Intersil ZL6100EVAL2Z Installation and operating instructions

1
Application Note 1507
ZL6100EVAL2Z Dual Channel Evaluation Board
Description
The ZL6100 is an integrated mixed-signal power
conversion and management IC that combines an
efficient step-down DC/DC converter with key power and
thermal management functions in a single package. The
ZL6100 incorporates current sharing and adaptive
efficiency-optimization algorithms to provide a flexible,
efficient power IC building block.
The ZL6100EVAL2Z platform is a 6-layer board with two
power rails. One rail is a single phase, 30A power rail.
The other rail is a dual phase, 60A power rail
demonstrating the current sharing capability of the
ZL6100.
A USB to SMBus adapter board can be used to connect
the eval board to a PC. The PMBus command set is
accessed by using the Zilker Labs PowerNavigator™
evaluation software from a PC running Microsoft
Windows.
Features
• 30A Single-phase and 60A Dual-phase Rails
• Optimized for Efficiency
• Configurable Through SMBus
• Onboard Enable Switch
• Power Good Indicators
Target Specifications
•V
IN = 12V
•V
OUT1 = 1.8V/60A max
•V
OUT2 = 1.5V/30A max
•f
sw = 300kHz
• Efficiency: 90% at 50% load
• Output Ripple: ±1.5%
• Dynamic response: ±3%
(50%-70%-50% load step, di/dt = 2.5A/µs)
• Board Temperature: +25°C
FIGURE 1. ZL6100EVAL2Z BLOCK DIAGRAM
ZL6100
VOUT1
ZL6100
ZL6100
VIN
SMBus
DDC
SMBus
DDC
SMBus
DDC
VOUT2
EN
SYNC
EN
SYNC
EN
SYNC
ENABLE
SW1
J10 J11
P1
P2
P3
SYNC
DDC
SMBus
TRACK
SYNC
DDC
SMBus
PGVTRK PG
September 11, 2009
AN1507.0
Author: Marty Pandola
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774 |Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright Intersil Americas Inc. 2009. All Rights Reserved
All other trademarks mentioned are the property of their respective owners.

2AN1507.0
September 11, 2009
Functional Description
The ZL6100EVAL2Z provides all circuitry required to
demonstrate the features of the ZL6100. The
ZL6100EVAL2Z has a functionally-optimized ZL6100
circuit layout that allows efficient operation up to the
maximum output current. Power and load connections
are provided through plug-in sockets.
All features of the ZL6100 such as current sharing, soft-
start delay and ramp times, supply sequencing, voltage
tracking, and voltage margining are available on this
evaluation board. For voltage tracking, the board is set
up for the single phase rail (VOUT2) to track the dual
phase rail (VOUT1). Contact the Zilker Labs sales office
for configuring the board for other tracking combinations.
Figure 1 shows a functional block diagram of the
ZL6100EVAL2Z board. The SMBus address is selectable
through a jumper on the top side of the board. All power
to the board (VIN and I2C bus) must be removed before
changing the jumpers.
The hardware enable function is controlled by a toggle
switch on the ZL6100EVAL2Z board. The power good
(PG) LEDs indicate the correct state of PG when external
power is applied to the ZL6100EVAL2Z board. (Note: If a
USB board is connected to the ZL6100EVAL2Z and no
power is applied to the board, the PG LEDs will turn on
even though the power rails are not enabled.) The right
angle headers at opposite ends of the board are for
connecting a USB to SMBus adapter board or for daisy
chaining of multiple evaluation boards.
Figures 2 and 3 show the two phases of the 60A circuit.
Figure 4 shows the single phase operational circuit. The
circuit consists of the ZL6100 IC with its minimal
component count to realize a 30A buck converter. The
board layout has been optimized for thermal
performance.
Figure 5 is the Interface and Figure 9 SMBus address
selection circuitry.
Operation
PMBus Operation
The ZL6100 utilizes the PMBus protocol. The PMBus
functionality can be controlled via USB from a PC running
the PowerNavigator evaluation software in a Windows XP
or Windows 2000/NT operating system.
Install the ZL6100EVAL2Z software using the CD
included in the ZL6100EVAL2Z kit.
For board operation, connect the included USB-to-SMBus
adapter board to J10 of the ZL6100EVAL2Z board.
Connect the desired load and an appropriate power
supply to the input and connect the included USB cable
to the PC running the PowerNavigator evaluation
software. Place the ENABLE switch in “DISABLE” and turn
on the power.
The evaluation software allows modification of all ZL6100
PMBus parameters. Each of the ZL6100 devices have
been pre-configured as described in this document, but
the user may modify the operating parameters through
the eval software or by loading a predefined scenario
from a configuration file.
Use the mouse-over pop-ups for PowerNavigator help.
Refer to Zilker Labs application note AN2033 “PMBus
™
Command Set DDC Products”, Intersil Corporation,
2009 for PMBus details.
The ENABLE switch can then be moved to “ENABLE” and
the ZL6100EVAL2Z board can be tested. Alternately, the
PMBus ON-OFF CONFIG and OPERATION commands may
be used.
Quick Start Guide
Stand Alone Operation
1. Set ENABLE switch to “DISABLE”
2. Apply load to VOUT+/VOUT- for each channel
3. Connect power supply to VIN+/VIN- (supply turned
off)
4. Turn power supply on
5. Set ENABLE switch to “ENABLE”
6. Monitor ZL6100EVAL2Z board operation using an
oscilloscope
USB (PMBus) Operation
1. Set ENABLE switch to “DISABLE”
2. Apply load to VOUT+/VOUT- for each channel
3. Connect power supply to VIN+/VIN- (supply turned
off)
4. Turn power supply on
5. Insert the Zilker Labs Eval Kit CD
6. Connect USB to SMBus adapter board to J10 of
ZL6100EVAL2Z
7. Connect supplied USB cable from computer to USB
to SMBus adapter board
a) Upon first-time connection, the Found New
Hardware Wizard will appear.
b) Windows XP users: Select ‘No’ at prompt to
search the Internet for drivers.
c) Follow the steps on the screen to install the
drivers from the CD.
8. Install the PowerNavigator evaluation software by
running setup.exe from the
PowerNavigator_installer folder on the CD.
9. Set ENABLE switch on EVB to “ENABLE”
10.Monitor and configure the ZL6100EVAL2Z board
using PMBus commands in the evaluation software
11.Test the ZL6100EVAL2Z operation using an
oscilloscope and the evaluation software.
Application Note 1507

3AN1507.0
September 11, 2009
Board Schematics
FIGURE 2. ZL6100EVAL2Z 60A CURRENT SHARING RAIL (PHASE A) CIRCUIT
Application Note 1507

4AN1507.0
September 11, 2009
FIGURE 3. ZL6100EVAL2Z 60A CURRENT SHARING RAIL (PHASE B) CIRCUIT
Board Schematics(Continued)
Application Note 1507

5AN1507.0
September 11, 2009
FIGURE 4. ZL6100EVAL2Z 30A SINGLE PHASE RAIL CIRCUIT
Board Schematics(Continued)
Application Note 1507

6AN1507.0
September 11, 2009
FIGURE 5. ZL6100EVAL2Z INTERFACE CIRCUITRY
Board Schematics(Continued)
Application Note 1507

7AN1507.0
September 11, 2009
FIGURE 6. POWER-IN CIRCUIT
Board Schematics(Continued)
Application Note 1507

8AN1507.0
September 11, 2009
FIGURE 7. PG LED CIRCUITRY
Board Schematics(Continued)
Application Note 1507

9AN1507.0
September 11, 2009
FIGURE 8. ENABLE SWITCH DEBOUNCE CIRCUIT
FIGURE 9. ADDRESS SELECTION CIRCUITRY
Board Schematics(Continued)
Application Note 1507

10 AN1507.0
September 11, 2009
Board Layout – 6 Layers
FIGURE 10. PCB – TOP LAYER
Application Note 1507

11 AN1507.0
September 11, 2009
FIGURE 11. PCB – INNER LAYER 1 (VIEWED FROM TOP)
Board Layout – 6 Layers(Continued)
Application Note 1507

12 AN1507.0
September 11, 2009
FIGURE 12. PCB – INNER LAYER 2 (VIEWED FROM TOP)
Board Layout – 6 Layers(Continued)
Application Note 1507

13 AN1507.0
September 11, 2009
FIGURE 13. INNER LAYER 3 (VIEWED FROM TOP)
Board Layout – 6 Layers(Continued)
Application Note 1507

14 AN1507.0
September 11, 2009
FIGURE 14. INNER LAYER 4 (VIEWED FROM TOP)
Board Layout – 6 Layers(Continued)
Application Note 1507

15 AN1507.0
September 11, 2009
FIGURE 15. PCB – BOTTOM LAYER (VIEWED FROM TOP)
Board Layout – 6 Layers(Continued)
Application Note 1507

16 AN1507.0
September 11, 2009
FIGURE 16. TOP ASSEMBLY DRAWING
Board Layout – 6 Layers(Continued)
Application Note 1507

17 AN1507.0
September 11, 2009
FIGURE 17. BOTTOM ASSEMBLY DRAWING
Board Layout – 6 Layers(Continued)
Application Note 1507

18 AN1507.0
September 11, 2009
Bill of Materials
PART NUMBER QTY UNIT REFERENCE DESIGNATOR DESCRIPTION MFR NAME MFR PART
H1045-00104-16V10-T 7 ea C7, C42, C60, C61,
C63, C64, C65 CAP, SMD, 0603, 0.1µF, 16V, 10%, X7R, ROHS MURATA GRM39X7R104K016AD
H1045-00105-25V10-T 7 ea C8, C9, C16, C24,
C25, C43, C62 CAP, SMD, 0603, 1µF, 25V, 10%, X5R, ROHS MURATA GRM188R61E105KA12D
H1045-00106-6R3V20-T 6 ea C17,C18,C31,C32,
C49, C50 CAP, SMD, 0603, 10µF, 6.3V, 20%, X5R, ROHS TDK C1608X5R0J106M
H1045-00225-16V10-T 2 ea C26, C98 CAP, SMD, 0603, 2.2µF,
16V, 10%, X5R, ROHS MURATA GRM188R61C225KE15D
H1045-00475-6R3V10-T 3 ea C4, C22, C39 CAP, SMD, 0603, 4.7µF,
6.3V, 10%, X5R, ROHS VENKEL C0603X5R6R3-475KNE
H1045-DNP 0 ea C44, C66, C99 CAP, SMD, 0603, DNPH
PLACE HOLDER, ROHS
H1046-00225-25V10-T 3 ea C5, C23, C40 CAP, SMD, 0805, 2.2µF,
25V, 10%, X5R, ROHS PANASONIC ECJ-2FB1E225K
H1065-00106-25V10-T 18 ea a) C1, C2, C3, C19,
C20, C21, C36, C37,
C38, C58,
CAP, SMD, 1206, 10µF,
25V, 10%, X5R, ROHS VENKEL C1206X5R250-106KNE
H1065-00106-25V10-T 0 ea b) C59, C72-C75,
C83, C84, C105 CAP, SMD, 1206, 10µF,25V, 10%, X5R,
ROHS
VENKEL C1206X5R250-106KNE
H1065-00476-6R3V20-T 30 ea a) C10 to C15, C27
to C30, C33 to C35,
C45 to C48,
CAP, SMD, 1206, 47µF,
6.3V, 20%, X5R, ROHS MURATA GRM31CR60J476ME19L
H1065-00476-6R3V20-T 0 ea b) C53, C77, C78,
C88 to C97 CAP, SMD, 1206, 47µF, 6.3V, 20%, X5R, ROHS MURATA GRM31CR60J476ME19L
APXA160ARA331MJC0G 7 ea C54,C55,C56,C57,
C101, C102, C103 CAP, SMD, 10x12, 330µF, 16V, 20%,
14mΩ, ALUM. ELEC.,
ROHS
NIPPON
CHEMI-CON APXA160ARA331MJC0G
APXA6R3ARA821MJC0G 9 ea C51,C52,C68,C69,
C70, C76, C79, C80,
C85
CAP, SMD, 10x12,
820µF, 6.3V, 20%,
10mΩ, ALUM. ELEC.,
ROHS
NIPPON
CHEMI-CON APXA6R3ARA821MJC0G
EMVA250ADA100MD55G 2 ea C6, C41 CAP, SMD, 4x5.2, 10µF,
25V, 20%, ALUM.
ELEC., ROHS
NIPPON
CHEMI-CON EMVA250ADA100MD55G
EMZA6R3ADA102MHA0G 3 ea C67, C81, C86 CAP, SMD, 8x10,
1000µF, 6.3V, 20%,
ALUM. ELEC., ROHS
NIPPON
CHEMI-CON EMZA6R3ADA102MHA0G
EMZA6R3ADA102MHA0G 0 ea DNP (C71, C82,
C87) CAP, SMD, 8x10, 1000µF, 6.3V, 20%,
ALUM. ELEC., ROHS
NIPPON
CHEMI-CON EMZA6R3ADA102MHA0G
IHLP5050FDERR56M01 3 ea L3, L6, L9 COIL-PWR INDUCTOR,
SMD, 13mm, 0.56µH,
20%, 37A, ROHS
VISHAY IHLP5050FDERR56M01
108-0740-001 6 ea P1, P2, P3 (2 EACH) CONN-JACK, BANANA-
SS-SDRLESS,
VERTICAL, ROHS
JOHNSON COMPONENTS 108-0740-001
142-0701-201 0 ea DNP (J1, J3) CONN-RF, SMA JACK,
50Ω, BMT, ST JOHNSON COMPONENTS 142-0701-201
Application Note 1507

19 AN1507.0
September 11, 2009
3-644456-4 3 ea JP1, JP2, JP3 CONN-HEADER, 1x4,
VERTICAL, TIN, WHT
NYLON, ROHS
AMP/TYCO 3-644456-4
881545-2 4 ea a) JP1-Pins 3 and 4,
JP2-Pins 3 and 4, CONN-JUMPER, SHUNT LP W/HANDLE, 2P,
2.54mm, BLK, ROHS
TYCO
ELECTRONICS 881545-2
881545-2 0 ea b) JP3-Pins 3 and 4,
J13-Pins 1 and 2 CONN-JUMPER, SHUNT LP W/HANDLE, 2P,
2.54mm, BLK, ROHS
TYCO
ELECTRONICS 881545-2
PJ-002A 1 ea J6 CONN-POWER JACK,
TH, 2.1mm, [email protected],
BLK, R/A, ROHS
CUI, INC PJ-002A
SSQ-105-02-T-D-RA 1 ea J11 CONN-SOCKET STRIP,
TH, 2x5, 2.54mm, TIN,
R/A, ROHS
SAMTEC SSQ-105-02-T-D-RA
TSW-105-07-T-D 1 ea J13 CONN-HEADER, 2x5,
BRKAWY, 2.54mm, TIN,
ROHS
SAMTEC TSW-105-07-T-D
TSW-105-08-T-D-RA 1 ea J10 CONN-HEADER, 2X5,
BRKAWY, 2.54mm, TIN,
R/A, ROHS
SAMTEC TSW-105-08-T-D-RA
BAT54XV2T1G-T 3 ea D5, D6, D8 DIODE-SCHOTTKY,
SMD, 2P, SOD523, 30V,
200mA, ROHS
ON
SEMICONDUCTOR BAT54XV2T1G
MBR0540T1G-T 3 ea D1, D2, D3 DIODE-RECTIFIER,
SMD, SOD-123, 2P,
40V, 0.5A, ROHS
ON
SEMICONDUCTOR MBR0540T1G
STPS20L45CG 1 ea D4 DIODE-RECTIFIER,
SCHOTTKY, SMD,
D2PAK, 45V, 10A, ROHS
STMICRO
ELECTRONICS STPS20L45CG
CMD17-21VGC/TR8-T 3 ea D9, D10, D11 LED, SMD, 0805,
GREEN, CLEAR, 10mcd,
2.1V, 20mA, 570nm,
ROHS
CHICAGO
MINIATURE CMD17-21VGC/TR8
BLM18BB750SN1-T 6 ea L10, L11, L12, L13,
L14, L15 FERRITE CHIP, SMD, 0603,75Ω, 25%,
300mA, 0.7Ω, ROHS
MURATA BLM18BB750SN1
BLM21AG102SN1D-T 0 ea DNP (L2, L5, L8) FERRITE CHIP, SMD,
0805, 1000Ω, 200mA,
100MHz, ROHS
MURATA BLM21AG102SN1D
BLM21AG102SN1D-T 3 ea L1, L4, L7 FERRITE CHIP, SMD,
0805, 1000Ω, 200mA,
100MHz, ROHS
MURATA BLM21AG102SN1D
ESDA6V1-4BC6 1 ea D7 DIODE-TVS, ESD, QUAD
BI-DIRECTIONAL, 6P,
SOT23-6L, 80W, ROHS
STMICRO
ELECTRONICS ESDA6V1-4BC6
MIC2920A-3.3WS 1 ea U4 IC-LDO REGULATOR,
4P, SOT-223, 3.3V,
400mA, ROHS
MICREL MIC2920A-3.3WS
SN74AUP1G02DCKR 1 ea U6 IC-SINGLE 2-INPUT
POSITIVE-NOR GATE,
SMD, 5P, SC70-5, ROHS
TEXAS
INSTRUMENTS SN74AUP1G02DCKR
Bill of Materials(Continued)
PART NUMBER QTY UNIT REFERENCE DESIGNATOR DESCRIPTION MFR NAME MFR PART
Application Note 1507

20 AN1507.0
September 11, 2009
SN74AUP1G17DCKR 1 ea U5 IC-BUFFER, SCHMITT
TRIGGER, 5P, SC-70-5,
3.6V, 4mA, ROHS
TEXAS
INSTRUMENTS SN74AUP1G17DCKR
ZL6100ALNFT 3 ea U1, U2, U3 IC-DIGITAL DC-DC
CONTROLLER, 36P,
QFN, 6x6, ROHS
INTERSIL ZL6100ALNFT
BSC016N03LSG 6 ea Q3, Q4, Q7, Q8,
Q11, Q12 TRANSIST-MOS, N-CHANNEL, 8P,
PG-TDSON-8, 30V,
100A, ROHS
INFINEON
TECHNOLOGY BSC016N03LSG
BSC030N03LS G 3 ea Q2, Q6, Q10 TRANSISTOR-MOS,
N-CHANNEL, 8P,
PG-TDSON-8, 30V,
100A, ROHS
INFINEON
TECHNOLOGY BSC030N03LS G
FDG6301N-T 13 ea Q13, Q15 to Q26 TRANSIST-MOS, DUAL
N-CHANNEL, SMD,
SC70-6, 25V, 220mA,
ROHS
FAIRCHILD FDG6301N
FDG6304P 1 ea Q14 TRANSIST-MOS, DUAL
P-CHANNEL, 6P,
SC70-6, -25V, -0.41A,
ROHS
FAIRCHILD FDG6304P
MMBT3904LT1G-T 3 ea Q1, Q5, Q9 TRANSISTOR, NPN,
SOT-23, 3P, 40V,
0.2A.0.35W, ROHS
ON
SEMICONDUCTOR MMBT3904LT1G-T
H2510-00R00-1/16W-T 15 ea R5, R17, R29, R52,
R77, R78, R79, R83
to R90
RES, SMD, 0402, 0Ω,
1/16W, 5%, TF, ROHS VENKEL CR0402-16W-00T
H2510-01002-1/16W1-T 15 ea a) R3, R16, R27,
R39,R40,R41,R46,
R49, R50,
RES, SMD, 0402, 10k,
1/16W, 1%, TF, ROHS PANASONIC ERJ-2RKF1002X
H2510-01002-1/16W1-T 0 ea b) R65, R67, R68,
R69, R72, R76 RES, SMD, 0402, 10k, 1/16W, 1%, TF, ROHS PANASONIC ERJ-2RKF1002X
H2510-01003-1/16W1-T 3 ea R1, R14, R25 RES, SMD, 0402, 100k,
1/16W, 1%, TF, ROHS PANASONIC ERJ2RKF1003
H2510-01102-1/16W1-T 3 ea R9, R22, R33 RES, SMD, 0402, 11k,
1/16W, 1%,TF, ROHS PANASONIC ERJ-2RKF1102V
H2510-01622-1/16W1-T 3 ea R10, R23, R34 RES, SMD, 0402,16.2k,
1/16W, 1%, TF, ROHS PANASONIC ERJ-2RKF1622
H2510-01962-1/16W1-T 1 ea R56 RES, SMD, 0402, 19.6k,
1/16W, 1%, TF, ROHS PANASONIC ERJ-2RKF1962
H2510-02152-1/16W1-T 1 ea R57 RES, SMD, 0402, 21.5k,
1/16W, 1%, TF, ROHS PANASONIC ERJ-2RKF2152X
H2510-02372-1/16W1-T 1 ea R58 RES, SMD, 0402, 23.7k,
1/16W, 1%, TF, ROHS PANASONIC ERJ-2RKF2372V
H2510-02612-1/16W1-T 1 ea R59 RES, SMD, 0402, 26.1k,
1/16W, 1%, TF, ROHS VENKEL CR0402-16W-2612FT
H2510-02701-1/16W1-T 1 ea R38 RES, SMD, 0402, 2.7k,
1/16W, 1%, TF, ROHS VENKEL CR0402-16W-2701FT
H2510-02872-1/16W1-T 1 ea R60 RES, SMD, 0402, 28.7k,
1/16W, 1%, TF, ROHS PANASONIC ERJ-2RKF2872X
Bill of Materials(Continued)
PART NUMBER QTY UNIT REFERENCE DESIGNATOR DESCRIPTION MFR NAME MFR PART
Application Note 1507
