INTRODUCTION
– This manual is integral part of the product. Read carefully the instructions contained since
it contains important indications for the safety of use and of maintenance.
– The technical information and the relative products of this manual could be modied
without any previous notice.
– The ow meter must be used for the use it has been built for. The improper use, possible
tampering of the instrument or parts of it and substitutions of any components not original,
makes the warranty to decay automatically.
– The manufacturer is considered responsible only if the instrument is used in its original
conguration and setting.
– The owmeter makes measures of liquids with conductivity greater than 5µS/cm; it consists
of a sensor (described in this manual) and a converter, for it see the manual provided.
– If the sensor is supplied in compact version to the converter, consider the operating
temperatures more restrictive, otherwise refer to the respective manuals (page 4).
– When transporting, unpacking and handling the owmeter, be careful and care.
– In the case of prolonged storage and of transport, use and store in the original container
in a dry place, do not place more than 3 packs one above the other.
– It is possible pallets storage and transport (in case of wooden crates do not place one
above the other).
– For the cleaning of the device use only a damp cloth, and for the maintenance/repairs,
contact the customer service.
– For the disposal of the device and of the packaging make strict reference to the regulations
– It is forbidden the reproduction of the present manual and of possible software supplied
with the instrument.
START UP AND MAINTENANCE OF THE INSTRUMENTS
– Before starting up the instrument, always make a sure connection to ground as suitable
to page 4.
– Verify periodically: the cables integrity, the tightening of the sealing elements (cable glands,
covers, etc.), the mechanical xing of the instrument on the pipe or on the wall stand

2
SENSOR FOR ELECTROMAGNETIC FLOW METER – MANUAL
2500_EN_IT_IS_R2_PED
Before using the instrument, always make a sure connection to the ground
Avoid any attempt to repair the instrument. If the instrument is not
functioning properly, please call the nearest assistance service
Pay maximum attention during the operations
ATTENTION !!!
DANGER !!!
SAFETY
GENERAL INFORMATION ON THE SENSORS INSTALLATION
Before install the sensor locate the
direction of the liquid in the piping
The sign of the ow rate is positive,
when the ow direction is from – to +
as printed on the tag plate.
If after the installation, for plant request
becomes necessary reverse the sign of
the ow, it is enough reverse the sign
of the coefcient KA
?
-+
Flow direction
liFting sensors
The sensors with eyebolts must be
lifted by the method shown below.
The eye-bolt are measured to sustain
exclusively the weight of the meter

3
SENSOR FOR ELECTROMAGNETIC FLOW METER – MANUAL
2500_EN_IT_IS_R2_PED
shrewdness and Precautions
3 X DN
2 X DN
2mm
2mm
Install the sensor away from bends and hydraulic accessories
Avoid positioning flanges by tigthening the nuts.
In vertical installations an ascending flow is preferable. For vertical installations with descending flow
direction contact the manufacturer
For installations in long pipe lines, please use anti vibration joints
Avoid a partially empty pipe, during operation the pipe must be either completely full of liquid or completely
empty
LONG PIPE
ANTI VIBRATION JOINTS
OPERATING TEMPERATURES
EBANITE PP RILSAN® PTFE HT
Liquid
Temp.
Ambient
Temp.
Liquid
Temp.
Ambient
Temp.
Liquid
Temp.
Ambient
Temp.
Liquid
Temp.
Ambient
Temp.
Liquid
Temp.
Ambient
Temp.
Min. Max Min. Max Min. Max Min. Max Min. Max Min. Max Min. Max Min. Max Min. Max Min. Max
°C 0 80 -5 60 0 60 0 60 0 70 0 60 -20 130 -10 60 -20 180 -10 60
°F 30 176 23 140 32 140 32 140 32 158 32 140 -4 266 14 140 -4 356 14 140

4
SENSOR FOR ELECTROMAGNETIC FLOW METER – MANUAL
2500_EN_IT_IS_R2_PED
GROUNDING INSTRUCTIONS
For correct operation of the meter is NECESSARY that the sensor and the liquid are equipotential,
so ALWAYS connect the sensor and converter to ground:
grounding with metallic PiPe
grounding with insulating PiPe
grounding when there is acathodic Protection over the PiPe
INSULATING GASKET
INSULATING BUSH
METALLIC RING
If the sensor must be install in the piping with a
cathodic protection, is necessary:
• using insulating bushes to isolate the bolts
• Grounding metallic rings should be provided
to ground the liquid using insulating gasket
between the rings
IMPORTANT: The ripple of DC power source
used for cathodic protection shall be = 0
INSULATING GASKET
METALLIC RING
If the sensor has to be mounted on a pipe made of
an insulating materials necessary:
• Install two metallic ring between the sensor
anges and the counter anges of the pipe line
or
• Use a sensor with the additional grounding
electrode

5
SENSOR FOR ELECTROMAGNETIC FLOW METER – MANUAL
2500_EN_IT_IS_R2_PED
OPERATIVE PRESSURE
Kpa 1000 1600 2500 4000 6400
psi 140 260 350 600 1000
DN PTFE EBON. PTFE EBON. PP PTFE EBON. PTFE EBON. EBON.
25 25
(21) 19 25 25 [32]
135
[95]
32 43
(26) 28 43 43 [40]
184
[115]
40 53
(32) 36 53 53 [63]
250
[184]
50 68
(60) 52 68 68 [35]
284
[101]
65 90
(78) 75 45 45 [53]
203
[156]
80 53
(89) 41 53 53 [68]
218
[200]
100 59
(70) 56 83 83 [94]
305
[273]
125 77
(94) 71 112 112 [130]
519
[380]
150 108
(106) 106 135 135 [113]
758
[328]
200 148 432 99
(148)
288
(433) 134 391 178 [178]
520
[519]
816
[519]
250 123 359 140
(156)
408
(455) 204 595 267 [185]
780
[540]
1124
[540]
300 142 415 175
(234)
510
(683) 201 588 278 [275]
812
[803]
1108
[803]
350 172 502 205
(325)
598
(946) 324 945 422 [318]
1231
[927]
1684
[927]
400 217 632 282
(312)
821
[phone] 619 [411]
1805
[1198]
2180
[1198]
450 194 564 281
(336)
981
(926) [398] [1161]
500 224 652 382
(317)
1113
(924) [465] [1356]
550 (379) (1105) [608] [1772]
600 323 942 568
(463)
1658
(1350) [774] [2258]
650 (429) (1251) [753] [2195]
700 356 1040 421
(503)
1230
(1468) [947] [2761]
750 (451) (1315) [1105] [3223]
800 476 1388 549 1603
850 (563) (1642) [1373] [4006]
900 450 1312 519
(618)
1515
(1803) [1408] [4106]
1000 582 1699 721
(736)
2105
(2146) [1598] [4662]
TORQUES (NM) FOR FLANGED SENSOR’S BOLTS
• Tighten uniformly in diagonally opposite sequence
• The torque listed in tab are applicable to anges: EN1092-1, DIN2501, BS4504, ANSI
B16.5, JIS
• Is recommended the use of gaskets DIN 2690
• For DN > 1000 contact the manufacturer
• (***)= ANSI 150
• [***]= ANSI 300

6
SENSOR FOR ELECTROMAGNETIC FLOW METER – MANUAL
2500_EN_IT_IS_R2_PED
NOTES FOR PED DIRECTIVE FOR SENSOR
Here below the tables of products subject to Directive 97/23/EC.
The models are : MS1000/MS2410/MS2500.
The tables show which category of PED is applicable according to the water operating
temperature (TAB A T <110 ° C TAB B T> = 110 ° C), sensor’s DN and its nominal pressure.
DN NOMINAL PRESSURE (PN)
10 16 25 40
25
USE PN 40
E
32 E
40 E
50
USE
PN 16
E
USE
PN 40
E
65 E E
80 E E
100 E E
125 E E
150 E E
200 EEEE
250 IIII
300 IIII
350 IIII
400 IIII
450 IIII
500 IIII
600 IIII
700 IIII
800 IIII
900 IIII
1000 IIII
1200 IIII
1300 IIII
1400 IIII
1500 IIII
1600 IIII
1700 IIII
1800 IIII
2000 IIII
2400 IIII
tab. a
Ped directive For water with
temPerature <110°c
all lining : PP, ebonite,PtFe
DN NOMINAL PRESSURE (PN)
10 16 25 40
25
USE PN 40
E
32 E
40 II
50
USE
PN 16
I
USE
PN 40
II
65 I II
80 I II
100 I II
125 I II
150 I II
200 I I II II
250 I II II II
300 I II III III
350 I III III III
400 II III III III
450 II III III III
500 II III III III
tab. b
Ped directive For water with
temPerature >=110°c
only PtFe lining
legenda
E OUT OF DIRECTIVE
I PED CAT. I
II PED CAT. II
III PED CAT. III
For products that falls in category I, is valid the declaration of conformity available on the
following page; the products in Category II and III are supplied with a specic declaration of
conformity for each instrument

7
SENSOR FOR ELECTROMAGNETIC FLOW METER – MANUAL
2500_EN_IT_IS_R2_PED
DECLARATION OF CONFORMITY TO EUROPEAN
DIRECTIVE PED – 97/23/CE
Prepared in accordance with Annex VII Legislative Decree no. 93 of 25 February 2000
transposing Directive no. 97/23/EC
Description of the
product
Misuratore di portata di liquidi del gruppo 2
Temperatura massima del liquido 110°C
Model family MS 2500 – MS1000 – MS2410
Conformity assessment
procedure applied Allegato II - categoria I - Modulo A
Standard reference UNI EN 13480-3
Hemina declares that the equipment specied above model should fall within the scope
of the Directive, are:
¾comply with the requirements of Directive 97/23/EC - PED and DL 93/2000 which
transposes in Italy
Identication and signature of the legal representative:
Roberto Guazzoni – President of Board of Directors
