IROAD QX2 User manual

IROAD QX2
Quick Start
Ver 1.2 (MAR. 2023)

English
Quick Start

PRECAUTIONS
3
※
※
※
※
※
※
※
※
※
Do not arbitrarily disassemble and modify the product.
It should be considered user’s fault and it will void the warranty.
Do not handle the product while driving, it can cause serious accidents.
(Please operate the product in a safe place after parking.)
Turn recorder off when exposed to direct sunlight or used for too long.
Otherwise, malfunction or breakdown will occur.
Do not remove SD card or turn off the power cable during the firmware update.
It may cause malfunction or loss of data.
Use of genuine IROAD memory card is recommended.
Failure to use genuine SD card may cause error or malfunction.
Real-time recording and playback via Wi-Fi could be delayed depending on the
specifications of your smart device.
Motion detection is initiated by an image sensor software.
Errors may occur depending on the surrounding environment and the voltage of the car.
If the GPS signal is good, ADAS will activate when the speed of the car is above the set
speed. The surrounding environment may cause errors.
Unauthorized connection of the uninterrupted power cable may cause malfunctions.
Connections must be different depending on the power type of the vehicle.
(Please contact a professional engineer if you need help to install it)

4
WARRANTY
IROAD Global guarantees the quality of the item.
Only signed members can use this Warranty.
Transferring and lending the card to others is strictly not allowed.
Warranty period of each part is as follows.
Product(Front/Rear Camera) : 1 Year / Memory Card : 6 Months
Cable(for Fuse,Rear,Cigar Power), Wifi Dongle : Does Not Cover
[IMPORTANT] Please keep this WARRANTY page to make use of after-sale-service!
●
●
●
PRODUCT NAME
SERIAL NUMBER
DATE OF PURCHASE
SUPPLIER SHOP NAME
CONTACT NUMBER

SPECIFICATIONS
Model
Image Sensor
Resolution
Viewing angle
Wi-Fi supported
Wi-Fi button
Audio input
Video/Audio
Vibration Sensor
Voice guidance
Built-in GPS
Storage medium
Recording mode
Uninterrupted
power
Power supply
Operating temperature
Humidity
Dedicated PC viewer
Application
Front : Sony STARVIS 5.0M CMOS Sensor
Rear : Sony STARVIS 2.0M CMOS Sensor
Front : QUAD HD 2560x1440p / Rear : FULL HD 1920x1080p
Front : 145° / Rear : 145°
Smartphone Playback/Settings, Firmware Update
Activate "Stand-by Mode for Registration"
Embedded MIC
H.264 / PCM
3-axis Acceleration Sensor
Effect sound/buzz alerted to inform the condition of the device
Voice guidance supported
Synced with Google Maps,
records the location and travelling speed of the vehicle
Micro SD 32GB ~ 256GB (Class10)
Driving(Normal, Hyperlapse), Event(Impact), Parking(Timelapse,
Motion Detection)
Uninterrupted Power
(Low voltage cut-off, overheating prevention is embedded)
DC 12V/24V
-10 ~ 60° C
10 ~ 95%
Win7, Win8, Win10 (64Bit), Mac (macOS 11.0 or higher)
Android 6.0, iOS 13.0 or higher
5
IROAD QX2

PACKAGE
6
Basic Components
Front Camera
/ Cradle Rear Camera / Cradle Uninterrupted Fuse Cable
IROAD Genuine
MicroSD Wi-Fi USB Dongle User Manual
Rear Camera
Cable
The Basic components may change without prior notice.
●
Optional Items
Cigar Jack
Power Cable OBD-Ⅱ Power Cable (Non-Electric / Eletric) USB MicroSD Reader

BUTTON SCENARIO GUIDE
7
POWER OFF / ON
MODE OPERATION
EXPLANATION
POWER OFF “Shutting down the system.” will be signaled,
and the device will be powered off.
OPERATION
POWER ON “Starting recording.” will be signaled,
and the device will be powered on.
Press and hold the button ( )
for 3 seconds long.
Press and hold the button ( )
for 3 seconds long.
Wi-Fi OFF / ON
MODE OPERATION
EXPLANATION
Wi-Fi OFF “Wi-Fi power is off.” will be signaled,
and Wi-Fi connection will be unavailable.
OPERATION
Press the button ( )
for 1 seconds long.
“Ding” sound will signal.
Wi-Fi ON “Wi-Fi power is on.” will be signaled,
and Wi-Fi connection will be available.
Press the button ( )
for 1 seconds long.
“Ding” sound will signal.
※
※
※
※
When 'OFF', the consumption power is reduced by 0.3w and the device operating time is increased by 10%.
'Wi-Fi ON/OFF' function allowing Users to turn Wi-Fi power on/off.
Do not confuse it with 'Wi-Fi registration button'.
When connecting to a smartphone, you must press 'Wi-Fi registration Button'
Smartphones that have already been registered previously, users do not have to
re-register even if the Wi-Fi on/off function was used
Default setting - Wi-Fi function is ON.

AUDIO RECORDING OFF / ON
MODE OPERATION
EXPLANATION
AUDIO
RECORDING OFF
“Voice recording is OFF.” will be signaled,
then videos will be recorded without audio.
OPERATION
Press the button ( )
for 4 seconds long.
“Ding-Dong” sound will signal.
AUDIO
RECORDING ON
“Voice recording is ON.” will be signaled,
then videos will be recorded with audio.
Press the button ( )
for 4 seconds long.
“Ding-Dong” sound will signal.
BUTTON SCENARIO GUIDE
8
Wi-Fi STAND BY MODE OFF / ON
MODE OPERATION
EXPLANATION
Wi-Fi STAND BY
MODE OFF
“Stand-by mode for registration is deactivated.”
will be signaled,
and Wi-Fi connection cannot be initiated.
OPERATION
Press the button ( )
shortly.
“Ding-Dong” sound will signal.
Wi-Fi STAND BY
MODE ON
“Stand-by mode for registration.”
will be signaled,
and Wi-Fi connection can be initiated.
Press the button ( )
shortly.
“Ding-Dong” sound will signal.

BUTTON SCENARIO GUIDE
9
MANUAL RECORDING
MODE OPERATION
EXPLANATION
MANUAL
RECORDING
“Manual recording.” will be signaled,
and manual recording will start.
OPERATION
Press the button ( )
shortly.
FORMATTING THE MICROSD CARD
MODE OPERATION
EXPLANATION
FORMATTING
THE MICRO SD
CARD
“SD Card is formatting. Please wait.”
will be signaled,
then the SD card will be formatted.
OPERATION
Press the button ( )
for 7 seconds long.

10
USING THE MOBILE APP
ANDROID DEVICE
On your Android device, open “Google Play Store” and download and install
“IROAD X VIEW”
1
After running the application, register your device.
- Activate the registration stand-by mode by pressing the Wi-Fi registration button
“Stand-by mode for registration” (Voice guidance)
2
Tap Connect Now
- From the IROAD X VIEW, select your dashcam.
- The SSID and model will be shown.
- Once the user selects the device, it will be registered & connected.
3
iOS DEVICE
On your iOS device, open “App Store” and download and install
“IROAD X VIEW”
1
After running the application, register your device.
- Activate the registration stand-by mode by pressing the Wi-Fi registration button
“Stand-by mode for registration” (Voice guidance)
2
Tap Connect Now
- follow the on-screen instructions to connect the product to your smartphone.
3
Select the Wi-Fi Network
- From the Wi-Fi setting menu on your smartphone, select the Wi-Fi network starting
with “IROAD”
4
Enter Password
- Enter “qwertyuiop” in the password field
Now the product is connected to your iOS device via Wi-Fi
5
The password is the first row of the alphabet on the keyboard
●

11
USING THE MOBILE APP
Main Screen
- Displays information about the connected product.
- Access to the live view screen.
- Access to the recorded videos.
- Configuring the dashcam settings.
A
Playback recording for Front / Rear Camera
- Playback the recorded videos.
- Choose video clip from the list and save it.(Video or Image)
B
Configuration System
- Configuring the dashcam settings.
(Once settings change the device will be rebooted)
C
CBA
2021.07.30 10:30:15
2021.07.30 10:30:15
2021.07.30 10:30:15
2021.07.30 10:30:15
2021.07.30 10:30:15
Normal
Normal
Normal
Normal
Normal
2021.07.30 10:30:15 0 km/h
Normal
info
Security LED
Battery Protection
Power OFF 12V / 24V
LOW BATTERY PROTECTION
System
SECURITY LED
high temperature shutdown
HIGH TEMPERATURE SHUTDOWN
Connect with Dash cam
IROAD DASH CAM
live view Recording list Settings
2CH QXD / FHD
Setting Language : Dash cam setting > System > System language > Change language.
English is the default language.
●
●

12
USING THE PC VIEWER
1
2
1
Front/Rear video playback screen
1
Video controller
2Map / Full-screen
Switch screens (Front / Rear)
6
Dashcam settings
Minimize / Maximize / close the PC viewer
7
Speed indicator
(only when GPS is connected)
3
Recording file list
5
G-sensor information
4
The following provides brief information about the PC VIEWER screen layout.
3
5
6
7
4

中文 (简体)
快速入门指南

注意事项
14
※
※
※
※
※
※
※
※
※
请勿随便拆卸或维修产品。
此为用户过失，无法保修。
驾驶途中请勿操作设备，可能引发事故。
(请将车辆停稳,再进行操作。)
在暴露于阳光直射或长时间使用的情况下请关闭行车记录仪。
否则，容易发生故障。
更新固件的过程中，请勿拔掉SD卡或电源线。
可能导致发生故障或者信息缺失。
请使用原装正品IROAD记忆卡。
如不使用原装正品，可能导致故障发生。
根据智能设备的参数，实时记录和监控记录录像回放可能会有所延迟。
移动侦测由图像传感器软件启动。
车辆电压和周边环境会导致故障发生。
如GPS信号良好，ADAS功能会由设置的速度值运行。
周边环境有可能导致故障发生。
随便连接不间断电源可能引发故障，请勿随便连接不间断电源。
电源连接根据车辆电源而定。
(如需安装，请咨询专业技术人员。

按钮指南
15
关上 / 开上 电源
模式 操作说明
关上 电源 将发出“关闭系统”信号，并关闭设备电源。
操作
按下 ( )键 3秒。
开上 电源 设备开机时将发出“开始录制”信号。按下 ( )键 3秒。
Wi-Fi关闭 / 开启
模式 操作说明
Wi-Fi关闭 将发出“Wi-Fi信号关闭”信号，
并且Wi-Fi连接将不可用。
操作
按 ( )键 1秒并释放。
“叮”声将发出信号
Wi-Fi开启 将发出“Wi-Fi信号开启”信号，
并且Wi-Fi连接将可用。
按 ( )键 1秒并释放。
“叮”声将发出信号
※
※
※
※
当Wi-Fi为“关闭”时，电耗将降低0.3w，行车记录仪运行时间将增加10％。
'Wi-Fi 开启/关闭'功能允许用户开启/关闭Wi-Fi电源。
不要将它与“Wi-Fi注册按钮”混淆。
连接智能手机时，用户需要按“Wi-Fi注册按钮”。
对于之前已经注册过的智能手机，即使使用了Wi-Fi开/关功能，用户也无需重新注册。
默认设置 - Wi-Fi功能开启。

录音关闭 / 开启
模式 操作说明
录音 关闭 “停止录制声音”。
将发出信号，并将录制没有音频。
操作
按下 ( )键 4秒钟。
“叮咚”的声音会发出信号。
录音 开启 “开始录制声音”。
将发出信号，并将录制音频。
按下 ( )键 4秒钟。
“叮咚”的声音会发出信号。
按钮指南
16
Wi-Fi 注册待机模式开启/关闭
模式 操作说明
Wi-Fi
注册待机模式开启
“注册的待机模式”。
将发出信号，并启动Wi-Fi连接。
操作
短按 ( )键。
“叮咚”的声音会发出信号。
Wi-Fi
注册待机模式关闭
“注册的待机模式已关闭”。
将发出信号，并且无法启动Wi-Fi连接。
短按 ( )键。
“叮咚”的声音会发出信号。

按钮指南
17
手动录影
模式 操作说明
手动录影 将提示“手动录影。”，
并开始手动录影。
操作
短按 ( )键。
格式化SD卡
模式 操作说明
格式化SD卡 将提示“正在格式化SD卡，请稍候，开始录制”，
格式化SD卡。
操作
按下 ( )键 7秒钟。

18
使用手机APP
安卓手机
在您的安卓设备上，打开“Google Play Store”并下载并安装“IROAD X VIEW”
1
打开APP后，注册您要连接的行车记录仪
- 按Wi-Fi注册按钮“注册待机模式”（语音指导）激活注册待机模式
2
点击立即连接
- 在 IROAD X VIEW 中，选择要连接的行车记录仪，点击下一步。
- 搜索到的行车记录仪将显示 SSID 和设备型号。
- 用户选择设备后，手机将进入加载屏幕。
加载完成后，设备将被注册和连接。
3
iOS 设备
在您的iOS设备上，打开“App Store”并下载并安装“IROAD X VIEW”
1
打开APP后，注册您要连接的行车记录仪
- 按Wi-Fi注册按钮“注册待机模式”（语音指导）激活注册待机模式
2
点击立即连接
- 按照屏幕上的说明将行车记录仪连接到手机。
3
选择Wi-Fi网络
- 从智能手机的 Wi-Fi 设定中，选择以“IROAD”开头的 Wi-Fi 网络
4
输入密码
- 在密码字段中输入“qwertyuiop”，然后点击加入
本产品已通过 Wi-Fi 连接到您的 iOS 设备
5
密码是键盘上字母的第一行
●

19
使用手机APP
2021.07.30 10:30:15
2021.07.30 10:30:15
2021.07.30 10:30:15
2021.07.30 10:30:15
2021.07.30 10:30:15
Normal
Normal
Normal
Normal
Normal
2021.07.30 10:30:15 0 km/h
Normal
info
Security LED
Battery Protection
Power OFF 12V / 24V
LOW BATTERY PROTECTION
System
SECURITY LED
high temperature shutdown
HIGH TEMPERATURE SHUTDOWN
主屏幕
- 显示相关产品的信息。
- 移动到实时录影屏幕。
- 查看和播放录制的视频。
-查看或更改行车记录仪设置。
A
回放前置/后置镜头录影
- 查看和播放录制的视频。
- 从列表中选择一个视频并储存。 （视频或图像）
B
设定系统
- 查看或更改行车记录仪设置。 （保存更改后，设备将重新启动）
C
CBA
Connect with Dash cam
IROAD DASH CAM
live view Recording list Settings
2CH QXD / FHD
设置语言：行车记录仪设置 > 系统 > 系统语言 > 更改语言.
英语是默认语言.
●
●
