INSTALLATION GUIDE
1. TECHNICAL SPECIFICATIONS
Wall mounting antivandal heavy duty reader/writer for F9000 keys.
PRODUCT:
- Solid metal antivandal housing: impact protection grade IK10.
- All weather outdoor usage: IP66, IP67 and IP69 protection grade.
- High corrosion resistance: tested for 480 hours in NSS (Neutral Salt Spray chamber).
- Security fixing screws.
- Ability to replace the mechatronic cylinder core.
- No sharp edges (all rounded edges).
- RS485 interface.
- Power supply: by Atlas
- Power consumption: 2W
- Multicolor signaling LEDs (green, blue, red).
- LxDxH = 150 x 90 x 53 mm
FEATURES:
EN60068-2-1, EN60068-2-2, EN60068-2-3, IEC 60529, IEC 62262.
CERTIFICATIONS:
- Operating temperature: -40°C ÷ +80°C
- Storage temperature: -40°C ÷ +80°C
- Humidity: max 93% without condensation
ENVINRONMENTAL CHARACTERISTICS:
2. PACKAGE CONTENTS
Back cover
fixing plate
1x
1x
Adhesive
gasket
Security fixing
screws
4x
Torx TR20 x 100
(M4 x 8)
Cable
gasket
1x
Front cover with
Electronic board
1x
90
150 53
UM = mm
4. DIMENSIONS
40
120
ø6
26
7
5. ELECTRICAL CONNECTIONS
TX/RX 485 (A)
TX/RX 485 (B)
(10 ÷24 Vdc)
(GND)
Heavy Duty Reader
connector (RS485)
- Wiring cable not included in the kit.
- Recommended cable: Ethernet
cable FTP AWG24 CAT5E (and above
or equivalent data cable).
- Min/max cross-section of the wires:
0.20÷1.5mm
2
(24÷15AWG).
- Min/max cable diameter: 3÷7mm
- Max length: up to 500mt
R
6. ELECTRICAL CONNECTIONS: ATLAS TYPE AND CONNECTORS
Wall fixings not provided in the kit. The installator must choose the most suitable fixings according to the
wall type and material. ISEO recommends to install the Heavy Duty Reader in a concerete wall by M10 steel
anchors with M6 bolts.
Minimum recommended traction load for anchors: 150Kg.
Maximum bolts diameters 6mm.
Maximum bolts head dimension: 14mm diameter x 6mm thickness.
1
2
R = 120 ohm - 1/4 W
(Supplied with the reader)
3.1 WARNINGS
Read this manual prior to use the device in order to ensure a safe and proper use.
Preserve this manual as future reference.
The installation of the device requires the intervention of qualified staff, adequately trained by ISEO.
The instructions should be carefully followed during the use of the product. These instructions should be
passed on by the installer to the user.
No modifications of any kind are permitted, except for those described in these instructions.
The product must be destined only for the use for which it is expressly designed and therefore as an heavy duty
reader and writer unit for civil and industrial locations. Any other use is considered improper and dangerous.
Keep the Front cover inside its box during the installation of the Back cover fixing plate, to prevent
drilling residues from entering inside the Electronic board.
Use the Adhesive gasket only in case of not-straight or no flat wall. If the Adhesive gasket is required,
take care to uniformly apply it to seal the reader to the wall, in order to avoid any water penetration.
Check if the Back cover gasket is correctly fitted in the slot. If not re-position it correctly in order to avoid
any water penetration.
Do not enlarge, damage or modify the Cable gasket, failure to do that it could compromise the water
sealing. Use a max cable diameter of 7mm to ensure the cable passage through the cable gasket hole.
Check the Wiring cable perfectly fits inside the Cable gasket hole without leaving any space that could
allow water penetration. Use a min cable diameter of 3mm to ensure the cable gasket impermeability.
3. WARNINGS
Back cover
gasket
ATLAS DIN
ATLAS STANDARD (STD)
ATLAS PLUS
CH1
4
3
2
1
(GND)
CH2
4
3
2
1
5
6
CH2
4
3
2
1
(GND)
CH1
4
3
2
1
(GND)
ø
min.3mm
max.7mm
ø
1x
R = 120 ohm - 1/4 W
(Connect to ATLAS)

UP
UP
9.1 INSTALLATION EXAMPLE: VERTICAL WITH ADHESIVE GASKET (NOT FLAT WALL)
8. INSTALLATION EXAMPLE: VERTICAL ON A WALL
UP
UP
8.1 INSTALLATION EXAMPLE: HORIZONTAL ON A WALL
7. ELECTRICAL CONNECTIONS EXAMPLE: TO ATLAS BY ETHERNET CABLE
Ethernet cable
FTP AWG24 CAT5E
(Max length 500mt)
R
4
3
2
1
ATLAS PLUS/STD CH1 (J5)
ATLAS DIN CH1 and CH2
R
A
B
Heavy Duty Reader
connector (RS485)
Maximum Ethernet cable length between Atlas and Heavy Duty Reader: 500mt.
Required Atlas power supply: 24Vdc.
Resistance value: 120 ohm (1/4W) on both Atlas and F9000 Reader sides.
Connect the ethernet cable shield to the Atlas GND connector only if Atlas NOT connected to ground.
(GND)
R = 120 ohm (1/4 W)
For more information about Atlas and its connectors, refer ot the Atlas Installation Guide avalable at:
app.iseo.com.
Adhesive
gasket
Back cover
fixing plate
9. ADHESIVE GASKET USE
WALL
WALL
7.1 ELECTRICAL CONNECTIONS EXAMPLE: TO ATLAS BY ETHERNET CABLE
Ethernet cable
FTP AWG24 CAT5E
(Max length 500mt)
R
4
3
2
1
R
A
B
(GND)
R = 120 ohm (1/4 W)
7.2 ELECTRICAL CONNECTIONS EXAMPLE: TO ATLAS BY ALARM CABLE
Alarm cable (shielded)
4 x 0,35mm - 22AWG
(Max length 100mt)
4
3
2
1
A
B
Required Atlas power supply: 24Vdc.
(GND)
R = 120 ohm (1/4 W)
ATLAS PLUS/STD CH2 (J11)
and CH1 (J5)
ATLAS PLUS/STD CH1 (J5)
ATLAS DIN CH1 and CH2
UP
UP
4
3
2
1
(GND)
4
3
2
1
5
6
CH1
CH2
See warnings in box 7
7.3 ELECTRICAL CONNECTIONS EXAMPLE: TO ATLAS BY ALARM CABLE
4
3
2
1
A
B
(GND)
R = 120 ohm (1/4 W)
4
3
2
1
(GND)
4
3
2
1
5
6
CH1
CH2
See warnings in box 7.2
Heavy Duty Reader
connector (RS485)
Heavy Duty Reader
connector (RS485)
Heavy Duty Reader
connector (RS485)
ATLAS PLUS/STD CH2 (J11)
and CH1 (J5)
Alarm cable (shielded)
4 x 0,35mm - 22AWG
(Max length 100mt)
Wall fixings not provided in the kit. Wall fixings not provided in the kit.
Wall fixings not provided in the kit.
Recommended capacitance conductor/conductor < 100pF/m.
Recommended conductors electrical resistance max 90 ohm/Km.
Maximum cable length between Atlas and Heavy Duty Reader: 100mt.
Resistance value: 120 ohm (1/4W) on both Atlas and F9000 Reader sides.
Connect the ethernet cable shield to the Atlas GND connector only if Atlas NOT connected to ground.
For more information about Atlas and its connectors, refer ot the Atlas Installation Guide avalable at:
app.iseo.com.
Recommended capacitance conductor/conductor < 100pF/m.
Recommended conductors electrical resistance max 90 ohm/Km.
R
RR
R
Ethernet cable FTP AWG24 CAT5E (and above).
Shielded alarm cable good quality 4 x 0,35mm (22AWG).
A
B
A
B
A
B
A
B
