ISOIL ISOMAG MS5000 User manual
MANUAL
ISOIL
INDUSTRIA
MAN_MS5000_IT_EN_IS_R03
MS5000
The manufacturer guarantees only English text available on our web site www.isoil.com
MAN_MS5000_IT_EN_IS_R03
ISOIL
INDUSTRIA
3 / 10
INTRODUCTION
This manual is integral part of the product. Read carefully the instructions contained since it contains important
indications for the safety of use and of maintenance.
The technical information and the relative products of this manual could be modied without any previous notice.
The ow meter must be used for the use it has been built for. The improper use, possible tampering of the instrument
or parts of it and substitutions of any components not original, makes the warranty to decay automatically.
The manufacturer is considered responsible only if the instrument is used in its original conguration and setting.
The owmeter makes measures of liquids with conductivity greater than 5µS/cm; it consists of a sensor (described in
this manual) and a converter, for it see the manual provided.
If the sensor is supplied in compact version to the converter, consider the operating temperatures more restrictive,
otherwise refer to the respective manuals (page 5).
When transporting, unpacking and handling the owmeter, be careful and care.
In the case of prolonged storage and of transport, use and store in the original container in a dry place, do not place
more than 3 packs one above the other. It is possible pallets storage and transport (in case of wooden crates do not
place one above the other).
For the cleaning of the device use only a damp cloth, and for the maintenance/repairs, contact the customer service.
For the disposal of the device and of the packaging make strict reference to the regulations.
It is forbidden the reproduction of the present manual and of possible software supplied with the instrument.
START UP AND MAINTENANCE OF THE INSTRUMENTS
Before starting up the instrument, always make a sure connection to ground.
Verify periodically: the cables integrity, the tightening of the sealing elements (cable glands, covers, etc.), the
mechanical xing of the instrument on the pipe or on the wall stand.
The manufacturer guarantees only English text available on our web site www.isoil.com
MAN_MS5000_IT_EN_IS_R03
4 / 10
L
“L” VALUES
DN L (mm) L (inches)
20 92 3.62
25 92 3.62
32 89 3.5
40 92 3.62
50 108 4.25
65 109 4.29
80 138 5.43
ASSEMBLY INSTRUCTIONS
The manufacturer guarantees only English text available on our web site www.isoil.com
MAN_MS5000_IT_EN_IS_R03
ISOIL
INDUSTRIA
5 / 10
TIGHTEN THE SCREWS
BLOCK THE PIPE *
Verify the ow direction
Assemble the sensor to the pipe
Tighten le wrapper to avoid possible drippings
Connect the instrument to ground by the socket on sensor
* Lock the pipe to a strong support
The manufacturer guarantees only English text available on our web site www.isoil.com
MAN_MS5000_IT_EN_IS_R03
6 / 10
OPERATING TEMPERATURE
LIQUID TEMPERATURE ENVIRONMENT TEMPERATURE
Min. Max. Min. Max.
°C 050 050
°F 32 122 32 122
The manufacturer guarantees only English text available on our web site www.isoil.com
MAN_MS5000_IT_EN_IS_R03
ISOIL
INDUSTRIA
7 / 10
ELECTRICAL CONNECTIONS OF SENSOR TO CONVERTER
(CONNECTIONS TO CONVERTER: SEE PROPER MANUAL)
Cavo 1
1
2
3
45
67
89
10
Cavo 2
Cavo 3
Cavo 12
Cavo 13
Cavo 6
Cavo 7
Cavo 8
Cavo 9
Cavo 10
CABLE FROM INSIDE THE
SENSOR (PINS 1 – 5) ALREADY
CONNECTED
CABLE C014 TO THE CONVERTER
(PINS 6 – 10)
VERSION SUITABLE FOR SENSOR’S
CONNECTION
COMPACT ALL SENSORS MODEL NO CONNECTIONS
SEPARATE WITHOUT
JUNCTIONS-BOX
STAINLESS STEEL
MODEL
NO CONNECTIONS
REQUIRED
(CABLE ALREADY
CONNECTED AND
POTTED)
SEPARATE WITH
OR WITHOUT
JUNCTIONS-BOX
ALL CARBON STEEL
MODELS
NO CONNECTIONS
REQUIRED
(CABLE ALREADY
CONNECTED AND
POTTED)
SEPARATE WITH
PREAMPLIFIER ALL SENSORS MODEL SEE BELOW
The manufacturer guarantees only English text available on our web site www.isoil.com
MAN_MS5000_IT_EN_IS_R03
8 / 10
MANUAL REVISION
REVISION DATE DESCRIPTION
MAN_MS5000_IT_EN_IS_R03 21/05/2021 GRAPHICS UPDATE AND NOMENCLATURE UPDATE
The manufacturer guarantees only English text available on our web site www.isoil.com
MAN_MS5000_IT_EN_IS_R03
ISOIL
INDUSTRIA
9 / 10
At the end of its lifetime, this product shall be disposed of in full compliance with the environmental regulations of the state
in which it is located.
ISOIL INDUSTRIA S.p.A.
HEAD OFFICE SERVICE
Via Fratelli Gracchi, 27
20092 Cinisello Balsamo (MI)
Tel +39 02 66027.1
Fax +39 02 6123202
Due to the constant technical development and improvement of its products, the manufacturer reserves the right to
make changes and/or modify the information contained in this document without notice.
If you want to nd the complete list of our distributors access at the following link:
http://www.isoil.it/en
