Iseki SSM48 Installation and operating instructions

SSM48
SSM54
SSM60
SRM48
SMM54
MODELS:
ISEKI MOWER DECK
Operation & Servise Manual

1
INTRODUCTION
Thank you very much for purchasing an ISEKI mower.
This operator’s manual is intended to provide the information necessary for operating
and maintaining your mower safely and properly. The contents are mainly composed of
the following two items:
Safety instructions: Essential items which you should observe while operating the
lawn mower
Technical instructions: Items which are necessary to operate, adjust, servise the
mower properly
Before starting to operate the machine for the first time, you should read this manual
thoroughly and carefully. The manual should be kept in a handy place so you can refer
to it when required. You are advised to refer to it from time to time to refresh your
understanding of the safety operation.
The lawn mower is designed to be used on well-kept lawns. Using the machine in order
places is not authorized. Besides, the manufacturer dose not pay for any damage caused
by unauthorized use, the risk being borne by the user. Proper use of the machine also
implies that the user follows the operational, adjusting, and servicing instructions
indicated in this manual.
When you have any question about your purchased machine, you are always welcome to
ask your dealers.
The paragraphs in the manual and the labels on the machine accompanied
by the caution mark indicate particularly important information about safe
operation to prevent accidents.You should always keep these precautions
in mind and follow then during operation.
Be sure to wear
personnel protective equipment
during operation
All information, illustrations, and specifications contained in this manual are based on the latest information available at
the time of publication. The right is reserved to make changes at any time without notice.

OPERATION & SERVICE MANUAL FOR MOWER DECK
2
INTRODUCTION .......................................................................................................................... 1
TABLE OF CONTENTS ................................................................................................................ 2
CHAPTER 1. FOR SAFE OPERATION ........................................................................................ 4
1-1. Safety labels ...................................................................................................................... 6
1-2. Position of the safety labels................................................................................................ 6
1) For TM3240, 3200, 3160 tractors...................................................................................... 6
2) For TH4330, 4290, 4260 tractors...................................................................................... 12
CHAPTER 2. GENERAL INFORMATION .................................................................................... 14
2-1. Introduction ........................................................................................................................ 14
2-2. Machine identification ........................................................................................................ 15
CHAPTER 3. SPECIFICATIONS .................................................................................................. 18
CHAPTER 4. NAME OF MAJOR COMPONENTS ...................................................................... 24
1) For TM3240, 3200, 3160 tractors...................................................................................... 24
2) For TH4330, 4290, 4260 tractors...................................................................................... 26
CHAPTER 5. INSTALLATION ON THE TM TRACTOR .............................................................. 28
Ⅰ
. SSM48 / SRM48 .................................................................................................................. 28
5-1. Before installation .......................................................................................................... 28
5-2. Installation of the bracket and cylinder on the tractor .................................................... 28
5-3. Installation of the linkage on the tractor ........................................................................ 29
5-4. Installation of the mower deck........................................................................................ 30
5-5. Installation of the drive shaft .......................................................................................... 31
5-6. Link adjustment.............................................................................................................. 32
Ⅱ.SSM54,60 / SMM54 .............................................................................................................. 33
5-7. Before installation .......................................................................................................... 33
5-8. Installation of the bracket and cylinder on the tractor .................................................... 33
5-9. Installation of the linkage on the tractor ........................................................................ 34
5-10. Installation of the mower deck...................................................................................... 35
5-11. Installation of the drive shaft ........................................................................................ 36
5-12. Link adjustment............................................................................................................ 37
5-13. Installation of the height adjuster ................................................................................ 38
CHAPTER 6. INSTALLATION ON THE TH TRACTOR................................................................ 40
6-1. Before installation .............................................................................................................. 40
6-2. Installation of the bracket and cylinder on the tractor ........................................................ 40
6-3. Installation of the linkage on the tractor.............................................................................. 41
6-4. Installation of the mower deck............................................................................................ 42
6-5. Link adjustment .................................................................................................................. 44
6-6. Installation of the height adjuster........................................................................................45
CHAPTER 7. MOWER OPERATION ............................................................................................ 46
7-1. Before operation ................................................................................................................ 46
TABLE OF CONTENTS

3
7-2. Cutting height adjustment ..................................................................................................46
7-3. Starting mowing operation..................................................................................................47
7-4. Stopping the mower .......................................................................................................... 48
7-5. Emergency stop ................................................................................................................ 48
7-6. Efficient mowing ................................................................................................................ 48
1) Mowing plan and method.................................................................................................. 48
2) For preventing damage of turf .......................................................................................... 49
3) For mowing tall grass........................................................................................................49
4) For mowing highly moistened grass or on a wet .............................................................. 49
5) For mowing low moisture content grass or when there is much dead grass .................... 49
CHAPTER 8. INSPECTION AND SERVICE OF EACH PART .................................................... 50
8-1. Inspection and replacement of the gear box ...................................................................... 50
1) Inspection of oil level ........................................................................................................ 50
2) Replacement of oil ............................................................................................................ 50
8-2. Inspection and replacement of the drive belt...................................................................... 51
1) Pre-operation check..........................................................................................................51
2) Inspection of the belt tension ............................................................................................ 51
3) Inspection of the belt ........................................................................................................ 53
4) How to replace the belt .................................................................................................... 53
8-3. Inspection and replacement of the blades.......................................................................... 54
1) Inspection of the blades .................................................................................................... 54
2) Replacement of the blades .............................................................................................. 54
8-4. Inspection of gauge wheels................................................................................................ 55
8-5. Inspection of rollers ............................................................................................................ 55
8-6. Cleaning under the belt cover ............................................................................................ 55
CHAPTER 9. LUBRICATING AND GREASING POINTS ............................................................ 56
1) For TM3240, 3200, 3160 tractors...................................................................................... 56
2) For TH4330, 4290, 4260 tractors...................................................................................... 61
CHAPTER 10. DISASSEMBLY AND REASSEMBLY .................................................................. 62
10-1. Gear Box .......................................................................................................................... 62
10-2. Backlash adjustment ........................................................................................................ 62
CHAPTER 11. STORING OF THE MOWER DECK...................................................................... 66
CHAPTER 12. TROUBLESHOOTING.......................................................................................... 68
CHAPTER 13. PACKING PARTS LIST ........................................................................................ 70
1) For TM3240, 3200, 3160 tractors...................................................................................... 70
2) For TM4330, 4290, 4260 tractors...................................................................................... 75

4
OPERATION & SERVICE MANUAL FOR MOWER DECK
Read this manual thoroughly and carefully
before starting the lawn mower for the first time.
Especially abide by the instruction for safe oper-
ation. If you do not, it may result in bodily
injuries.
If you have consumed intoxicating beverages,
are drowsy from medication, ill, or tired, never
operate the machine.
When you let someone else operate the machine,
instruct this person how to operate the machine
and also advise the reading of this manual.
Never permit the following persons to operate
the machine:
-Persons not properly trained to operate the
machine
-Persons who cannot understand the instructions
mentioned on the caution labels
-Person women
-Children
Local regulations may restrict the age of the
operator.
Keep in mind that the operator or user is respon-
sible for any accident or hazard caused by the
machine to other people or their property.
Never perform operations other than those for
which the machine is designed. Operations the
mower is not designed for may cause damage to
the machine, shorten service life, or in the worst
case lead to a serious accident.
Never attempt unauthorized modification of the
machine as this could be very hazardous.
Take care as rotating one blade can cause other
blades to rotate.
Do not touch rotating blades.
Never step on the mower deck.
Be sure to alert them by signaling before you
make a new move when you are working with
co-workers.
While mowing, always wear substantial shoes
and long trousers. Do not operate the machine
barefoot or while wearing open sandals.
When operating, adjusting, or servicing the
machine, avoid wearing long loose clothes,
accessories or letting long hear hang loose,
which could be caught in rotating parts or on
projections. Be sure to use necessary protective
devices such as a headgear, safety glasses, ear
plugs, gloves, etc.
It is recommended to wear ear protectors such as
ear plugs, earmuffs, etc. But your ears should not
be plugged to the extent that horns of other
machines and call from other persons are inaudi-
ble.
Stop the blades and keep the mower in the trans-
port position when crossing surfaces other than
grass or when transporting it to and from the
area to be mowed.
It is not recommendable to operate the machine
on a slope.
Place the machine on level and hard ground
when servicing the machine or mounting or dis-
mounting the mower.
Stop the engine and remove the engine key when
servicing the machine or mounting or dismount-
ing the mower.
Be sure to apply the hydraulic lift lock without
fail when servicing the mower.
Use proper tools when servicing the machine.
Using makeshift tools may lead to injuries or
poor service, which may result in unexpected
accidents during operation.
CHAPTER 1. FOR SAFE OPERATION

5
CHAPTER 1. FOR SAFE OPERATION
Service the machine in a place sufficiently illu-
minated in order to avoid unexpected accidents.
The engine, muffler, radiator, etc. are very hot
just after operation, so wait until those heated
parts cool down sufficiently to avoid burns.
Avoid high-pressure fluids. Escaping fluid under
pressure can penetrate the skin and cause serious
injury, so keep hands and body away from pin
holes and nozzles ejecting such fluids. Be sure to
consult your dealer about any hydraulic and fuel
injection system trouble.
In any hydraulic fluid is injected accidentally
into the skin, it must be removed within a few
hours by a doctor familiar with this type of
injury.
Keep all nuts, bolts and screws tight to be sure
that the equipment is in safe working condition.
Be sure to reinstall the removed parts in place.
A first aid kit and a fire extinguisher should be
kept in a place always in instant access.
Be sure to wear safety glasses and gloves when
servicing the machine.

6
OPERATION & SERVICE MANUAL FOR MOWER DECK
1-1. Safety labels
The following labels are stuck on the mower. You
should read the safety instructions in the manual.
But never fail to read the labels on the machine
as well. Their respective code numbers are also
mentioned below, so order replacements from
your dealer if any of them are lost or damaged.
1-2. Position of the safety labels
Pay attention to the safety labels on the mower,
and observe the instructions they give to avoid
physical injuries.
1) For TM3240, 3200, 3160 tractors
SSM48-TM3160E4
Fig.1-1

7
CHAPTER 1. FOR SAFE OPERATION
(1) Danger label
Caution:
Keep clear of the mower blades while the
engine is running.
(2) Belt label
Caution:
Do not remove the safety covers while the
engine is running.
(3) Discharge label
Caution:
Keep a safe distance from the mower.
(4) Hot label
Caution:
Keep clear the hot surface.(6) Maintenance
label
(5) PTO label
Caution:
Keep clear of the PTO shaft while the engine is
running.
(6) Maintenance label
Caution:
Shut off the engine and remove the starter key
before performing maintenance or repair work.

8
OPERATION & SERVICE MANUAL FOR MOWER DECK
SSM54-TM3240E4 / HE4
Fig.1-2
(1) Danger label
Caution:
Keep clear of the mower blades while the
engine is running.
(2) Belt label
Caution:
Do not remove the safety covers while the
engine is running.
(3) Discharge label
Caution:
Keep a safe distance from the mower.
(4) Hot label
Caution:
Keep clear the hot surface

(5) PTO label
Caution:
Keep clear of the PTO shaft while the engine is
running.
(6) Maintenance label
Caution:
Shut off the engine and remove the starter key
before perform
9
CHAPTER 1. FOR SAFE OPERATION
SSM60-TM3240E4 / HE4
Fig.1-3

10
OPERATION & SERVICE MANUAL FOR MOWER DECK
SRM48-TM3160E4
Fig.1-4
SMM54-TM3240E4 / HE4
Fig.1-5

(4) PTO label
Caution:
Keep clear of the PTO shaft while the engine is
running.
(5) Maintenance label
Caution:
Shut off the engine and remove the starter key
before performing maintenance or repair work.
(1) Belt label
Caution:
Do not remove the safety covers while the
engine is running.
(2) Hot label
Caution:
Keep clear the hot surface.
(3) Danger label
Caution:
Keep clear of the mower blades while the
engine is running.
11
CHAPTER 1. FOR SAFE OPERATION

2) For TH4330, 4290, 4260 tractors
SSM60-TH4330E4
Fig.1-6
12
OPERATION & SERVICE MANUAL FOR MOWER DECK
(1) Belt label
Caution:
Do not remove the safety covers while the
engine is running.
(2) Hot label
Caution:
Keep clear the hot surface

13
CHAPTER 1. FOR SAFE OPERATION
(6) Maintenance label
Caution:
Shut off the engine and remove the starter key
before performing maintenance or repair work.
1-3. Maintenance of the safety labels
-The labels should always be clearly seen, that is,
nothing should obscure them.
-Wash the labels with soap water and wipe with a
soft cloth when they have become dirty.
-Order new labels from your dealers when some
of them are torn or lost.
-A new label should be placed in the same place
where the old one was located.
-Clean the place to enable the label to stick and
squeeze out all sir bubbles trapped under it when
sticking on a new label.
(3) Danger label
Caution:
Keep clear of the mower blades while the
engine is running.
(4) PTO label
Caution:
Keep clear of the PTO shaft while the engine is
running.
(5) Discharge label
Caution:
Keep a safe distance from the mower.

14
OPERATION & SERVICE MANUAL FOR MOWER DECK
2-1. Introduction
The information in this publication describes the
operation, maintenance and assembly of the
Mid-Mount Mower. Every effort has been to
provide correct and concise information to you,
the operator, as available at date of publication.
Your ISEKI Dealer is available, should items in
this manual or details of your machine not be
understood.
This manual is supplied with each machine to
familiarize the operator with proper instructions
needed for operation and maintenance. Studying
and adhering to these instructions will insure
optimum machine performance and longevity. A
machine that is maintained properly and operat-
ed in the intended manner will provide greater
dividends than one that is neglected and/or oper-
ated in a manner other than as intended. Design
and servicing of this machine has been kept as
simple as possible to permit maintenance opera-
tions to be carried out with tools normally avail-
able.
This manual should be thoroughly read and
understood prior to operation of this machine.
Inexperienced operators should study the con-
tents of this publication and receive instructions
from an experienced operator when possible.
Your ISEKI Dealer can assist in areas concern-
ing machine operation and provide details con-
cerning safe operation. It is suggested that this
manual be kept readily accessible, preferably
with the machine, for future reference if ques-
tions or concerns arise. If original manual should
become damaged, consult your ISEKI Dealer in
regards to acquiring a replacement.
Note:
Left-hand and right-hand is determined by the
facing the direction the machine will travel when
in use.
The customer is strongly advised to use an offi-
cial ISEKI Dealer in connection with any service
problems and adjustments that may occur. The
ISEKI Dealer network is specially trained and
equipped for all service work and to advise cus-
tomer on specific applications of the tractor in
local conditions.
Caution:
In some of the illustrations used in this
Operator Instruction Book, panels or guards
may have been removed for clarity. Never oper-
ate the tractor with these panels and guards
removed. If the removal of a shield is necessary
to make a repair, it MUST be replaced before
operation.
Caution:
READ THIS BOOK IN ITS ENTIRETY
PRIOR TO OPERATING MACHINE. Use only
ISEKI parts for repairs and/or replacement.
CHAPTER 2. GENERAL INFORMATION

15
CHAPTER 2. GENERAL INFORMATION
2-2. Machine identification
Each mower is identified by means of model and
serial numbers.
To ensure prompt, efficient service when order-
ing parts or requesting repairs from authorized
ISEKI Dealer, record these numbers in the
spaces provided.
Fig.2-1
Machine Model Number:
Machine Serial Number:
Date of Delivery:
Dealer Name and Address:
Dealer Telephone Number:
Dealer E-mail Address:
Dealer Fax Number:

16
OPERATION & SERVICE MANUAL FOR MOWER DECK
The mower identification plate (1) is located on
the right-hand side of the deck.
SSM48-TM3160E4
Fig.2-2
SSM54-TM3240E4 / HE4
Fig.2-3
SSM60-TM3240E4 / HE4
Fig.2-4
SRM48-TM3160E4
Fig.2-5
SMM54-TM3240E4 / HE4
Fig.2-6
SSM60-TH4330E4
Fig.2-7

17
CHAPTER 2. GENERAL INFORMATION

18
OPERATION & SERVICE MANUAL FOR MOWER DECK
SSM48-TM3160E4
CHAPTER 3. SPECIFICATIONS
inch (mm)
inch (mm)
inch (mm)
inch (mm)
lbs (kg)
inch (mm)
inch (mm)
inch (mm)
inch (mm)
inch (mm)
inch (mm)
inch (mm)
rpm
rpm
rpm
rpm
m/s
m/s
inch (mm)
SSM48-TM3160E4
TM3160-F
Rotary Mower
Side Discharge
48" (1224)
3
33.9 (862)
60.0 (1523)
10.8 (274)
242.5 (110)
Adjustable in 7 stages by pin replacement
1.2 (30)
1.6 (40)
2.0 (50)
2.4 (60)
2.8 (70)
3.5 (90)
4.7 (120)
2045
2250
3477
3824
1.7
77.9
85.7
16.9 (428)
Model
Suitable Machine
Type
Discharge Type
Cutting Width
Number of Blades
Dimension Overall Length
Overall Width
Overall Height
Weight (Mower Deck + Linkage)
Cutting Height Adjustment
Cutting Heights
Gear Box
Gear Ratio (Bevel Gear: In/Out)
Blade Tip Velocity
Blade Length
Input
Output
(rated)
(max.)
(rated)
(max.)
(rated)
(max.)

19
CHAPTER 3. SPECIFICATIONS
SSM54-TM3240E4 / HE4
inch (mm)
inch (mm)
inch (mm)
inch (mm)
lbs (kg)
inch (mm)
inch (mm)
inch (mm)
inch (mm)
inch (mm)
inch (mm)
inch (mm)
rpm
rpm
rpm
rpm
m/s
m/s
inch (mm)
Rotary Mower
Side Discharge
54" (1369)
3
36.6 (929)
67.2 (1708)
13.2 (335)
308.6 (140)
Dial Gauge
(Adjustable in 7 stages by pin replacement)
1.2 (30)
1.6 (40)
2.0 (50)
2.4 (60)
2.8 (70)
3.5 (90)
4.7 (120)
SSM54-TM3240E4
TM3240-F TM3200-F
TM3240-FH TM3200-FH
2127
2340
3616
3977
1.7
18.6 (472)
2045
2250
3477
3924
2013
2214
3422
3764
1935
2129
3290
3618
89.3
98.2
85.9
94.5
84.5
93.0
81.3
89.4
SSM54-TM3240HE4Model
Suitable Machine
Type
Discharge Type
Cutting Width
Number of Blades
Dimension Overall Length
Overall Width
Overall Height
Weight (Mower Deck + Linkage)
Cutting Height Adjustment
Cutting Heights
Gear Box
Gear Ratio (Bevel Gear: In/Out)
Blade Tip Velocity
Blade Length
Input
Output
(rated)
(max.)
(rated)
(max.)
(rated)
(max.)
