IO-Power Technology IOP-DAPI-12243A-2 User manual

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 1 / 12 Retention Period：6Y
IO-Power IOP-DAPI-12243A-2
Outdoor 12VDC to 24VAC Power Inverter
(Special Design for Speed Dome 24VAC Power Solution)
IOP-DAPI-12243A-2
User Manual
IOP-DAPI-12243A-2
EV20_01

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 2 / 12 Retention Period：6Y
Direcotory
Trademark and Copyright Notice.............................................................................................................................3
About this Manual......................................................................................................................................................4
Product Warranty.......................................................................................................................................................4
Housing Warranty..................................................................................................................................................4
DC to AC Control Board Warranty.......................................................................................................................4
Attention of the Product Use ....................................................................................................................................5
Attention of the Product storage ..........................................................................................................................5
Attention of the product use ..........................................................................................................................5
Product Specification.................................................................................................................................................7
Product Installation Instructions...............................................................................................................................9
Input DC 12V power ..............................................................................................................................................9
DC Jack Female insert hole (DC Plug insert) ..................................................................................................10
Waterproof and heat-resistant beam head (waterproof rubber harvest broken hold stuffing)...................10
Insert the DC Jack Male head-end and into a waterproof rubber at the PCBA Female hole....................10
Lock waterproof and heat-resistant beam head (please do the waterproof protection).............................10
Mounting instructions ..............................................................................................................................................11
Firstly, put the waterproof rubber gaskets on the screws...............................................................................11
Then set the screw, through another set of waterproof rubber gaskets, on the stainless steel bracket ..11

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 3 / 12 Retention Period：6Y
Finally, screw the bracket tight into the screw holes in the bottom side of the housing .............................11
Pole fixation..........................................................................................................................................................11
Wall fixation ..........................................................................................................................................................11
Product operation instructions ...............................................................................................................................12
12VDC input power instruction ..........................................................................................................................12
24VAC output power instruction ........................................................................................................................12
Trademark and Copyright Notice
IOP-DAPI-12243A-2 is specially designed for 12VDC to 24VAC. For example, Speed Dome
powered by 24VAC is especially suitable.
Adopting power by Outdoor DC UPS 12VDC, transforming from 12VDC to 24VAC to establish
Outdoor DC to AC UPS power system.
All parts of the product, including software and accessories, their copyrights are owned by
IO-Power technology limited, without IO-Power technology license, transcript may not be any
imitation, copying or translation.
Product specifications and information referred to in this manual are for reference only,
specification changes, without prior notice, please consult with agent or dealer before purchase
latest product specification data.
Copyright reserved

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 4 / 12 Retention Period：6Y
About this Manual
This manual discusses IO-Power 12VDC to 24VAC Power Inverter which can be used in
outdoor environment. Powered by on-line Outdoor DC UPS, IOP-DAPI-12243A-2 Power Inverter
powers up 24VAC devices. Integrate the Inverter and DC UPS into DC to AC UPS power system.
This manual uses the following criteria to communicate instructions and information:
Readers ‘attention’. These attentions to include the special conditions referred to
in this manual or use the recommendation and note references.
Reader ‘beware’. In this case, readers can result in equipment damage or risks.
Hazard. Means that there is a potential risk of this can result in physical damage.
Before using any equipment, please pay attention to the risks associated with the
circuit, as well as familiar with standard practices required to prevent accidents
from happening.
Bold: has an important function and set of steps require your attention.
Product Warranty
Housing Warranty
IO-Power IOP-DAPI-12243A-2 is a specially designed outdoor DC to AC Inverter, adopting
industrial metal shell and professional antirust powered coating. It is suitable for outdoor
environment.
Users operate this product under the construction of this manual, and under normal use.
IO-Power provides 1 year warranty for the housing.
DC to AC Control Board Warranty
IOP-DAPI-12243A-2 is designed to input 12VDC and to output 24VAC, providing 60W output
power (max) @ 24VAC, 2.5A (Peek output power support 100W Max) to power up 24VAC devices.
The Control Board can normally work at -30°C~70°C.
The range of input voltage for Control Board is 12VDC (10VDC~15VDC Max).The limitation for

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 5 / 12 Retention Period：6Y
input current is 12VDC 6A~ while output current is 2.5A(Max), output voltage 24VAC.The output
24VAC-60W(Max) (Peek output power support 100W Max)。
Users operate this product under the construction of this manual, and under normal use.
IO-Power provides 1 year warranty for the Control Board.
Attention of the Product Use
Attention of the Product storage
High and low temperature storage
IOP-DAPI-12243A-2 must be stored at -40°C ~ 80°C to keep the safety and normal operation.
Attention of the product use
This product is DC to AC Power Inverter; users should pay attention to the following:
1. In accordance with the product specification data for the use of this product, please do not
remove or change this equipment without authorization of any of the main parts, so as to avoid
the safe use of the extension of the problem.
2. This product do not exceed 80°C heat and closer to the source of fire or less than -40°C to
direct low-temperature cooling, resulting in damage of electronic components and batteries.
3. When the product casing when the temperature exceeds 70°C, do not carry out charging and
discharging operations to avoid danger.
4. Do not place this product in high humidity and put into water or close to the highly volatile
chemical solvents to avoid danger.
5. Installation and assembly connectors in accordance with product instructions, not adjacent to
the wrong wire connection to avoid the danger.
6. Do not hammer or other items to the hammer strike, trample on the battery and cause strong
impact or throws, drops, heavy blow to this product to avoid danger.

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 6 / 12 Retention Period：6Y
7. When erecting system IOP-DAPI-12243A-2 series, if the distribution box or patch box space
license case, recommend this product fixed inside the box, it will help to reduce this product at
the risk of excessive high temperature operating temperature.
8. When erecting system IOP-DAPI-12243A-2 series, under erection conditions permit,
recommends that this product is fixed to the Lee side, or not to be in the rain, it will help to
reduce this product is too high or low humidity and rain water environments such as operational
risks.
9. When erecting system IOP-DAPI-12243A-2 series, under erection conditions permit,
recommend this product fixed on the back of sunshine, or not to be light, it will help to reduce
this product is caused by excessive heat and sunshine of sunshine product ageing body and
wiring to speed up operation of the environmental risks.
10. When system erecting IOP-DAPI-12243A-2series, even this products has IP66~IP67 of
waterproof dust of grade, but for seeking products and system of indoor outside electricity
security, recommendations all connector are then for professional of waterproof department in;
if used general electrical tape for waterproof Department in, please be sure to for 2 times
different direction of package covered waterproof Department in, has reached actual waterproof
dust of benefit.
11. IOP-DAPI-12243A-2 is designed to adopt by Outdoor 12VDC UPS power system. Therefore,
please make sure that both input and output voltage and current are in its range to avoid
dangers

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 7 / 12 Retention Period：6Y
Product Specification
IOP-DAPI-12243A-2 Specification
Model Number
IOP-DAPI-12243A-2
Outdoor 12VDC to 24VAC
Iron Airtight Housing
IP 67
Input DC Voltage
12VDC (10VDC~15VDC Max)
**Before using, please confirm that the upper cover is marked with input
12Vdc / 6A~ or 24VDC / 3A~ voltage mode, please follow the instructions
input voltage power supply.
Input DC Current
12VDC 6A~ (Recommended for 8A above will be better)
Output AC Voltage
24VAC (22VAC~28VAC Max)
Output AC Current
2.5A and peak power supply 4A Max
Output Power Frequency
47-63 Hz
Output Power Watts
Operating power 60W and peak power supply 100W Max
Input Connector
DC Female Jack, 1mm spring leaf in Φ6.5mm, OD: 5.5mm / Pin ID:
2.0mm, insertion depth: 7.8mm
The chassis can be inserted into the joint depth: 30mm
Output Connector
DC Female Jack, 1mm spring leaf in Φ6.5mm, OD: 5.5mm / Pin ID:
2.0mm, insertion depth: 7.8mm
The chassis can be inserted into the joint depth: 30mm
DC Plug to DC Plug
DC Plug to DC Plug Connector Cable : OD: 5.5mm / ID 2.1mm, Barrel
Length: 29.2mm

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 8 / 12 Retention Period：6Y
Connector Cable
(Newly added product
accessories)
Cable Length: 19cm, OD 5.0mm, 18AWG
Transform Efficiency
80% ~ +-5%
Protection
Input power overcurrent protection
Low input voltage protection
High input voltage protection
Output power overcurrent protection
Short circuit protection
Imported power polarity protection for anti-welding
Power surge 5KVA protection
Industrial Housing &
Connector
Iron Airtight Housing
IP 67 Gland Connector
** Top cover marked 12VDC / 6A ~ and 24VDC / 3A ~ of the shipping
product input voltage mark distinction
Operating Temperature
-30°C ~ +70°C (Use at -30°C environment, please be sure to inform in
advance, related accessories and wires should be replaced;
Recommends that the equipment will be installed in the power distribution
box)
Storage Temperature
-40°C ~ +80°C
Rel. Humidity
10~95%RH
Dimension
210mm(L) x 92mm(W) x 50mm(H)
Weight
0.5Kg (body); 0.7Kg (packing with fixing sheet)
Housing
IP67
Certification
CE : EMC Directive 2014/30/EU for CE Marking / EN55032:2015 Class B
FCC: FCC Part 15 Subpart B Class B / CISPR 22 : 2008 Class B / ANSI
C63.4 : 2014
Installation
1.Street lamp pole mount or Upright pole mount
2.Wall mount installation
Warranty
12 months
Remark 1: Product specifications change, without notice, consultation with agent or dealer before buying the
latest specifications
Remark 2: Before using, please confirm that the upper cover is marked with input 12Vdc / 6A ~ or 24Vdc / 3A
~ voltage mode, please follow the instructions input voltage power supply.

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 9 / 12 Retention Period：6Y
Product Installation Instructions
Input DC 12V power
DC 12V / 6A~
DC Plug
24VAC –60W
2.5A Max

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 10 / 12 Retention Period：6Y
DC Jack Female insert hole (DC Plug insert)
Waterproof and heat-resistant beam head (waterproof rubber
harvest broken hold stuffing)
Insert the DC Jack Male head-end and into a waterproof rubber at
the PCBA Female hole.
Lock waterproof and heat-resistant beam head (please do the
waterproof protection)

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 11 / 12 Retention Period：6Y
Mounting instructions
Firstly, put the waterproof rubber gaskets on the screws
Then set the screw, through another set of waterproof rubber gaskets, on
the stainless steel bracket
Finally, screw the bracket tight into the screw holes in the bottom side of
the housing
Pole fixation
Suggest using stainless steel cable belt to pass through the stainless steel fixing brackets on either
side of the hole, and then fix the belt tightly to poles or garden lamp posts or street light lay … etc.
Wall fixation
Drill two holes on the wall, and put plastic plugs into the holes. And then screw the self-tapping
stainless screws in. Finally, go through the stainless steel fixing brackets on either side of the holes,
pressing down and keep the product fixed.

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
勁電科技有限公司 台灣30055新竹市北區金竹路100號1樓Tel:[phone] Fax:+ 886-3-5357297
http://www.io-power.com.tw http://www.io-power.com.cn e-mail: io-[email protected]
Form No.：IOP-DOC-011-001 12 / 12 Retention Period：6Y
Product operation instructions
12VDC input power instruction
Powered by on-line Outdoor DC UPS, IOP-DAPI-12243A-2 Power Inverter powers up 24VAC
devices. It transforms from input 12VDC to output 24VAC.
24VAC output power instruction
By transforming from 12VDC to 24VAC, IOP-DAPI-12243A-2 provides 24VAC 2.5A 60W for
24VAC devices, such as Speed Dome.
