Intertech Nitrox SD-1021 User manual

PDU SD-1021
Per outlet control
User Manual
© 2013 – Inter-Tech Elektronik Handels GmbH – D-30855 Langenhagen –
Germany www.inter-tech.de – [email protected]e

2
Safety Precauons
To avoid potenal problems when using PDU:
● If the building has 3-phase AC power, ensure that the server
and monitor are on the same phase. For best results, they
should be on the same circuit.
● To avoid potenally fatal shock hazard and possible damage
to equipment, test AC outlets at the server and monitor for
proper polarity and grounding.
● To ensure the safety of network communicaon, it is
recommended that the PDU be installed in a network firewall
to prevent malicious aacks by hackers, which will affect the
safety of power consumpon.
Safety instrucons
Read all the following safety guidelines to protect yourself and
your PDU.
WARNING: All outlets of the PDU output high voltage. Necessary
precauons should be taken.
WARNING: Do not push any objects through the openings of the
PDU. Doing so may cause fire or electric shock by
shorng out interior components.
WARNING: There is a possibility of severe electrical shock from
either the live or neutral side of any of the power
outlets or their wiring, even if one of the circuit

3
breakers is disabled.
WARNING: The PDU is intended for indoor use only.
WARNING: To help protect the PDU from electrical power
fluctuaons, use a surge suppressor, line condioner
or uninterrupble power supply.
WARNING: Be sure that nothing rests on the cables of the PDU
and that it is not located where it may be stepped on
or tripped over.
WARNING: Do not spill food or liquids on the PDU. If it gets wet,
disconnect the power immediately.
WARNING: Keep the PDU away from heat sources.
WARNING: One output can only be connected to a single device.
Do not use extension cords to power mulple devices,
so as not to damage the output relay due to the
accumulaon of inrush currents from mulple devices.
Rack mount safety consideraons
When installing the PDU, make sure the following environmental
specificaons are met:
Elevated Operang Ambient Temperature: If the PDU is installed
in a closed or mul-unit rack assembly, the operang ambient
temperature of the rack environment may be greater than room
ambient temperature. Therefore, consideraon should be given to
installing the equipment in an environment compable with the
manufacturer’s maximum rated ambient temperature. See above.

4
Reduced Air Flow: Installaon of the equipment in a rack should
be such that the amount of air flow required for safe operaon of
the equipment is not compromised.
Mechanical Loading: Mounng of the equipment in the rack
should be such that a hazardous condion is not created due to
uneven mechanical loading.
Circuit Overloading: Consideraon should be given to the
connecon of the equipment to the supply circuit and the effect
that overloading of circuits might have on over current protecon
and supply wiring. Appropriate consideraon of equipment
nameplate rangs should be used when addressing this concern.
Reliable Grounding: Reliable grounding of rack-mounted
equipment should be maintained.
Parcular aenon should be given to supply connecons other
than direct connecons to the branch circuit, such as power strips
or extension cords.

5
Features and Benefits
The PDU is an Internet-ready power strip equipped with an
intelligent current meter to indicate the total power consumpon
of the Power Distribuon Unit (PDU). Each PDU includes PDU
Ulity soware to monitor and manage mulple PDUs.
Funcons Descripon
Ethernet Ethernet connecon for the built-in
web server.
Alarm Blinking LED „SIGNAL“
A B
OUTLET
A B
POWER
SIGNAL
FUNCTION
Funcon
Buon
Reset: Press once short - LED signal 1x
Factory sengs: Press ll LED has flashed 6 mes
LED Indicator Circuit Status (red): Circuit Status LEDs
labeled alphabecally to indicate the
PDU’s circuit status.
ENV1 RJ11 connecon for oponal accessory
to measure temperature and humidity.

Alarms and monitoring
The PDU delivers accurate, real-me global current monitoring of
all connected devices via the onboard web interface or through
the PDU Ulity soware. Users have the ability to set a current
alarm threshold that, once exceeded, will cause the PDU to flash
a LED or to send a noficaon message, or both.
Sequenal power applicaon
The PDU incorporates a sequenal power applicaon feature that
prevents all power outlet receptacles from turning on at once,
eliminang the potenal of current surges that could render the
equipment inoperable. Together with the global current
monitoring, the sequenal power applicaon feature lets users
safely install more equipment on exisng power circuits without
the worry of current overloads.
Features：
System
 Built-in Web Server to Support Remote Power Management.
 10/100 Base-T Ethernet Port
 IPv4 and IPv6 Support
 SNMP Control (v1,v2c,v3)
 Telnet, SSHv2 Encrypon Support
 Radius Authencaon
 User Account for Three Different Permissions Management
6

7
System
 Alarm Noficaon via Email, SNMP, Syslog or LED
 SSLv3, TLS1.0,TLS1.1,TLS1.2 Support
 IP Address Filtering
 Max. of 100000 entries for each Power Consumpon Data and
Event Log
 Remote firmware Upgrade Support
 Alive of Heart Beat Trap Available.
 Definable Reset Buon
 Fahrenheit and Celsius Switchable
 Export and Import PDU Configuraon
 Support wireless network connecon
Power Management
 True RMS Current Measurement.
 Remote Per Outlet On/Off Power Switching
 User Defined Alarm Thresholds for Warning and Overload.
 User Defined Power On/OFF Sequence Time.
 Timed & Scheduled On/Off/Reboot Switching
 Alternave Outlet Restart Mode: Memorized Previous Status,
Always On or Always Off
 Ping-No-Answer Alarm
 Outlet Acon via Pre-Set Event, Including Power Event,
Environment Event and Receiving Trap from Other Devices.
 Free Bundle Management Ulity.

8
Geng Started
Before installing your PDU, refer to the following list to ensure you
have all items that shipped with the PDU, as well as other items
necessary for proper installaon. The standard PDU package
includes the following:
• Power Distribuon Unit
.
• Power Cord

9
Installaon Instrucons
This secon will provide a quick instrucon to install the PDU.
A) Elevated Operang Ambient - If installed in a closed or
mul-unit rack assembly, the operang ambient temperature
of the rack environment may be greater than room ambient.
Therefore, consideraon should be given to installing the
equipment in an environment compable with the maximum
ambient temperature specified by the manufacturer.
B) Reduced Air Flow - Installaon of the equipment in a rack
should be such that the amount of air flow required for safe
operaon of the equipment is not compromised.
C) Mechanical Loading - Mounng of the equipment in the
rack should be such that a hazardous condion is not
achieved due to uneven mechanical loading.
D) Circuit Overloading - Consideraon should be given to the
connecon of the equipment to the supply circuit and the
effect that overloading of the circuits might have on over
current protecon and supply wiring. Appropriate
consideraon of equipment nameplate rangs should be
used when addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted
equipment should be maintained. Parcular aenon should
be given to supply connecons other than direct connecons
to the branch circuit (e.g. use of power strips)."
Diagram

10
Hardware
1. Unpack the product and place it to a proper place
2. Put the power cord of the computers into the sockets A and B
3. Connect the KVM to internet using the Ethernet socket
3. Connect the KVM to the power grid

11
Web interface:
The default seng for the way to get IP address is DHCP. If
PDU can not get the IP from DHCP server, the IP address will
stay at 192.168.0.200
Default ID: snmp
Default Password: 1234
Aer login to web, user can check all operaon instrucon in web
page of “Info.”

12
Informaon
Overview
Display current, temperature and humidity informaon, event log
and outlet status.
Note:
Current Monitor
ENV Monitor
Event List
Outlet Status

13
Seng column
S: Schedule is set. PDU will execute the pre-set outlet acon in
specified me automacally.
P: Ping funcon is acve. If the specified device stops ping
response, PDU will execute the pre-set outlets acon
E: PDU will execute the pre-set outlets' acon according to event
happen.
System
System informaon
Event Log
System memory can log up to 100000 entries.

14
Management
Control
1. Directly control outlet.
2. Set a number of outlets as a group to control them by one
funcon buon.

15
Schedule
Pre-set me to turn on or off the specified outlet
1. Outlet A is scheduled to off at 10:00 on 2022/03/29.
2. Outlet B executes off/on at 12:00 every Sunday.
3. Outlet C executes on at 14:00 every day.

26
Event Acon
Pre-set outlet acon once the current, temperature or humidity
over threshold
Note:
1. Receive Trap message 1.3.6.1.4.1.17420.1.6, IP is 192.168.0.1;
aer 10 seconds, Outlet C will OFF/ON.
2. When ENV(1) the temperature exceeds the upper limit, aer 5
seconds, Outlet A will “OFF”
3. When current over warning threshold, aer 1 second, Outlet A will
“OFF”..

171
Ping Acon
Ping-No-Answer power acon
Automacally reboot the locked device by ping its IP
1. Ping 192.168.0.1, if there is no response within 5 minutes,
Outlet A will OFF/ON
2. Ping 192.168.0.100, if there is no response within 15 minutes,
Outlet D will OFF.

18
Receive Trap OID equal to: User can input the private OID to
trigger the specified outlet acon.
Device
Outlets and circuits name, sequence on/off and outlet owner
configuraon
The max. length of outlet name is 36 characters
The max. me for delay on/off is 9999 seconds
Aer Restart:
Define the outlet acon aer power restart
Last Status: Aer power restart, outlets remain the same power
status.
ON: Turn on outlets aer power restart.

19
OFF: Turn off outlets aer power restart.
Note:
Aer PDU is plugged into main power, PDU system will start to
sequenally turn on the output socket according to the pre-set
delay me in PDU web interface. The factory default seng for
delay me is one second for each outlet; therefore the 8 ports
PDU will take 8 seconds, 24 ports PDU will take 24 seconds to
complete start-up procedure.
Before the sequence procedure is completed, if a PDU is
unplugged from the power source, the outlets which are not
turned on will be regarded as remaining at the power-off status.
Next me the PDU is plugged into main power, these outlets will
not be automacally turned on. These outlets can only be turned
on by web interface.
Carbon Emission Rate: Users can check this parameter through
power plant.

20
Threshold
Set threshold of current, temperature and humidity.
Set total current
and voltage
threshold
Set outlets
threshold
Set temperature
and humidity
threshold
