INVONS h-BT600 User manual

User Manual of Bluetooth HEADSET
Model No.: h-BT600
INVONS
Dongguan Haoyinliang Electronics Co.Ltd
一、Instructions
1、Insert the power adaptor into the 100-240V AC socket，Then put the
3.5mm plug on the adaptor into DC 5V socket on the transmitter，turn on the
power switch on the transmitter, at the same time the LED of Power will indicate
blue color and the transmitter is ready to work well, and the transmitter have
charging function at this time, the power indicate LED on the transmitter will turn
off when the power switch is turned off。See following Picture-1：
Picture-1
2、Use the 3.5mm audio cable connect with such as TV,PC,DVD/CD, Mobile or
MP3/MP4/MP5 etc output socket of audio source，Connect the other end of audio
cable to the socket hole of audio in on the transmitter。Power switch turn on，at
the same time Led of audio indicate will glitter red and blue alternate，the
transmitter is searching other Bluetooth device to connecting。Press the power key
2.3
WL
孔
DC 5V Socket
Power Indicate LED
Transmitter

of receiver around 5 seconds to turn on the Bluetooth function of headphone
receiver, at this same time Led of audio indicate will glitter red and blue alternate
on the headphone receiver，the audio LED light of transmitter will glitter one time
around 10 seconds when the receiver and transmitter connect successful，and
headphone receiver will glitter one time around on 5 seconds。See following
Picture-2、3 ：
Piture-2 Picture-3
3、You can do what you want when connected well，to adjust the
transmitter heavy bass potentiometer and single、the double channel switch
to choose the sound quality that you like。The receiver also can adjust the
volume key to adjust the sound ，some people have different sensitivity to
the ear ，you may need to adjust the left and right channel size
potentiometer for listening。The receiver supports cell phone connection
can take as a normal Bluetooth headphone used，after connecting the
phone press the power button to pause, play and switch，double-click the
3.5mm audio socket
Power on/off
Audio Indicate LED
Audio Indicate LED
Power on/off

power button to dial the last calling number。See following picture-5、6：
Picture-5 Picture-6
4、When the receiver’s built-in Li-ion battery is low and
Below 3.2V the receiver begins alarm and blinking red lamp，
it is turned off directly under 3V，then need to charge the
receiver and put the receiver into the charging slot of the
transmitter ，the receiver automatically shut down when the
receiver is charging，the power indicate LED will turn red
when charged, and the power indicate LED will turn blue when
the receiver charge is full （the first charge is 4-6 hours）。
See Picture-7、8 ：
Microphone
Mono/Stereo switch
Heavy bass switch
Volume control
Balance left and
right control
Power button

Picture-7 Picture-8
二、Matters need attention：
1．Audio indicate LED will turned off without 3.5mm audio cable input When the 5V
power adaptor connect with the transmitter，Bluetooth function will turn on when insert
the 3.5mm audio cable into the transmitter and at the same time the audio indicate LED
will glitter blue and red alternate，Bluetooth function turned off when removed the
3.5mm audio cable from the transmitter。
2．Avoid exposure to heat and humidity。
3．Headphone no uses for a long time，the receiver should be charged one time 3 to
6 months，this protect the battery life。
4、To play the role of headphone and better appreciate music, please select the
appropriate volume。
5、Don’t turn the volume of the player or headphone to the maximum
Chargeable pin
Power indicate
Diagram while charging

level lest you damage your hearing。
6、Using the headphone may impair your ability to listen the
Outside world，Please don’t use this product as much as possible without
affecting your personal safety 。
Accessories:
Power adaptor 5V 500mA
3.5mm audio cable
3.5 mm adaptor cable
