ROLLING GARDEN WORK SEAT
OWNER’S MANUAL
WARNING:
Read carefully and understand all INSTRUCTIONS before
operating. Failure to follow the safety rules and other basic
safety precautions may result in serious personal injury.
Item # 41725

Page of 6
2
Thank you very much for choosing a NORTHERN TOOL + EQUIPMENT CO., INC. Product! For
future reference, please complete the owner’s record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to
become familiar with this product before you begin using it.
This machine is designed for certain applications only. Northern Tool + Equipment cannot be
responsible for issues arising from modification. We strongly recommend this machine not be modified
and/or used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the machine until you have first contacted Northern
Tool + Equipment to determine if it can or should be performed on the product.
For technical questions please call 1-800-222-5381.
INTENDED USE
The Rolling Garden Work Seat helps avoid back pain and injury by relieving the pressure caused by
continuous stooping, kneeling and squatting. This garden work seat has an old-fashioned tractor seat
that swivels in any direction and 10in. pneumatic tires that move over any surface. It comes with a
storage area under the seat for your tools, gloves, etc. The seat adjusts up to 18in. off the ground and
the heavy-duty, welded steel tube frame has a 300 lb. capacity. .
Weight Capacity: 300 lbs
10in. Pneumatic tires
The seat adjusts up to 18in. off the ground
TECHNICAL SPECIFICATIONS
Item
Description
Capacity
300lbs.
Tool Tray Capacity
5 lbs.
Tires
10in. Pneumatic
GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions listed
below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this Seat until they have read
this manual and have developed a thorough understanding of how it works.
WARNING: The warnings, cautions, and instructions discussed in this owner's manual
cannot cover all possible conditions or situations that could occur. It must be understood by the
operator that common sense and caution are factors, which cannot be built into this product, but must
be supplied by the operator.

Page of 6
3
SAVE THESE INSTRUCTIONS.
WORK AREA
Keep the work area clean, free of clutter and well lit. Cluttered and dark work areas can cause
accidents.
Keep children and bystanders away while operating the Seat. Distractions can cause you to lose
control, so visitors should remain at a safe distance from the work area. The Seat is not a toy and
should not be used as such by children.
Be aware of all power lines, electrical circuits, water pipes and other mechanical hazards in your
work area, particularly those hazards below the work surface hidden from the operator’s view that
may be unintentionally contacted and may cause personal harm or property damage.
PERSONAL SAFETY
Stay alert. Watch what you are doing and use common sense when using the Seat. Do not use
the Seat while you are tired or under the influence of drugs, alcohol or medication. A moment of
inattentiveness while operating the Seat may result in serious personal injury.
Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in moving
parts.
Use safety apparel and equipment. Use safety goggles or safety glasses with side shields which
comply with current national standards, or when needed, a face shield. Use a dust mask in dusty
work conditions. This applies to all persons in the work area. Also wear non-skid safety shoes, a
hardhat and gloves. Use a dust collection system and hearing protection when appropriate.
USE AND CARE
Do not modify the Seat in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the equipment. There are specific applications for which the Seat
was designed.
Always check for damaged or worn out parts before using the Seat. Broken parts will affect the
Seat’s operation. Replace or repair damaged or worn parts immediately.
Do not exceed the load capacity of the Seat.
Distribute the load evenly. Uneven loads may cause the Work Seat to tip, resulting in personal
injury to the operator or others.
Use the Seat on flat and level surfaces capable of supporting the maximum load capacity.
Store the Seat in a secure place out of the reach of children when not in use. Make sure the Seat
is in good working condition prior to storage and before each re-use.
Never stand on Seat.
WARNING: Make sure the tires are inflated to 30 PSI, the pressure indicated on the tire
sidewall. Do not over inflate: Use a hand pump only. A high-pressure air hose can easily overfill the
tires resulting in an explosion and possible injury.

Page of 6
4
MAINTENANCE
Maintain your Seat. It is recommended that the general condition of the Seat be examined before
it is used. Keep your Work Seat in good working order by adopting a program of conscientious
repair and maintenance. If any abnormal vibrations or noise occurs, have the problem corrected
before further use. Have all necessary repairs made by a qualified service professional.
ASSEMBLY
Step
1
Step 2
Step
3
Step 4
Step 5
Step 6

Page of 6
5
Step7
Step8
DIAGRAM & PARTS LIST

Page of 6
6
Distributed by
Northern Tool + Equipment Co., Inc.
Burnsville, Minnesota 55306-6936
Made in China
For replacement parts and technical questions, please call 1-800-222-5381.
WARRANTY
One-Year Limited Warranty
Parts#
Description
Quantity
Parts#
Description
Quantity
#01
Seat
1
#14
Flat Washer 8MM
6
#02
Elevating Bolts
1
#15
Lock Nut M8
6
#03
Main Frame
1
#16
Round Bolt M8x25
2
#04
Basket
1
#17
Flat Washer 8 MM
4
#05
3.50-4 Wheel
4
#18
Lock Nut M8
4
#06
Connecting Plate
3
#19
Hexagon Bolt M8x20
3
#07
Axle
1
#20
Hexagon Bolt M8x25
1
#08
Handle
1
#21
Flat Washer 20 MM
1
#09
Plastic Tray
1
#22
Cotter Pin
1
#10
Cross BoltM10x15
4
#23
Lock Nut M12
4
#11
Flat Washer 10
4
#24
Flat Washer 12 MM
4
#12
Lock Nut M10
4
#25
Connecting Plate Tool Box
1
#13
Round Bolt M8x15
4
