IOGear GCS1644 User manual

4-Port DualView Dual-Link
DVI KVMP Switch
IOGEAR’s GCS1644 4-Port DualView Dual-Link DVI KVMP Switch marks a leap in KVM
functionality by combining IOGEAR’s Display Technology with the widescreen graphics resolution
of today’s 30+ inch monitors, supporting DualView / Dual-Link DVI, 2560 x 1600 (higher than
1080p HD). Four DualView / Dual-Link display computers can be accessed and controlled from
a single console running dual-displays!
This unique KVMP can increase efciency and save equipment cost for applications where high
resolution, dual-display large or wide screen monitors are required:
• CAD (Computer Aided Design) and CAM (Computer Aided Manufacturing)
• Desktop Publishing / Graphic Design / Video Editing
• Medical / Surgical / Diagnostic Displays
• And High-End Gaming, where high and ultra-high video resolution is demanded.
The GCS1644 also features two USB 2.0 peripheral ports for asynchronously sharing USB
devices between your computers. A powered USB hub may be attached to the peripheral
ports for added functionality. Audio and microphone support makes sharing speakers and a
microphone a convenience for the users which serves as an extra value.
The IOGEAR’s Display Technology remembers your monitor’s ideal resolution and refresh rate
(EDID), making it possible to boot all your computers simultaneously, switch back and forth
between computers, and still maintain the ideal video settings of the monitor.
The GCS1644 offers an out-of-box solution including all cabling required for “Set-up and Go”!
Share Two DVI Monitors with a Single Keyboard, Mouse and Four Computers!
GCS1644
www.iogear.com
Share 2 Dual-Link DVI monitors, keyboard, mouse and speakers•
between 4 USB computers with dual monitor support
Maximum video resolution: DVI-D Dual-Link: 2560 x 1600•
Supports Special monitors with 3840 x 2400•
2 USB 2.0 ports for peripherals sharing•
Audio enabled - full bass response provides 2.1 stereo sound •
Multi-platform OS support - Windows®, Mac, Sun Solaris™ , Linux®•
IOGEAR’s Display Emulation Technology reads and remembers the•
monitor’s parameters (EDID) so there is no delay or change of video
resolution when switching between, or booting computers
Asynchronous hotkey switching between KVM focus, USB peripheral,•
and Audio ports
Complete keyboard and mouse emulation for error free booting and•
real-time switching
Computer switching via front panel push buttons or hotkeys •
Supports MAC and Sun keyboard and special keys•
Firmware upgradeable•
Plug & Play - no software installation required•
Buzzer ON/OFF via hotkey •
HDCP Compliant•

Requirements:
Console
2 Displays with DVI ports•
A USB Keyboard and Mouse•
Optional
Audio jacks for speakers and mic•
Package Contents:
1 x 4-Port Dual View Dual Link DVI KVMP Switch
4 x Dual Link DVI KVM Cables
4 x Dual Link DVI cables
1 x USB to PS/2 Converter
1 x Firmware Upgrade Cable
1 x Power Adapter
1 x Quick Start Guide
1 x Warranty Card
How does it work?How does it work?
WIN
Compatible
Linux
Compatible
Sun
Compatible WARRANTY
3
VISTA
Compatible
32/64
4-Port DualView Dual-Link DVI KVMP Switch
Share Two DVI Monitor with a Single Keyboard, Mouse, and Four Computers!
23 Hubble, Irvine
CA 92618
P. 949.453.8782
F. 949-453-8785
[e-mail]
www.iogear.com
© 2008 IOGEAR®
IOGEAR, the IOGEAR logo, are trademarks or registered trademarks of IOGEAR, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered
trademarks of their respective holders. IOGEAR makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change
without notice. IOGEAR, Inc. assumes no responsibility for any inaccuracies or errors that may appear in this document.
GCS1644
SPECIFICATIONS
Function GCS1644
Computer Connections
Direct 4
Port Selection Hotkeys or Pushbutton
Console Connectors
Monitor 2 x Dual Link DVI-I Female
Keyboard 1 x USB Type A Female
Mouse 1 x USB Type A Female
Audio 1 x Mini Stereo Jack Female (Green)
Microphone 1 x Mini Stereo Jack Female (Pink)
CPU Connectors
Monitor 8 x Dual Link DVI-I Female
Keyboard & Mouse 4 x USB Type B Female
Audio 1 x Mini Stereo Jack Female (Green)
Microphone 1 x Mini Stereo Jack Female (Pink)
Switches
F/W Upgrade 1 x 4-conductor 3.5mm Jack
Port Selection 5 x Pushbutton
Power Connections 1 x DC Jack
Connectors
USB 2 x USB Type A Female
LEDs
Mode 3 (Orange)
KVM 4 (Green)
Audio 4 (Green)
USB Peripherals 4 (Green)
Emulation
Keyboard USB
Mouse USB
Power
Voltage DC 5.3V
Video Resolution Single Link DVI: 1920x1200; Dual Link DVI: 2650x1600
Scan Interval 1~99 seconds (5 seconds by default)
Amps 2.4A
Environment
Operating Temperature 0~50˚C
Storage Temperature -20~60˚C
Humidity 0~80% RH, Non-condensing
Housing
Case metal
Dimensions (Unit)
W x H x D 17.0” (43.24 cm) x 1.7” (4.4 cm) x 6.1” (15.41 cm)
