iPuray BRT-F011-T User manual

Product Description of BRT-F011-T Page 1of 4
Shenzhen Asia Bright Industry co., Ltd., Building 10, Asia Industrial Park, Gangtou, Bantian, Shenzhen, China.
www.a-brt.com. [email protected].
© 2015 All rights reserved. Subject to change without notices.
Rotary Knob Fan Speed Control Switch
with Remote Control
(No Neutral Required)
Model #：BRT-F011-T
Features:
BRT-F011-T is a speed control switch which has a built-in micro controller unit. In addition to a
wall mount rotary knob unit for turning on/off the motor and for adjusting the motor’s speed, it
also has a handheld remote control. The wall mount unit is designed for easy installation and
retrofit, directly fit into standard wall box with no need for the neutral.
Step-less speed control using wall mount rotary knob or a remote control ;
Memory function. The motor always stars at last speed;
Good for all AC motors;
ABS-V0 flame resistance material; and
Classical 86 series design and high quality build.
Front View and Back View:
Fig. 1 and Fig. 2 show the front view and the back view of BRT-F011-T rotary knob fan speed
control switch with remote control respectively.
Fig. 1 Front View Fig. 2 Back View

Product Description of BRT-F011-T Page 2of 4
Shenzhen Asia Bright Industry co., Ltd., Building 10, Asia Industrial Park, Gangtou, Bantian, Shenzhen, China.
www.a-brt.com. [email protected].
© 2015 All rights reserved. Subject to change without notices.
As shown in Fig. 1 and Fig. 2, BRT-F011-T speed control switch set includes a wall mount unit
and remote control. The wall mount unit has a rotary knob and an infrared detector on the front,
and wiring terminal blocks on the back. The remote control has three control buttons and a wall
mount bracket.
Specification Parameters:
Input Voltage
220～
240V(50Hz/60Hz)
Operation
Environment
No-condensation 20-90% RH，
-20℃～40℃
Wattage
150W
Load type
Motor
Mounting Hole
Spacing
60mm
Matching
Box
75mm x 75mm x 50mm
Dimension
86mm x 86mm x 43mm
Weight
87g
Remote Control
Mode
Infrared
Remote Control
Distance
Up to 8m
Remote Control
Dimension
107mm x 36mm x 14mm
Wiring Diagram and Installation Guide:
BRT-F011-T speed control switch only require two wires for installation:
Hot wire (ACL): Coming from the power line with 220V; and
Load wire: Going to the load.
Fig. 3 BRT-F011-T Wiring Diagram
Warning: Please make sure power is turned off before starting installation!
Fig. 3 shows the wiring diagram and Fig. 4 shows the step-by-step installation instructions. There

Product Description of BRT-F011-T Page 3of 4
Shenzhen Asia Bright Industry co., Ltd., Building 10, Asia Industrial Park, Gangtou, Bantian, Shenzhen, China.
www.a-brt.com. [email protected].
© 2015 All rights reserved. Subject to change without notices.
are three easy steps:
Step one: Use a screwdriver to pry off the front plate in position A;
Step two: Wiring according to the diagram and the labelled ports of the switch; and
Step three: Install screws and front plate.
Fig. 4 BRT-F011-T Installation Guide
Operation Guide:
BRT-F011-T speed control switch can be controlled either using the rotary knob of the wall mount
unit or the remote control as shown in Fig 5.
Fig. 5 BRT-F011-T Speed Control
Control using rotary knob: Pressing the knob will turn on the motor at its last speed, and
pressing again will turn off the motor. Rotating the knob clockwise will increase the speed, and
rotating the knob counter-clockwise will decrease the speed.

Product Description of BRT-F011-T Page 4of 4
Shenzhen Asia Bright Industry co., Ltd., Building 10, Asia Industrial Park, Gangtou, Bantian, Shenzhen, China.
www.a-brt.com. [email protected].
© 2015 All rights reserved. Subject to change without notices.
Control using remote: Pressing the On/Off button will turn on the motor at its last speed, and
pressing again will turn off the motor. Pressing the “+” button will increase the speed, and
pressing the “-” button will decrease the speed.
Applications:
BRT-701 speed control switch is ideal for regulating the speed of all kinds of AC motors. It has
wide applications at various locations such as homes, schools, laboratories, hospitals, bar,
restaurant, etc, to control the speed of ventilation fans, pumps, or blowers.
