Interton Phone Clip User manual

User Guide
Interton Phone Clip

2 3
Statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this de-
vice may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable pro-
tection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communi-
cations.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful inter-
ference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
Welcome
Congratulations on your purchase of a Intergon Phone Clip.
Interton Phone Clip will allow you to wirelessly connect your 2.4
GHz wireless aids to Bluetooth-enabled mobile phones. This en-
ables clear and hassle-free phone connectivity, whether you are
at home, in the office or on the move.
Please read this manual carefully to fully benefit from the
Interton Phone Clip. Ask your hearing care professional if you
have any questions.
For your safety, carefully read the chapter Important Information,
on pages 24-30
FCC ID:X26BTB-1

4 5
National restrictions:
Norway: You are not allowed to operate the equipment within 20
km of the centre of Ny Ålesund.
This product is in compliance with the following regulatory stan-
dards:
In EU: The device conforms to the Essential Requirements ac-
cording to - Annex I of Council Directive 93/42/EEC for medical
devices (MDD) and essential requirements and other relevant pro-
visions of Directive 1999/5/EC (R&TTE). The declaration of con-
formity may be consulted at www.interton.com.
In US: FCC CFR 47 Part 15, subpart C, section 15.247 and
15.249.
Other identified applicable international regulatory requirements
in countries outside EU and US. Please refer to local country
requirements for these areas.
The product is categorized as receiver class 2 according to
EN 300 440.
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications can void the user’s authority to operate
the equipment.
Intended use
Interton Phone Clip is intended to enable 2.4 GHz wireless hear-
ing instrument users to better follow phone conversations. The
essential performance of the Interton Phone Clip is to transfer
signals between a phone with Bluetooth capabilities and a 2.4
GHz wireless hearing instrument.
List of countries
Products are intended for sale in countries within European
Economic Area as well as Switzerland.

6 7
Contents
Description ......................................8-9
Getting Started....................................10
ON and OFF ......................................12
Bluetooth Pairing...................................13
Basic Use ........................................16
Volume Control....................................18
Operating Time....................................18
Wearing Your Interton Phone Clip . . . . . . . . . . . . . . . . . . . . . . 19
Light indicators....................................21
Introduction to Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . 22-23
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-30
Technical specifications .............................31
Warranty.........................................32
Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-39
Notes ........................................40-41

5
7
4
1
3
6
2
8 9
5 Multifunctional button
6 Clip
7 Pairing button (behind cover)
Description
1 Volume control
2 Mini-USB for charging
3 LED (Light Emitting Diode) indicator
4 Own voice microphone inlet

10 11
Pairing to hearing instruments
Note! The following information is intended primarily for your
hearing care professional, who in most cases will complete the
tasks that are necessary before the Interton Phone Clip can be
used with your hearing instruments. However, the process is
designed to be simple and should be easily accomplished by
almost anyone.
1. Make sure Interton Phone Clip is turned on. Your hearing in-
struments must be off – open the battery door.
Getting Started
Charging the Battery
Before using your Interton Phone
Clip, you need to fully charge the
rechargeable battery. To charge
it, plug the charging cable as
shown in the picture below. Then
plug the other end of the charging
cable into a power outlet.
During the charging process, the
LED indicator will show a solid red
light. A solid green light will indi-
cate the fully charged status.
Charging an empty battery typi-
cally takes about 3 hours. It is
safe to leave the charger con-
nected overnight – the battery cannot be overcharged.
• When charging your Interton Phone Clip for the first time, leave
it to charge for at least 3 hours, even if the battery indicator
turns into a solid green light earlier.
• For safety reasons, recharge the battery only with chargers
supplied by Interton.
Do not charge the Interton Phone Clip while it
is on your body.

12 13
Bluetooth Pairing
If your mobile phone is Bluetooth-enabled and supports the
appropriate profiles, it can communicate with the Interton Phone
Clip only after completing two simple procedures: pairing and
connecting.
The pairing procedure allows you to control which Bluetooth
devices are permitted to communicate with each other. It needs
to be completed only once for each device you wish to use with
your Interton Phone Clip.
You can pair up to 8 Bluetooth devices with the Phone Clip, but
only 1 Bluetooth device can be connected at a time.
The pairing procedure is described in the section which follows.
Once a mobile phone is permitted to communicate with the
Interton Phone Clip by the pairing procedure, the connection pro-
cedure configures the device to actually output its audio signal
over the Bluetooth connection. This procedure is also described
in the section which follows.
Pairing to mobile phone
The pairing procedure is controlled by your mobile phone.
Different mobile phones have different menu structures. You
should therefore refer to your mobile phone’s manual if you
cannot complete the pairing procedure with the generic steps
described here.
2. With the tip of a pen or similar object, press the small pairing
button on the back of your Interton Phone Clip device hidden
by the bottom cover (see picture below). Press shortly until the
LED indicator turns to solid blue. Your Interton Phone Clip will
remain in pairing mode for 20 seconds.
3. While pairing mode is activated, close the battery doors of
both hearing aids and make sure they are ON. A successful
pairing will be indicated by an audible melody played in both
hearing aids. You are now ready to use the Interton Phone
Clip!
ON and OFF
To turn ON your Interton Phone Clip, press and hold the multi-
functional button (5 on page 9) for about 1 second until you see
the LED indicator displaying a solid blue light. The blue light will
be on for 4 seconds.
To turn it OFF, press and hold the multifunctional button for about
3 seconds until the LED indicator flashes quickly 4 times and then
goes dark.

14 15
1. The Interton Phone Clip is OFF. Place your mobile phone next
to the Phone Clip, and make sure your phone is ON.
Press and hold the multifunctional button on the Phone
Clip for 7 seconds. The LED will now be solid blue for two
minutes indicating that Bluetooth pairing mode is active. The
Interton Phone Clip will be in Bluetooth pairing mode only in
the first two minutes after having been turned ON.
2. Find the connectivity settings of your phone. Look for the
“Bluetooth” feature in the main menu or one of the submenus,
such as “Connectivity”.
3. On your mobile phone, ensure that the Bluetooth is turned
ON.
4. On the mobile phone choose to search for Bluetooth devices.
5. Your mobile phone should present a list of Bluetooth devices
discovered. Select “Hearing Aid Phone” from this list.
6. Your mobile phone may then ask you to enter a passcode. If
so, enter “0000” (four zeros).
Your Interton Phone Clip should now be paired to your mobile
phone. Some mobile phones may ask which Bluetooth service
you wish to enable. enable, select “Headset”.
Connecting
Once your mobile phone and Interton Phone Clip are paired, the
mobile phone needs to be connected before it will actually send
the appropriate audio signals.
This function should also appear in your mobile phone’s “Blue-
tooth” menu, usually under a list of “Paired Devices”. In that list,
highlight your Interton Phone Clip and select “Connect”.
• When your Interton Phone Clip and mobile phone are connected,
you may see a headset symbol on the main screen of your
mobile phone, similar to this:
The connection between the Interton Phone Clip and the mobile
phone will be maintained for as long as both devices are turned
ON and remain within range of each other. If either device is
switched OFF or moves out of range, you may have to perform
the connection procedure again.
On some phone you can configure “Automatic Reconnection”.
We recommend that you do so if the feature is available. Refer to
the user guide of your mobile phone for instructions on how to do
this if supported.

16 17
To reject incoming calls press the multifunction button twice on
the Phone Clip.
You can also reject calls by pressing the reject button on your
mobile phone.
Making a Call
Initiating a phone call is not any different with or without Interton
Phone Clip: Simply use the mobile phone keyboard to enter or
select the number to dial.
If connected, the phone streaming mode will be activated auto-
matically, and you will hear the ringing tones in the hearing instru-
ments
Ending a Call
To end a call via your Interton Phone Clip, briefly press the multi-
functional button. The call will terminate and your hearing instru-
ments will return to the last used program.
You can also end calls by pressing the appropriate button on your
mobile phone.
Basic Use
Accept and Reject Calls
Turn the device ON. When a call is received on your mobile phone,
the Bluetooth indicator will flash and after a certain delay you will
hear the ringing tone in your hearing instruments.
To accept the incoming call, briefly press the multifunctional
button on your Interton Phone Clip. If you are wearing two hearing
instruments, the caller’s voice will be streamed to both of them.
You can also accept calls by pressing the accept button on your
mobile phone.
• If desired, your hearing care professional can set your hear-
ing aids’ microphones to remain ON even in the event of
an incoming call, so to mix the phone streamed signal with
external sound.
• In case you are also using a Interton TV (optional), please
notice that mobile phone calls will always take priority
over other audio sources. In the event of an incoming
phone call, the Interton TV will be temporarily stopped. It
will be automatically resumed once the phone call has been
terminated.

18 19
Wearing Your Interton Phone Clip
Clip your Interton Phone Clip on your sweater, jacket or other
clothing so that the microphone inlet faces upwards. Keep the
device within a range of 10-30cm from your mouth. You may also
clip it on to the sun visor in your car.
Reset the Phone Clip
With the tip of a pen or similar object, press the small pairing but-
ton on the back of your Interton Phone Clip device hidden by the
bottom cover (see picture below). Keep pressed for at least 10
seconds and when released, the device is reset.
Volume Control
Your Interton Phone Clip has an easy to operate volume control
(1 on page 8) for increasing or decreasing the loudness of the
streamed signal.
Depending on the phone, you can also utilize the volume control
that is built in your mobile phone.
It is also possible to use the Interton Remote Control (optional) to
adjust the volume.
Operating Time
Battery consumption and the operating time of your Interton
Phone Clip depend greatly on the usage of the device.
Your Interton Phone Clip battery can be recharged hund reds of
times. If the operating time reduces substantially, please contact
your hearing care professional.

20 21
Light indicators
The Light indicator (3 on page 8) on your Interton Phone Clip serves
as a multipurpose user interface, providing information on the
status of your device.
Interton Phone Clip
status
Mode Condition
Pairing Solid Blue for 20 seconds Ready for pairing with
hearing instruments
Solid Blue for 2 minutes Ready for pairing with
Bluetooth phone
Charging Solid Red Charging
Solid Green Fully charged
Normal Flashes Blue twice every Incoming call or
2 seconds call connected
Flashing Red once every Battery low
5 seconds
Flashes blue 2 times after No call pending
pressing multifunctional
button
Off None of the normal
modes are present,
or Power is Off
LED indicator

22 23
Introduction to Bluetooth
What is Bluetooth?
Bluetooth provides a way for devices like mobile phones to com-
municate wirelessly.
First, check whether the phone you wish to use offers Bluetooth
connectivity. Look for the following symbol on the device or its
user guide.
Second, the range of possible applications on a Bluetooth-
enabled device is defined by “profiles”. The device you wish to
use with your Interton Phone Clip must support the appropriate
Bluetooth profiles.
To receive or place phone calls your mobile phone must support
either the “handsfree” or the “headset” profile. Many, but not all
mobile phones support these Bluetooth profiles. Look for this
information in your mobile phone user guide.
Bluetooth Operating Range
In free air, your Interton Phone Clip supports Bluetooth op-
eration up to a range of approximately 10 meters. Line-of-sight
between the devices is not required. However, the following
factors may affect the maximum range:
• Interference in the environment
• The mobile phone which you are connecting to may support
a more limited range than the 10 meters supported by the
Interton Phone Clip
If your mobile phone moves out of range, the connection will
be terminated. If the device is then moved again within the range,
the Interton Phone Clip will attempt to re-establish connection.
Whether it achieves to do so will depend on delay since the link
was broken and on the mobile phone properties.

24 25
General warnings
• Keep this device out of reach of children
• Interton Phone Clip uses low-powered digitally coded trans-
missions in order to communicate with other wireless devices.
Although unlikely, nearby electronic devices may be affected.
In that case, move the Interton Phone Clip away from the
affected electronic device.
• When using Interton Phone Clip and the device is affected by
electromagnetic interference, move away from the source.
• Avoid exposing your product to rain, moisture or other liquids
to protect against damage to the product or injury to you.
• Keep the product and any cords and cables away from oper-
ating machinery.
• If the product overheats, if the product has been dropped or
damaged, if the product has a damaged cord or plug, or if the
product has been dropped in a liquid, discontinue use and
contact your hearing care professional.
• Dispose of the product according to local standards and regu-
lations.
• Do not use in areas where there are explosive hazards.
Important Information
Maintenance and Care
• Clean the Interton Phone Clip using a damp cloth. Never use
household cleaning products (washing powder, soap etc…) or
alcohol to clean the device
• When Interton Phone Clip is not in use, turn it OFF and store
it safely
• Protect Interton Phone Clip from excessive moisture (bathing,
swimming) and heat (radiator, car dashboard). Protect it from
excessive shock and vibration.
• Protect the microphone and charger inlets from debris and
dirt. If necessary, use the cleaning brush provided with your
hearing instruments to clean these areas.

26 27
• Do not make any changes or modifications to this device.
• Opening the Interton Phone Clip might damage it. If problems
occur which cannot be resolved, consult your hearing care
professional.
• Interton Phone Clip may only be repaired by an authorized
service center.
• Do not use Interton Phone Clip in areas where RF transmis-
sion is prohibited, e.g. air planes etc.
• Do only connect Interton Phone Clip to connections which it is
explicitly intended for.
BUILT-IN BATTERY CARE: Please observe the
following if the product contains a battery
• Your product is powered by a rechargeable battery.
• The full performance of a new battery is achieved only after
two or three complete charge and discharge cycles.
• The battery can be charged and discharged hundreds of
times, but will eventually wear out.
• Unplug the charger from the electrical plug and the product
when not in use. Do not leave a fully charged battery connect-
ed to a charger, since overcharging may shorten its lifetime.
Ignition of flammable atmospheres
• Do not use the product in environments where there is a dan-
ger of ignition of flammable gasses.
General Precautions
• Do not use this device in locations where it is forbidden to use
electronic devices.
• X-ray radiation (e.g. CT scans, MRI scans) may adversely affect
the correct functioning of this device. We recommend that you
switch the device OFF before undergoing X-ray procedures
and keep it outside the room.
• High-powered electronic equipment, larger electronic instal-
lations and metallic structures may impair and significantly
reduce the operating range.
• If the hearing instruments do not respond to the device be-
cause of an unusual field disturbance, move away from the
disturbing field.
• Your hearing instruments and this device were given a unique
communication code during the fitting. This ensures that the
device will not affect hearing instruments worn by others.

28 29
• If left unused, a fully charged battery will lose its charge over
time.
• Leaving the product in hot places, such as in a closed car in
the summer conditions, will reduce the capacity and lifetime
of the battery.
• A product with a cold battery may not work temporarily, even
when the battery is fully charged. Battery performance is par-
ticularly limited in temperatures well below freezing.
Battery warning!
• ”Caution” – The battery used in this product may present a risk
of fire or chemical burn if mistreated.
• Do not attempt to open the product or replace the battery.
It is built-in and not changeable. Use of other batteries may
present a risk of fire or explosion and the warranty will be ter-
minated.
• The battery in your product can not be removed or replaced
by the user. Any attempt to do so is risky and may result in
damage of the product.
• Only recharge the Interton Phone Clip only with a power sup-
ply unit that has been supplied together with the product.
• Dispose of batteries according to local regulations. Please re-
cycle when possible.
• Do not dispose the battery as household waste or in a fire as
it may explode.
• Batteries may explode if damaged.
CHARGER CARE: Please observe the follow-
ing if the product is supplied with a charger
• Do not attempt to charge your product with anything other
than the AC adapter provided. The use of any other types may
damage or destroy the product and could be dangerous. Use
of other chargers may invalidate any approval or warranty.
• For availability of approved enhancements, please check with
your hearing care professional.
• Charge the product according to the instructions supplied
with the product.

30 31
Charger warning!
• When you disconnect the power cord or any enhancement,
grasp and pull the plug, not the cord.
• Never use a charger that is damaged.
• Do not attempt to disassemble the charger as it may expose
you to dangerous electric shock.
• Incorrect reassembly can cause electric shock or fire when
the product is subsequently used.
• Avoid charging your product in extremely high or low tempera-
tures and do not use the charger outdoors or in damp areas.
• Do not charge the Interton Phone Clip while it is on your body.
Technical specifications
Operating range: up to 3 meters
Wireless: 2,4 GHz
Operating temperature: 0 to 45 degree C
Storage temperature: -20 to 45 degree C
Charging temperature: 0 to 45 degree C
Temperature test, transport and storage information
The product is subject to various tests in temperature and damp
heating cycling between -25 C and +70C according to internal
and industry standards.

32 33
What is not covered by this warranty?
Problems arising from improper handling or care, excessive use,
accidents, repairs made by an unauthorized party, exposure to
corrosive conditions or damage due to foreign objects entering
the device are NOT covered by the limited warranty and may void
it. The above warranty does not aff ect any legal rights that you
might have under applicable national legislation governing sale of
consumer products. Your Hearing Care Professional may have
issued a warranty that goes beyond the clauses of this limited
warranty. Please consult your Hearing Care Professional for
further information.
Serial number:
Date of purchase:
Warranty
The Interton Phone Clip is covered by a limited warranty issued
by the manufacturer for a period of 12 months from the day of the
original purchase. Please notice that extended warranties may
apply in your country. Please contact your local Hearing Care
Professional for more information.
What is covered by this warranty?
Any electrical component, that because of workmanship, manu-
facturing or design defects fails to function properly under nor-
mal use during life of this warranty will be replaced or repaired
at no charge for parts or labour when returned to the point of
purchase.
If it is determined that repair is not feasible, the entire unit may be
replaced with an equivalent unit upon mutual agreement of the
Hearing Care Professional and the customer.

34 35
SYMPTOM
The Phone Clip does not
respond to any (long or short)
presses on the multifunctional
button
The pairing button on the
Phone Clip is pressed but no
pairing melody is played in
the hearing aid
The Phone Clip cannot be
found by the mobile phone
when searching for it in the
Bluetooth menu
CAUSE
The battery in the Phone Clip is
depleted
The Phone Clip and hearing aid
are not within wireless range
The Phone Clip and hearing aid
have not been simultaneously in
pairing mode
The Phone Clip and mobil phone
are not within wireless range
The Phone Clip is not in Blue-
tooth pairing mode
POSSIBLE REMEDY
Charge the battery
Assure that Phone Clip and hearing aids are within wireless
range, and repeat pairing process
Repeat pairing process, and assure that the battery doors on
both hearing aids are closed within 20 seconds after the pairing
button has been pressed on the Phone Clip
Assure that Phone Clip and mobile phone are within wireless
range, and repeat Bluetooth pairing process
The Phone Clip is only in Bluetooth pairing mode for 120 sec-
onds after having been activated. Repeat the Bluetooth pairing
process
TROUBLESHOOTING GUIDE

36 37
SYMPTOM
The Bluetooth pairing failed
The mobile phone is ringing
but the light indicator on the
Phone Clip does not flash,
and no ringing tones will
sound in the hearing aids
CAUSE
The Phone Clip left Bluetooth
pairing mode before mobile
phone completed the pairing
session
The user entered a wrong
4-digit PIN code
The Phone Clip is powered off
The Phone Clip and mobile
phone have not been paired
The Bluetooth connection
between the Phone Clip and
the mobile phone is lost
POSSIBLE REMEDY
Repeat the Bluetooth pairing process, and assure that the pro-
cess is completed within 120 seconds after having been acti-
vated in the Phone Clip
Repeat the Bluetooth pairing process and if a PIN code is re-
quested, enter 0000 (four zeros)
Power on the Phone Clip
Perform the Bluetooth pairing process and make a Bluetooth
connection between the Phone Clip and the mobile phone
Assure that Bluetooth is enabled in the mobile phone and make
a Bluetooth connection between the Phone Clip and the mobile
phone again, e.g. by pressing the multifunction button briefly on
the Phone Clip.
As for any details of the Bluetooth operation of the mobile phone,
please refer to its user guide
TROUBLESHOOTING GUIDE

38 39
SYMPTOM
The mobile phone is ringing
and the light indicator on the
Phone Clip do flash, but no
ringing tones will sound in
one or both hearing aids
The remote user does not
hear my voice clearly
The sound from the hearing
aids is either to low or too
high
There is no sound in the
hearing aids although being
in the phone program
CAUSE
The Phone Clip and hearing aids
are not within wireless range
The battery in the hearing aid
is so depleted that it no longer
supports audio streaming
The Phone Clip microphone does
not pick up your voice correctly
The audio input level is not
suitable for listening
The Phone Clip and hearing aids
are not within wireless range
POSSIBLE REMEDY
Assure that Phone Clip and hearing aids are within wireless
range
Replace the battery in the hearing aid with a new one
Assure that the Phone Clip microphone is kept close to your
mouth, and that the Phone Clip does not rub against any clothing
during the call
Adjust the volume on the mobile phone until the sound is suitable,
or adjust the volume using the ”+” and ”-” keys on the Phone Clip
until the sound is suitable.
Alternatively (option), use the ”+” and ”-” keys on the Remote Con-
trol for doing this operation
Assure that Phone Clip and hearing aids are within wireless
range
TROUBLESHOOTING GUIDE
