Ironton 61475 User manual

READ & SAVE THESE INSTRUCTIONS
Heavy-Duty Demolition Breaker Hammer
Owner’s Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #61475

Page 2 of 19
Thank you very much for choosing an Ironton™product!
For future reference, please complete the owner’s record below:
Serial Number/Lot Date Code: ________________________________
Purchase Date: ____________________________________________
Save the receipt, warranty, and this manual. It is important that you read
the entire manual to become familiar with this product before you begin
using it.
This breaker hammer is designed for certain applications only. Northern
Tool and Equipment is not responsible for issues arising from
modification or improper use of this product such as an application for
which it was not designed. We strongly recommend that this product not
be modified and/or used for any application other than that for which it
was designed.
For technical questions, please call 1-800-222-5381.

Page 3 of 19
Table of Contents
Intended Use..........................................................................................................................................4
Packaging Contents..............................................................................................................................4
Technical Specifications......................................................................................................................4
Important Safety Information...............................................................................................................4
Specific Operation Warnings...............................................................................................................6
Grounding..............................................................................................................................................6
Extension Cords....................................................................................................................................7
Main Parts of Demolition Breaker Hammer........................................................................................9
Assembly Instructions........................................................................................................................10
Before Each Use..................................................................................................................................10
Operating Instructions........................................................................................................................11
After Each Use.....................................................................................................................................12
Maintenance ........................................................................................................................................12
Troubleshooting..................................................................................................................................13
Parts Diagram......................................................................................................................................14
Parts List..............................................................................................................................................15
Replacement Parts..............................................................................................................................17
Limited Warranty.................................................................................................................................18

Page 4 of 19
Intended Use
The Ironton Pro Demolition Hammer Kit delivers over 34 ft. lb. of impact energy to break up the
hardest surfaces. The balanced ergonomic design and a 360° side handle make it easy to switch
between vertical and horizontal applications for breaking up foundations and footings. Anti-vibration
control lets you use this lower wall breaker hammer longer with less fatigue.
Packaging Contents
Hammer
Handle
2 Chisels
Owner’s Manual
Technical Specifications
Property
Specification
Motor
110V, 60Hz, 15A
Impact Energy
55 J
Impact Rate
1,400 BPM
Important Safety Information
⚠WARNING
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
this equipment for a purpose for which it was not intended.
Industrial or commercial applications must follow OSHA requirements.
⚠WARNING
WORK AREA SAFETY
Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit.
Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas

Page 5 of 19
may put you dangerously close to cutting tools and rotating parts.
Do not use the product where there is a risk of causing a fire or an explosion; e.g., in the presence
of flammable liquids, gases, or dust. The product can create sparks, which may ignite the
flammable liquids, gases, or dust.
Do not allow the product to come into contact with an electrical source. The tool is not insulated
and contact will cause electrical shock.
Keep children and bystanders away from the work area while operating the tool. Do not allow
children to handle the product.
Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your
work area. Some of these hazards may be hidden from your view and may cause personal injury
and/or property damage if contacted.
⚠WARNING
PERSONAL SAFETY
Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use
the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating the tool may result in serious personal injury.
Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts. Air vents on the tool often cover moving parts and should be avoided.
Wear the proper personal protective equipment when necessary. Use ANSI Z87.1 compliant safety
goggles (not safety glasses) with side shields, or when needed, a face shield. Use a dust mask in
dusty work conditions. Also use non-skid safety shoes, hardhat, gloves, dust collection systems,
and hearing protection when appropriate. This applies to all persons in the work area.
Do not overreach. Keep proper footing and balance at all times.
Remove keys or wrenches before connecting the tool to an air supply, power supply, or turning on
the tool. A wrench or key that is left attached to a rotating part of the tool may cause personal
injury.
Secure the work with clamps or a vise instead of your hand when practical. This safety precaution
allows for proper tool operation using both hands.
⚠CAUTION
DEMOLITION BREAKER HAMMER USE AND CARE
Do not force the hammer. Products are safer and do a better job when used in the manner for
which they are designed. Plan your work, and use the correct product for the job.
Check for damaged parts before each use. Carefully check that the product will operate properly
and perform its intended function. Replace damaged or worn parts immediately. Never operate the
product with a damaged part.
Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with
the power switch is dangerous and must be repaired by an authorized service representative

Page 6 of 19
before using.
Disconnect the power/air supply from the product and place the switch in the locked or off position
before making any adjustments, changing accessories, or storing the tool. Such preventive safety
measures reduce the risk of starting the tool accidentally.
Store the hammer when it is not in use. Store it in a dry, secure place out of the reach of children.
Inspect the tool for good working condition prior to storage and before re-use.
Use only accessories that are recommended by the manufacturer for use with your product.
Accessories that may be suitable for one product may create a risk of injury when used with
another tool. Never use an accessory that has a lower operating speed or operating pressure than
the tool itself.
Keep guards in place and in working order. Never operate the product without the guards in place.
Do not leave the tool running unattended.
Specific Operation Warnings
⚠WARNING
To reduce the risk of injury always wear eye protection
Wear ear protection with Hammer. Exposure to noise can cause hearing loss.
Wear heavy duty anti vibration gloves.
Be sure the bit is secured in place before operation.
Hold power tools by insulated gripping surfaces, when performing an operation where the cutting
tool may contact hidden wiring or its own cord.
When drilling or screwing into walls, ceilings, etc., make sure beforehand that you will not damage
any hidden electric cables. During this work you should not touch any metal parts of the machine;
only touch the machine by the plastic housing.
Always be sure you have a firm footing.
Hold the tool firmly with both hands.
Be sure no one is below you when using the tool in high locations.
Do not point the tool at anyone in the area when operating. The bit could fly out and seriously
injure someone.
Burn hazard. Do not touch the bit or parts close to the bit immediately after operation; they will be
extremely hot.
Grounding
⚠WARNING
This machine must be grounded while in use to protect the operator from electrical shock. This
unit is equipped with an electrical cord that has an equipment grounding conductor and a
grounding plug. The plug MUST be plugged into a matching receptacle that is properly installed

Page 7 of 19
and grounded in accordance with ALL local codes and ordinances.
DO NOT MODIFY THE PROVIDED PLUG. If it will not fit the receptacle, have the proper
receptacle installed by a qualified electrician.
CHECK with a qualified electrician or service person if you do not completely understand the
grounding instructions, or if you are not sure the tool is properly grounded.
Grounded Tools: Tools with 3-Prong Plugs
Tools marked with Grounding Required have a 3-wire cord and 3-prong grounding plug. The plug
must be connected to a properly grounded outlet. If the tool should electrically malfunction or break
down, grounding provides a low resistance path to carry electricity away from the user, reducing the
risk of electric shock. (See Figure A.)
The grounding prong in the plug is connected through the green wire inside the cord to the grounding
system in the tool. The green wire in the cord must be the only wire connected to the tool’s grounding
system and must never be attached to an electrically live terminal.
Your tool must be plugged into an appropriate outlet, properly installed and grounded in accordance
with all codes and ordinances. The plug and outlet should look like those in the following illustration.
Double Insulated Tools: Tools with Two-Prong Plugs
Tools marked Double Insulated do not require grounding. They have a special double insulation
system which satisfies OSHA requirements and complies with the applicable standards of
Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code.
(See Figure B.)
Double insulated tools may be used in either of the 120 volt outlets shown in the following illustration.
Extension Cords
⚠WARNING
USE A PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When

Page 8 of 19
using an extension cord, be sure to use one heavy enough to carry the current your product will
draw. An undersized cord will cause a drop in line voltage, resulting in loss of power and cause
overheating.
Be sure your extension cord is properly wired and in good condition. Always replace a damaged
extension cord or have it repaired by a qualified person before using it. Protect your extension
cords from sharp objects, excessive heat and damp or wet areas.
Grounded tools require a 3-wire extension cord. Double Insulated tools can use either a 2- or 3-
wire extension cord.
As the distance from the supply outlet increases, you must use a heavier gauge extension cord.
Using extension cords with inadequately sized wire causes a serious drop in voltage, resulting in
loss of power and possible tool damage.
The smaller the wire’s gauge number, the greater the capacity of the cord. For example, a 14-
gauge cord can carry a higher current than a 16-gauge cord. Minimum extension cord wire size is
shown in the following table:
Minimum Wire Size Of Extension Cords
Nameplate AMPS
Cord Length
25'
50'
100'
150'
0-6
18 AWG
16 AWG
16 AWG
14 AWG
6-10
18 AWG
16 AWG
14 AWG
12 AWG
10-12
16 AWG
16 AWG
14 AWG
12 AWG
12-16
14 AWG
12 AWG
NOT RECOMMENDED
When using more than one extension cord to make up the total length, make sure each cord
contains at least the minimum wire size required.
If you are using one extension cord for more than one tool, add the nameplate amperes and use
the sum to determine the required minimum cord size.
If you are using an extension cord outdoors, make sure it is marked with the suffix W-A (Win
Canada) to indicate it is acceptable for outdoor use.
Make sure your extension cord is properly wired and in good electrical condition. Always replace
a damaged extension cord or have it repaired by a qualified electrician before using it.
Protect your extension cords from sharp objects, excessive heat, and damp or wet areas.

Page 9 of 19
Main Parts of Demolition Breaker Hammer
Subassembly
Main Handle
Power Switch
Power Light
Side Handle Knob
Side Handle
Chisel Lock
Chisel

Page 10 of 19
Assembly Instructions
⚠WARNING
Make sure that the trigger is in the OFF position and unplug the hammer from its electrical outlet
before performing any procedure in this section.
Adjusting the Side Handle
1. Loosen the side handle knob.
2. Twist the side handle into the desired position.
3. Tighten the side handle knob.
Before Each Use
⚠WARNING
Be sure the bit is secured in place before operation.
When drilling or screwing into walls, ceilings, etc., make sure beforehand that you will not damage
any hidden electric cables. During this work you should not touch any metal parts of the machine;
only touch the machine by the plastic housing.
Be sure no one is below you when using the tool in high locations.
Always remove the plug from the power source before installing or removing a bit or accessory
from the chuck.

Page 11 of 19
Operating Instructions
⚠WARNING
To reduce the risk of injury always wear eye protection
Wear ear protection with Hammer. Exposure to noise can cause hearing loss.
Wear heavy duty anti vibration gloves.
Be sure the bit is secured in place before operation.
Hold power tools by insulated gripping surfaces, when performing an operation where the cutting
tool may contact hidden wiring or its own cord.
Always be sure you have a firm footing.
Hold the tool firmly with both hands.
Do not point the tool at anyone in the area when operating. The bit could fly out and seriously
injure someone.
Burn hazard. Do not touch the bit or parts close to the bit immediately after operation; they will be
extremely hot.
Use only well-sharpened bits that are in good condition and appropriate to task.
To prevent the bit from jamming, keep the motor running when pulling the bit out of a completed
hole.
Installing the Non-collared Chisel
1. Move the chisel lock to the unlocked position.
2. Slide the chisel in as far as it will go with the notch facing up.

Page 12 of 19
3. Move the chisel lock to the locked position.
After Each Use
⚠WARNING
Do not remove the chisel until it has cooled.
Store the tool in dry and clean place.
Keep away from children.
Maintenance
⚠WARNING
Do not use solvents to clean the hammer.
If the supply cord of this power tool is damaged, it must be replaced and only by a qualified
service technician.
Maintain the hammer by adopting a program of conscientious repair and maintenance in accordance
with the following recommended procedures. It is recommended that the general condition of any tool
be examined before it is used. Keep your tool in good repair. Keep handles dry, clean, and free from
oil and grease. The following chart is based on a normal operation schedule.
Maintenance Interval
Maintenance Point
Before each use
Inspect the general condition of the tool. Check for:
1. loose hardware,
2. misalignment or binding of moving parts,
3. damaged cord/electrical wiring,
4. cracked or broken parts, and
5. any other condition that may affect its safe operation.
After use
Wipe external surfaces of the tool with a clean cloth.

Page 13 of 19
Troubleshooting
Use the table below to troubleshoot problems before contacting service personnel or your local
dealer. If the problem continues after troubleshooting, call your local dealer for assistance.
Failure
Possible Cause
Corrective Action
Hammer will not
start.
1. Cord is not connected.
2. No power at the outlet.
3. The hammer’s thermal reset breaker
tripped (if equipped).
4. Internal damage or wear (carbon
brushes or trigger, for example).
1. Check that cord is plugged in.
2. Check the power at the outlet. If the
outlet is not powered, turn off the
hammer and check the circuit breaker.
If the breaker is tripped, make sure the
circuit is the right capacity for the
hammer and the circuit has no other
loads.
3. Turn off the hammer and allow it to
cool. Press the hammer’s reset button.
4. Have a technician service the
hammer.
Hammer
operates slowly.
1. Forcing hammer to work too fast.
2. Extension cord is too long or cord
diameter is too small.
1. Allow hammer to work at its own
rate.
2. Do not use an extension cord. If an
extension cord is needed, use one with
the proper diameter for its length and
load.
Performance
decreases over
time.
1. Carbon brushes worn or damaged.
2. Bit is dull or damaged.
1. Have a qualified technician replace
the brushes.
2. Keep bits sharp. Replace as
needed.
Excessive noise
or rattling.
Internal damage or wear (carbon
brushes or bearings, for example).
Have a technician service the hammer.
Overheating.
1. Forcing hammer to work too fast.
2. Bit dull or damaged.
3. Blocked motor housing vents.
4. Motor being strained by long or small
diameter extension cord.
1. Allow hammer to work at its own
rate.
2. Keep bits sharp. Replace as
needed.
3. Wear ANSI-approved safety goggles
and NIOSH‑approved dust
mask/respirator while blowing dust out
of motor using compressed air.
4. Do not use an extension cord. If an
extension cord is needed, use one with
the proper diameter for its length and
load.

Page 14 of 19
Parts Diagram

Page 15 of 19
Parts List
Part Number
Part Description
Quantity
1
Chisel Chuck
1
2
Locking Lever
1
3
Spring Column Pin
2
4
Pull Rod
2
5
Front Cover
1
6
Pull Rod Spring
2
7
Pull Ring
2
8
Needle Roller
2
9
Hex Bolt M8 x 30
6
10
O-Ring Ø74 x Ø2
1
11
O-Ring Ø46.5 x Ø5
1
12
Impact Hammer
1
13
O-Ring Ø62 x Ø3
1
14
Sealing Ring Ø37.2 x Ø26.6 x 5
1
15
Shank Sleeve
1
16
Small Urethane Ring
1
17
Locking Ring
1
18
Mouth
1
19
Mouth Cover
1
20
Mouth Washer
2
21
Urethane Ring
1
22
Aluminum Head
1
22A
Hex M8 x 40
4
23
Ø8 Spring Washer
4
24
Ø8 Flat Washer
5
25
O-Ring Ø53 x Ø2.5
1
26
Cylinder
1
27
O-Ring Ø35 x Ø5.5
1
28
Piston
1
29
Sealing Ring Ø35 x 7
1
30
Piston Pin
1
31
Connecting Rod Assembly
1
32
Crank Washer
1
33
NK18/20 Needle Bearing
1
34
Hex Bolt M8 x 1 x 35
1
35
Hex Bolt M6x 20
22
36
Hex Bolt M6×25
2
37
Cover
1
38
Gear Cover
1
39
6302 Z Ball Bearing
1
40
Ø22 Retaining Ring
1
41
Final Gear
1
42
Distance Ring
1
43
Hex Bolt M6 x 35
6
44
Inner Cover
1
45
O-Ring Ø109x Ø3.1
1
46
6205 DD Ball Bearing
1
47
6205 DD Bearing Cover
1
48
Hex Bolt M5 x 12
7
49
Crank Shaft
1
50
Pin Ø5 x 14
2
51
Housing Assembly
1

Page 16 of 19
Part Number
Part Description
Quantity
52
O-Ring Ø20 x Ø2
1
53
Oil Tank Cover
1
54
Fan Cover
1
55
ST4.8 x 35 Tapping Screw
2
56
6201 RZ Ball Bearing
1
57
Counter Gear
1
58
6001 RZ Bearing Cover
1
59
M5 x 10 Embedding Screws
2
60
6203 DD Bearing Cover
1
61
6203 DD Ball Bearing
1
62
6001 RZ Ball Bearing
1
63
Woodruff Key 4 x 16
2
64
Crank Shaft Ring
1
65
Armature
1
66
6201 RS Ball Bearing
1
67
Fan Guide
1
68
Stator
1
69
ST4.8 x 70 Tapping Screw
2
70
Ø5 Flat Washer
2
71
Stator Assembly
1
72
Carbon Brush Bracket Subassembly
1
73
ST4.2 x 16 Tapping Screw
8
74
Helical spring
2
75
Carbon Brush
2
76
Switch Support
1
77
Hex Bolt M5 x 16
4
78
Power Switch
1
79
Rivet
2
80
Wiring Terminal
1
81
Cord Clip
1
82
Electricity Feels
1
83
Indicator
1
84
Side Handle Assembly Base
1
85
Shock Absorption Spring Washer
1
86
Shock Absorption Spring
1
87
Shock Absorption Jacket
1
88
Main Handle
1
89
M14 Bolt
1
90
Rubber Stopper-1
1
91
Rubber Stopper-2
1
92
Cover
2
93
Nut M8
1
94
M8 Bolt
1
95
ST4.2 x 10 Tapping Screw
2
96
Jacket Platen
1
97
Jacket Orientation Piece
1
98
Cord Armor
1
99
Cord
1
100
Grip
1
101
M8 x 10 Hex Head Screw
2
102
M10 x 120 Long Screw
1
103
Clip
2
104
Side Handle Assembly
1
105
Function Knob
1

Page 17 of 19
Part Number
Part Description
Quantity
106
Nut M10 x 18
1
107
4mm Hex Wrench
1
108
5mm Hex Wrench
1
109
6mm Hex Wrench
1
110
Dual Screw Driver
1
111
Grease
1
Replacement Parts
For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.
Not all product components are available for replacement. The illustrations provided are a
convenient reference to the location and position of parts in the assembly sequence.
When ordering parts, the following information will be required: item description, item model
number, item serial number/item lot date code, and the replacement part reference number.
The distributor reserves the rights to make design changes and improvements to product lines
and manuals without notice.

Page 18 of 19
Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only
(''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both
materials and workmanship, normal wear and tear excepted, for a period of one year from date of
purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in
accordance with product instructions. There are no other warranties, express or implied, including the
warranty of merchantability or fitness for a particular purpose. If the product does not comply with this
limited warranty, Your sole and exclusive remedy is that We will, at our sole option and within a
commercially reasonable time, either replace the product or product component without charge to You
or refund the purchase price (less shipping). This limited warranty is not transferable.
Limitations on the Warranty
This limited warranty does not cover: (a) normal wear and tear; (b) damage through abuse, neglect,
misuse, or as a result of any accident or in any other manner; (c) damage from misapplication,
overloading, or improper installation; (d) improper maintenance and repair; and (e) product alteration
in any manner by anyone other than Us, with the sole exception of alterations made pursuant to
product instructions and in a workmanlike manner.
Obligations of Purchaser
You must retain Your product purchase receipt to verify date of purchase and that You are the original
purchaser. To make a warranty claim, contact Us at 1-800-222-5381, identify the product by make
and model number, and follow the claim instructions that will be provided. The product and the
purchase receipt must be provided to Us in order to process Your warranty claim. Any returned
product that is replaced or refunded by Us becomes our property. You will be responsible for return
shipping costs or costs related to Your return visit to a retail store.
Remedy Limits
Product replacement or a refund of the purchase price is Your sole remedy under this limited warranty
or any other warranty related to the product. We shall not be liable for: service or labor charges or
damage to Your property incurred in removing or replacing the product; any damages, including,
without limitation, damages to tangible personal property or personal injury, related to Your improper
use, installation, or maintenance of the product or product component; or any indirect, incidental or
consequential damages of any kind for any reason.
Assumption of Risk
You acknowledge and agree that any use of the product for any purpose other than the specified
use(s) stated in the product instructions is at Your own risk.
Governing Law
This limited warranty gives You specific legal rights, and You also may have other rights which vary
from state to state. Some states do not allow limitations or exclusions on implied warranties or
incidental or consequential damages, so the above limitations may not apply to You. This limited
warranty is governed by the laws of the State of Minnesota, without regard to rules pertaining to
conflicts of law. The state courts located in Dakota County, Minnesota shall have exclusive jurisdiction
for any disputes relating to this warranty.

Page 19 of 19
Distributed by:
Northern Tool & Equipment Company, Inc.
Burnsville, Minnesota 55306
www.northerntool.com
Made in China
Table of contents
Other Ironton Power Hammer manuals
Popular Power Hammer manuals by other brands

Metabo HPT
Metabo HPT H 60ME Handling instructions

Makita
Makita HM001G instruction manual

Hilti
Hilti TE 300-A36 Original operating instructions

Wacker Neuson
Wacker Neuson EHB 11 BLS Operator's manual

Hilti
Hilti TE 500 Original operating instructions

Parkside
Parkside PAH 1300 B2 Translation of the original instructions
