IPSO DR30SL User manual

Technical specifications
Installation instructions
Operating instructions
Maintenance
OWNER'S MANUAL
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER
MANDR30SL 7/02
Gas: Natural and LP
Electric
Steam
IPSO - USA
99 Aberdeen Loop
Panama City, FL, 32405
Phone: [phone]
DR30SL
-
USA
30 lb. SLIM DR LAUNDRY DRYER
D0450

Page 2
IMPORTANTNOTICES—PLEASEREAD
For optimum efficiency and safety, we recommend that you read the manual before operating the equipment. Store this
manual in a file or binder and keep for future reference.
WARNING: Purchaser must post the following notice in a prominent location:
WARNING: For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion or to prevent property damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this
or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Clear the room, building, or area of all occupants.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
WARNING: In the event the user smells gas odor, instructions on what to do must be posted in a
prominent location. This information can be obtained from the local gas supplier.
WARNING: Wear safety shoes to prevent injuries.
WARNING: Purchaser must post the following notice in a prominent location:
FOR YOURSAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING: A clothes dryer produces combustible lint and should be exhausted outside the building.
The dryer and the area around the dryer should be kept free of lint.
WARNING: Be safe, before servicing machine, the main power should be shut off.

Page 3
ATTENTION:L’ACHETEUR DOIT PLACER L’AVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
ATTENTION:L’ACHETEUR DOIT PLACER L’AVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
AVERTISSEMENT. Assurez-vousdebien
suivre les instructions donnees dans cette
notice pour reduire au minimum le risque
d’incendie ou d’explosion ou pour eviter tuot
dommage materiel, toute blessure ou la mort.
__ Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
apparell.
__ QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
•Ne pas tenter d’allumer d’apparell.
• Ne touchez a aucun interrupteur. Ne pas
vous servir des telephones se trouvant dans
le batiment ou vous vous trouvez.
• Evacuez la piece, le batiment ou la zone.
•Appelez immediatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
•Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
__ l’installation et l’entretien doivent etre assures
par un installateur ou un service d’entretien
qualifie ou par le fournisseur de gaz.
POUR VOTRE SECURITE
Ne pas entreposer ni utiliser d’ essence
ni d’autres vapeurs ou liquides
inflammables dans le voisinage de cet
appareil ou de tout autre appareil.

Page 4
WARNING: To avoid fire hazard, do not dry articles containing foam rubber or similar
texture materials. Do not put into this dryer flammable items such as baby bed
mattresses, throw rugs,undergarments (brassieres, etc.) and other items which use
rubber as padding or backing. Rubber easily oxidizes causing excessive heat and
possible fire. These items should be air dried.
WARNING: Synthetic solvent fumes from drycleaning machines create acids when drawn
through the dryer. These fumes cause rusting of painted parts, pitting of bright or plated
parts, and completely removes the zinc from galvanized parts, such as the tumbler basket. If
drycleaning machines are in the same area as the tumbler, the tumbler's make-up air must
come from a source free of solvent fumes.
WARNING: Do not operate without guards in place.
WARNING: Check the lint trap often and clean as needed but at least a minimum of once per day.
WARNING: Alterations to equipment may not be carried out without consulting with the
factory and only by a qualified engineer or technician. Only Manufacture’s parts may be
used.
WARNING: Remove clothes from dryer as soon as it stops. This keeps wrinkles from
setting in and reduces the possibility of spontaneous combustion.
WARNING: Be safe - shut main electrical power and gas supply off externally before
attempting service.
WARNING: Never use drycleaning solvents, gasoline, kerosene, or other flammable liquids
in the dryer. FIRE AND EXPLOSION WILL OCCUR. NEVER PUT FABRICS
TREATEDWITHTHESELIQUIDS INTO THE DRYER.NEVERUSETHESE
LIQUIDSNEARTHEDRYER..
WARNING: Do not place items exposed to cooking oils in your dryer. Items contaminated
with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.
WARNING: Never let children play near or operate the dryer. Serious injury could occur if a child
should crawl inside and the dryer is turned on.
WARNING: Never tumble fiberglass materials in the dryer unless the labels say they are machine
dryable. Glass fibers break and can remain in the dryer. These fibers cause skin irritation if they
become mixed with other fabrics.
WARNING: Before operating gas ignition system - purge air from natural gas or propane gas lines
per manufacturer’s instructions.
WARNING: To reduce the risk of electric shock, disconnect this appliance from the power supply
before attempting any user maintenance other than cleaning the lint trap. Turning the controls to the
OFF position does not disconnect this appliance from the power supply.

Page 5
IPSO DRYER WARRANTY
The IPSO Manufacturing Company (IPSO) warrants all new equipment (and the original parts
thereof) to be free from defects in material or workmanship for a period of three (3)
years from the date of sale thereof to an original purchaser for use, except as hereinafter
provided. With respect to non-durable parts normally requiring replacement in less than
three (3) years due to normal wear and tear, and with respect to all new repair or replacement
parts for IPSO equipment for which the three (3) year warranty period has expired, or
for all new repair or replacement parts for equipment other than IPSO equipment, the warranty
period is limited to ninety (90) days from date of sale. The warranty period on each new
replacement part furnished by IPSO in fulfillment of the warranty on new equipment or
parts shall be for the unexpired portion of the original warranty period on the part replaced.
With respect to electric motors, coin meters and other accessories furnished with the new
equipment, but not manufactured by IPSO, the warranty is limited to that provided by the
respective manufacturer.
IPSO's total liability arising out of the manufacture and sale of new equipment and parts, whether
under the warranty or caused by IPSO's negligence or otherwise, shall be limited to IPSO repairing
or replacing, at its option, any defective equipment or part returned f.o.b. IPSO's factory,
transportation prepaid, within the applicable warranty period and found by IPSO to have been
defective, and in no event shall IPSO be liable for damages of any kind, whether for any injury
to persons or property or for any special or consequential damages. The liability of IPSO does
not include furnishing (or paying for) any labor such as that required to service, remove or
install; to diagnose troubles; to adjust, remove or replace defective equipment or a part; nor
does it include any responsibility for transportation expense which is involved therein.
The warranty of IPSO is contingent upon installation and use of its equipment under normal
operating conditions. The warranty is void on equipment or parts; that have been subjected
to misuse, accident, or negligent damage; operated under loads, pressures, speeds, electrical
connections, plumbing, or conditions other than those specified by IPSO; operated or repaired
with other than genuine IPSO replacement parts; damaged by fire, flood, vandalism, or such
other causes beyond the control of IPSO; altered or repaired in any way that effects the reliability
or detracts from its performance, or; which have had the identification plate, or serial number,
altered, defaced, or removed.
No defective equipment or part may be returned to IPSO for repair or replacement without prior
written authorization from IPSO. Charges for unauthorized repairs will not be accepted or paid
by IPSO.
IPSO MAKES NO OTHER EXPRESS OR IMPLIED WARRANTY, STATUTORY OR OTHERWISE, CONCERNING
THE EQUIPMENT OR PARTS INCLUDING, WITHOUT LIMITATION, A WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, OR A WARRANTY OF MERCHANTABILITY. THE WARRANTIES GIVEN ABOVE ARE
EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IPSO NEITHER ASSUMES,
NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT, ANY OTHER WARRANTY OR LIABILITY IN CONNECTION
WITH THE MANUFACTURE, USE OR SALE OF ITS EQUIPMENT OR PARTS.
For warranty service, contact the Distributor from whom the IPSO equipment or part was
purchased. If the Distributor cannot be reached, contact IPSO.
IDENTIFICATION NAMEPLATE
The Identification Nameplate is located on the rear wall of the dryer. It contains the dryer serial
number, product number, model number, electrical specifications and other important data that
may be needed when servicing and ordering parts, wiring diagrams, etc. Do not remove this
nameplate.

Page 6
Contents
Safety Instructions ........................................................................................... 2-4
Cissell Dryer Warranty ..................................................................................... 5
Table of Contents.............................................................................................. 6
Symbols ............................................................................................................. 7
Unpacking / General Installation .................................................................... 8-9
Technical Data and Dimensions ...................................................................... 10-11
Electric Connections ........................................................................................ 12
Gas Connections ............................................................................................... 13
Gas Piping Installation ....................................................................................14-15
Gas service Installation Instructions ............................................................... 16
Gas Pipe Size Chart .......................................................................................... 17
Steam Piping Installation Instructions ............................................................18-19
Dryer Installation with Multiple Exhaust .......................................................20-21
Dryer Make-Up Air Requirements ................................................................... 22
Dryer Installation with Seperate Exhaust ....................................................... 23
Exhaust and Venting ........................................................................................ 24
Rules for Safe Operation of Dryer .................................................................... 25
Direct-Spark Ignition Operation...................................................................... 26-27
General Maintenance .......................................................................................28-29
Air Switch Adjustment ......................................................................................30
Operating Instruction for Double Timer ....................................................... 31
PARTS ............................................................................................................... 32-62
Aligning Basket .............................32
Front View .....................................33
Control Door Assembly .................34
Door Assembly ...............................35
Front Panel Assembly - OPL .........36
Front Panel Assembly - Coin ........37
Thermostat Assembly.....................38-41
Mech. Coin Control Asm. ..............42
DMP Coin Control Assembly ........43
DX3 Coin Control Assembly .........44
2 Timer Control Assembly .............45
DMP OPL Control Assembly.........46
DX3 OPL Control Assembly ..........47
PRO/HC Control Assembly ...........48
Lint Door Assembly .......................49
Basket & Spider Assembly.............50
Rear View....................................... 51
Air Switch Assembly ......................52
Basket Bearing/Sheave Assy .........53
Motor & Fan Assembly .................54-55
Idler Assembly ...............................56
Rear Control Box Assembly ..........57
Nat. Gas Heating Unit Asm. ..........58
L.P.GasHeatingUnitAsm............59
Steam Heating Unit Asm. ..............60
Electric Heating Unit Asm. ...........61
Recommended Spare Parts List ....62

Page 7
Rotation in two directions
Rotation dans les deux sens
Drehbewigung in zwei
Richtungen
Movimiento rotativo en los
dos sentidos
Caution
Attention
Achtung
Atencion; precaucion
Direction of rotation
Sens de mouvement continu
De rotation Drehbewegung
in Pfeilrichtung movimiento
Giratorio o rotatorio en el
sentido de la flecha
The following symbols are used in this manual and/or on the machine.
NOTE!
On
Marche
Ein
Conectado
Off
Arrêt
Aus
Desconectado
Hot! Do Not Touch
Heiß! Nicht Beruhren
Haute temperature! Ne pas
toucher
Caliente! no tocar
Start
Demarrage
Start
Arranque de un
movimiento
Emission of heat in general
Emission de chaleur en
general
Warmeabgabe allgemein
Emisión de calor
Cooling
Refroidissement
Kühlen
Enfriamiento
dangerous voltage
tension dangereuse
Gefährliche elektrische
Spannung
tension peligrosa End of Cycle
DescriptionSymbol
SYMBOLS
Symbol

Page 8
Unpacking/General Installation (All Dryers)
Uponarrivaloftheequipment,anydamageinshipmentshouldbereported
to the carrier immediately.
Upon locating permanent location of a unit, care should be taken in
movementandplacementofequipment.
See outline clearance diagrams for correct dimensions.
Remove all packing material such as: tape, manuals, skid, etc.
Leveling:Usespiritlevelontopofdryer.Adjustlevelingboltsondryer
(see adjustable leveling bolts in maintenance section).
Check voltage and amperes on rating plate before installing the dryer.
The construction of the dryers permits installation side-by-side to save
space or to provide a wall arrangement. Position dryer for the least
amount of exhaust piping and elbows, and allow free access to the rear
of dryer for future servicing of belts, pulleys and motors. Installation
clearancefromallcombustable material is 0" ceiling clearance, 0" rear
clearance, and 0" side clearance.
Beforeoperatingdryer,openbasketdoorandremoveblockingbetween
front panel and basket. Read the instruction tags, owner’s manual,
warnings,etc.
IMPORTANT
Openingtheclothesloadingdoordeactivatesthedoorswitch
toshutoffthemotors,fan,gas,steam,orelectricelement.To
restartthedryer,closethedoorandpressinthepushtostart
button.
IMPORTANT
This dryer is designed for a capacity maximum load.
Overloadingitwillresultinlongdryingtimesanddampspots
on some clothes.
IMPORTANT
Maximumoperatingefficiencyisdependentuponproperair
cIrculation. The lint screen must be kept cleaned daily to
insureproperaircirculationthroughoutthedryer.
IMPORTANT
Provideadequateclearanceforairopeningintothecombustion
chamber.
UNPACKING
GENERAL
INSTALLATION(ALL
DRYERS)

Page 9
Unpacking/General Installation (All Dryers)
The dryer is so designed that when an operator opens the dryer door,
the basket and exhaust fan stop. You can expect fast drying from the
laundrydryer. Hot,dryairisproperlyandeffectivelymovedthrough
thebasketandexhaustedthroughalinttraptotheatmosphere. Thedryer
comes equipped with an inclined self-cleaning lint screen. In this
system,lintaccumulatesontheundersideofthescreenuntilablanket
oflint fallsfrom thescreen tothebottomofthedryercabinet. Thelint
shouldberemoved dailyorasrequiredtopreventanover-accumulation.
IMPORTANT
Provideadequateclearanceforairopeningsintothecombustion
chamber.
Permanent press, durable press and other modern day fabrics require
thecarethatyourlaundrydryersnowprovide. Attheendofthedrying
cycle, a timed “Cool-Down” control automatically takes over and
continuestherotationofthefanandbasketwithoutheatuntilthegarment
loadreachesasafecooltemperature. Thisfunctionisperformedatthe
end of each drying cycle.
Replacementpartsforthisdryerareavailablefromyourdistributoror
bycontractingthefactoryattheaddressorphonenumberprintedonthe
cover page of this manual.
GENERAL
INFORMATION
DRYER
“COOL-DOWN”
CYCLE
REPLACEMENT
PARTS

Page 10
HD30SL Dryer Dimensions - Standard Gas, Steam and Electric Heated
snoitacificepSerusaeM.S.U cirteM erusaeM
yticapaC )neniLyrD( .sbl03gk6.31
teksaB
retemaiDsehcni72mm586
htpeDsehcni
03mm267
emuloVtf01
3
retil382
tenibaC
thgieHsehcni61/5-86mm5371
htdiWsehcni4/3-82mm037
htpeDsehcni74mm4911
gninepOrooD
retemaiDsehcni8/
5-22mm575
thgiehgnidaoLsehcni2/1-92mm057
erutarepmeT
muminiM001
0
F83
o
C
mumixaM581
0
F58
0
C
rotoM
gnisrever-noN.P.H2/1Wk73.0
murD-gnisreveR.P.H2/1Wk73.0
naF.P.H2/1Wk73.0
tsuahxE
etaRwolFmfc006m0201
3
h/
retemaiDsehcni8mm302
sreyrDcirtcelE-.nnoCcirtcelE gnisreveR-noNgnisreveR
V802HP3-06A76A86
V042/022HP3-06/05A06/
55A06/55
V514/083HP3-05A73/43A63/33
V084HP3-06A03A13
sreyrDsaG,maetS-.nnoCcirtcelE gnisreveR-noNgnisreveR
V042-802
/511HP1-06/05A5.9A/N
V042-802HP3-06/05A7.2A4.5
V084HP3-06A3.1A5.2
V514-083HP3-06/05A4.1A3.4
rewoP
cirtcelEWk5.22Wk5.22
sa
Gh/utB000,001h/lack002,52
maetSP.H.B5.4h/lack000,83
noitcennocmaetS
telnI"4/302ND
teltuO"2/151ND
noitcennoCsaG
noit
cennoCsaG"2/151ND
erusserPsaG"21-"5bm03-21
gnippihS snoisnemiD
)DxWxH( 25X23X37 sehcni 519X4581 mm1231X
thgieW
teN.s
bl925gk042
ssorG.sbl465gk652

Page 11
IPD30SL Dryer Dimensions
(Illustration)
IPSO
DR50

Page 12
Electric connection
Theconnection needstobe madeinthe wiringboxattheback. Open thecoverplate
(G) in order to reach the connection clamps.
The connection cable needs to be brought in through the opening on the side of the
wiring box.
It is necessary to ground the dryer for your personal safety and to ensure a good
operation.
115 and 208-240 V - 1 ph
The mains wires (Ll) and (L2) should be connected to the 2 left blocks and the
yellow/green grounding wire (PE) should be connected to the grounding block.
208-240 and 480 V - 3 ph
The 3 mains wires (L1), (L2) and (L3) should be connected to the 3 left blocks and
the yellow/green grounding wire (PE) should be connected to the grounding
block.
380-415V - 3 ph
The 3 mains wires (L1), (L2) and (L3) should be connected to the 3 left blocks,
the blue neutral (N) should be connected to the right block and the yellow/green
grounding wire (PE) should be connected to the grounding block.
G
Dryers must be electrically grounded by a separate #14 or larger green wire from the grounding terminal
within the Service Connection Box, to a cold water pipe. In all cases, the grounding method must comply
with local electrical code requirements; or in the absence of local codes, with the National Electrical Code,
ANSI/NFPA 70 or the Canadian Electrical Code, CA C22.1.
See wiring diagram furnished with dryer. Do not change wiring without consulting the factory, as you may
voidthe factorywarranty. DONOT CONNECTTHEDRYERTOANYVOLTAGEORCURRENTOTHER
THAN THAT SPECIFIED ON THE DRYER RATING PLATE. (Wiringdiagramislocatedonrearwallof dryer.)
All panels must be in position before operation of dryer.
«Attention. Lors des opérations d’entretien
des commandes, ètiqueter tous les fils avant
de les dèconnecter. Toute erreur de câblage
peut être une source de danger et de panne»
PE L1 L2 L3 N
208-240V
3 X 208-240V
3 X 380-415 + N

Page 13
The gas supply pipe should be connected to the union (I), which is on the right next
to the wiring box on the back.
It is very important to have the connections done by a qualified technician, in order
to make sure that the installation is effected in accordance with the prevailing
standards and instructions.
Thedryer shouldbeconnected tothetype ofgas, whichisindicated ontheserial plate.
The use of too small gas pipes can result in unsufficient gas supply, which can lead
to a bad heating-up and a poor drying quality.
When the dryer is used in combination with a weighing platform, the gas supply
pipe has to be made of flexible material to allow the weighing system to keep
moving freely.
I
It is important to work with the right gas pressure (see technical remarks) in order to
obtain a good ignition, heating and consequently a good operation in general.
After the gas supply has been connected, the gas tap in the dryer should beturned on
(clockwise).
Test all connections for possible leaks by means of a soap solution, but
never with a flame.
Gas connection

Page 14
Gas Piping Installation
1. The installation must conform with local codes, or in the
absence of local codes with the National Fuel Gas Code as,
ANSI Z223.1 or the CAN/CGA-B149, Installation Codes.
2. Check identification nameplate for type of gas for dryer.
3. Checkthe altitude of dryer.
4. Check with utilities company for proper gas pressure and gas
supplyline.
5. Natural gas only—check the gas pressure inlet supply to
dryer,11”watercolumn(27.4mbar)maximum.Manifold
pressure—3.5” water column (8.8 mbar) pressure .
6. L.P. gas only—manifold pressure—13” water column (32.4
mbar)maximum.
CAUTION:Lowgaspressureandintermittentgaswillcause
gasignitionproblemsandinadequatedryingoflaundry.
GAS PIPING
INSTALLATION

Page 15
Gas Piping Installation (Illustrations)
The dryer and it’s individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of 1/2 psi (.04 bar).
The dryer must be isolated from the gas supply piping system by closing it's individual manual shutoff
valve during any pressure testing of the gas supply piping system at test pressures equal to or less
than 1/2 psi (.04 bar).

Page 16
The size of the gas service pipe is dependant upon many variables,
such as tees, lengths, etc. Specific pipe size should be obtained from
the gas supplier. Refer to the “Gas Pipe Size” chart in this manual for
general gas pipe size information.
CAUTION:Gaslooppipingmustbeinstalledasillustrated
tomaintainequalgaspressureforalldryersconnectedtoa
single gas service
Other gas-using appliances should be connected upstream
fromtheloop.
WARNING:
LIQUIFIEDPETROLEUMGASESONLY!
A gas pressure regulator for liquified petroleum gases is not
furnished on the gas heated clothes dryers. This regulator is normally
furnished by the installer. In accordance with American Gas
Association (AGA) standards, a gas pressure regulator, when
installed indoors, must be equipped with a vent limiter or a vent line
must be installed from the gas pressure regulator vent to the outdoors.
Gas Service Installation Instructions
GAS SERVICE
INSTALLATION
INSTRUCTIONS
GAS PRESSURE
REGULATOR FOR
LIQUIFIED
PETROLEUM GASES

Page 17
Gas Pipe Size Chart
TOTAL BTU/HR
(for LP Gas correct
total BTU/HR below by
multiplying by .6)
TOTAL
KCAL
HOUR
GAS PIPE SIZE FOR 1000 BTU (250 KCAL) NATURAL GAS
AT 7” (17.5 MM) W.C. PRESSURE
In figuring total length of pipe, make allowance for tees and elbows. (150 ft.)
45,72 m
(125 ft.)
38,1 m
(100 ft.)
30,48 m
(75 ft.)
22,86 m
(50 ft.)
15,24 m
(25 ft.)
7,62 m
60,000
80,000
100,000
120,000
140,000
160,000
180,000
200,000
300,000
400,000
500,000
600,000
700,000
800,000
900,000
1,000,000
1,100,000
1,200,000
1,300,000
1,400,000
1,500,000
1,600,000
1,700,000
1,800,000
1,900,000
2,000,000
2,200,000
2,400,000
2,600,000
2,800,000
3,000,000
3,200,000
3,400,000
3,600,000
3,800,000
4,000,000
15000
20000
25200
30200
35200
40300
45300
50400
75600
100800
126000
151200
176400
202000
230000
250000
270000
300000
330000
350000
380000
400000
430000
450000
480000
504000
550000
605000
650000
705000
750000
806000
850000
907000
960000
1000000
3/4
3/4
3/4
3/4
3/4
3/4
1
1
1
1 1/4
1 1/4
1 1/2
1 1/2
1 1/2
2
2
2
2
2
2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3/4
3/4
3/4
1
1
1
1
1
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3/4
3/4
1
1
1
1
1
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
3/4
1
1
1
1
1 1/4
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
4
4
3/4
1
1
1
1
1 1/4
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
4
4
4
4
3/4
1
1
1
1 1/4
1 1/4
1 1/4
1 1/2
1 1/2
2
2
2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
2 1/2
3
3
3
3
3
3
3
3 1/2
3 1/2
3 1/2
3 1/2
3 1/2
4
4
4
4
4
4

Page 18
Steam Piping Installation Instructions
1. Set and anchor dryer in position. Machine should be level to
assure proper steam circulation.
2. To prevent condensate draining from headers to dryer, piping
should have a minimum 12" above respective header. Do not
make steam connection to header with a horizontal or
downwardly facing tee or elbow.
3. Whenever possible, horizontal runs of steam lines must drain,
by gravity, to respective steam header. Water pockets, or an
imporperly drained steam header will provide wet steam,
causing improper operation of dryer. If pockets or improper
drainage cannot be eliminated, install a by-pass trap to drain
condensate from the low point in the steam supply header to
thereturn.
4. In both steam supply and steam return line, it is recommended
that each have a 3/4" union and 3/4" globe valve. This will
enable you to disconnect the steam connections and service
the dryer while your plant is in operation.
5. Before connecting trap and check valve to dryer, open globe
valve in steam supply line and allow steam to flow through
dryer to flush out any dirt and scale from dryer. This will
assure proper operation of trap when connected.
6. Afterflushingsystem,install bucket trap(withbuilt-in
strainer) and check valve. For successful operation of dryer,
install trap 18" below coil and as near to the dryer as
possible. Inspect trap carefully for inlet and outlet markings
andinstallaccordingto trap manufacturer's instructions. If
steam is gravity returned to boiler, omit trap but install check
valve in return line near dryer.
7. Install union and globe valve in return line and make final
pipe connections to return header.
STEAM PIPING
INSTALLATION
INSTRUCTIONS

Page 19
Steam Piping Installation (Illustration)

Page 20
Dryer Installation With Multiple Exhaust
For Exhaust Duct less than 14 feet (5 m) and 2 elbows equivalent
andless than0.3 inches(.8 mbar)static pressure.
DRYER EXHAUSTS
Area of section “A-A” must be equal to the sum of dryerexhaustpipesentering
multiple exhaust pipe. (See chart below.)
HD30SL
No. of Dryers
Duct Diameter
(in inches)
(in CM)
1 2 3 4 5 6 7 8 9 101112131415161718192021222324
8 1214161820222324262728293031323334353637383940
20 30 35 41 46 51 56 58 61 66 68 71 73 76 78 81 84 86 89 91 94 97 99100
_ _ _ _
_ _ _ _
_ _ _ _
_ _ _ _
_ _ _ _
_ _ _ _
Exhaust
Booster Fan
Power Supply
to Fan
RelayCoils
Start and Stop
Switches on
Dryers
