor Intercom Units with Linux
OS devices are registered trademarks of Interra
Technology in Turkey and other countries.
All other trademarks mentioned herein are property
of the Interra Technology.
© 2022, Interra, Printed in Turkey, All Rights
Reserved.
Printed on recycled paper.
TS EN ISO 9001:2008

Outdoor Intercom Unit with Linux OS
4
©2022 INTERRA PM220621055BEN
IT
Product Manual
TO OUR CUSTOMERS
One of our most important aims is to provide you with the best documentation possible to use
successfully your Interra products. Focusing on this, we will keep on improving our documentation to
better suit your needs. Our publications will be updated as new volumes as soon as changes are
introduced.
If you have any questions or comments regarding this publication, do not hesitate to contact us:
E-mail: [email protected]om.tr
Tel: [phone] Fax: [phone]
Most Current Product Manual
To obtain the most up-to-date version of this product manual, please visit our Web site at:
http://www.interratechnology.com
You can determine the version of an Interra document by examining its literature number found on the
bottom right corner of any page.
The first two letters of the literature are the type of document. The numbers that follow are the creation
date of the document and the last letter is the version (e.g., PM181017001A is the version A of a
product manual created on the date 17/10/18.

Outdoor Intercom Unit with Linux OS
5
©2022 INTERRA PM220621055BEN
IT
Product Manual
1. Content of The Document
This document contains Interra brandmark’s ITR640-0001 & ITR641-0001 –Outdoor Intercom Unit with Linux
OS coded devices’ electronic and all essential feature information for programming these products. In each
subtitle is explained the characteristics of the device. Modifications of the product and special change requests
are only allowed in coordination with product management.

Outdoor Intercom Unit with Linux OS
6
©2022 INTERRA PM220621055BEN
IT
Product Manual
2. Product Description
ITR640-0001& ITR641-0001 are Outdoor Intercom Unit with Linux OS that is mainly used for making interacting
with the related indoor intercom unit such as an indoor monitor. ITR640-0001 & ITR641-0001 products features
are described below :
•Application: The outdoor panel is based on TCP/IP communication protocol, supporting digital video
intercom and SIP communication protocol.
•Operating System: ITR640-0001 & ITR641-0001 outdoor intercom unit’s operating system is Linux.

Outdoor Intercom Unit with Linux OS
7
©2022 INTERRA PM220621055BEN
IT
Product Manual
2.1. Technical Information
The following table shows the technical information of the ITR640-0001 & ITR641-0001 Outdoor Intercom Unit
with Linux OS.
Product Code
ITR640-0001
ITR641-0001
Power Supply
DC 12 V POE
DC 12 V POE
Power Consumption
1.5 W (Standby)
3 W (Rated)
1.5 W (Standby)
3 W (Rated)
CPU
1 GHz
1 GHz
SD Ram
64 MB DDR2
64 MB DDR2
Ethernet
10M / 100 Mbps
10M / 100 Mbps
Video Codec
H.264
H.264
Audio Codec
G.711U, G.711A
G.711U, G.711A
Camera
1/4 MP CMOS
1 MP CMOS
Camera Resolution
1280 x 720
1280 x 720
Night Vision
LED Night Vision
LED Night Vision
Flash
128 Mb
128 Mb
Reader
10,000 IC/ID Cards
10,000 IC/ID Cards
Lock Control
1x
1x
RS 485
1x
1x
Exit Button
1x
1x
Type of Protection
IP 55
IP 65
Temperature Range
Operation (-5℃...55℃)
Storage (-10℃...70℃)
Operation (-5℃...55℃)
Storage (-10℃...70℃)
Maximum Air Humidity
< 90 RH
< 90 RH
Colour
Black, Gold
Light Grey, Black
Dimensions
99,5 x 160 x 47 mm (W x H x D)
111 x 170.5 x 38.6 mm (W x H x D)
Configuration
via Web Page
via Web Page

Outdoor Intercom Unit with Linux OS
8
©2022 INTERRA PM220621055BEN
IT
Product Manual
2.2. Connection Diagram & Features
The following diagram shows how to mount the device on a proper surface. For doing a reliable and
accomplished installation, screw-down strength is less than 0.4 Nm. Once the device installation is completed,
please check the connection and if needed please re-tighten the screws.
Fig. 1 : Connection Diagram of ITR640-0001 Outdoor Intercom Unit
Fig. 2 : Connection Diagram of ITR641-0001 Outdoor Intercom Unit

Outdoor Intercom Unit with Linux OS
9
©2022 INTERRA PM220621055BEN
IT
Product Manual
The following figure, shows appearance dimension drawing of the Outdoor Intercom Units :
Fig. 3 : Dimension Diagram of ITR640-0001 Outdoor Intercom Unit
Fig. 4 : Dimension Diagram of ITR641-0001 Outdoor Intercom Unit

Outdoor Intercom Unit with Linux OS
10
©2022 INTERRA PM220621055BEN
IT
Product Manual
The following figure, shows the proper location of the installation :
Fig. 5 : A proper location for installation (varies from person to person)
Recommended
During the installation, the camera should be 1450-1550 mm above the ground. The
camera tether for photographing the human face should be the top priority.
General :
Fig. 6 : General Look of the Indoor Monitor

Outdoor Intercom Unit with Linux OS
11
©2022 INTERRA PM220621055BEN
IT
Product Manual
Fig. 7 : General Look of the Indoor Monitor
System Diagram :
The following figure shows the connectors of the ITR640-0001.
Fig. 8 : Connectors of the ITR640-0001
The following figure shows the connectors of the ITR641-0001.
Fig. 9 : Connectors of the ITR641-0001

Outdoor Intercom Unit with Linux OS
12
©2022 INTERRA PM220621055BEN
IT
Product Manual
Power / Unlock Signal Output:
Power input interface connects with 12 V DC power adapter. The wiring diagram is as follows:
Fig. 10 : Power input connections
Switching Value Output:
It provides a contact signal of switching value and needs, independent power supply for the lock. The electric
lock can be connected in two ways including a normally-open connection and a normally-closed connection.
The wiring diagram is as below:
Fig. 11 : Switching Value Output connections
Network:
Connect to the management centre, indoor monitor or another network device through the network switch.
Fig. 12 : Network cable connection

Outdoor Intercom Unit with Linux OS
13
©2022 INTERRA PM220621055BEN
IT
Product Manual
Exit Button/Door Magnetic Switch:
Connect with Exit button and door magnetic switch; DIN is reserved terminal, please don’t connect it.
Fig. 13 : Exit Button/Door Magnetic interface pin connection

Outdoor Intercom Unit with Linux OS
14
©2022 INTERRA PM220621055BEN
IT
Product Manual
2.3. Troubleshooting
Some common failures and troubleshooting methods are listed for your reference. In case of failure which
cannot be repaired, do not disassemble or repair the product by yourself. Please contact the after-sales
technical service department.
When outdoor panel fails to call indoor monitor:
When setting villa outdoor panel, please make sure building No. and unit No. of the outdoor
panel are the same as the ones of the indoor monitor.
Please check whether the network is connected.
Please check if there are any security settings for the network, such as VLAN configuration.
The indoor monitor cannot be set as a sub-device only. The main device is required.

Outdoor Intercom Unit with Linux OS
15
©2022 INTERRA PM220621055BEN
IT
Product Manual
2.4. Safety Instructions
To protect you and others from harm or protect your device from damage, please read the following
information before using your device.
Do not install equipment in the following areas:
Do not install equipment in high temperature, humidity, near the magnetic field, such as generators,
transformers or magnets etc.
Do not place the equipment near the heating items such as the electric heater or the liquid container.
Do not place the device directly in the sun or near the heat source, which may cause the body to be
discoloured or deformed.
Do not install the equipment in an unstable position to avoid property losses or personal injury caused
by the falling of the device.
Prevent electric shock, fire and explosion
Do not use a damaged power cord, plug or loose outlet.
Do not touch the power cord with wet hands or unplug the power source by pulling the power supply.
Do not bend or damage the power cord.
Do not touch the device with wet hands.
Do not let the power slide, or cause a collision.
Do not use the power supply without the manufacturer’s approval.
Do not splash water or other liquids into the equipment.
Clean Device Surface

Outdoor Intercom Unit with Linux OS
16
©2022 INTERRA PM220621055BEN
IT
Product Manual
Use a soft cloth dipped in a small amount of water to clean the surface of the machine and dry it with a
dry cloth.
Other Matters Needing Attention
To prevent damage to the paint or housing, do not expose the device to chemical products, such as
thinner, gasoline, alcohol, insect repellent, sunscreen, pesticides, etc.
Do not disassemble, refit or modify the device at your discretion. The arbitrary modification is not
covered under warranty. When any repair is required, please contact the customer service centre.
When the device emits abnormal sound, smell or smoke, unplug the power immediately and contact
the customer service centre in time.
If you do not use the device for a long time, it is recommended to unplug the power adapter, take out
the memory card and put the device in a dry environment.
Do not beat or hit the device with a hard object.

Outdoor Intercom Unit with Linux OS
17
©2022 INTERRA PM220621055BEN
IT
Product Manual
3. Basic Operations
Call indoor monitor:
In standby mode, press the call button on the outdoor panel to call the indoor monitor. During the call, press the
call button on the outdoor panel again to end the call. If the call fails or the indoor monitor is busy, the outdoor
panel will emit a beep.
Unlocking by card:
Put the registered IC/ID card in the card reader area of the outdoor panel. If ID/IC card has been authorized,
after unlocking the door by card, the system will issue a voice message that “the door has been opened”,
otherwise it will emit a beep.
Unlocking by access password:
In standby mode, enter “unlocking password +#”. After unlocking, the system will issue a voice message that
“the door has been opened”, otherwise it will emit a beep (for the C3 digital keypad model).

Outdoor Intercom Unit with Linux OS
18
©2022 INTERRA PM220621055BEN
IT
Product Manual
CONTACT INFORMATION
THE INTERRA WEBSITE
Interra provides documentatıon support via our
web site www.interratechnology.com. This website
is used as a means to make files and information
easily available to customers. Accessible by using
your favourite Internet browser, the website
contains the following information:
-Information about our products and
projects.
-Overview of Interra company and values.
-Product Support: Datasheets, product
manuals, application descriptions, latest
software releases, ETS databases and
archived software.
EUROPE, Turkey
Interra
Cumhuriyet Mah. Kartal Cad. Simkan Plaza No:95/1
Kartal/İstanbul
Tel: [phone] Fax: [phone]
Web adress: http://www.interratechnology.com
