Confidential ION Audio Service Manual
ION Audio
Party Bot Micro
[iRB02]
Service Manual
v1.0
2015.09.17
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by ION Audio. If you are not the authorized, intended
recipient, you are hereby notified that any review, dissemination, distribution or duplication of
this document is strictly prohibited. If you are not authorized, please contact ION Audio and
destroy all copies of this document. You may contact ION Audio at suppo[email protected].
© Copyright ION Audio
ATTENTION!
This document contains sensitive proprietary
information.
All recipients must have a current non-disclosure
agreement on file with ION Audio.
Do not make illegal copies of this document.

Confidential ION Audio Service Manual
Preface
This document is intended to assist the service technician in the operation, maintenance and
repair of the ION Audio device. Together with the User Reference Manual, this document
provides a complete description of the functionality and serviceability of the Device. Any
comments or suggestions you may have pertaining to the document are welcome and
encouraged.
Read This!
In addition to any purchase price that ION Audio may charge as consideration for ION Audio
selling or otherwise transferring this service manual (“Manual”) to you, if you are not a service
and repair facility (“Service Center”) authorized by ION Audio in writing to be an authorized
Service Center, ION Audio sells or transfers the Manual to you on the following terms and
conditions:
Only Service Centers authorized by ION Audio in writing are authorized to perform service and
repairs covered by an ION Audio warranty (if any), and transfer of the Manual to you does not
authorize you to be an authorized Service Center. Therefore, if you perform, or if the Manual
is used to perform, any service or repairs on any ION Audio product or part thereof, any
and all warranties of ION Audio as to that product and any service contract with ION Audio
for that product shall be voided and shall no longer apply for such product, even if your
services or repairs were done in accordance with the Manual.
All service or repairs done by you or with reference to the Manual shall be solely your
responsibility, and ION Audio shall have no liability for any such repairs or service work. All such
service or repairs are performed at the sole risk of the person performing the service or
repairs. You agree that all such work will be performed in a competent, professional and safe
manner at all times and to indemnify and fully hold ION Audio and its successors and assigns
harmless in the event of any failure to so perform.
Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of
resale or other transfer.
As the owner of the copyright to the Manual, ION Audio does not give you the right to copy the
Manual, and you agree not to copy the Manual without the written authorization of ION Audio.
ION Audio has no obligation to provide to you any correction of, or supplement to, the Manual,
or any new or superseding version thereof.
ION Audio shall have the right to refuse to sell or otherwise transfer repair parts or materials to
you in its sole discretion. You shall not use, sell or otherwise transfer spare or replacement parts
supplied by ION Audio to you (i) to repair or be used in products manufactured for or by third
parties or (ii) to any third parties for any purpose.
You shall not make any warranties or guarantees with respect to the products of ION Audio or
the use thereof on behalf of ION Audio or in your own name.
The foregoing describes the entire understanding related to sale or transfer of the Manual to you,
and no other terms shall apply unless in a writing signed by an authorized representative of ION
Audio.
All Trademarks are property of their respective companies.

Confidential ION Audio Service Manual
Warnings
TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE
THIS PRODUCT TO WATER OR MOISTURE.
The arrowhead symbol on a lightning flash inside a triangle is
intended to alert the user to the presence of uninsulated
“dangerous voltage” within the enclosed product which may be of
sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point inside a triangle is intended to alert the user
to the presence of important operating, maintenance and servicing
instructions in the literature which accompanies the product.
REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED ION
AUDIO SERVICE CENTER WILL VOID THE ION AUDIO WARRANTY.
PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO
COMPETE WITH ANY ION AUDIO DISTRIBUTOR OR AUTHORIZED REPAIR
SERVICE CENTER IN THE PROVISION OF REPAIR SERVICES OR TO BE OR
MAKE REPAIRS AS AN AUTHORIZED SERVICE CENTER.
ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED ION
AUDIO SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF
THAT ENTITY, AND ION AUDIO SHALL HAVE NO LIABILITY TO THAT
ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
Regarding the Power Supply Fuse
Caution: The product under service may employ the use of a
replaceable fuse. Danger of fire or electrocution if fuse is incorrectly
replaced. Replace with only the same type or equivalent type
recommended by the equipment manufacturer.
Regarding the Internal Battery
Caution: The product under service may employ the use of a
internal battery. Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instruction.

Confidential ION Audio Service Manual
Safety Instructions
Carefully read the applicable items of the operating instructions and these safety suggestions
before using this product. Use extra care to follow the warnings written on the product itself and
in the operating instructions. Keep the operating instructions and safety suggestions for
reference in the future.
1. Power Source. The product should only be connected to a power supply which is
described either in the operating instructions or in markings on the product.
2. Power Cord Protection. AC power supply cords should be placed such that no one is likely
to step on the cords and such that nothing will be placed on or against them.
3. Periods of Non-use. If the product is not used for any significant period of time, the
product’s AC power supply cord should be unplugged from the AC outlet.
4. Foreign Objects and Liquids. Take care not to allow liquids to spill or objects to fall into
any openings of the product.
5. Water or Moisture. The product should not be used near any water or in moisture.
6. Heat. Do not place the product near heat sources such as stoves, heat registers, radiators
or other heat producing equipment.
7. Ventilation. When installing the product, make sure that the product has adequate
ventilation. Improperly ventilating the product may cause overheating, which may damage
the product.
8. Mounting. The product should only be used with a rack which the manufacturer
recommends. The combination of the product and rack should be moved carefully. Quick
movements, excessive force or uneven surfaces may overturn the combination which may
damage the product and rack combination.
9. Cleaning. The product should only be cleaned as the manufacturer recommends.
10. Service. The user should only attempt the limited service or upkeep specifically described in
the operating instructions for the user. For any other service required, the product should be
taken to an authorized service center as described in the operating instructions.
11. Damage to the Product. Qualified service personnel should service the unit in certain
situations including without limitation when:
a. Liquid has spilled or objects have fallen into the product,
b. The product is exposed to water or excessive moisture,
c. The AC power supply plug or cord is damaged,
d. The product shows an inappropriate change in performance or does not operate
normally, or
e. The enclosure of the product has been damaged.

Part name Description Quantity Price/US
2
＂
full range
5W,4ohm 11.0733
Radiator FA51F34FXB000 10.1150
li battery
3.7V/1000mAH,28#,UL1571,L=50mm
11.6867
enamelled wire red,L=180MM,5MM, 10.0140
enamelled wire green,L=180MM 10.0140
FFC connecting
FFC-5P,P=0.5mm,L=150mm,4mm 10.0788
LED BRL-10C05A06,highlight,0.5W,red,SMD 10.1750
LED BGL-10C05A06,highlight,0.5W,green,SMD 10.1575
LED BBL-10C05A06,highlight,0.5W,blue,SMD 10.1575
PCB LED PCB ,FR4,R=23.5mm 10.1740
FPC connector FPC connector 5P,0.5MM 10.0718
NPNaudion MPS8050S-D,STO-23,KEC 30.0515
capacitor 104,VDC50,±10%,X7R,0603 30.0050
capacitor 105,VDC50,±10%,X7R,0603 30.0189
SMD resistor 1/10W,1KΩ,±5%,0603 30.0012
SMD resistor 1/4W,15Ω,±1%,1206 10.0018
SMD resistor 1/4W,8.2Ω,±1%,1206 20.0037
LED DIP,Φ3*5 Φ3 10.0490
LED DIP,Φ3*5,L-03R2B141W36-01,red light 10.0228
tact switch AN-S442,PTS06204B-7.5H-250-BB-S 50.1838
slide switch AN-S256,SK-13D01G4,1P3T 10.0508
FR4 dual board BT PCB ,FR4,R=28.7mm 10.2595
IC STM8S003F3P6,TSSOP20,ST 10.2765
IC MCP6001T-I/OT,SOT23-5,Microchip 10.1125
IC NJM062V,SOP8,JRC, 20.3150
IC TP4054,SOT23-5,TP 10.0875
IC HT6879,MSOP10,HEROIC 10.1575
IC TLV70433DBVR,SOP-5,TR 10.0683
3.5 port AN-J0432,PJK0326-0-B-S-AG,SMT 10.1225
USB socket AN-J4309,USB0402A-B-LB-S,micro usb 10.0595
FPC connector FPC 5P,0.5MM 10.0753
NPN audion KTC9014S-C,SOT23,KEC 20.0186
PFET Si2301BDS,SOT-23,TDD 20.0525
SMD resistor 1/4W,0.68Ω,±1%,1210 10.0096
SMD resistor 1/16W,1.3KΩ,±1%,0402 10.0005
SMD resistor 1/16W,120Ω,±1%,0402 10.0005
SMD resistor 1/16W,10KΩ,±1%,0402 18 0.0085
SMD resistor 1/16W2.2KΩ,±1%,0402 10.0005
SMD resistor 1/16W75KΩ,±1%,0402 10.0005
SMD resistor 1/16W4.99KΩ,±1%,0402 10.0005
SMD resistor 1/16W15KΩ,±1%,0402 10.0005
SMD resistor 1/16W,10Ω,±1%,0402 40.0019
SMD resistor 1/16W,47KΩ,±1%,0402 50.0024
SMD resistor 1/16W,100KΩ,±1%,0402 50.0024
SMD resistor 1/16W18KΩ,±1%,0402 10.0005
SMD resistor 1/16W,1KΩ,±1%,0402 20.0009
SMD resistor 1/16W,4.7KΩ,±1%,0402 10.0005
SMD resistor 1/16W,6.8KΩ,±1%,0402 10.0005
SMD resistor 1/16W,6.2KΩ,±1%,0402 20.0009
SMD resistor 1/16W,0Ω,±1%,0402 20.0009

SMD resistor 1/16W,43.2KΩ,±1%,0402 10.0005
SMD resistor 1/16W,82KΩ,±1%,0402 10.0005
SMD resistor 1/16W20KΩ,±1%,0402 20.0009
SMD resistor 1/16W22KΩ,±1%,0402 20.0009
SMD resistor 1/16W,100Ω,±1%,0402 20.0009
SMD resistor 1/16W2.2KΩ,±1%,0402 10.0005
capacitor 10UF,VDC50,±20%,Y5V,0805 10.0082
capacitor 105,VDC10,±10%,X7R,0402 40.0154
capacitor 10UF,VDC6.3,±20%,X7R,0603 11 0.2406
capacitor
2u2,X5R,±
60.0273
capacitor 82PF,VDC50,±5%,NPO,0402 10.0010
capacitor 104,X7R,± 12 0.0130
capacitor
220PF,NP0,±
40.0102
capacitor 330PF,VDC50,±5%,NPO,0402 20.0053
capacitor
222,5%,50V,0402,Murata,GRM1555C1H22
10.0032
capacitor 33PF,VDC50,±5%,NPO,0402 10.0010
capacitor 560PF,VDC50,±5%,NPO,0402 10.0035
capacitor 100PF,VDC50,±5%,NPO,0402 10.0010
capacitor 334,X7R,± 10.0035
capacitor 47PF,VDC50,±5%,NPO,0402 50.0051
V-CHIP capacitor
100uF/16V,±20%,-40/+105
℃
,Φ6.3*5.4
40.1365
connector IPEX,IPEX-001,SMD 10.0788
SMD beads 2K,100MHZ,0.5A,±25%,0603 10.0140
SMD beads
1.5K@100MHZ,0.25A,±25%,CB2012-
20.0280
antenna rubber antenna,2.4G,2DBi,ROHS 10.3063
common mode
双绕common mode inductor,710*6*5-3mH 10.1575
semi-finished
BTMA V3.0 ASSY 12.5375
USB cable 5P,28#,UL2725,250mm,USB-A,micro usb 10.1925
3.5 plug attached
AN-W1540,UL2547,26#,610mm,3.5,black 10.2083
DC motor SFE-130S-14180-38 10.6125
ceramic capacitor
104,VDC50,±10%,SL,
立式圆盆型
,
棕10.0228
flex cable 2P 26#,UL1007,150mm,3mm 10.0193
flex cable 2P 26#,UL1007,70mm,3mm 10.0140
flex cable 1P 26#,UL1007,50mm,3mm 10.0088
copper paper 100*100*0.3MM 10.0875
dome ISP31-B,PC,ROHS,V1.0 10.2787
gasket ISP31B,(1),ABS 10.0642
support DN-PB0041,ABS 10.0843
button(front
）ABS,white 10.0733
button
（
back
）
ABS,white 10.0733
LED support ABS,white 10.0917
speaker ring ABS,white 10.0513
Vibration
ABS,white 10.0550
BT sign PC，white highlight 10.1833
battery sign PC，white highlight 10.1833
arm ABS,silver 20.3007
front cover ABS,white highlight 10.4327
rear cover ABS,white highlight 10.4235
base cover ABS,black 10.2695
motor support
ABS 10.0807
motor support
ABS 10.0642

rear-wheel（left）ABS,black 10.0568
rear-wheel（right）ABS,black 10.0568
rear-wheel（right）ABS,black 10.0330
rear driving-wheel POM 10.0568
front wheel ABS,black 20.1137
front driving-wheel
balck silicon（50°）10.0862
front driving-wheel
ABS,black 10.0403
front wheel drive
ABS,black 10.0458
front support fixed
ABS，black 10.0458
front support adjust
ABS,black 10.0422
front protect
ABS,white 10.1375
front wheel bracket ABS,white 20.1283
gear1 POM 20.1173
gear2 POM 20.1393
gear3 POM 10.0697
steering wheel Low carbon steel, white zinc plating，Φ10.0642
rear axle shaft Low carbon steel, white zinc plating，10.1027
front axle shaft
Low carbon steel, white zinc plating
，
Φ
10.0770
gear shaft Low carbon steel, white zinc plating，Φ10.0513
stop pin
Low carbon steel, white zinc plating
，
Φ
10.0587
spring
SUS304
，
Φ5.5*Φ4.5*10.5mm
10.0917
screw M2.5*6mm,D6mm,Φ9 20.3850
screw Φ2*3.5mm,D5.5mm, 40.0213
screw Φ3*6mm,D7.5mm 10.0026
screw Φ2*10mm,D3mm 60.0143
screw Φ2*10mm,D3.5mm 70.0116
screw Φ2.6*8mm,D4.5mm 50.0104
screw Φ2*5mm,3.5mm 40.0067
screw Φ2*4mm,D4mm 40.0081
screw PWB2.0*6*6 30.0066
blister PVC,T=0.4mm,3,ROHS,V1.1 10.2420
packaging bag PE,60*100*0.06mm 10.0015
packaging bag PE,150*220*0.06mm 10.0084
master carton A=A,T=6mm,197*197*326mm 0.125 0.0493
inner carton A3A,T=3mm,183*183*151mm 0.25 0.0362
barcode label 76*50mm 10.0165
service card 280*210mm 10.0312
manual english manual,V1.0 10.0917
barcode label (UPC EAN-13,38*26mm)v1.0 20.0154
special sticker 64*13mm,V1.0 40.0425
mark sticker 10.0018
destination label GA0/GA1/GA2 10.0017
mark sticker BLACK&361C,Φ30mm 10.0017
15.8404
