inVue NETPRO CG24P User manual

High Security 300
Mechanical Handheld Security Installation
MP601
All manuals and user guides at all-guides.com

2 3
Read entire instruction guide before starting installation.
System Components
1. HS300 Power-Up Recoiler (MP601)
2. Handheld Sensor (MP607)
3. Puck (MP217, MP218)
4. 5V Power Supply
System Components
High Security 300 is designed for the toughest security
for smartphones in the most high risk environment. This
system provides mechanical security and power-up ability.
5
10
20
30
Drill Multi Tool
AF6313
5V Power Supply
PS5VUS
PS5VEU
PS5VAUS
PS5VUK
PS5VARG
HS300 Mechanical Recoiler
MP601
Puck
MP217
MP218
Handheld Sensor
MP607
T-20 Bit
(included with
Multi Tool)
T-27 Bit
(included with
Multi Tool)
H.S. Bit
AF6315
All manuals and user guides at all-guides.com

4 5
Drill a 45 mm (1.75”) diameter hole in display
counter.
1
RECOILER & PUCK INSTALLATION
5
10
20
30
Puck
Spacer
(For display counters
between 3.175 mm, 0.125”
and 12.7 mm, 0.5” thick.)
Recoiler
All manuals and user guides at all-guides.com

6 7
Slide recoiler up through hole in display counter. Use
spacer if needed. Loosely hand tighten cap above
counter onto recoiler.
2a2b
Recoiler
Spacer
(For display counters
between 3.175 mm, 0.125”
and 12.7 mm, 0.5” thick.)
Cap
Rotate recoiler until cut out in recoiler is towards back
of display counter. Fully tighten cap.
Back of
display
counter
Cut out in
recoiler
Recoiler
Front of
display
counter
All manuals and user guides at all-guides.com

8 9
3aFully tighten screws on puck with T-20 bit. 3b
Pull recoiler up and slide both parts of puck together
on cap. Confirm lock is at back of display counter.
Back of
display
counter
Front of
display
counter
All manuals and user guides at all-guides.com

10 11
Plug power supply into recoiler cable and outlet.
4ATTACHING MERCHANDISE
Spacer
(For phones thinner than
11.75 mm, 0.46”)
Sensor
Arms
Power
Connector
All manuals and user guides at all-guides.com

12 13
1 2
Wipe back of phone with alcohol wipe provided. Let it
dry completely. Plug power connector into phone.
CONTENTS: One pad saturated in
Isopropyl Alcohol
75%
DIRECTIONS: Apply topically as
needed to cleanse surface mounting area.
FOR EXTERNAL USE ONLY
KEEP OUT OF REACH OF
CHILDREN
KEEP AWAY FROM EYES
AND FIRE
Route power connector cable through if phone charg-
ing port is at the bottom or side of the phone.
All manuals and user guides at all-guides.com

14 15
3 4aIf phone is thinner than 11.75 mm (0.46”): Use
spacer. Remove film from spacer and place around rim
of sensor. Remove film from spacer. Center phone on
sensor and press firmly for at least 10 seconds.
Spacer
Confirm phone is placed on sensor correctly so orien-
tation of phone is correct on recoiler. Make sure cut out
in sensor is towards top of phone.
Top of Phone
Cut out in
sensor
All manuals and user guides at all-guides.com

16 17
4b5
If phone is thicker than 11.75 mm (0.46”): DO NOT
use spacer. Remove clear film off adhesives. Center
phone on sensor. Press firmly for at least 10 seconds.
Choose correct arms for phone.
MP054 – Large Arms
(For phones with wider
power port)
MP053 – Standard Arms
All manuals and user guides at all-guides.com

18 19
6 7
Slide all 4 arms into slots on sensor. Place arms
opposite of each other. Squeeze all arms and tighten
screw with T-20 bit to lock arms in sensor.
Pull recoiler out of puck and attach sensor to recoiler.
Recoiler
All manuals and user guides at all-guides.com

20 21
8 9
Fully tighten both screws with H.S. Bit (AF6315). Optional: Lock screw with T-27 bit to prevent from
lifting recoiler.
All manuals and user guides at all-guides.com

All manuals and user guides at all-guides.com

© 2013 InVue Security Products Inc. All rights reserved.
InVue is a registered trademark of InVue Security Products.
SD0148 Rev0 03/06/13
www.invuesecurity.com
