1 GENERAL DESCRIPTION
1.1 INTRODUCTION
The Panel PC line PRISMA you have purchased is made are based on fanless CPUs technology,
using Intel chipsets for dynamic applications in any industrial process.
Besides HDDs for the OS, the following optionals are available upon request: SSD or mSATA
modules.
The MiniPCI -E interface can be used for other expansion boards such as wireless LAN or 3G board to
expand the device mobility.
1.2 NOTES
The instructions given in this manual are not a contractual obligation. The warranty conditions are
determined by law. The warranty is normally provided concerning malfunction of the product and
does not cover damages caused by misuse and tampering.
All rights are reserved. Any reproduction or translation of this manual is prohibited without our
permission.
1.3 WARNINGS
1.3.1 SYMBOLS AND CONVENTIONS
1.3.2 SAFETY
Read these safety instructions carefully. Keep this user’s manual for later reference and observing
all the warnings on the product as follow.
This symbol alerts the user to the risk of damage to things
or loss of data, if the observations are not respected.
This symbol warns the user of a hazard which may cause
serious injury or death, if the observations are not respected.
• Disconnect this equipment from any outlet before cleaning.

6 MNL236
ENGLISH
• Dropping the PPC fall may cause damage to people and
property.
• Make sure the voltage of the power source is correct
before connecting the equipment to the power outlet.
• If the equipment is not used for a long time, disconnect it
from the power source to avoid damages.
Store the equipment according to the temperature and humidity ranges written in this manual.
If any of the following situations arises, get the equipment checked by service personnel:
The power cord or plug is damaged.
• Liquid has penetrated into the equipment;
• The equipment does not work well, or you cannot get it to work;
• The equipment has obvious signs of breakage or damage.
This manual contains all instructions for proper installation and maintenance the product you
purchased. In the box packaging all the support documentation is provided.
1.4 RODUCT LABEL
All products are identifi ed with a production label that shows all the product’s identifying elements:
• Manufacturer’s mark
• Product Description
• Product Model
• Serial Number
• In the rear part, near the connection connectors, the product is
equipped with an earth socket identifi ed by the appropriate symbol.
Make sure that the earth cable is connected to the socket when it
is connected to machine. The power socket must be as close as
possible to the equipment and be easily disconnectable.

MNL236 7
ENGLISH
1.5 LIMITED RESPONSIBILITY DECLARATION
Any updates to the product could be the cause of updates to this manual, therefore the
manufacturer reserves the right to modify it, in whole or in part, without warning obligation.
The manufacturer also will not accept any liability for damage caused to people or things close to
it in the following cases:
• Misuse of the product and its accessories;
• Improper assembly and installation;
• Unauthorised, modifcation or interventions;
• Using not original spare parts;
• Failure to comply with the rules established by this manual.
Keep the manual with the utmost care in a dry place and protected, always available for
future reference. The manual should be kept as long as the product is in operating life.
In case of user’s manual loss or damage, ask the manufacturer for a new one.
1.5.1 MAINTENANCE AND WARRANTY
The product of this manual does not require any maintenance from the user besides the usual
cleaning of the screen, which must be performed with a specifi c non-aggressive, alcohol-free
cleaning agent, sprayed on a soft cloth. For product repair, the user shall contact the manufactur.
1.6 PACKAGING
The packaging consists of a cardboard box enclosing PP foam shells that guarantee the reliability
of delivery. Extract the product from the PP foam shells, check the product and remove the plastic
and PP foam shells and check that the following items are included:
• The PRISMA Panel PC;
• Documentation (this manual);
• The power plug;
• BIOS UTILITY CD;
• Driver CD.
Never open the equipment. For safety reasons, only qualified service personnel
should open the equipment.
Do not use sharp or scratching objects or corrosive substances that can damage
the active surface of the touch screen.

8 MNL236
ENGLISH
1.7 USAGE
This Panel PC is a computer complete with a monitor on which all the necessary programs can be
installed for a correct operation of the machine or of other devices connected to the machine.
The product can be placed on a surface (using specifi c optional supports) or by wall/ceiling mount
(using specifi c optional brackets) and connected to an Ethernet network if needed.
For further information on the various connections see chapter
For information on connections, see the following chapter: CONNECTIONS INFORMATION.
1.7.1 TOUCH SCREEN OPERATION
The touch screen used for the products mentioned in this manual are of resistive technology and are
designed to operate for at least 10 million of pressures. Designed for use on the LCD screen, the
glass plates of appropriate size have a coating of uniform resistivity. With a touch, the conductive
coating provides electrical contact with the conductive coating of glass. The diff erence in
potential created at the point of contact provides the exact position of the point touched. The electronic
command and control scans and sends this information to the computer for processing. For each
touchscreen is available a driver for device control that have to be loaded and calibrated with
the operating system provided with the motherboard. If there is no operating system preinstalled,
drivers will be provided in the packaging.

MNL236 9
ENGLISH
For the system specification see the CHAPTER HARDWARE CONFIGURATION
Power Supply
PFIxxZZ2 12Vdc Over-voltage
power protection
fuse
PFIxxZZ3 24Vdc
LCD Panel
Display
(Code PFIxxZZx)
Type Brightness Resolution Viewing Angle
18,5” B/L LED 300 nits 1366 x 768 (H/V) 170°/160°
Ambient temperature
Operational
Storage
Optional Wide Temperature Range
Operation
0 to +50°C
0 to +50°C
-20 to +70°C
-20 to +70°C
-10 to +60°C
-10 to +60°C
Relative humidity
Operational
Storage
Storage
10% ~ 95% @ 40°C, non-condensing
5% ~ 95%
Vibration
Operational
Storage
2 - 9 Hz: 3 mm amplitude / 9 - 200 Hz: 1 g
2 - 8 Hz: 7,5 mm amplitude / 8 - 200 Hz: 2 g / 200 - 500 Hz: 4 g
Shock Operation
Operational
Storage
15 g, 11 ms
30 g, 6 ms
Altitude Max. 3,000 m
2 GENERAL DESCRIPTION
• Class protection IP65: Compliant with CEI EN 60529
• Material used for the case: Aluminum
2.1 OPERATING CONDITIONS AND STORAGE
2.2 TECHNICAL FEATURES
Waterproof solution, frontal IP 65 rating for: 18,5”
• Available with 2 diff erents CPU (J1900, INTEL i5)
• PCT Touch screen
• SSD / mSATA
• RAM: 16MB (max) for i5 version and 8MB (max) for J1900 version

10 MNL236
ENGLISH

MNL236 11
ENGLISH
3 HARDWARE ONFIGURATION
3.1 18,5” TECHNICAL SPECIFICATION - INTEL MOBILE CORE™
CPU:
Intel Mobile Core™ i5 Processor mobile 45W power consumption.
System Chipset:
Intel QM77 express chipset.
BIOS:
64M DIP Flash ROM.
System memory:
Support 2 * 1066/1333/1600 MHz DDRII SO-DIMM (System max 16GB) and two function channels.
Expansion Slots:
1 * PCI slot (Optional).
1 * MINI PCI-E (Internal).
Audio:
Realtek ALC662 6-channel Audio Codec integrated.
Ethernet LAN:
Integrated Intel® 82574L and 82579LM Gigabit Ethernet.
Special features:
Support ACPI S3
Support CPU Smart FAN
Support Watch Dog
PC Port
• 2 x USB 2.0
• 2 x USB 3.0
• 2 x COM (3 - Optional)
• 2 x GIGABIT LAN (2 - Optional)
• 1 x DISPLAY PORT
• 1 x HDMI
• 1 x AUDIO
• 1 x VGA OUT
Power:
• 12Vdc
• 9-27Vdc (Optional)

12 MNL236
ENGLISH
3.2 18,5” TECHNICAL SPECIFICATION - INTEL ® J1900
CPU:
Intel® J1900 Quad-Core 2 GHz.
Chipset:
Intel® Bay trail SOC
Memoriy:
1xDDR3L -1600/1333 MHz SD RAM up to 8GB.
Display:
Integrated Intel® bay trail SOC
Ethernet Lan:
2 (max) x RTL8111F 10/100/1000Mbps ethernet PCI-E Gigabit LAN.
Storange:
1xSSD
1xSATAIII2.5inch notebook hard disk
1xSATA Hard disk interface for you choose
Audio:
Integrated ALC662 6 CHANNEL OUTPUT, Support MIC/Line-Out
Expansion Slots:
1xMini PCIe support WIFI/3G.
1xMSATA Support SSD/WIFI

MNL236 13
ENGLISH
2
VGA
(optional)
6
HDMI
3
LAN
4
USB
(esterne)
Second version
First version

14 MNL236
ENGLISH
2
VGA
(optional)
PIN NO. DESCRIPTION
1 RED
2 GREEN
3BLUE
4NC
5 GND
6 GND
7 GND
8 GND
9NC
10 GND
11 NC
12 DDCDAT
13 HSYNC
14 VSYNC
15 DDCCLK
4 CONNECTION INFORMATION
4.1 SERIAL PORT CONNECTOR
The COM serial Port are a standard DB-9 connector.
RS-485 FULL DUPLEX
Pin Signal
2 RXD -
3 TXD -
7 RXD +
8 TXD +
1
COM1
COM2
COM3
COM4
23
78
4.2 VGA CONNECTOR
The pc card has HDSUB type connectors 15 PIN for CRT VGA connections.
the VGA interface confi guration is done by the doftware utility, and no jumper settings is required.

MNL236 15
ENGLISH
4
USB 2.0
Pin Signal
1 VBUS
2 D -
3 D +
4 GND
5 StdA_SSRX−
6 StdA_SSRX+
7 GND_DRAIN
8 StdA_SSTX−
9 StdA_SSTX+
Shell Shell
5
USB 3.0
3
LAN
4.3 ETHERNET CONNECTORS
The RJ-45 connector is for ethernet. To connect the board to a 1000/100/10 base - T hub, just plug one
end of the cable into connector and connect the other end (phone jack) to a 1000/100/10 - base -T hub.
4.4 USB PORT CONNECTOR 2.0
This port connects the Pc with at USB cable
4.5 USB PORT CONNECTOR 3.0
This port connects the pc with an USB 3.0 Cable.

16 MNL236
ENGLISH
Pin Signal Pin Signal
1TMDS Data2+ 2TMDS Data2 (shielding)
3TMDS Data2- 4TMDS Data1+
5TMDS Data1 (shielding) 6TMDS Data1-
7TMDS Data0+ 8TMDS Data0 (shielding)
9TMDS Data0- 10 TMDS Clock+
11 TMDS Clock (shielding) 12 TMDS Clock-
13 CEC 14 (N.C)
15 SCL 16 SDA
17 Ground DDC/CEC 18 DC input +5V
19 Hot plug detect
6
HDMI
Connector
4.6 HDMI CONNECTOR

MNL236 17
ENGLISH
4.7 POWER SUPPLY CONNECTION
This Panel Pc is avalilable in two diff erent power supply version:
• 12 Vdc
• 24 Vdc
The connector is the
same for both versions
- +
- +

18 MNL236
ENGLISH
5 POLE SUPPORT MOUNTING
Panel pc is ready to be mounted on pole support and it is complete with connecting cables. Please
get the pole in position into area of usage and mount the keyboard support as indicated. Then
tighten the bolt.
Be Careful: please leave
the cables as indicate.
Please don’t put the
cables curves inwards

MNL236 19
ENGLISH
To install the device are
necessary at least 2 people

20 MNL236
ENGLISH
Once the cable are passed, please put the
PPC close to fi xing support and tighten
with screw.
Then fi x it with specifi c screws supplied.
