Iqua Freedom BHS-701 User manual

Bluetooth®Wireless Stereo Headset
BHS -701
User Guide

BHS-701_Headset_US_UG.fm Page 0Monday, August14,20061:02 PM

1
EN
BHS-701 sales package content
Overview of the product
a)
b)
c)
d)
8
BHS-701_Headset_US_UG.fm Page 1 Monday, August 14, 2006 1:02 PM

2
Product Specifications
Model: BHS-701
Size: 140 (L) x 166 (W) x 53 (H) mm
Weight: 83g
Talk time: Up to 12 h
Music playing time: Up to 10 h
Standby time: Up to 350 h
Charging time: Within 3.5h
Battery type: Li-Polymer battery
Bluetooth Standard: Bluetooth Spec. 1.2
Supported Bluetooth profiles: Handsfree 1.0 and Headset 1.1
A2DP, AVRCP
Connection: Point-to-point
Paired devices: Up to 8, one at a time
Operating distance: 10 meters
Operating temperature range: -20ºC to +55ºC
Storage temperature range: -20ºC to +55ºC
BHS-701_Headset_US_UG.fm Page 2 Monday, August 14, 2006 1:02 PM

3
EN
Contents
English ................................................................................................................4
Français ............................................................................................................15
Español .............................................................................................................27
Português ..........................................................................................................39
BHS-701_Headset_US_UG.fm Page 3 Monday, August 14, 2006 1:02 PM

4
Overview of the product
BHS-701 sales package content
(See page 1)
a) Stereo headset
b) Wall charger
c) User guide
d) Quick guide
e) Bluetooth dongle (market dependent)
Overview of the product (See page 1)
1. Indicator Light
Status indication with blue and red lights
2. Volume Down-button
Decreases the volume
3. Volume Up-button
Increases the volume
4. Multifunction-button
Power on/off, answer/end call, play/pause
music
5. Forward button
Forward to next song track
6. Backward button
Go back to the previous song track
7. Charging connector
8. How-to-wear the headset
Your Iqua BHS-701 is designed to be
comfortably worn behind your head with the
strap. The microphone is integrated in the
right earpiece.
BHS-701_Headset_US_UG.fm Page 4 Monday, August 14, 2006 1:02 PM

5
EN
Getting Started
Charging the battery
Before using BHS-701 for the first time, you must charge it for approximately 3.5 hours. When
the battery is fully charged, it provides up to 12 hours of talk time, 10 hours of music listening
time and up to 350 hours of standby time. Always use the charger provided in the sales
package.
1. Connect the charger cable to BHS-701.
2. Plug the charger into a wall socket. The red light will turn on.
3. When the battery is fully charged, the red light will turn off automatically.
Switching on and off
To switch on BHS-701
When the headset is powered off, press and hold the Multifunction -button until you hear a
sound and the blue light flashes.
To switch off BHS-701
When the headset is powered on, press and hold the Multifunction -button until you hear a
sound and the red light flashes once and then turns off.
BHS-701_Headset_US_UG.fm Page 5 Monday, August 14, 2006 1:02 PM

6
Pairing the BHS-701 and your mobile phone
Pairing is the process of linking BHS-701 with your compatible Bluetooth mobile phone*. After
this process is completed, you can use the BHS-701 with the paired mobile phone. If you want
to use the BHS-701 with another mobile phone, you must repeat the pairing process again.
Even though BHS-701 can be paired with up to 8 compatible phones it can only be connected
to one phone at a time. Once it is paired with 8 phones, the 9th paired device will replace the
1st paired device.
First time usage
When the BHS-701 is powered on for the very first time, it will enter pairing mode automatically
(blue and red lights flash alternately). Please follow the steps 3-6 below to pair your headset
with your phone.
Later on usage
After powered on, BHS-701 will automatically reconnect to the last-connected phone.
If the connection is failed due to phone not found, the headset will automatically enter into
pairing mode (blue and red lights flash alternately). Please follow the steps 3-6 below. If the
headset is not paired with any phone in 2 min. it will go to "powered on but no Bluetooth
connection" -mode (blue light flashes continuously). You can switch the headset off and switch
it on again.
* For latest compatibility information please visit www.iqua.com
BHS-701_Headset_US_UG.fm Page 6 Monday, August 14, 2006 1:02 PM

7
EN
To manually pair BHS-701 and your mobile phone:
1. When power is off, press and hold the Multifunction -button until you here a sound and the
blue and red lights start flashing alternately.
2. Release the button. BHS-701 is now in pairing mode.
3. Check your phone user guide for details on how to search and pair.
4. When phone has found the headset, it will show Iqua BHS-701 on its screen.
5. In order to pair with the phone, enter the PIN code of BHS-701, which is 0000.
6. After pairing, BHS-701 automatically connects with your mobile phone. Once pairing and
connection are succeeded, you will hear a sound and the blue light flashes every 3 seconds.
The headset is now ready to make and receive calls.
Disconnecting BHS-701 and your phone
To disconnect BHS-701 and the phone, simply switch off the headset.
Reconnecting the paired BHS-701 with the phone
To reconnect BHS-701 to the last phone used, simply switch on the headset and it will
automatically connect to the phone. If the connection is failed due to phone not found, the
headset will automatically enter into pairing mode (blue and red lights flash alternately).
Please see the pairing instruction in this user guide.
There are occasions when headset is temporarily out of Bluetooth operating range (up to
10 meters, e.g. user wearing the headset walks away from the phone), the headset will be
disconnected from the phone and user will hear a warning tone from the headset). Headset is
now in "powered on but no Bluetooth connection" -mode (blue light flashes continuously).
BHS-701_Headset_US_UG.fm Page 7 Monday, August 14, 2006 1:02 PM

8
Once the headset is back in range again, long press the Multifunction -button, the connection
will be re-formed. If the headset is out of range for less than 1 minute, it will reconnect to phone
automatically.
Call Functions
Answer a call
Press the Multifunction -button shortly to answer an incoming call. You will hear a sound
when the call is answered.
End a call
To end an active call, press shortly the Multifunction -button. You will hear a sound when the
call is ended.
Reject a call
When you receive an incoming call that you do not want to answer, press and hold the
Multifunction -button. You will hear a sound when call is rejected.
Redial the last dialed number
Press and hold the Multifunction -button until you hear a sound. Press and hold Multifunction
-button one more time until you hear a sound to dial the number.
BHS-701_Headset_US_UG.fm Page 8 Monday, August 14, 2006 1:02 PM

9
EN
Voice dialing (when supported by the phone)
To activate the voice dialing feature of your phone, shortly press Multifunction -button. When
you hear a sound, you can speak the voice tag. Refer to the user guide of your phone for
details. Some phone models do not support voice dialing.
Adjusting volume
Press the Volume Up -button to increase the volume. To decrease the volume, press Volume
Down -button.
Erase paired devices
The BHS-701 can be paired to up to 8 devices. Once it is already paired to 8 devices, the 9th
paired device will replace the 1st paired device. You can also erase the paired device list of
the headset in order to pair it with new devices. When headset is powered on, long press both
the Forward and Backward -buttons until you see purple LED light (the headset has erased
all previous paired device information).
Reset hardware
To reset the hardware, while the charger is plugged into the headset and headset is powered
on, shortly press both Volume Up and Volume Down- buttons simultaneously. The headset
will be powered off (light turns off) once the hardware is reset. You may do this hardware reset
and restart the headset in case the headset is jammed.
BHS-701_Headset_US_UG.fm Page 9 Monday, August 14, 2006 1:02 PM

10
Music functions
To Play
Make sure your headset is connected to mobile phone in Advanced Audio profile. Simply press
Multifunction -button to play the music on the headset.
To Pause
While listening to the music, press Multifunction -button to pause the music.
Skip one track forward
While listening to the music, press the Forward -button to change to the next song.
Skip one track back
While listening to the music, press the Backward -button to change to the previous song.
Fast forward
While listening to the music, press and hold the Forward -button.
Rewind
While listening to the music, press and hold the Backward -button.
BHS-701_Headset_US_UG.fm Page 10 Monday, August 14, 2006 1:02 PM

11
EN
Light indication summary
The BHS-701's LED lights can be blue or red and are usually accompanied by a sound signal.
•Blue light flashes continuously - power is on but no Bluetooth-connection.
•Blue light flashes every 3 second - headset in standby mode (paired and connected).
•Blue and red light flashing alternately - in pairing mode, waiting for user to complete
pairing with mobile phone.
•Red light flashes every 3 seconds - low battery.
•Red light on continuously - charging the battery.
Power Management
This product is powered by a built-in rechargeable battery which can not be changed. Do not
attempt to replace the battery. Rechargeable battery can be charged and discharged
hundreds of times, but it will eventually wear out. After a period of time that will vary depending
on the use and usage conditions you may find that the built-in battery will power your product
for only a couple of hours requiring you to charge more frequently.
Do charge your device only with the charger provided in the sales package. Unplug the
charger when not in use. Do not leave the device connected to the charger for longer period
than needed, since overcharging may shorten the battery lifetime.
If left unused a fully charged battery will discharge itself over time.
BHS-701_Headset_US_UG.fm Page 11 Monday, August 14, 2006 1:02 PM

12
Temperature extremes may affect the ability of the battery to charge. Always try to keep the
device between 15 °C and 25 °C (59 °F and 77 °F). Leaving the device in hot or cold places
such as in closed car in summer or winter conditions will reduce the capacity and lifetime of
the battery. A device with hot or cold battery may not work for a while even when the battery
is fully charged. Battery performance is particularly limited in temperatures well below
freezing. Do not charge in humid environment.
Care and Maintenance
– Do not expose the device to liquid, moisture or humidity as it is not waterproof.
– Do not use or store the device in dusty, dirty areas. Its moving parts and electronic
components can be damaged.
– Do not store the device in hot areas. High temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain plastics.
– Do not store the device in cold areas. When the device returns to its normal temperature,
moisture can form inside the device and damage electronic circuit boards.
– Do not drop, knock, or shake the device. Rough handling can break internal circuit boards
and fine mechanics.
– Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device.
– Use a soft, clean, dry cloth to clean any lenses.
– Do not expose your device to contact with sharp objects as this will cause scratches and
damage.
– Do not stick anything inside the device as this may damage internal components.
BHS-701_Headset_US_UG.fm Page 12 Monday, August 14, 2006 1:02 PM

13
EN
– Do not dismantle the device or the charger as they do not contain serviceable parts and
taking apart the device may expose you to dangerous voltages or other hazards.
Act according to your local rules and do not dispose of this product as part of your
normal household waste. Dispose of this product in a separate collection system
meant for recycling of electrical and electronic products.
How to get service for my IQUA Product?
If you believe that you are entitled to a repair or replacement of your IQUA product based on
your statutory rights under the applicable national laws relating to the sale of consumer
products or warranty given by the retailer who has sold the IQUA Product to you, please
contact your retailer.
DECLARATION OF CONFORMITY
We, Iqua Ltd., declare under our sole responsibility, that the product, BHS-701, conforms with
the provisions of the following Council Directive: 1999/5/EC.
0560
BHS-701_Headset_US_UG.fm Page 13 Monday, August 14, 2006 1:02 PM

BHS-701_Headset_US_UG.fm Page 14 Monday, August 14, 2006 1:02 PM

FR
15
Présentation de l'appareil
Contenu du coffret de vente du BHS-701
(Voir page 1)
a) Casque stéréo
b) Chargeur
c) Manuel d'utilisation
d) Guide rapide
e) Clé Bluetooth (selon le marché)
Présentation de l'appareil (Voir page 1)
1. Voyant lumineux
Renseigne sur l’état dans lequel se trouve
l’appareil à l’aide d’une lumière bleue et d’une
lumière rouge
2. Touche de diminution du volume
Permet de diminuer le volume
3. Touche d'augmentation du volume
Permet d'augmenter le volume
4. Touche multifonction
Permet d'allumer/d'éteindre l'appareil, de
répondre/mettre fin aux appels ou de lire/
mettre sur pause la musique
5. Touche piste suivante
Permet de passer à la chanson suivante
6. Touche piste précédente
Permet de retourner à la chanson précédente
7. Connecteur de chargement
8. Comment porter le casque
Votre Iqua BHS-701 se porte confortablement
derrière votre tête. Le microphone est intégré
à l'écouteur de droite.
BHS-701_Headset_UG_fr.fm Page 15 Monday, August 14, 2006 1:00 PM

16
Présentation introductive
Chargement de la batterie
Avant d'utilisez le BHS-701 pour la première fois, vous devez le charger pendant environ
3 heures et 30 minutes. Lorsque la batterie est entièrement chargée, l'appareil a une
autonomie de 12 heures en conversation, de 10 heures en mode de lecture de musique et de
350 heures en veille. Utilisez toujours le chargeur fourni dans le coffret de vente.
1. Raccordez le câble du chargeur au BHS-701.
2. Branchez le chargeur dans une prise murale. La lumière rouge s’allume.
3. Une fois la batterie complètement chargée, le voyant rouge s’éteint automatiquement.
Mise en marche et arrêt
Pour mettre le BHS-701 en marche
Lorsque le casque est éteint, maintenez la touche multifonction enfoncée jusqu'à ce que
vous entendiez un signal sonore et que la lumière bleue se mette à clignoter.
Pour éteindre le BHS-701
Lorsque le casque est allumé, maintenez la touche multifonction enfoncée jusqu'à ce que
vous entendiez un signal sonore et que la lumière rouge clignote une fois puis s'éteigne.
BHS-701_Headset_UG_fr.fm Page 16 Monday, August 14, 2006 1:00 PM

17
FR
Mise en liaison du BHS-701 avec votre téléphone mobile
La mise en liaison est le processus qui consiste à établir un lien entre le BHS-701 et votre
téléphone mobile compatible Bluetooth*. Une fois ce processus achevé, vous pouvez utiliser
le BHS-701 avec le téléphone mobile lié. Si vous souhaitez utiliser le BHS-701 avec un autre
téléphone mobile, vous devez répéter le processus de liaison. Même s’il est possible de relier
jusqu’à 8 téléphones compatibles avec le BHS-701, ce dernier ne peut être connecté qu’à un
seul téléphone à la fois. Une fois la liaison établie avec 8 téléphones, le 9ème appareil lié
remplace le 1er appareil lié.
Première utilisation
Lorsque le BHS-701 est allumé pour la première fois, il entre en mode de mise en liaison
automatiquement (les lumières bleues et rouges clignotent alternativement). Suivez les
étapes 3 à 6 ci-dessous pour mettre en liaison le casque avec votre téléphone.
Utilisation ultérieure
Après sa mise en marche, le BHS-701 se reconnecte automatiquement au dernier téléphone
auquel il a été connecté.
Si la connexion échoue parce que le téléphone est introuvable, le casque entre
automatiquement en mode de mise en liaison (les lumières bleues et rouges clignotent
alternativement). Suivez les étapes 3 à 6 ci-dessous. Si le casque ne se lie à aucun téléphone
en l'espace de 2 minutes, il passe en mode "allumé mais sans connexion Bluetooth" (la
lumière bleue clignote en continu). Vous pouvez alors éteindre le casque puis le rallumer.
* Pour obtenir les dernières informations concernant les produits compatibles, consultez le site
www.iqua.com.
BHS-701_Headset_UG_fr.fm Page 17 Monday, August 14, 2006 1:00 PM

18
Pour lier manuellement le BHS-701 à votre mobile :
1. Lorsque l'appareil est éteint, maintenez la touche multifonction enfoncée jusqu'à ce que
vous entendiez un signal sonore et que les lumières bleue et rouge se mettent à clignoter
alternativement.
2. Relâchez la touche. Le BHS-701 est maintenant en mode de mise en liaison.
3. Consultez le manuel d'utilisation de votre téléphone pour obtenir des informations détaillées
sur la procédure de recherche et d’établissement d’une liaison.
4. Une fois que le téléphone a localisé le casque, il affiche Iqua BHS-701 sur son écran.
5. Afin d’établir la liaison, entrez le code PIN du BHS-701, c’est-à-dire le code 0000.
6. Après la liaison, le BHS-701 se connecte automatiquement à votre téléphone mobile. Une
fois la liaison et la connexion établies, vous entendez un signal sonore et la lumière bleue
clignote toutes les 3 secondes. Le casque est alors prêt à émettre et recevoir des appels.
Déconnexion du BHS-701 de votre téléphone
Pour déconnecter le BHS-701 du téléphone, il vous suffit d'éteindre le casque.
Rétablissement de la connexion entre le BHS-701 lié et votre téléphone
Pour rétablir la connexion entre le BHS-701 et le dernier téléphone utilisé, il vous suffit
d’allumer le casque pour qu’il se reconnecte automatiquement avec ce téléphone. Si la
connexion échoue parce que le téléphone est introuvable, le casque entre automatiquement
en mode de mise en liaison (les lumières bleues et rouges clignotent alternativement).
Reportez-vous aux instructions relatives au processus de liaison, dans le présent manuel.
BHS-701_Headset_UG_fr.fm Page 18 Monday, August 14, 2006 1:00 PM
