IPSO DR30SLG User manual

Page 1
MAN2030I (ECN5752) 8/99 5C D0539
MODELS
GAS STEAM ELECTRIC
DR30SLG DR30SLS DR30SLE
OWNER'S MANUAL
30 Lb. Laundry Dryer
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
IPSO-USA
3101 S. Haven Hwy. 77 Phone: [phone]
Suite A
Panama City, FL 32405
- USA

Page 2
IMPORTANTNOTICES—PLEASEREAD
For optimum efficiency and safety, we recommend that you read the manual before operating the equipment. Store
this manual in a file or binder and keep for future reference.
WARNING: Purchaser must post the following notice in a prominent location:
WARNING: For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion or to prevent property damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or
any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Clear the room, building or area of all occupants.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
WARNING: In the event the user smells gas odor, instructions on what to do must be posted in a
prominent location. This information can be obtained from the local gas supplier.
WARNING: Purchaser must post the following notice in a prominent location:
FOR YOURSAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING: A clothes dryer produces combustible lint and should be exhausted outside the
building. The dryer and the area around the dryer should be kept free of lint.
WARNING: Be safe, before servicing machine, the main power should be shut off.
WARNING: Wear safety shoes to prevent injuries.

Page 3
ATTENTION:L’ACHETEUR DOIT PLACER L’AVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
AVERTISSEMENT. Assurez-vousdebien
suivre les instructions donnees dans cette
notice pour reduire au minimum le risque
d’incendie ou d’explosion ou pour eviter tuot
dommage materiel, toute blessure ou la mort.
__ Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
apparell.
__ QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
•Ne pas tenter d’allumer d’apparell.
• Ne touchez a aucun interrupteur. Ne pas
vous servir des telephones se trouvant dans
le batiment ou vous vous trouvez.
• Evacuez la piece, le batiment ou la zone.
•Appelez immediatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
•Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
__ l’installation et l’entretien doivent etre assures
par un installateur ou un service d’entretien
qualifie ou par le fournisseur de gaz.
POUR VOTRE SECURITE
Ne pas entreposer ni utiliser d’ essence
ni d’autres vapeurs ou liquides
inflammables dans le voisinage de cet
appareil ou de tout autre appareil.
ATTENTION:L’ACHETEUR DOIT PLACER L’AVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:

Page 4
WARNING: To avoid fire hazard, do not dry articles containing foam rubber or similar texture materials.
Do not put into this dryer flammable items such as baby bed mattresses, throw rugs,undergarments
(brassieres, etc.) and other items which use rubber as padding or backing. Rubber easily oxidizes causing
excessive heat and possible fire. These items should be air dried.
WARNING: Synthetic solvent fumes from drycleaning machines create acids when drawn through the
dryer. These fumes cause rusting of painted parts, pitting of bright or plated parts, and completely
removes the zinc from galvanized parts, such as the tumbler basket. If drycleaning machines are in the
same area as the tumbler, the tumbler's make-up air must come from a source free of solvent fumes.
WARNING: Do not operate without guards in place.
WARNING: Check the lint trap often and clean as needed but at least a minimum of once per day.
WARNING: Alterations to equipment may not be carried out without consulting with the factory and
only by a qualified engineer or technician. Only Manufacturers parts may be used.
WARNING: Remove clothes from dryer as soon as it stops. This keeps wrinkles from setting in and
reduces the possibility of spontaneous combustion.
WARNING: Be safe - shut main electrical power and gas supply off externally before attempting
service.
WARNING: Never use drycleaning solvents, gasoline, kerosene, or other flammable liquids in the dryer.
FIREAND EXPLOSION WILL OCCUR. NEVER PUT FABRICSTREATED WITH THESE LIQUIDS
INTO THE DRYER. NEVER USE THESE LIQUIDS NEAR THE DRYER..
WARNING: Do not place items exposed to cooking oils in your dryer. Items contaminated
with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.
WARNING: Never let children play near or operate the dryer. Serious injury could occur if a child
should crawl inside and the dryer is turned on.
WARNING: Never tumble fiberglass materials in the dryer unless the labels say they are machine
dryable. Glass fibers break and can remain in the dryer. These fibers cause skin irritation if they
become mixed with other fabrics.
WARNING: Before operating gas ignition system - purge air from natural gas or propane gas lines
per manufacturer’s instructions.
WARNING: To reduce the risk of electric shock, disconnect this appliance from the power supply
before attempting any user maintenance other than cleaning the lint trap. Turning the controls to the
OFF position does not disconnect this appliance from the power supply.

Page 5
IPSO DRYER WARRANTY
IPSO warrants all new equipment (and the original parts thereof) to be free from defects in material or workmanship for
a period of two (2) years from the date of sale thereof to an original purchaser for use, except as hereinafter provided. With
respect to non-durable parts normally requiring replacement in less than two (2) years due to normal wear and tear, and with
respect to all new repair or replacement parts for IPSO equipment for which the two (2) year warranty period has expired,
or for all new repair or replacement parts for equipment other than IPSO equipment, the warranty period is limited to ninety
(90) days from date of sale. The warranty period on each new replacement part furnished by IPSO in fulfillment of the
warranty on new equipment or parts shall be for the unexpired portion of the original warranty period on the part replaced.
With respect to electric motors, coin meters and other accessories furnished with the new equipment, but not manufactured
by IPSO, the warranty is limited to that provided by the respective manufacturer.
IPSO’s total liability arising out of the manufacture and sale of new equipment and parts, whether under the warranty or
caused by IPSO’s negligence or otherwise, shall be limited to IPSO-USA repairing or replacing, at its option, any defective
equipment or part returned f.o.b. IPSO’s factory, transportation prepaid, within the applicable warranty period and found by
IPSOtohavebeen defective, and in no event shallIPSO beliablefor damages of any kind, whether foranyinjuryto persons
or property or for any special or consequential damages. The liability of IPSO does not include furnishing (or paying for)
any labor such as that required to service, remove or install; to diagnose troubles; to adjust, remove or replace defective
equipment or a part; nor does it include any responsibility for transportation expense which is involved therein.
The warranty of IPSO is contingent upon installation and use of its equipment under normal operating conditions. The
warranty is void on equipment or parts; that have been subjected to misuse, accident, or negligent damage; operated under
loads, pressures, speeds, electrical connections, plumbing, or conditions other than those specified by IPSO; operated or
repaired with other than genuine IPSO replacement parts; damaged by fire, flood, vandalism, or such other causes beyond
the control of IPSO; altered or repaired in any way that effects the reliability or detracts from its performance, or; which
have had the identification plate, or serial number, altered, defaced, or removed.
No defective equipment or part may be returned to IPSO for repair or replacement without prior written authorization from
IPSO. Charges for unauthorized repairs will not be accepted or paid by IPSO.
IPSO MAKES NO OTHER EXPRESSED OR IMPLIED WARRANTY, STATUTORY OR OTHERWISE,
CONCERNING THE EQUIPMENT OR PARTS INCLUDING, WITHOUT LIMITATION, A WARRANTY OF
FITNESS FOR A PARTICULAR PURPOSE, OR A WARRANTY OF MERCHANTABILITY. THE
WARRANTIES GIVEN ABOVE ARE EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED. IPSO NEITHER ASSUMES, NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT, ANY
OTHER WARRANTY OR LIABILITY IN CONNECTION WITH THE MANUFACTURE, USE OR SALE OFITS
EQUIPMENT OR PARTS.
Forwarrantyservice,contactthe distributor from whom the IPSO equipmentorpartwaspurchased. If the distributor cannot
be reached, contact IPSO.
IDENTIFICATION NAMEPLATE
The identification nameplate is located on the rear wall of the dryer. It contains the dryer serial number, product number, model
number, electrical specifications and other important data that may be needed when servicing and ordering parts, wiring diagrams,
etc. Do not remove this nameplate.

Page 6
TABLEOFCONTENTS
30 LB. LAUNDRY DRYER
PAGE
ModelNumbers &CompanyAddress ......................................... 1
ImportantNotices ...................................................................... 2-4
Dryer Warranty ............................................................................ 5
TableofContents ......................................................................... 6
Warnings,CautionaryNotesandSymbols ................................. 7-8
UnpackingandGeneralInstallation .............................................. 9
DryerOutlineDimensions(Illustration) ................................. 10-11
GeneralSpecifications ........................................................... 12-13
MainDriveMotorList................................................................ 14
GeneralInformation.................................................................... 15
GroundingInstructions ................................................................ 16
PipingRecommendations............................................................ 17
GasPipingInstallation ........................................................... 18-19
GasServiceInstallation .............................................................. 20
Gas Pipe Size Chart.................................................................... 21
SteamPipingInstallation........................................................ 22-23
DryerInstallationwithMultipleExhaust ................................ 24-25
DryerInstallationwithSeparateExhaust.................................... 26
Make-Up AirRequirements .......................................................... 27
ExhaustandVenting ...................................................................... 28
RulesforSafeOperationofDryer .................................................. 29
OperatingInstructions-CoinMeterModels .................................30-33
PAGE
Service Savers............................................................................ 34
Troubleshooting ..................................................................... 35-38
DirectSparkIgnition.............................................................. 39-40
GeneralMaintenance ............................................................ 41-42
BurnerAirInletShuttersAdjustment .................................... 43-44
BearingReplacementInstructions .............................................. 45
BasketAlignment ....................................................................... 46
ShimmingtheBasketandSpiderAssembly ................................ 47
AirSwitchAdjustment ............................................................... 48
Dryer - Front View ............................................................... 49-50
Dryer - Rear View ................................................................ 51-52
Control Panel and Access Door ............................................ 53-54
FrontPanel and DoorAssembly................................................. 55
ThermostatAssembly................................................................. 56
ExhaustDuct and AirSwitchAssemblies .................................. 57
SteamHeatingUnit .................................................................... 58
GasHeating Unit ................................................................... 59-60
ElectricHeatingUnit .................................................................. 61
ElectricBonnet“UR”Model...................................................... 62
ElectricHeatingCircuit .............................................................. 63

Page 7
NOTE!
on
marche
Ein
conectado
off
arrêt
Aus
desconectado
Hot! DoNot Touch
Heiß! NichtBeruhren
Hautetemperature!Nepas
toucher
Caliente! notocar
start
demarrage
Start
arranquedeunmovimiento
emission of heat in general
êmissiondechaleuren
general
Warmeabgabeallgemein
emisióndecalor
cooling
refroidissement
Kühlen
enfriamiento
dangerousvoltage
tensiondangereuse
Gefährlicheelektrische
Spannung
tension peligrosa
SYMBOLS
Symbol Description
The following symbols are used in this manual and/or on the machine:

Page 8
SYMBOLS
Symbol Description
rotationintwodirections
rotationdanslesdeuxsens
DrehbewigunginzweiRichtungen
movimientorotativoenlosdos
sentidos
End of Cycle
caution
attention
Achtung
atencion;precaucion
directionofrotation
sensdemouvementcontinuderotation
DrehbewegunginPfeilrichtung
movimientogiratorioorotatorio
en el sentido de la flecha

Page 9
Unpacking/General Installation (All Dryers)
Uponarrivalof the equipment, anydamageinshipmentshould be
reported to the carrier immediately.
Upon locating permanent location of a unit, care should be taken in
movementandplacementofequipment.
See outline clearance diagrams for correct dimensions.
Remove all packing material such as: tape, manuals, skid, etc.
Leveling: Use spirit level on top of dryer. Adjust leveling bolts on
dryer (see adjustable leveling bolts in maintenance section).
Check voltage and amperes on rating plate before installing the dryer.
The construction of the dryers permits installation side-by-side to
save space or to provide a wall arrangement. Position dryer for the
least amount of exhaust piping and elbows, and allow free access to
the rear of dryer for future servicing of belts, pulleys and motors.
Installation clearance from all combustable material is 0" ceiling
clearance, 0" rear clearance, and 0" side clearance.
Before operating dryer, open basket door and remove blocking
between front panel and basket. Read the instruction tags, owner's
manual,warnings,etc.
IMPORTANT
Openingtheclothesloadingdoordeactivatesthedoorswitch
toshutoffthemotors,fan,gas,steam,orelectricelement.To
restartthedryer,closethedoorandpressinthepushtostart
buttonandholdbriefly.
IMPORTANT
This dryer is designed for a capacity maximum load.
Overloadingitwillresultinlongdryingtimesanddampspots
on some clothes.
IMPORTANT
Maximumoperatingefficiencyisdependentuponproperair
circulation. The lint screen must be kept cleaned daily to
insureproperaircirculationthroughoutthedryer.
IMPORTANT
Provideadequateclearanceforairopeningintothecombustion
chamber.
UNPACKING
GENERAL
INSTALLATION (ALL
DRYERS)

Page 10
L28UR30 Outline Dimensions—Gas, Steam and Electric Models

Page 11
L28US30 Outline Dimensions—Gas Model

Page 12
General Specifications
Basket Load Capacity ...................................... 30lb(13.6kg)Dryweight
Basket Size ................................................... 27 1/4" (720 mm) Diameter x
30 1/4" (760 mm) Deep
TotalAmps,Voltage,Cycle ................................. Refer to rating plate on dryer
Floor Space .................................................. URmodels: 68 1/2” H (1740 mm)
x 28 3/4" W (730 mm) x
47 1/2" Deep (1207 mm)
US models: 68” H (1727 mm)
x 28 3/4" W (730 mm) x
47 1/2" Deep (1207 mm)
Exhaust Air Duct Size .................................. UR: 8" Diameter (203 mm)
US: 6" Diameter (152 mm)
Pressure Maximum ...................................... 3" Static Pressure
Maximum Air Displacement........................ 350 cfm (595 m³/h)
*Btu Input ..................................................... 80,000 Btu per hour
(natural and LP gases)
Dryer Gas Burners ....................................... Natural gas—3.5" (8.7 mbar) WC
regulated pressure.
LP gas—11" (27 mbar) WC gas
pressure.
GasSupply .................................................... 1/2" (DN15) pipe
connection
Net Weight ................................................... 495 lb (225 kg) approx.
Domestic Shipping Weight .......................... 526 lb (239 kg) approx.
(1 carton)
Export Shipping Weight ............................... 664 lb (301 kg) approx.
(1 box)
Maximum Air Displacement........................ 700 cfm (1190 m³/h)
Recommended Operating Range.................. 530-630 cfm
(900-1070 m³/h)
GasSupply .................................................... 1/2" (DN15) pipe
connection
*Btu Input ..................................................... 100,000 Btu per hour
(natural and LP gases)
Electronic Ignition ....................................... Direct spark ignition
system
Net Weight ................................................... 437 lb (198 kg) approx.
Domestic Shipping Weight .......................... 472 lb (214 kg) approx.
(1 carton)
Export Shipping Weight ............................... 476 lb (216 kg) approx.
(1 box)
Export Shipping Dimensions ....................... 74" L (1880 mm) x 31" W
(787 mm) x 52" H (1321 mm)
* Input ratings as shown are for elevations up to 2000 ft. (610 m).
For elevations above 2000 ft., ratings should be reduced 4% for each
1000 ft. (305 m) above sea level.
GENERAL
SPECIFICATIONS FOR
30 lb. LAUNDRY DRYERS
30 lb. GAS
ENERGY-SAVER
SPECIFICATIONS
30 lb. GAS (STANDARD)
SPECIFICATIONS

Page 13
Maximum Air Displacement ........................ 700 cfm (1190 m³/h)
Recommended Operating............................. 530-630 cfm
Range (900-1070 m³h)
Steam Supply Connection ............................ 3/4" (DN20)
Steam Return Connection ............................ 3/4" (DN20)
Operating Steam Pressure............................ 7-15 lb (3.18-6.9 kg) low
pressure
100 lb (56.7 kg) high
pressure
Steam Consumption ..................................... 3.4 BHP - 117.3 lb
(53.21 kg/h. with normal
load - high pressure
2.6 BHP - 89.7 lb
(40.69 kg/h. with normal
load - low pressure
Net Weight ................................................... 478 lb (217kg)
Domestic Shipping Weight .......................... 522 lb (237kg)
(approx. 1 carton)
Export Shipping Weight ............................... 526 lb (239 kg)
(approx. 1 box)
Export Shipping Dimensions ....................... 74" L (1880 mm) x 35" W
(889 mm) x 55" H (1397 mm)
Maximum Air Displacement ........................ 700 cfm (1190 m³h)
Recommended Operating............................. 530-630 cfm
Range (900-1070 m³/h)
Heater Input .................................................. 21 kW/h (18,061 kcal/h)
Total Heater Current .................................... See chart on separate page
Net Weight (approx.) ................................... 463 lb (210 kg)
Domestic Shipping Weight .......................... 498 lb (226kg)
(approx. 1 carton)
Export Shipping Weight ............................... 513 lb (233kg)
(approx. 1 box)
Export Shipping Dimensions ....................... 74" L (1880 mm) x 31" W
(787mm) x 52" H (1321 mm)
General Specifications
30 lb. STEAM MODEL
SPECIFICATIONS
30 LB. ELECTRIC MODEL
SPECIFICATIONS
NOTE:
See electric heating unit section for further specifications.

Page 14
Main Drive Motors
Motor No. Voltage Hz. Phase HP kW Amps RPM
MTR300 115/200-240 60 1 1/2 .37 6.2/3.1 1725
MTR300 200-240 50 1 1/2 .37 3.7 1425
MTR214 208-230/460 60 3 1/2 .37 2.5/1.1 1725
MTR302 200-240/346-415 50 3 1/2 .37 2.0/1.0 1425
MTR302 220/380 60 3 1/2 .37 1.8/0.9 1725
Note: All motors have built-in thermal overload protection.

Page 15
General Information
The dryer is so designed that when an operator opens the dryer door,
thebasket and exhaust fan stops. You canexpectfastdrying from a
laundry dryer. Hot, dry air is properly and effectively moved through
thebasket and exhausted throughalinttrap to the atmosphere.The
dryer comes equipped with an inclined, self-cleaning lint screen. In
this system, lint accumulates on the underside of the screen until a
blanket approximately 1/4” (6 mm) thick is formed. This blanket of
lint will fall from the screen to the bottom of the dryer cabinet and
should be removed daily, or as required, to prevent an over
accumulation.
Permanent press, durable press and other modern day fabrics require
the care that your laundry dryers now provide.
At the end of the drying cycle, a timed “cool-down” control
automaticallytakesoverandcontinues the rotation of the fan and
basket without heat until the garment load reaches a safe cool
temperature.This function is performed at the endof eachdrying
cycleandcontinues for two minutes.
Dryers must be electrically grounded by a separate #14 or larger
greenwirefromthe grounding terminal within the service connection
box to a cold water pipe, or through the fourth green wire properly
groundedandconnected to the grounding terminal. Inallcases,the
GENERAL
INFORMATION
DRYER
COOL-DOWN

Page 16
Grounding Instructions (Illustration)
ELECTRICAL
CONNECTIONS
grounding method must comply with local electrical code
requirements; or in the absence of local codes,withtheNational
Electrical Code, ANSI/NFPA 70 or the Canadian Electrical Code,
CA C22.1.
See wiring diagram furnished with dryer. Your dryer is completely
wired at the factory and it is only necessary for the electrician to
connect the power leads to the wire connectors within the service
connection box on the rear of the dryer. Do not change wiring
withoutconsulting factory asyoumayvoid the factorywarranty.Do
notconnectthedryertoanyvoltageor current other than that
specified on the dryer rating plate. (Wiring diagram is located on
rear wall of dryer.)
ELECTRICAL
CONTROLS SERVICING Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation.
Verify proper operation after servicing.
Attention. Lors des operations d’entretien des commandes,
etiqueter tous les fils avant de les deconnecter. Toute erreur
de cablage peut etre une source de danger et de panne.

Page 17
Piping Recommendations
1. Trap each dryer individually. Always keep the trap clean
andingoodworkingcondition.
2. When dryer is on the end of a line of equipment, extend
header at least 4 feet (1.22 m) beyond dryer. Install globe
valve, union, check valve and by-pass trap at end of line. If
gravity return to boiler, omit trap.
3. Insulate steam supply and return line for safety of operator
and safety while servicing dryer.
4. Keep dryer in good working condition. Repair or replace any
worn or defective parts.
1. Keep steam coils clean.
2. Check periodically and clean as often as required.
3. Remove lint and dirt accumulation from coil fins periodically
as dirty lint-laden coil fins decrease the efficiency of steam-
heated dryers.
PIPING
RECOMMENDATIONS
STEAM HEATING
UNITS

Page 18
Gas Piping Installation
1. The installation must conform with local codes, or in the
absence of local codes with the National Fuel Gas Code,
ANSI Z223.1 or the CAN/CGA-B149, Installation Codes.
2. Check identification nameplate for type of gas for dryer.
3. Checkthe altitude of dryer.
4. Check with utilities company for proper gas pressure and gas
supplyline.
5. Natural gas only—check the gas pressure inlet supply to
dryer,11 inches (27 mbar) water columnmaximum. Manifold
pressure—3.5 inches (8.7 mbar) water column pressure.
6. L.P. gas only—manifold pressure—13 inches (32 mbar)
watercolumnmaximum.
CAUTION:Lowgaspressureandintermittentgaswillcause
gasignitionproblemsandinadequatedryingoflaundry.
GAS PIPING
INSTALLATION

Page 19
Gas Piping Installation (Illustration)
The dryer and it’s individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa).
The dryer must be isolated from the gas supply piping system by closing it's individual manual shutoff
valve during any pressure testing of the gas supply piping system at test pressures equal to or less
than 1/2 psi (3.5 kPa).

Page 20
The size of the gas service pipe is dependant upon many variables,
such as tees, lengths, etc. Specific pipe size should be obtained from
the gas supplier. Refer to the “Gas Pipe Size” chart in this manual for
general gas pipe size information.
CAUTION:Gaslooppipingmustbeinstalledasillustrated
tomaintainequalgaspressureforalldryersconnectedtoa
single gas service
Other gas-using appliances should be connected upstream
fromtheloop.
WARNING:
LIQUIFIEDPETROLEUMGASESONLY!
A gas pressure regulator for liquified petroleum gases is not
furnished on gas heated clothes dryers. This regulator is normally
furnished by the installer. In accordance with American Gas
Association (AGA) standards, a gas pressure regulator, when
installed indoors, must be equipped with a vent limiter or a vent line
must be installed from the gas pressure regulator vent to the outdoors.
Gas Service Installation Instructions
GAS SERVICE
INSTALLATION
INSTRUCTIONS
GAS PRESSURE
REGULATOR FOR
LIQUIFIED
PETROLEUM GASES
