Intex Quick-Fill AP633 User manual

194
PO
(194PO) AP633 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/29/2021
SAVE THESE INSTRUCTIONS
Page 1
WARNING
• Adult use only.
• Household use only.
• Do not drop unit into water or expose unit to rain or water.
• Do not direct air stream at face or body.
• Do not operate for more than 5 minutes at a time. Unplug and let cool at least 15 minutes.
• Unplug unit when not in use.
• Do not obstruct vent holes or open source.
• Do not insert objects into the ination or deation connector.
• The DC supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.
• To reduce the risk of electric shock, do not expose to rain. Store indoors.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Suitable for inating air mats, airbeds, inatable pools and inatable toys only.
FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID PROPERTY DAMAGE, ELECTRIC SHOCK,
BURNS OR OTHER INJURY.
CAUTION
• To reduce the risk of electric shock, do not expose to rain. Store indoors.
INTEX®OWNER'S MANUAL
Quick-Fill™ Electric Air Pump
Model AP633 12V 3A
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
NAMES OF PARTS
PARTS DESCRIPTION:
1. PUMP
2. DEFLATION CONNECTOR
3. INFLATION CONNECTOR
4. SWITCH
5. AC ADAPTER
6. DC CIGARETTE CORD
7. NOZZLES
8. VENT HOLES / SLOTS
NOTE: Drawings for illustration purpose only. May not reect actual product. Not to scale.
194-*PO-R0-2205
5
3
6
4
8
7
1
2

194
PO
(194PO) AP633 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/29/2021
SAVE THESE INSTRUCTIONS
Page 2
INFLATION
1. Attach nozzle to the ination connector if necessary and hold pump against ination valve on item to be inated.
See Fig (1).
NOTE: Use the appropriate nozzle on small ination valves as on small air mattresses, etc.
2.1. Connect the end of the pump line cord to the DC cigarette cord (6) rst, then plug in the DC line cord into a car cigarette
lighter outlet. See Fig (2.1).
2.2. Connect the end of the pump line cord to the AC adapter (5) rst, then plug in the AC adapter into an AC electrical outlet.
See Fig (2.2).
3. SWITCH ON: Press “I”; SWITCH OFF: Press “0”. See Fig (3).
DEFLATION
1. Attach nozzle to the deation connector if necessary and hold pump against ination valve on item to be deated.
See Fig (4).
NOTE:
On large items like inatable boats and large air mattresses, the pump will t directly into the ination valves and
provide faster deation times. Use the appropriate nozzle on small ination valves as on small air mattresses, etc.
2.1. Connect the end of the pump line cord to the DC cigarette cord (6) rst, then plug in the DC line cord into a car cigarette
lighter outlet. See Fig (2.1).
2.2. Connect the end of the pump line cord to the AC adapter (5) rst, then plug in the AC adapter into an AC electrical outlet.
See Fig (2.2).
3. SWITCH ON: Press "I"; SWITCH OFF: Press "0". See Fig (3).
OPERATING INSTRUCTIONS
FIG (2.1)
110-120V
FIG (2.2)
FIG (2.1)
110-120V
FIG (2.2)
FIG (3): SWITCH
FIG (4): ATTACH NOZZLE
FIG (3): SWITCH
MAINTENANCE INSTRUCTIONS
No specic air pump maintenance is required. Air pump has no user serviceable parts.
MOVING AND STORAGE INSTRUCTIONS
Move the product, air pump and accessories to the power source location. Make sure the power cord is free of twist, kink and
knot. Fold the power cord loosely, and return pump and nozzles to package when not in use.
OR
FIG (1): ATTACH NOZZLE

194
PO
(194PO) AP633 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/29/2021
SAVE THESE INSTRUCTIONS
Page 3
WARNING: Changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o󰀨 and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit di󰀨erent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
CAN ICES-3 (B)/NMB-3(B)
