iroda TG-600V User manual
TG-600V
GLUE GUN
• Readinstructionsbeforeuse.
• DONOTrell,igniteorusenearopename,heater,furnaceor
combustiblematerials.
• KEEPAWAYFROMCHILDREN.
• Useonlyhigh-qualitybutanegas.
• Donottouchheatedtipduringuse,orbeforesucienttimehas
passedforcooling.
• Alwaysbesuretheunitiscoolbeforestoring.
• Storeproperlywhennotinuse.
• Keepinadryplace,outofthereachofchildren.
• DONOTleaveunitunattendedwhenoperatingorhot.
• IfyourTG-600Vmalfunctionsdonottrytorepair.Contactyour
dealeroronlinesupportforhelp.
3
IMPORTANT SAFETY INSTRUCTIONS
Warnings:
GlueStick
RearChamber
FuelControlWheel
FoldingRest
Stand
Trigger FuelCartridge
Chamber
FillingValve
IgnitionButton
DESCRIPTION
2
LiquidEnergyCell
(LEC)
HOW TO USE THE TG-600V INSERT LEC INTO TG-600V
INSERT GLUE STICK
REFILLING LEC
• Useonlyhigh-qualitybutanegas.
• Rellinawell-ventilatedareaawayfromany
ignitionsourceandotherpeople.
1. RemoveFuel Cartridge Chamber Cap
atbottomofTG-600V.(Fig.2.1)
2. InsertLECintochamberwithblue at
side toward inside of chamber.
3. ReplaceChamberCap.(Fig.2.2)
1. Placegluestickinrearchamber.(Fig.3)
2. Pushforwarduntilgluestickstops.
3. Ifusingshortsticksorforcontinuous
use,insert2sticks,onebehindtheother.
4. Waitseveralminutesafterinsertingfor
gluetoreachowtemperature.
1. Holdbutanecanisterupsidedownwhenlling
(Fig.1)
2. Firmlypressnozzleofbutanefuelintothe
Filling ValveoftheLEC.
3.Stopllingwhengasoverows.(Gasoverow
duringrellingisnormalanddoesnotindicatealeak)
4.Waitforafewminutesbeforeuseforgastostabilize.
Fig.1
Fig.2.1
Fig.2.2
Fig.3
(LiquidEnergyCell)
Butane
45
67
ADVANCE GLUE STICK IGNITE
TURN ON FUEL
• PullTriggerbackgentlytowardshandle.
(Fig.4)
• PushupFuel Control Wheelandturn
wheeltotheright.(Fig.5)
Fig.4 Fig.6.1
Fig.5 Fig.6.2
1. Pushred Ignition Buttonuntilignited.
(Fig.6.1)
2. Tipwillstarttoglowred.(Fig.6.2)
3. Allow3-5minutestoallowglueto
soften
8 9
DISPENSE GLUE NOTE
TROUBLE SHOOTING
USING REST STAND
TURN OFF UNIT
• GentlysqueezeTriggeruntildesiredamount
ofglueisdispensed.(Fig.7)
AftertheTG-600Vcoolsandisusedatalatertime,itisnormalfor
upto1"ofhardenedgluetobedispensedbeforehotglueows
fromnozzle.
• Toreducetheriskofpersonalinjury,propertydamage,ordamage
toyourTG-600V,donotattempttorepairtheunitbody.
• PulldownmetalFolding Stand.(Fig.8)
• Positionguninstandwhennotactivelyusing.
• RotateFuel Control Wheel (Fig.9)leftuntil
theendanditsnapsintolockedposition.
• Toavoidclogging/drippingafterusepullback
thegluestickabout1".
Fig.7
Fig.8
Fig.9
• Thisproduct,whenusedforsolderingandsimilarapplications,
produceschemicalsknowntotheStateofCaliforniatocause
cancerandbirthdefectsorotherreproductiveharm.
• DepartmentofTransportationHazardousMaterialsRegulations
forbidthecarriageofbutaneorotherammablegasproductson
passengeraircraft.Donotpackthisitemoranyotherammable
gasitem,inanycheckedorcarry-onbaggage.
SPECIAL WARNING
11
SPECIFICATIONS
Dimensions Length 228mm(9inches)
Width 48mm(1.9inches)
Height 205mm(8.1inches)
Weight EmptyTank 380g(13.4oz)
Fuel Butane
OperatingTime MidSetting Approx.150min.
FuelCartridgeCapacity 1oz(30ml)
FlameTemp ≈347~410℉(175~210℃)
10
www.pro-iroda.com
WARNING
-Readtheinstructionsbeforeusingtheappliance.
CAUTION:
-Accessiblepartsmaybeveryhot.Keepyoungchildren
awayfromtheappliance.
