The ISL70001ASEHEV1Z evaluation board is designed to
demonstrate the features of the ISL70001ASEH, a TID and SEE
hardened 6A synchronous buck regulator IC with integrated
MOSFETs intended for Space applications. For more detailed
information about the ISL70001ASEH, please refer to the
ISL70001ASEH datasheet.
The ISL70001ASEHEV1Z evaluation board accepts a nominal 3V
to 5.5V input voltage and provides a regulated output voltage
ranging from 0.8V to 85% of the input voltage at output currents
ranging from 0A to 6A. The output can be quickly set to any of six
commonly used preset voltages (0.8V, 1.0V, 1.2V, 1.8V, 2.5V,
3.3V) or adjusted to an alternate voltage using the onboard
potentiometer. A PGOOD (Power-Good) signal goes high and
lights a red LED to indicate that the output voltage is within a
±11% typical regulation window. A toggle switch is provided to
conveniently enable or disable the output voltage.
The ISL70001ASEHEV1Z evaluation board can be set to run from
the nominal 1MHz internal oscillator of the ISL70001ASEH or
synchronized to a 1MHz ±20% external clock. Two or more
ISL70001ASEHEV1Z evaluation boards can be synchronized to
each other in a Master/Slave configuration, with all Slave units
switching 180° out-of-phase with respect to the Master unit.
Schematic and BOM
A schematic and BOM of the ISL70001ASEHEV1Z evaluation
board are shown in Figure 1 and Table 1, respectively. The
schematic indicates numerous test points, which allow virtually
all nodes of the evaluation circuit to be monitored directly. The
BOM shows components that are representative of the types
needed for a design, but these components are not
space-qualified. Equivalent space-qualified components would
be required for flight applications.
Recommended Test Equipment
• A 0V to 6V power supply with at least 10A source current
capability.
• An electronic load capable of sinking current up to 6A.
• Two digital multimeters (DMMs).
• A 500MHz dual-trace oscilloscope.
Quick Start
1. Short J1, J2 (pins 2-3), J4 (pins 1-2), J5 and J15.
2. Open J3, J7 and J9-J13.
3. Toggle S2 to the down (OFF) position.
4. Turn on the power supply. Set the output voltage to 3.3V and
set the output current limit to 10A. Turn off the power supply.
5. Connect the positive lead of the power supply to TP1 and the
negative lead of the power supply to TP2.
6. Turn on the electronic load and set the output current to 3A.
7. Connect the positive lead of the electronic load to TP44 and
connect the negative lead of the electronic load to TP45.
8. Configure one DMM to monitor the input voltage from TP22 to
TP25.
9. Configure another DMM to monitor the output voltage from
TP38 to TP39.
10. Connect Channel 1 of the oscilloscope to J6 (or from TP33 to
TP28) to monitor the rectangular waveform on the LXx pins.
11. Connect Channel 2 of the oscilloscope to J14 (or from TP36 to
TP37) to monitor the output voltage.
12. Toggle S2 to the up (ON) position.
13. Verify the output voltage is 0.8V ±3% and the frequency of the
LXx waveform is 1MHz ±10%.
Configuration Options
The ISL70001ASEHEV1Z evaluation board can be easily
configured for a number of different applications. Table 2
provides the available settings for the jumpers and toggle switch
and explains their respective functions.

AN1842 Rev.1.00 Page 2 of 9 Jun 11, 2013
ISL70001ASEHEV1Z
0.8V ADJUST
ITAR
1.8V 2.5V 3.3V 1.0V 1.2V
100UF 100UF
1000PF
ISL70001ASEHQ
47UF 47UF 47UF
VOUT
100UF
1UH
LX
~/ISL70001ASEH/ISL70001ASEHEV1ZA
ISL70001ASEHEV1Z
ISL70001ASEHEV1Z
EVALUATION BOARD
SCHEMATIC
1
1.5K
100UF
LTST-C170CKT
1
10K
47UF
316 221
5K
0.01UF
0.1UF
0
1K
1UF
VIN_EN
1UF
499
1K
PGOOD
1K
1
0.01UF
100
1
1K
4700PF
499
100UF
VIN
100UF
1UF
1UF
OSCAR MANSILLA07-02-2012
A
VIN
10
OSCAR MANSILLA
TIM KLEMANN 07/02/2012
SYNC
0.22UF
1K
2N7002
100UF
VIN
100UF 100UF 100UF
3.01K
IN
IN
40
7
8
9
10
11
12
13
14
15
16
17
18
42
41
39
38
37
36
35
33
34
32
31
2
1
2
3
2
3
1
3
1
2
2
12
TP33
TP32
TP35
TP41
TP40
TP45
TP34
R8
J3
L1
J4
S2
TP44
TP1
TP2
Q1
R3
C25
TP11
TP12
TP13
TP14
TP16
TP5
TP6
J1
R4
TP17
TP15
TP39
TP19
J6
J14
R7
R19
TP46
TP47
D2
TP37
TP42
TP43
E
E
E
E
E
E
E
E
E
E
E
E
E
E
EEE
E
E
E
E
E
E
EEEEE EE
M/S
PVIN3
SYNC
ZAP
TDI
TDO
SS
PGOOD
DVDD
DVDD
DGND
DGND
AGND
AGND
AVDD PGND5
LX5
PVIN5
PVIN5
PVIN4
PVIN4
LX4
PGND4
PGND4
PGND3
PGND3
LX3
PVIN3 EEEEEEE
E
EE
RELEASED BY:
DRAWN BY:
SHEET
HRDWR ID
1
12
23
34
45
56
67
78
8
DATE:
DATE:
DATE:
TESTER
FILENAME:
MASK# REV.
OF
DATE:ENGINEER:
TITLE:
UPDATED BY:
5
30 29 28 27 26 25 24 23 22
21
20 19
43 44 45 46 48
1
2 3 4 6
13
21
13
47
C1
C20
C21
C3 C5
R10
J13
C23
J2
C12
C2 C4
C9 R1
C8
R2
J9
J10
J11
J12
R11
R13 R14 R15 R16
C6
D1
C11
C14
C15 C19 C22 C24
R17
J7
TP20
TP21
TP23 TP24 TP26 TP28
TP36 TP38 TP22
TP18
R5
TP27
R6
C7
C10
J15
R18
TP25
J5
C18 C17 C16
R12
E
PVIN1 PVIN1
LX2
PGND2 PGND2
PGND1 PGND1
LX1
REF FB EN PORSEL PVIN6 PVIN6
LX6
PGND6 PGND6
PGND5 PVIN2
PVIN2
U1
FIGURE 1. ISL70001ASEHEV1Z SCHEMATIC

ISL70001ASEHEV1Z
AN1842 Rev.1.00 Page 3 of 9
Jun 11, 2013
TABLE 1. ISL70001ASEHEV1Z BOM
REF DES QTY PART NUMBER VALUE DESCRIPTION MANUFACTURER
C1-C4 4 47µF Capacitor, Ceramic, 10%, 10V, X7R, 1210 Various
C5, C7, C9, C10 4 1µF Capacitor, Ceramic, 10%, 10V, X7R, 0603 Various
C6, C11 2 0.01µF Capacitor, Ceramic, 10%, 16V X7R, 0603 Various
C8 1 0.1µF Capacitor, Ceramic, 10%, 16V, X7R, 0603 Various
C12 1 0.22µF Capacitor Ceramic, 10%, 16V, X7R, 0603 Various
C14 1 1000pF Capacitor Ceramic, 10%, 16V, X7R, 0603 Various
C15-C24 10 100µF Capacitor Ceramic, 20%, 6.3V, X5R, 1210 Various
C25 1 4700pF Capacitor, Ceramic, 10%, 50V, X7R, 0603 Various
D1 1 MBRS320T3G-T Diode, Schottky, 20V, 3A, SMC On Semiconductor
D2 1 LTST-C170CKT Diode, LED, Green Vishay
J1, J3, J5, J7, J9-J13 9 69190-202HLF Connector, Header, 1x2, Thru-hole BERG/FCI
J2, J4 2 68000-236HLF-1X3 Connector, Header, 1x3, Thru-hole BERG/FCI
J1-J5, J7, J9-J13, J15 12 SPC02SYAN Connector, Jumper, 2-pin Sullins
J6, J14 2 131-4353-00 Jack, Scope Probe, Thru-hole Tektronics
L1 1 CDRH127/LDNP-1R0NC 1µH Inductor, 30%, 14A, SMD Sumida
Q1 1 2N7002-7-F-T Transistor, MOSFET, N-channel, SOT-23 Diodes, Inc.
R1, R7 2 1ΩResistor, Film, 1%, 1/10W, 0603 Various
R2, R3, R6, R8, R13 5 1kΩResistor, Film, 1%, 1/10W, 0603 Various
R4, R14 2 499ΩResistor, Film, 1%, 1/10W, 0603 Various
R5 1 10kΩResistor, Film, 1%, 1/10W, 0603 Various
R10 1 10ΩResistor, Film, 1%, 1/4W, 1206 Various
R11 1 3.01kΩResistor, Film, 1%, 1/10W, 0603 Various
R12 1 1.5kΩResistor, Film, 1%, 1/10W, 0603 Various
R15 1 316ΩResistor, Film, 1%, 1/10W, 0603 Various
R16 1 221ΩResistor, Film, 1%, 1/10W, 0603 Various
R17 1 3296W-1-502LF 5kΩResistor, Potentiometer, Trim, 10%, 1/2W, Thru-hole Bourns
R18 1 100ΩResistor, Film, 1%, 1/10W, 0603 Various
R19 1 0ΩResistor, Film, 1%, 1/10W, 0603 Various
S2 1 GT11MSCBE-T Switch, Toggle, SPDT, SMD ITT/C&K
TP1, TP2, TP5, TP6, TP40-45 10 1514-2 Terminal, Turret, Thru-hole Keystone
TP11-TP28, TP32-TP39 26 5002 Connector, Test Point, Thru-hole Various
U1 1 ISL70001ASEHFE/PROTO IC, Regulator, Switching, 6A, CQFP-48 w/ heatsink Intersil
1 SP2000-0.020-AC-1212-NA Thermal Interface Material, Sil-Pad, 12inx12inx0.020in,
with adhesive, cut to 0.4inx0.4in and place under U1
Bergquist

ISL70001ASEHEV1Z
AN1842 Rev.1.00 Page 4 of 9
Jun 11, 2013
TABLE 2. CONFIGURATION OPTIONS
REF. DESIGNATOR SETTING FUNCTION
J1
Short Selects AVDD to be monitored by the EN pin through a resistive divider (R4 and R6) if S2 is toggled to the down
position.
Open Allows an external voltage connected to TP5 to be monitored by the EN pin through a resistive divider (R4 and R6)
if S2 is toggled to the down position.
J2
Short 2-3 Selects Master mode, which forces the chip to run from the internal 1MHz oscillator. In Master mode, the SYNC
pin is an output that provides a nominal 1MHz clock signal.
Short 1-2
Selects Slave mode, which allows the chip to be synchronized to another ISL70001ASEH or to an external clock. In Slave
mode, the SYNC pin is an input that accepts a 1MHz synchronizing signal from the SYNC pin of another ISL70001ASEH
configured as a Master or from an external clock.
J3
Short
Loads the SYNC pin with R5, which is a 10kΩresistor. If synchronization to an external clock over long distances
is required, it may be necessary to use a controlled impedance trace to avoid excessive ringing on the SYNC line.
If this is the case, the SYNC trace should be terminated into 50Ωat the Slave units. This can be accomplished by
replacing R5 on the Slave units with a 50Ωresistor. Please note that the SYNC pin of an ISL70001ASEH is not
designed to drive a 50Ωload.
Open Disconnects the SYNC pin from R5.
J4
Short 2-3 Selects the 5V input UVLO threshold. Use this setting when the nominal input voltage is 5V.
Short 1-2 Selects the 3.3V input UVLO threshold. Use this setting when the nominal input voltage is 3.3V. Also use this
setting for nominal input voltages between 5V and 3.3V.
J5
Short Selects the 0.8V preset output voltage option as long as J7 and J9-J13 are open.
Open Allows output voltages other than 0.8V to be selected.
J7
Short Selects the 1.0V preset output voltage option as long as J5 and J9-J13 are open.
Open Allows output voltages other than 1.0V to be selected.
J9
Short Selects the 1.2V preset output voltage option as long as J5, J7 and J10-J13 are open.
Open Allows output voltages other than 1.2V to be selected.
J10
Short Selects the 1.8V preset output voltage option as long as J5, J7, J9 and J11-J13 are open.
Open Allows output voltages other than 1.8V to be selected.
J11
Short Selects the 2.5V preset output voltage option as long as J5, J7, J9-J10 and J12-J13 are open.
Open Allows output voltages other than 2.5V to be selected.
J12
Short Selects the 3.3V preset output voltage option as long as J5, J7, J9-J11 and J13 are open.
Open Allows output voltages other than 3.3V to be selected.
J13
Short Selects the adjustable output voltage option as long as J5, J7 and J9-J12 are open. Potentiometer, R17, can be
used to adjust the output voltage.
Open Allows the preset output voltage options to be selected.
J15
Short Shorts out R18, allowing normal operation of the evaluation board.
Open Facilitates control loop stability measurements by allowing a signal to be injected across R18.
S2
Short 2-3 S1 in the up position shorts contacts 2-3. This pulls the EN pin low to disable the output voltage.
Short 1-2 S1 in the down position shorts contacts 1-2. This enables the output voltage as long as the voltage on the EN pin
exceeds 0.6V.

ISL70001ASEHEV1Z
AN1842 Rev.1.00 Page 5 of 9
Jun 11, 2013
Layout Guidelines
1. Use a four layer PCB with 2 ounce copper.
2. Layer 2 should be a dedicated ground plane and layer 3
should be a dedicated power plane split between VIN and
VOUT.
3. Layers 1 and 4 should be used primarily for signals, but can
also be used to increase the VIN, VOUT and ground planes as
required.
4. Connect all AGND, DGND and PGNDx pins directly to the
ground plane. Connect all PVINx pins directly to the VIN
portion of the power plane.
5. Locate ceramic bypass capacitors as close as possible to U1.
Prioritize the placement of the bypass capacitors on the pins
of U1 in the order shown: REF, SS, AVDD, DVDD, PVINx (C5,
C7), EN, PGOOD, PVINx (C1-C4).
6. Locate the output voltage resistive divider as close as
possible to the FB pin of the IC. The top leg of the divider
should connect directly to the POL (Point Of Load) and the
bottom leg of the resistive divider should connect directly to
AGND. The junction of the resistive divider should connect
directly to the FB pin.
7. Locate the Schottky diode, D1, as close as possible to the LXx
and PGNDx pins of the IC. A smaller Schottky diode may be
used as long as derating requirements are satisfied.
8. Use a small island of copper to connect the LXx pins of U1 to
the inductor, L1, on layers 1 and 4. Void the copper on layers
2 and 3 adjacent to the island to minimize capacitive
coupling. Place most of the island on layer 4 to minimize the
amount of copper that must be voided from the ground layer
(layer 2).
9. Keep all signal traces as short as possible.
10. A small series snubber (R10 and C14) connected from the
LXx pins to the PGNDx pins may be used to damp ringing on
the LXx pins if desired.
11. For optimum thermal performance, place a pattern of vias on
the top layer of the PCB directly underneath U1. Connect the
vias to the ground plane (layer 2), which serves as a heatsink.
Thermal interface material such as a Sil-Pad should be used
to fill the gap between the vias and the bottom of U1 to insure
good thermal contact. Using a Sil-Pad has the added benefit
of raising the bottom of U1 from the PCB surface so that a
slight bend can be added to the leads for strain relief.
12. Refer to Figures 2 through 7 for an example layout.
FIGURE 2. SILK SCREEN TOP

ISL70001ASEHEV1Z
AN1842 Rev.1.00 Page 6 of 9
Jun 11, 2013
FIGURE 3. FIRST LAYER ETCH
FIGURE 4. SECOND LAYER ETCH

ISL70001ASEHEV1Z
AN1842 Rev.1.00 Page 7 of 9
Jun 11, 2013
FIGURE 5. THIRD LAYER ETCH
FIGURE 6. FOURTH LAYER ETCH

ISL70001ASEHEV1Z
AN1842 Rev.1.00 Page 8 of 9
Jun 11, 2013
FIGURE 7. SILK SCREEN BOTTOM

Corporate Headquarters
TOYOSU FORESIA, 3-2-24 Toyosu,
Koto-ku, Tokyo 135-0061, Japan
www.renesas.com
Contact Information
For further information on a product, technology, the most
up-to-date version of a document, or your nearest sales
office, please visit:
www.renesas.com/contact/
Trademarks
Renesas and the Renesas logo are trademarks of Renesas
Electronics Corporation. All trademarks and registered
trademarks are the property of their respective owners.
IMPORTANT NOTICE AND DISCLAIMER
RENESAS ELECTRONICS CORPORATION AND ITS SUBSIDIARIES (“RENESAS”) PROVIDES TECHNICAL
SPECIFICATIONS AND RELIABILITY DATA (INCLUDING DATASHEETS), DESIGN RESOURCES (INCLUDING
REFERENCE DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND
OTHER RESOURCES “AS IS” AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF THIRD PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for developers skilled in the art designing with Renesas products. You are solely responsible
for (1) selecting the appropriate products for your application, (2) designing, validating, and testing your application, and (3)
ensuring your application meets applicable standards, and any other safety, security, or other requirements. These
resources are subject to change without notice. Renesas grants you permission to use these resources only for
development of an application that uses Renesas products. Other reproduction or use of these resources is strictly
prohibited. No license is granted to any other Renesas intellectual property or to any third party intellectual property.
Renesas disclaims responsibility for, and you will fully indemnify Renesas and its representatives against, any claims,
damages, costs, losses, or liabilities arising out of your use of these resources. Renesas' products are provided only subject
to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing. No use of any Renesas resources
expands or otherwise alters any applicable warranties or warranty disclaimers for these products.
(Rev.1.0 Mar 2020)
© 2020 Renesas Electronics Corporation. All rights reserved.

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Renesas Electronics:
ISL70001ASEHEV1Z
