1 Presentation
The FJ-AC-MBS-1 interfaces allow a complete and natural integration of
Fujitsu air conditioners into Modbus RTU (EIA-485) networks.
Reduced dimensions. 93 x 53 x 58 mm
3.7” x 2.1” x 2.3”
Quick and easy installation.
Mountable on DIN rail, wall, or even inside the indoor unit of AC.
•External power not required.
•Direct connection to Modbus RTU (EIA-485) networks. Up to 63 FJ-AC-MBS-1 devices can be connected in the
same network.
FJ-AC-MBS-1 is a Modbus slave device.
•Direct connection to the AC indoor unit.
•Configuration from both on-board DIP-switches and Modbus RTU.
•Total Control and Supervision.
•Real states of the AC unit's internal variables.
•Allows simultaneous use of the AC’s remote controls and Modbus RTU.
* Up to 63 IntesisBox devices can be installed in the same Modbus RTU bus. However, depending on the configured speed, the installation of Modbus Repeaters
may be required
•SCADA
•PLC
•DDC
•BMS
•HMI
•Controller
•etc
Up to 63 AC
indoor units*
Modbus RTU
EIA-485 network
Modbus RTU
Master
device
FJ-AC-MBS-1
FJ-AC-MBS-1
FJ-AC-MBS-1

IntesisBox®ModBus RTU –Fujitsu User Manual r1.0 EN
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox®is a registered trademark of Intesis Software SLU
URL
EmailP
hone
http://www.intesisbox.com
[e-mail]
[phone]
6/21
2 Connection
The interface comes with cable + connectors for direct connection to the AC indoor unit, and with a plug-in terminal
block of 3 poles for connection to a Modbus RTU EIA-485 network.
Connect to the AC indoor unit
The FJ-AC-MBS-1 connects directly to the indoor unit internal control board. In the control board locate the socket
connector marked as CN65.
Figure 2.1 FJ-AC-MBS-1 connection diagram
Connection to the EIA-485 bus
Connect the EIA-485 bus wires to the plug-in terminal block of FJ-AC-MBS-1 and keep the polarity on this connection
(A+ and B-). Make sure that the maximum distance to the bus is 1,200 meters (3,937 ft). Loop or star typologies are
not allowed in the case of the EIA-485 bus. A terminator resistor of 120Ωmust be present at each end of the bus to
avoid signal reflections. The bus needs a fail-safe biasing mechanism.
CN65
AC indoor unit
Electronic control board
200 mm / 7.9”
40 mm / 1.6”
Connection cable
provided with the
interface
90 mm / 3.5”
53 mm / 2.1”
Use this hole to
attach the cable
using the staple and
the screw provided
with the interface
Fixing screw
ModBus RTU
EIA-485
Bus
IntesisBox®
FJ-AC-MBS-1
AC Unit
B A SG
EIA485
For wall mounting,
extract the upper and
lower staples until you
listen the "click".
SW1
SW2
SW3
