Energy Smart®Electric
Water Heater Controller
100261231
Installation, Operation and
Troubleshooting Instructions
®
Table of Contents
Installation and Setup, 2
Operation, 5
Troubleshooting, 7
Regulatory Notices, 11

2
INSTALLATION AND SETUP
1Get to know your Energy Smart®
Electric water heater controller.
With your new electric water heater controller, you can:
• Monitor and control your water heater with a smart
phone, tablet, or computer over your home’s wireless
(WiFi) network.
• Receive alerts when you’re low on hot water.
• Create custom water heating schedules that are
controlled by your computer or other device through
your home’s WiFi network.
Reset Button Beeper
Status LED
Figure 1.
MAC
Address
Label
2Review the requirements.
To get started, you will need:
• A working wireless (WiFi) network router with Internet
access.
• A personal computer, smart phone, or tablet computer
connected to your home’s WiFi network.
• One of the following water heater models:
ES2H40HD045V, ES2J40HD045V, ES2H50HD045V,
ES2J50HD045V, ES2J65HD045V, ES2H80HD045V,
ES2J80HD045V, ES40R92-45D, ES40R123-45D,
ES50R92-45D, ES50R123-45D, ES80H123-45D.
• One #2 Phillips screwdriver.
Read and follow all of the instructions, cautions, and
warnings in your water heater’s use and care guide.
WARNING! Even if the water heater’s temperature
control is set to a relatively low temperature, hot
water can scald. Install thermostatic mixing valves at
each point-of-use to reduce the risk of scalding.
3Install the Controller.
WARNING! Working on an energized circuit can result
in severe injury or death from electrical shock. Turn power
off before performing this installation. Check wires with a
non-contact circuit tester to make sure power is off.
S
tep 2:
Remove access cover.
Discard screws.
Longer screws
provided.
Do NOT remove
junction box covers. Connection Pins
Figure 2.
S
tep 1: Turn power off at source (circuit breaker).
are installed as described in step 4 above. Screws
must be installed to prevent equipment damage.
Step 4:
Secure controller
with the longer
screws (2). The
longer screws are
provided with the
controller.
Cover
Access
Port
Controller
Step 3: Plug controller
into water heater.
WARNING! Do not turn power on unless screws
Step 5: Turn water heater’s power back on according
to its use and care guide.
Step 6: Watch the water heater’s display screen for
the Grid icon to appear (Figure 3). This may
take a minute or so after power has been
turned on.
Step 7: Activate the screen by touching any button,
then releasing it.
Step 8: If the screen is locked, touch and hold the
Lock button for at least 5 seconds. The Lock

3
icon will disappear from the screen. This
indicates that the control buttons have been
unlocked. See Figure 3.
Step 9: Touch the Grid Enabled button (top right).
The Grid Enabled button must be lit before
continuing with the set up.
°F/°C
F
GRID
ENABLED
VACATION
STANDARD
ENERGY
SMART
LOCK
ELEMENT ALERT GRID
Figure 3.
Water Heater User Interface
(located on the front of your Energy Smart®
electric water heater).
Grid Enabled Button
Lock Button
Grid Icon
NOTE: The appearance of the
screen and icons may vary.
4Complete Setup.
Step 1: Check the Status LED on the controller.
The Status LED should brighten gradually, then
dim suddenly. If it does not brighten gradually
and dim suddenly, press the reset button 8
times with a paper clip (about once per second)
until you hear a beep. See Figure 1. The beep
indicates that the controller has been reset.
Step 2: Open a wireless network control panel on your
device (computer, smart phone or tablet).
A list of available wireless networks should be
displayed (Figure 4).
Step 3: Disconnect your device (computer, smart
phone or tablet) from your home’s WiFi
network.
You will connect to a different network during the
next step.
Example: List of SSIDs Displayed in
Available Wireless Networks
Figure 4.
Step 4: Select the “energySmart” network (Figure 5).
Your device (computer, smart phone or tablet)
will connect to it.
Select “energySmart” Network
Figure 5.
Step 5: Once your computer is connected to the
energySmart network,
A. Open a browser window.
B. Type 192.168.10.1 into the browser’s Ad-
dress or Location bar, then press [Enter].
See Figure 6.
NOTE: The page may load automatically when
the browser window is opened.
Browser’s Address/Location Bar
Figure 6.
Step 6: Follow these steps to connect the controller
to your network:
A. Locate your home’s wireless network in the
list (Figure 7).

4
B. IMPORTANT: If your router is set to hide
its SSID, look for its MAC address instead.
You will be asked to enter its SSID during
the next step.
C. Click the “Join” button next to your home’s
wireless network (Figure 7).
D. If necessary, type your wireless network
password in the dialog box, then click OK.
E. When you have connected successfully, the
Status LED will be on steady (no blinking,
flashing, or dimming). However, if you don’t
get a steady LED status light, repeat all
steps in this section.
Step 7: Reconnect your device (computer, smart
phone or tablet) to your home’s wireless
network.
Step 8: Register and sign in as described in the next
step.
5Get started with Iris®.
Before you try to sign in, check the following:
• The Energy Smart®Electric Water Heater Controller
must be connected to your home’s wireless network.
• Your home’s wireless network must be connected to
the Internet.
• The controller must be enabled before you can
control and monitor your water heater through Iris®.
See “
3
Install the Controller,” Steps 6 through 9.
For more information about your water heater’s user
interface, see your water heater’s use and care guide.
To get started with Iris®, follow these steps:
Step 1: Register, then sign in to your Iris®account at:
www.lowes.com/iris
Step 2: Click the ‘Add Devices’ button.
Step 3: Follow the on-screen instructions.
Customer Care
If you need assistance, call 855-469-IRIS. Help is also
available at www.lowes.com/iris/support.
{MAC Address}
{MAC Address}
Your Wireless Network
Figure 7.
OTHER

5
OPERATION
User Controls and Indicators
Reset Button Beeper
Status LED
Figure 8.
MAC
Address
Label
°F/°C
F
GRID
ENABLED
VACATION
STANDARD
ENERGY
SMART
LOCK
ELEMENT ALERT GRID
Figure 9.
Water Heater User Interface
(located on the front of your Energy Smart®
electric water heater).
Grid Enabled Button
Lock Button
Grid Icon
NOTE: The appearance of the
screen and icons may vary.
Status LED
The green LED on top of the controller indicates its
connection status or error state as described below. See
Figure 8.
See Troubleshooting for an explanation of each flash
code (page 8).
Beeper
Audible beeps indicate status changes that require your
attention. If you hear a beep, refer to the Troubleshooting
section to determine its meaning.
Reset Button
The reset button is located toward the center of the
electric water heater controller (Figure 1).
To reset the controller and put it in Access Point (AP)
Mode:
1. Press the reset button 8 times with a paper clip
(about once per second) until you hear a beep. See
Figure 8.
The beep means that the controller has been
disconnected from the WiFi network and has been
reset.
2. If you can’t connect to an SSID in the available
networks list, repeat step 1. (See Figures 5 & 7).
This may be necessary in areas with multiple WiFi
signals or when the WiFi signal strength is weak.
To restart the controller without going into Access Point
(AP) Mode:
1. Press and hold the reset button down until you hear a
beep (about 12 seconds).
2. Release the button. The controller will reconnect
to the web server. However, it will not default to AP
Mode.

6
Enabled / Disabled
Enabled
To control your water heater through Iris®, your controller
must be enabled and connected. It is enabled when the
Grid Enabled button is lit up (backlit). See Figure 9.
To enable the controller:
1. Unlock the water heater’s user interface (if it is
locked). To do so, touch the lock button for at least
5 seconds. The Lock icon will disappear from the
screen.
2. Touch the Grid Enabled button until it lights up
(backlit).
Disabled
While disabled, all water heater parameters can be
viewed through Iris®, but they can only be changed
through the water heater’s user interface. This safety
feature can be used to ensure local control only.
The controller is disabled if:
• The Grid Enabled button is not lit up (not backlit)
• The controller’s LED is flashing “3 seconds ON, 3
seconds OFF.”
IMPORTANT: In the event of a power outage, the Grid
Enabled Button will turn OFF automatically. See Figure 9.
Enable it as described in Enabled above.
To disable the controller so that the water heater can only
be controlled locally:
1. Unlock the water heater’s user interface (if it is
locked). To do so, touch the lock button for at least
5 seconds. The Lock icon will disappear from the
screen.
2. Touch the Grid Enabled button until its light goes out
(no longer back lit).
Parameters
You can monitor and control the following water heater
parameters through Iris®: operating mode, temperature
set point (up to Maximum Set Point), and heating
schedule. Estimated Hot Water Level may be viewed
through Iris®.
For safety reasons, your temperature setting through Iris®
cannot exceed the temperature that is programmed into
your water heater’s user interface.
For example, if the user interface on the water heater is
set at 120°F, the set point range in Iris®would be 80°F to
120°F. 120°F would be the Maximum Set Point.
WARNING! Even if the water heater’s temperature
control is set to a relatively low temperature, hot
water can scald. Install thermostatic mixing valves at
each point-of-use to reduce the risk of scalding.
Read and follow all of the instructions, cautions, and
warnings in your water heater’s use and care guide.
Parameter List
When you change any of the following parameters, the
new values will only display on the web user interface.
The remote settings will not be displayed on the water
heater’s user interface, but this will not effect your
intended settings.
Mode
Standard, Energy Smart and Schedule
Set Point
Temperature setting range: 80°F to 150°F (27°C to 65°C).
NOTE: Your temperature setting through Iris®cannot
exceed the temperature that is programmed into the water
heater’s user interface.
Heating Schedule
This parameter allows you to set water heating schedules
through Iris®.
Estimated Hot Water Level
The estimated hot water level may be viewed through Iris®.
This parameter is not configurable.

7
TROUBLESHOOTING
Frequently Asked Questions
Q. The power to my house went out. When it came
back on, I couldn’t control my water heater
through Iris®. What’s wrong?
A. In the event of a power outage, the Grid Enabled
Button will turn OFF automatically. When it does,
the controller is disabled and your water heater
cannot be controlled through Iris®. To restore
functionality, follow the instructions in the Enabled
section, page 6.
Q. I’m trying to increase the water temperature
setting though Iris®. It doesn’t work. Why won’t
it work?
A. For safety reasons, your temperature setting
through Iris®cannot exceed the temperature that
is programmed into your water heater’s user
interface. For example, if your water heater itself is
set to 110°F, then 110°F is the highest temperature
setting allowed in Iris®. Check your water heater’s
temperature setting and adjust as necessary.
Q. One of the parameters shown in Iris®is different
than what is displayed on the water heater’s
user interface. Is this okay?
A. Yes. The controlling parameters are displayed in
Iris®. See Parameters on page 6.
Continued on the next page.

8
Status LED Flash Codes
Status LED: Brief flash On/Off
Description Power Up
Beeper One Brief Beep
Reset Button Effect N/A
Notes / Remedy This flash code occurs when the controller is powering up. See Note 1 at
the end of the troubleshooting section.
Status LED 3 Seconds On, 3 Seconds Off
Description Controller Disabled
Beeper None
Reset Button Effect A reset will change the controller’s state to Access Point (AP) mode. To
reset the controller, press the reset button 8 times with a paper clip (about
once per second) until the controller beeps.
Notes / Remedy This flash code indicates that the controller is disabled. (This may occur
following a power outage.) To enable the controller, unlock the water
heater’s user interface and touch the Grid Enabled button. The Grid
Enabled button LED will turn on. See Figure 9.
NOTE: When unlocking the user interface, you must touch the lock button
for at least 5 seconds. The Lock icon will disappear from the screen.
The following status LED codes will not display when the wireless
controller is disabled:
• Steady On, Brightens Briefly (Connected & Posting).
• Steady On (Connected & Waiting).
• Brightens Gradually, Dims Gradually (Search Mode).
• Brightens Gradually, Dims suddenly (Access Point [AP] Mode).
• 2 Flashes, PAUSE, 3 Flashes, PAUSE, 3 Seconds On, Off
(No Connectivity).
Continued on the next page.

9
Status LED: Brightens gradually, dims suddenly.
Description Access Point (AP) Mode
Beeper None
Reset Button Effect A reset will cause the controller to re-scan the WiFi networks.
To reset the controller, press the reset button 8 times with a paper clip (about once per
second) until the controller beeps.
Notes / Remedy This state occurs when a new controller is powered up. It will also occur after the wireless
controller has been reset. In this mode, the wireless controller will operate as an access
point to connect to a WiFi local network. See Note 2 at the end of the troubleshooting
section.
Status LED: Steady on, brightens briefly when posting.
Description Connected & Posting
Beeper None
Button Press Effect To change the controller’s state to Access Point (AP) mode, press the reset button 8 times
with a paper clip (about once per second) until the controller beeps.
To restart the controller, press and hold the reset button down until you hear a beep (about
12 seconds), then release. The controller will reconnect to web server.
Notes / Remedy Normal Operation
Continued on the next page.
Status LED Flash Codes (Continued)

10
Status LED: Steady On
Description Connected & Waiting (No Internet Connectivity)
Beeper None
Button Press Effect To change the controller’s state to Access Point (AP) mode, press the reset button 8 times
with a paper clip (about once per second) until the controller beeps.
To restart the controller, press and hold the reset button down until you hear a beep (about
12 seconds), then release. The controller will reconnect to web server.
Notes / Remedy This state occurs when the internet connection drops while the controller is Connected &
Posting. The controller is still connected to the local WiFi network. Check your router’s
internet access.
Status LED: 2 Flashes, PAUSE, 3 Flashes, PAUSE, 3 Seconds On, Off. (Repeats.)
Description No Connectivity
Beeper None
Button Press Effect None
Notes / Remedy Call 855-469-IRIS. Help is also available at www.lowes.com/iris/support.
Status LED: Brightens Gradually, Dims Gradually.
Description Search Mode
Beeper None
Button Press Effect To change the controller’s state to Access Point (AP) mode, press the reset button 8 times
with a paper clip (about once per second) until the controller beeps.
Notes / Remedy This state occurs when the WiFi connection drops while the controller is Connected &
Posting. (Example: Router power turned off, etc.)
• Verify that the router is powered.
• Verify that the controller is enabled. See
“Install the Controller” on page 2 (steps 6
through 9).
Continued on the next page.
Status LED Flash Codes (Continued)

11
Status LED: OFF
Description Power OFF
Beeper None
Button Press Effect None
Notes / Remedy See Note 1.
NOTES:
1. If power is lost and then turned back on again (power OFF/ON), the controller will be disabled and the water heater
will be controlled locally. (The LED status will be “3 seconds On, 3 seconds Off”.) To re-establish remote control and
monitoring, enable the controller. To enable the controller, unlock the water heater’s user interface and touch the Grid
Enabled button. The Grid Enabled button LED will turn on. See Figure 9.
NOTE: When unlocking the user interface, you must touch the lock button for at least 5 seconds. The Lock icon will
disappear from the screen.
2. While in AP mode, certain conditions can interfere with connecting your WiFi device to the controller. Some of the
things that may inhibit connection are multiple/strong WiFi signals, long distances, working microwave ovens, and
walls between the router, controller, and WiFi device.
These and other conditions may make connecting to a network problematic. In such cases, reset the controller by
pressing the reset button 8 times with a paper clip (about once per second) until the controller beeps. This will prompt it
to find better broadcasting parameters. Also, changing the location of the WiFi device can improve this process.
REGULATORY NOTICES
FCC (United States)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, (2) This
device must accept any interference received including
interference that may cause undesired operation.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instruction manual, may cause interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause interference to radio or
television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician.
CAUTION: Changes or modifications to this equipment
not expressly approved by the party responsible for
compliance (A.O. Smith Corporation) could void the
user’s authority to operate the equipment.
ICES-003 (Canada)
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.

12
Copyright © 2014 A.O. Smith Corporation.
All Rights Reserved.
Energy Smart®is a registered trademark of American Water Heater Company. All Rights Reserved.
IRIS and IRIS and Wave Design are trademarks or registered trademarks of LF, LLC. All Rights Reserved.
