Intex 94PO User manual

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 1
INTEX® OWNER’S MANUAL
INFLATABLE KAYAK
IMPORTANT!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance,
Visit www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time
©2010 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd. - Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle Rechte vorbehalten.
Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O
Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European
Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union
durch/Intex Trading B.V., P.O. Box nr. 1075 – 4700 BB Roosendaal – The Netherlands
094PO-R0-1108
IMPORTANT
THIS BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
READ IT THOROUGHLY BEFORE USING THIS PRODUCT AND
KEEP IT FOR FUTURE REFERENCE.

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 2
TABLE OF CONTENTS
INTRODUCTION.............................................................................................................................3
MANUFACTURE’S CERTIFICATION..............................................................................................3
WARNING.......................................................................................................................................3
MANUFACTURER’S RECOMMENDATION....................................................................................4
DESCRIPTION................................................................................................................................5
INFLATING INSTRUCTIONS ..........................................................................................................6
HOW TO USE BOSTON VALVE.....................................................................................................6
SEAT INSTALLATION......................................................................................................................6
PADDLE ASSEMBLY.......................................................................................................................7
SAFETY AND OPERATION INSTRUCTIONS..............................................................................7-8
CARE AND MAINTENANCE...........................................................................................................8
DISASSEMBLY AND STORAGE.....................................................................................................9
TROUBLESHOOTING....................................................................................................................9
REPAIRS.........................................................................................................................................9
CONTACT OFFICE LIST...............................................................................................................10

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 3
Introduction
This manual has been compiled to help you to operate your craft with safety and pleasure. It contains
details of the craft, the equipment supplied or fitted, its systems, and information on its operation and
maintenance. Please read it carefully, and familiarize yourself with the craft before using it.
If this is your first craft, or you are changing to a type of craft you are not familiar with, for your own
comfort and safety, please ensure that you obtain handling and operating experience before
assuming command of the craft. Your dealer or national sailing federation or yacht club will be
pleased to advise you of local sea school, or competent instructors.
PLEASE KEEP THIS MANUAL IN A SECURE PLACE, AND HAND IT OVER TO THE NEW OWNER
WHEN YOU SELL THE CRAFT. RECORD THE “HULL IDENTIFICATION NUMBER” (HIN) WHICH IS
PRINTED ON THE KAYAK’S HULL IN THE FOLLOWING BOX:
HIN: ________________________
Manufacture’s Certification
Our kayaks comply with ISO 6185 standard established by the International Organization for
Standardization.
NMMA (FOR USA ONLY) certification means that the kayak, sold in the United States, has been
judged by the National Marine Manufacture’s Association to be in compliance with the U.S. Coast
Guard Regulations and American Boat and Yacht Council (ABYC) standards and recommended
practices.
WARNING
•This is not a life saving device. Use only under competent supervision. Never allow diving into
this product. Never leave in or near the water when not in use. Never tow from any vehicle.
•Read the complete Owner’s Manual before use and store this Manual in a safe place for future
reference.
•Follow all the Safety and Operating Instructions on this Manual.
•Inflatable kayaks intended for beach use, short-time and short-distance cruising.
•Never navigate alone. Beware of offshore winds and currents.
•Do not exceed the maximum recommended capacities. Overloading violates regulations.
•Everyone on board must wear a Personal Floatation Device (PFD).
•Use caution when stepping or climbing aboard the kayak. Step into the center of the kayak for
maximum stability.
•Distribute the weight of passengers, gear, tackle box, and accessories so that the kayak sits
level fore (front) to aft (back) and side-to-side.
•Do not use your kayak if you suspect a puncture or leak.
•Adults should inflate the chambers in numbered sequence.
•Not for white water rafting or any other extreme sports activities.
•Follow these rules to avoid drowning, paralysis or other serious injuries.

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 4
Manufacturer’s Recommendation
The total number of persons and total weight shall not exceed the limits printed on the kayak. Please refer to
the boat's hull label for the actual values of your boat.
CRAFT LABEL FORMAT
Europe hull identification number (HIN).
USA hull identification number (HIN).
Manufacturer’s recommended maximum load capacity.
Maximum person’s capacity.
Manufacturer’s name and country of origin.
Model name and number.
Manufacturer’s recommended working pressure.
NMMA (for USA only) certification means that the boat, sold in the United States, has been
judged by the National Marine Manufacture’s Association to be in compliance with the U.S.
Coast Guard Regulations and American Boat and Yacht Council (ABYC) standards and
recommended practices.
6
5
4
3
2
1
7
MAXIMUM CAPACITIES
MAXIMUM-KAPAZITÃT
CAPACITÉS MAXIMUM
PERSONS
PERSONEN
PERSONNES
MANUFACTURER
HERSTELLER
FABRICANT
MODEL
MODELL
MODÈLE
RECOMMENDED WORKING PRESSURE FOR EACH CHAMBER
EMPFOHLENE ARBEITENDE DRUCK FÜR JEDE LUFTKAMMER
RECOMMANDÉ FONCTIONNEL PRESSION POUR CHAQUE CHAMBRE À AIR
CN-XEE ________
LOAD CAPACITY
BASIC FLOTATION ___Kg ( ___ Lbs) MAX.
National Marine Manufacturers Association
+ = ___ Kg ( ___ Lbs)
____________________
= ___ bar ( ___ psi)
CHINA
1
3
4
5
6
7
8
MAXIMUM CAPACITIES
PERSONS OR ____kg (___Lbs)
____ ____ POUNDS, PERSONS, GEAR
= ___ = ___
DESIGN COMPLIANCE WITH NMMA REQUIREMENTS BELOW IS VERIFIED.
MFGR. RESPONSIBLE FOR PRODUCTION CONTROL
ISO 6185 PART 1 TYPE
Do not overinflate or use high pressure air
compressor to inflate.
Adults should inflate the chambers with cold air in
numbered sequence.
This boat not rated for propulsion by a motor.
Use the enclosed ruler to check while inflating.
Nicht zu stark aufblasen und keinen Kompressor
zum Aufblasen verwenden.
Erwachsene sollten die kammern in der
angegebenen Reihenfolge mit kalter luft aufblasen.
Das Boot kann nicht durch einem Motor betrieben
werden.
Verwenden Sie das belgefügte Meßgerät um die
korrekte Füllung zu überprüfen.
Ne pas surgonfler. Ne pas utiliser de compresseur
pour le gonflage.
Le gonflage doit être effectué par un adulte avec de
l'air froid en suivant les étapes suivantes.
Ce bateau n'est pas adapté pour être équipé d'un
moteur.
Utiliser la règle jointe pour ajuster le gonglage de la
chambre à air principale.
BY INTEX®
XEE ________
2
8

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 5
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
Description
Challenger Kayak Series
3
12
" " - Recommended seating arrangement of the occupants.
1 52 34 4 5
123
6
K1 K2
6
Boston valve
Grab line
Seat or seat cushion
Inflatable floor
Cargo net
Skeg
1
2
3
4
5
6
Descriptions

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 6
Inflating Instructions
Before starting, locate a clean area free of stones or other sharp objects. Unroll the kayak so it is laid
out flat, and locate your pump.
Use a hand or foot operated air pump to inflate the boat. Do not use high-pressure air compressors.
Adults should inflate the chambers following the numerical sequence marked on the valves. It is very
important to follow the numerical sequence; failure to do so will result in an improperly inflated boat.
Fill each chamber until it is stiff to the touch but NOT hard. Use the enclosed ruler to check the main
chamber for proper inflation. DO NOT OVER INFLATE. Fill with cold air only.
IMPORTANT: Air temperature and weather condition do affect the internal air pressure of inflatable
products. In cold weather the product will lose some pressure due to the fact that the air will contract.
If this occurs, you may want to add a little air to the product. However, in hot weather, the air will
expand. You must let some air out to prevent the product from failing due to overpressure.
How to Use Boston Valve:
1. Double valve cap (valve lets air in, not out).
2. Quick deflation cap.
3. Unscrew Double valve cap.
4. Insert output end of air pump into valve and fill. Do not over inflate or use high pressure
compressor.
5. To deflate: unscrew quick-deflation cap. CAUTION: Double valve does not operate when this cap
is off. Do not unscrew this cap while boat or inflatable is in water.
Seat Installation (Certain Models):
1. Inflate each seat cushion slowly to about 75% of its capacity.
2. Attach the seat cushion hinge to the hinge on the kayak. Repeat the
connection on the other side and for all seats. See Fig A.
3. Finish inflating the seat cushions slowly until it is firm to the touch but
NOT hard. DO NOT OVER INFLATE!
4. To disassemble the seats, deflate the seats first and reverse the
installation procedures.
5. Some seat cushions after inflation are tuck in directly into the fore, mid or aft locations of the
kayak cockpit.
Fig A
12
3
4
5

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 7
1. Press and align the push-bottom on the short shaft with the paddle blade hole, ensure the
push-bottom is securely snapped onto the paddle blade hole.
2. Join the 3 shafts together with the couplers and securely tighten the coupler covers.
3. To disassemble, reverse the assembly steps. Note: is not necessary to detach the paddle blades
from the shafts.
Safety and Operating Instructions
Before Departing from the Shore or Dock
Know all required information and inform your passengers:
•Take a boating safety course and get hands-on training from your boat dealer or local boating
authorities.
•Know all local regulations and hazards related to water activities and boat operation.
•Check weather forecast, local currents, tides and wind conditions.
•Advise someone on land of the time you plan to be back at your starting point.
•Explain basic boat operation to all passengers.
•Children and non-swimmers need special instructions in the use of life jacket or personal floatation
devices (PFD).
•Be sure that one of your passengers can operate the boat in case of emergency.
•Learn how to determine the distance you can cover, and remember that bad weather conditions
can alter this.
•Review all safety requirements regularly.
Check the working condition of the boat and equipments:
•Check inflation pressure.
•Inspect the valves caps.
•Check the load is evenly distributed, fore (front) to aft (back) and side-to-side.
Make sure that all required safety equipment is on board (check the laws and regulations of the
country or locality in which you are boating to see if additional equipment may be needed):
•One personal flotation device (PFD) per person.
•Air pump, oars, repair kit and tool kit.
•Any other mandatory equipment.
•The boat papers and your boating license (if applicable).
•Lights are required if operating after dark.
Paddle Assembly:
1
2

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 8
Rules to Observe During Navigation
•Be responsible, do not neglect the safety rules, this could jeopardize your life and the lives of
others.
•Always keep control of your boat.
•Respect local regulations and practices.
•Near the shore, navigate in the designated boating area.
•Remember that weather conditions can rapidly deteriorate. Always be sure that you can reach a
shelter rapidly.
•Everyone on board must always wear a personal flotation device (PFD).
•Do not drink alcohol or take drugs before or while operating your boat. Maintain passenger
sobriety.
•Do not exceed the authorized number of persons or weight.
•Make sure your passengers remain seated at all times. At planning speeds, in rough water or
during sharp turns, all passengers should position themselves in seats or on the floor.
•No bow riding. Bow riding is illegal in most areas and is extremely dangerous. In case of falling,
the man overboard is in the way of the propeller.
•Be especially careful when docking. Arms and legs may be injured if they are outside the boat.
•Keep clear of swimmers and divers. Always avoid areas where divers/swimmers are in the water.
•Keep a sharp lookout especially when operating near beaches and launch sites. The Alpha flag
indicates proximity of divers. You MUST maintain a safe distance as required by your local boating
laws, which may range from 50 meters (164 feet) to 91 meters (300 feet).
•Avoid sharp turns at high speeds. You could get ejected from the boat.
•Do not make changes in direction without advising passengers.
•Avoid all contact between the buoyancy tubes and sharp objects or aggressive liquids
(such as acid).
•Do not smoke on board.
Care and Maintenance
The kayak is made of the highest quality materials and complies with ISO 6185 standards. Altering
the construction of the kayak will endanger your own safety, safety of the occupants and void the
limited warranty!
There is very little that you have to do to keep your kayak in good condition for many years. Do not
store your kayak inflated. If you store it in a closet, basement or garage, we suggest you pick a cool,
dry place, making sure the kayak is clean and dry before you store it - or mold can accumulate.
Use as few cleaning agents as possible, do not discharge waste agents into water, and clean your
kayak preferably on land.
Clean your kayak after a trip to prevent damage from sand, salt water or sun exposure.
Most dirt can be removed with a garden hose, a sponge and mild soap. Make sure the kayak is
completely dry before storing. Store the product and accessories in a dry, temperature controlled,
between 32 degrees Fahrenheit (0 degrees Celsius) and 104 degrees Fahrenheit (40 degrees
Celsius) storage location.

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 9
Disassembly and Storage
First clean your kayak thoroughly following the Care and Maintenance instructions. Open all air valves,
deflate kayak completely and remove all the accessories from the kayak.
Flip the kayak over. Fold the left side of the kayak over and then fold the right side over the left. Fold
the bow end twice to the middle of the kayak tightly while forcing out any remaining air; repeat this
procedure for the stern. Replace all air valves’ caps. With two opposing folded sides, fold one end over
the other like closing a book.Your kayak is ready for storage. Fold the kayak loosely and avoid sharp
bends, corners and creases which can damage the kayak.
Troubleshooting
If your kayak appears a bit soft, it might not be because of a leak. If the kayak was inflated late in the
day with 32 °C (90 °F) air, that air might cool down to 25 °C (77 °F) overnight. The cooler air exerts
less pressure on the hull, so it could appear soft the next morning.
If there has been no temperature variation, you need to start looking for a leak:
•Take a good look at your kayak from just a few feet away. Flip it over and closely check over the
outside. Any large leaks should be clearly visible.
•If you have an idea where your leak is, use a mix of dishwashing liquid and water in a spray
bottle, and spray over the suspicious areas. Any leak will produce bubbles that will pinpoint the
location of the leak.
•Check valves for leak, if necessary, spray soapy water around the valve and the valve base.
Repairs
Through constant use you may occasionally puncture your kayak. Most leaks only take a few minutes
to repair. Your kayak comes with a repair kit, and additional repair supplies can be ordered from Intex
Consumer Service or from our website.
First locate the leak; soapy water will bubble out from the source of the leak. Thoroughly clean the
area surrounding the leak to remove any dirt or grime.
Cut a piece of repair material large enough to overlap the damaged area by approximately 1.5 cm
(1/2”). Round off the edges, and place over the damaged area. Using a pencil, trace the outline of the
patch lightly. Apply adhesive to the underneath side of the patch and around the area to be repaired.
Coat the affected area lightly but completely with glue.
Place the patch on the damaged area and press down firmly. You may want to use a weight on top to
keep it in place. Allow 12 hours for repair to dry. After patch has dried, apply glue around the edges for
a complete seal (dry 4 hours).

94PO
(94PO) "NMMA" KAYAK ENGLISH 7.5” X 10.3” 08/08/2010
SAVE THESE INSTRUCTIONS
Page 10
AREAS LOCATION
• UNITED STATES INTEX RECREATION CORP.
• CANADA 14779 Bar Harbor Road
Fontana, CA 92336
Tel: [phone]
Fax: [phone]
Website: www.intexcorp.com (U.S./Canada only)
Consumer Service Hours: 8:30 am to 5:00 pm
Pacific Time, Mon. thru FRI. only.
• MEXICO KAY INTERNACIONAL, S.A. DE C.V.
SAN JERONIMO # 550- INT.501 Y 502. COL.
JARDINES DEL PEDREGAL. C.P. 01900
MÉXICO D.F.
Tel: [phone] (Collect Call)
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Website: www.intexmexico.com.mx
• PANAMA SUPRO MUNDIAL S.A./
• PARAGUAY PRODUCTOS SUPERIORES S.A.
• ECUADOR Boulevard Andrews, Albrook,
• HONDURAS Panama, Rep. of Panama
• EL SALVADOR Tel: [phone]
• NICARAGUA Fax: [phone]
E-mail: [e-mail]
• COSTA RICA CENTURY USA, LLC
• DOMINICAN REPUBLIC 4731 W. Atlantic Ave., Suite B-3
• GUATEMALA Delray Beach, FL 33445, USA
• COLOMBIA Tel: [phone]
• VENEZUELA Fax: [phone]
E-mail: [email protected]
• MIDDLE EAST REGION FIRST GROUP INTERNATIONAL
Al Moosa Group Building, 1st Floor,
Office 102 & 103, UMM Hurair Road,
Karama, Dubai, UAE
TEL: [phone]INTEX(46839) / [phone]
FAX: [phone]
E-mail: [email protected].
Website: www.firstgroupinternational.com
• ASIA INTEX DEVELOPMENT CO. LTD.
9th Floor,
Dah Sing Financial Centre
108 Gloucester Road,
Wanchai, Hong Kong
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Website: www.intexdevelopment.com
For answers to most frequently asked questions, please visit
www.intexcorp.com. Non U.S. Residents, please visit www.intexdevel-
opment.com.
