Intex Quick-Fill AP643 User manual

167
PO
(167PO) AP643 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 05/12/2021
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
INTEX®OWNER'S MANUAL
Quick-Fill™ Electric Air Pump
Model AP643 110 – 120Volt ~ 60Hz 2A
PARTS DESCRIPTION:
1. PUMP
2. INFLATION CONNECTOR
3. DEFLATION CONNECTOR
4. SWITCH
5. AC LINE CORD
6. NOZZLES
7. AIR HOSE
OPERATING INSTRUCTIONS
General
• This appliance has a polarized plug (one blade is wider than the other). This plug will t in a polarized outlet only one
way. If the plug does not t fully in the outlet, reverse the plug. If it still does not t, contact a qualied electrician to
install the proper outlet. Do not change the plug in any way.
• Return pump, hose and nozzles to package when not in use.
SERVICING OF A DOUBLE-INSULATED PRODUCT:
In a double-insulated product, two systems of insulation are provided instead of grounding. No grounding means is provided
on a double-insulated product, nor should a means for grounding be added to the product. Servicing of a double-insulated
product requires extreme care and knowledge of the system, and should be done only by qualied service personnel.
Replacement parts for a double-insulated product must be identical to those parts in the product.
A double-insulated product is marked with the words “DOUBLE INSULATION” or “DOUBLE INSULATED” and with the
symbol .
NAMES OF PARTS
READ AND SAVE THESE INSTRUCTIONS
Page 1 167-*PO-R0-2205
• For Indoor Household Use Only.
• Adult use only.
• Do not drop unit into water or expose unit to rain or water.
• Do not direct air stream at face or body.
• Do not operate for more than 10 minutes at a time. Unplug and let cool at least 10 minutes.
• Unplug unit when not in use.
• Do not obstruct vent holes or open source.
• Do not insert objects into the ination or deation connector.
• If the AC supply cord is damaged, it must be replaced by the manufacturer or its service agent or similarly qualied
persons in order to avoid a hazard.
• Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord
under furniture or appliances. Arrange cord away from tra󰀩c area and where it will not be tripped over.
FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID PROPERTY DAMAGE, ELECTRIC SHOCK,
BURNS OR OTHER INJURY.
WARNING
• To reduce the risk of electric shock or injury, use indoors only, do not expose to rain. Store indoors.
CAUTION
NOTE: Drawings for illustration purpose only. May not reect actual product. Not to scale.
3
12
6
4
7
5

167
PO
OPERATING INSTRUCTIONS
INFLATION
1. Attach nozzle or air hose to the ination connector if necessary and hold pump against ination valve on item to be
inated. See Fig (1).
NOTE: On large items like inatable boats and large air mattresses, the pump will t directly into the ination valves and
provide faster ination times. Use the appropriate nozzle on small ination valves as on small air mattresses, etc.
2. Plug in the AC line cord into an AC electrical outlet. See Fig (2).
3. SWITCH ON: Press “I”; SWITCH OFF: Press “0”. See Fig (3).
DEFLATION
1. Attach nozzle or air hose to the deation connector if necessary and hold pump against ination valve on item to be
deated. See Fig (4).
NOTE: On large items like inatable boats and large air mattresses, the pump will t directly into the ination valves and
provide faster deation times. Use the appropriate nozzle on small ination valves as on small air mattresses, etc.
2. Plug in the AC line cord into an AC electrical outlet. See Fig (2).
3. SWITCH ON: Press “I”; SWITCH OFF: Press “0”. See Fig (3).
(167PO) AP643 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 05/12/2021
READ AND SAVE THESE INSTRUCTIONS
Page 2
FIG (1): ATTACH NOZZLE
OR ATTACH HOSE
MAINTENANCE INSTRUCTIONS
No specic air pump maintenance is required. Air pump has no user serviceable parts.
MOVING AND STORAGE INSTRUCTIONS
Move the product, air pump and accessories to the power source location. Make sure the power cord is free of twist, kink
and knot. Fold the power cord loosely, and return pump and nozzles to package when not in use.
FIG (4): ATTACH NOZZLE
OR ATTACH HOSE
FIG (3): SWITCH
FIG (2)
220-240V 110-120V
FIG (2)
220-240V 110-120V
FIG (3): SWITCH
