Samsung BACnet Gateway MIM-B17N User manual

uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGX^Y YWXZTWZTX\GGG㝘䟸G[aZ`aW]

Data Management Server2
MIM-D00AN
BACnet Gateway
MIM-B17N
LonWorks Gateway
MIM-B18N
Air Conditioner
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
DB68-03733A(1)
EN
This manual is made with 100% recycled paper.
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGX^Z YWXZTWZTX\GGG㝘䟸G[aZ`aW]

E-2
Safety Precautions
XDo not attempt to install or repair this DMS2 by yourself.
X This DMS2 contains no user-serviceable parts.
Always consult authorized service personnel for repairs.
XWhen moving, consult authorized service personnel for
disconnection and installation of the DMS2.
XEnsure that the wall is strong enough to support the
weight of the DMS2.
XMust install the DMS2 with rated power supply.
XIn the event of a malfunction (burning smell, etc.),
immediately stop operation, turn off the electrical
breaker, and consult authorized service personnel.
WARNING
CAUTION
X  Do not use inflammable gases near the DMS2.
X  Do not spill water into the DMS2.
X  Do not operate the DMS2 with wet hands.
X  Do not install the DMS2 in a location where it will come
into contact with the combustible gases, machine oil,
sulphide gas, etc.
X  Do not press buttons with a pointed thing.
X  Do not pull or bend the DMS2 cable excessively.
X  Do not use this DMS2 for other purpose.
X  Do not spray an insecticide or other combustible things
on the DMS2.
X  Do not clean the DMS2 with benzene, solvents or other
chemicals.
X  Do not give a shock to the DMS2 or disassemble it by
yourself.
xBefore using the DMS2, read carefully these instructions.
xAfter reading the instructions, keep this user's manual in a handy and safe place.
If a user is changed, you must hand over the manuals.
xNever attempt to install the air conditioning system or to move the DMS2 by yourself.
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGY YWXZTWZTX\GGG㝘䟸G[aZ_a[[

E-3
Contents
XG ENERAL D ESCRIPTION ....................................................... 4
XV IEWING THE P ARTS ........................................................... 6
XB EFORE U SE ...................................................................... 8
XM AIN F UNCTION ............................................................. 10
XS TARTING DMS2 ........................................................... 14
XC ONTROL AND M ONITORING ............................................. 18
XZ ONE M ANAGEMENT ....................................................... 59
XS CHEDULE ..................................................................... 64
XEHP P OWER C ONSUMPTION I NSPECTION ............................ 73
XC ONTROL L OGIC M ANAGEMENT ........................................ 84
XS YSTEM S ETTINGS ........................................................... 97
XC HECK B EFORE USING P ANEL .......................................... 151
XS ETTING N ETWORK I NFORMATION ................................... 152
XC HECKING I NDOOR /O UTDOOR U NIT I NFORMATION ............ 154
XC HECKING DMS2 V ERSION ............................................ 155
XD ATA B ACKUP S ETTING ................................................. 158
XC HECKING E RROR I NFORMATION ..................................... 160
XR ESET P ASSWORD ......................................................... 161
XB UTTON L OCK .............................................................. 162
XS AFETY H ALT ............................................................... 163
XT ROUBLESHOOTING ....................................................... 164
XS PECIFICATIONS ............................................................ 166
XL ICENSE ....................................................................... 167
Note XThe contents and pictures used in this user manual
may be changed without advance notice for the
functional reinforcement and improvement of a
product.
This System is strictly restricted to authorized user. Any
illegal access shall be punished with a related-law.
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGZ YWXZTWZTX\GGG㝘䟸G[aZ_a[[

E-4
General Description
The DMS2 is an Internet based device for central management of Samsung system
air-conditioners. It supports LAN & WAN and operates 24 hours without a separate PC.
Introduction of DMS2 (Data Management Server2)
The DMS2 provides the following advantages:
XEveryday Device–The DMS2 is operational all year long 24 hours.
X Independent Operation–The DMS2 can operate schedule control and power distribution
without a PC.
Note In order to run power distribution, relevant controllers need to be installed.
XInternet Control
Web – The DMS2 has a built-in web server function and can be accessed from a
remote location to operate status
monitoring, control, trouble history, and schedule setting of the system
air-conditioners.
Using an Upper Level Controller–When a separate upper level controller (S-NET
series) is used, a number of DMS2 can be controlled with one central management
system.
XData Storage–The DMS2 has its own database built-in, therefore, trouble history,
indoor unit installation information, and power distribution data can be saved and
retrieved.
XLarge Scale Management–At most 256 indoor units can be connected to one DMS2
and therefore, only one DMS2 can manage small and medium size buildings.
XAutomatic ”e-mail” sending–When an error is occurred, inform the error details to an
e-mail saved on DMS2.
Advantages of DMS2 System
Note XPlease be advised that once you are permitted access
to the system, you will be deemed to have consented
to having software relating this system automatically
updated or modified on a periodic basis. You will be
deemed to have consented to having software relating
this system automatically updated or modified on a
periodic basis.
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGG[ YWXZTWZTX\GGG㝘䟸G[aZ_a[[

E-5
XDMS2: The abbreviation of Data Management Server2.
XUpper Controller: S-NET 3, RMS and DMS2 which allows controlling by accessing to a
web page.
XOnOff Controller: A device that controls 16 groups of the DVM air conditioner.
A central control device of a DVM system which is located between a
DMS2 and an outdoor unit.
XAHU(Air Handling Unit): Executes heat exchange between air and cooling unit using
central air conditioning duct method.
XERV(Energy Recovery Ventilator): Ventilating system using heat recovery function.
Terms
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGG\ YWXZTWZTX\GGG㝘䟸G[aZ_a[[

E-6
Viewing the Parts
Front View
No. Name Description

LCD Display Display current time/ Check menu

Menu button Access to main menu
▼/▲button Select the function you want and set detailed functions in
main menu
Set button Check the function you want from main menu
and select it

Bottom cover Unfasten 2 screws on the bottom and separate the bottom
cover from DMS2. Then check cable connection part.



Name Description
Power Turns blue when the power is supplied.
CPU Alive Blinks in orange with 1 second intervals during normal
operation.
Ethernet–Linked Turns green during normal connection.
Ethernet–Active Blinks in orange during normal transmission/reception.
COM1~5 – TX Blinks in green during normal transmission.
COM1~5 – RX Blinks in green during normal reception.
Check Turns green when notice occurs.
Indicator
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGG] YWXZTWZTX\GGG㝘䟸G[aZ_a[\

E-7
DI Terminal1
Connect Digital Input
- Channel 1~Channel 5
DI Terminal2
Connect Digital Input
- Channel 6~Channel10
DO Terminal 2
Connect Digital Output
- Channel 6~Channel 10
DO Terminal1
Connect Digital Output
- Channel 1~Channel 5
Power
Terminal
Connect
DMS2 adapter
Reset Button
Reset DMS2
RS485
Communication
terminal
Connect for RS485
communication with
devices such as OnOff
Controller/Outdoor
unit
- COM1 ~ COM5
Cable tie groove
Arrange cables connected to
DMS2
LAN Terminal
Connect LAN cable
Serial Terminal
Service agent checks error
status
SD Card Socket
Socket for sub memory (SD or MMC)
(Sub memory is for DMS2 program update and set
information saving)
※Purchase SD card separately.
XSeparate bottom cover by unfastening 2 screws on the bottom.
Bottom View
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGG^ YWXZTWZTX\GGG㝘䟸G[aZ_a[\

E-8
XConnecting outdoor unit and DMS2
- You can control up to 80 outdoor units and 256 indoor units by using DMS2.
※You can connect up to 16 (outdoor) units per each communication channel of the
DMS2.
- If the number of connected outdoor unit increases, it may take long time for tracking.
OnOff
controller
DMS2
Internet
Web Client
RMS Senter
S-NET 3
TCP/IP
R5 485
(DVM Series)
Outdoor Unit
Max 256
Indoor units
SIM/PIM
Power meter
Before Use
System Configuration
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGG_ YWXZTWZTX\GGG㝘䟸G[aZ_a[\

E-9
XInstall Windows XP SP2, Windows 2000 SP4 or later version
XInstall Internet Explorer 7.0 or later version
※You can use Internet Explorer 6.0 but it is not recommended.
XInstall Silverlight 2.0 or later version
Web Browser Specification
Note XVisit internet homepage (http://www.microsoft.
com/silverlight/) to download Silverlight. Or you can
download it through the download link which is noticed
automatically when the PC is connected to the Internet
and you access to DMS2 for the first time.
XSilverlight operates normally with Windows XP SP2 or
later version.
It may not operate normally with former version of
Windows.
All settings of DMS2 will be arranged in web page which built in
DMS2.
You should access to DMS2 IP to use DMS2 web page.
There are 2 ways to access DMS2 IP.
(For about settings, refer to installation manual.)
XStatic IP setting
XDynamic IP(DHCP) setting
Computer Settings for DMS2 Connection
X For devices that supports new communication, you must set the communication mode
of the channel to 'NEW' from 'System settings Tracking' menu, and for the SIM/PIM
with conventional communication, communication mode must be set to 'IM'. Set of
Indoor/outdoor units, with conventional communication type, cannot be connected to
DMS2 with new communication.
X When 'NEW' is set as communication mode of the channel, virtual OnOff controller
address will be assigned.
(Channel 0: Virtual OnOff controller 11, Channel 1: Virtual OnOff controller 12,
Channel 2: Virtual OnOff controller 13, Channel 3: Virtual OnOff controller 14,
Channel 4: Virtual OnOff controller 15)
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGG` YWXZTWZTX\GGG㝘䟸G[aZ_a[]

E-10
Device Type
Indoor Unit
Indoor unit communication error
Indoor unit sensor related error
Other errors
Outdoor Unit
Outdoor unit communication error
Pipe inspection error
Outdoor unit sensor related error
Outdoor unit related other errors
Communication error
such as OnO controller
Option device related communication
error
Main Function
The DMS2 saves at most 1024 cases of trouble history.
If the number of errors exceeds 1024, only the latest 1024 cases
are stored by deleting the oldest trouble history.
XDevice name, address, error occurrence time, error solvation
time, trouble history will be saved. You can check it in web
page or upper controller.
XWhen an error occurs, it sends trouble history to e-mail saved
in DMS2.
Save Trouble History
The DMS2 receives/manages setting and control data from the
upper level controller and sends the received data to the lower
level system.
X Upper controller: S-NET 3, RMS and DMS2 which allows
controlling by accessing to a web page.
X S-NET 3: System air conditioner controlling and monitoring
program that is used by installing on a PC.
X RMS: A device which supervises operation status and break
down status by connecting to DMS2 for system air
conditioner remote service. If break down is detected,
it notifies service agent and makes fast service possible.
Interface with Upper Level Controller
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGXW YWXZTWZTX\GGG㝘䟸G[aZ_a[]

E-11
Item Content Remark
Schedule Period Starting and ending date of a schedule
Exception Day
Setup
Set an exception day within a schedule period to
ignore the schedule control
Devices to
be applied Select devices to receive schedule control
Event
Set indoor unit operation modes
- Device On time
- Device O time
- Desired temperature
- Operation mode: Auto/Cool/Dry/Fan/Heat/O
- Remote control usage Enable RC/ Disable RC/
Cond.RC
- Fan speed: Auto/Low/Mid/High
- Air ow: None/Vertical/Horizontal/All
- ERV operation mode: Auto/HeatEx/ByPass/Sleep
- ERV Fan speed: Low/High/Turbo
Weekly Repeat:
Maximum 10 events
per day
Daily Repeat:
Maximum 70 events
The schedule function of the DMS2 can be set through the Web
or using the upper level controller. 1day/Everyday/Every week
schedules can be set.
XEach schedule can be used selectively by using the run
schedule/stop schedule order.
XAt most 256 schedules can be set.
XIndoor unit control is possible at least 1 minute of interval by
set schedule.
Set and Run Schedule
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGXX YWXZTWZTX\GGG㝘䟸G[aZ_a[]

E-12
System Architecture
The DMS2 calculates and distributes the power consumed by each indoor unit by
receiving the total power usage from the watt-hour meter interface modules (SIM/PIM)
and taking into account the operation status of the indoor units.
The DMS2 saves at most 1 year of data. After a year, the oldest data is deleted and
the latest data is saved. This data can be checked through the built-in Web page of
the DMS2 or by S-NET 3.
Save Integrated Power Distribution Data
Main Function (Continued)
OnOff
controller
DMS2
Internet
Web Client
RMS Senter
S-NET 3
TCP/IP
R5 485
(DVM Series)
Outdoor Unit
Max 256
Indoor units
Power meter
SIM
/PIM
SIM
/PIM
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGXY YWXZTWZTX\GGG㝘䟸G[aZ_a[]

E-13
XTime segmentation is used to divide 24 hours into different sections and to distribute
power according to each section.
XThis function is used when the power consumption fee is different according to
different time slots or when a building is charged differently depending on the
consumption time.
X1 section (A) is set as 24hours, and the factory default setting is set as 1 section.
The time, 24hours, can also be divided into 2 sections (A,B,A), 3 sections (A,B,C,A) or
4 sections (A,B,C,D,A)
XDMS2 shows the result of the power distribution for each section you set.
Input manually (When setting 2 sections, 3 sections, and 4 sections)
Time Segmentation
If communication error occurs between DMS and the lower level controllers,
actual power consumption and the result of power distribution value may not be
same. Make sure to solve communication error status.
- Example of communication error : Communication error between DMS2 and
SIM(PIM)/SIM(PIM) and watt hour meter/DMS2
and outdoor unit/indoor and outdoor units.
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGXZ YWXZTWZTX\GGG㝘䟸G[aZ_a[]

E-14
Set the current time of DMS2 system.
X“2009/01/01 01:01:01” is factory setting. Set the current time as DMS2 system time.
You can set DMS2 time in [System Settings] [System environment setting]
(R efe r to pa ge 117~118)
Starting DMS2
Current time setting
(1) Make sure that OnOff controller communication cables(R1, R2) or outdoor unit
communication cables(R1, R2) are connected.
XFor communication between DMS2 and OnOff controller/outdoor unit,
OnOff controller communication cable(R1, R2) or outdoor unit communication
cable (R1, R2) should be connected.
(2) Execute tracking.
XDMS2 communicates with outdoor unit and brings information about installed
indoor unit and outdoor unit.
XAfter tracking, you can use indoor unit control and other menu.
XFor tracking, refer to [System Settings] [Tracking] (Refer to page 140~152)
Connecting OnOff controller & outdoor unit
Starting DMS2
If DMS2 time does not set as the current time, DMS2 may cause malfunction when
using Schedule or control logic management.
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGX[ YWXZTWZTX\GGG㝘䟸G[aZ_a[^

E-15
Access to DMS2 & Login
Address bar
1
Run internet explorer on your computer.
2
Enter IP address (http://192.168.0.100) on the address bar,
and then press [ENTER].
X
If it is the first access to DMS2, “Install Microsoft Silverlight”
message will be displayed.
- The message will not appear if Microsoft Silverlight have
already installed.
If the message window and login screen does not
appear, check PC setting status.
3
Click [Run] and continue installation.
XAccess to DMS2 again after installation.
3
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGX\ YWXZTWZTX\GGG㝘䟸G[aZ_a[^

E-16
Starting DMS2 (Continued)
4
Enter ID and password when DMS2 main web page appears.
Then click [LOGIN].
XThe default DMS2 user ID is 'admin' and password is
'ac0530'.
XDepending on authorization settings which set by the
administrator, access to some functions may be restricted.
XTo edit user authorization, refer to [System Settings]
[User authorization management]. (Refer to page 100)
Note XOnly authorized users can access to web page.
XFewer than 5 concurrent users are recommended
because connection speed may slow down.
XDMS2 manager should change ID and password for
security and management. (Refer to page 98)
XLogout: To log out, click [LOGOUT] on the top of the
menu.
Silverlight will run normally with Windows XP SP2 or later
version. With former version of Windows, DMS2 may not
operate normally.
4
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGX] YWXZTWZTX\GGG㝘䟸G[aZ_a[^

E-17
Logged-in User with No Authorization
1
When the screen above appears, ask for manager.
XDepending on control authorization setting, there can be
a user who does not have control authorization.
X
Above screen will appear when the logged-in user does
not have control authorization.
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGX^ YWXZTWZTX\GGG㝘䟸G[aZ_a[^

Devices controlled and monitored by DMS2
Control and Monitoring
Type Display Remote controller
(Controlling range) Type Display Remote controller (Controlling range)
Indoor unit
display icon
MINI AHU
display icon
ERV
display icon
Fresh duct
display icon
AHU
display icon
DI
(Digital Input)
display icon
ERV PLUS
display icon
DO
(Digital Output)
display icon
When users select multiple devices, 'Basic Control' will be displayed on the screen.
(This is when different types of multiple devices are selected.)
DMS2 can control and monitor the devices in the above table.
E-18
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGX_ YWXZTWZTX\GGG㝘䟸G[aZ_a[^

Monitoring Indoor Unit Operation Status
1
1
Click [Control and Monitoring] when DMS2 web page menu screen appears.
X[Control and Monitoring] screen will appear when you log-in to DMS2 web page.
2
Check the current status of all devices.
XYou can check the current controlling status of all installed indoor units, ERV, AHU,
ERV PLUS, Fresh duct, MINI AHU and other devices.
Note XWhen the advanced functions (such as Sleep mode, Energy saving function) are
selected through wired/wireless remote controllers or indoor unit panel,
set operation mode on the remote controllers and DMS2 may be displayed
differently. Also, when controlling by DMS2, additional functions will be canceled.
XDepending on the model of indoor unit, Horizontal/All air flow direction control
may not be possible. In this case, vertical or fixed flow will be displayed depending
on indoor unit’s basic operation specification.
XAHU, ERV, ERV PLUS, Fresh duct, MINI AHU, and other devices will be displayed
only when the corresponding devices are installed.
2
Some functions available on DMS2 web page may not be functional at BACnet
Gateway and LonWorks Gateway. For detailed function, refer to the installation
manual or contact Samsung Electronics.
E-19
uhzhktzYtptTkWWhulupiWZ^ZZhOXPUGGGX` YWXZTWZTX\GGG㝘䟸G[aZ_a[^
