Issey Miyake TO automatic User manual

Before using your watch, please read the instructions in this
manual carefully for its proper use and care, and keep this manual
for ready reference.
Instruction

20
21
HOW TO USE AUTOMATIC MECHANICAL WATCH
• This is an automatic mechanical watch with manual winding mechanism.
• If the watch is worn on the wrist, the mainspring will be wound
automatically through normal wrist movement. It can also be wound up by
turning the crown.
• To start the watch after it stops completely, wind it up either by turning the
crown or swinging it from side to side until the second hand starts moving.
Then, set the time and date before wearing the watch on the wrist.
• To wind up the watch by turning the crown, turn it clockwise slowly. The
watch cannot be wound by turning the crown counterclockwise. After the
watch is wound up fully, turning the crown further will not break the spring.
• Once the watch is wound up fully, it operates more than 50 hours. If the
watch is used without being wound up fully, gain or loss of the watch may
result. To avoid this, wear the watch for more than 8 hours a day. If the
watch is used without wearing on the wrist; if it is used on the desk, for
example: be sure to wind it up fully every day at a fixed time.
CONTENTS
HOW TO USE AUTOMATIC MECHANICAL WATCH . . . . 21
PARTS NAMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
TIME SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
ADJUSTING THE LEATHER BAND . . . . . . . . . . . . . . . . . 24
TO PRESERVE THE QUALITY OF YOUR WATCH . . . . . 25
REMARKS ON THE REPLACEMENT PARTS . . . . . . . . . 30
TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
ACCURACY OF MECHANICAL WATCHES . . . . . . . . . . . 33
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
The symbol and character indicate that unless the
following safety regulations are strictly observed,
serious personal injury may result.
The symbol and character indicate that unless the
following safety regulations are strictly observed,
slight personal injury or property may result.



22
23
TIME SETTING
(1) Pull out the crown to the second click.
(2) Turn the crown to the current time.
* The mechanism of the mechanical watch is
different from that of the quartz watch. To set
the time accurately, first turn the minute hand
4 to 5 minutes behind of the desired time and
then advance it to the correct time.
(3) Push the crown back in to the normal position.
PARTS NAMES
Minute Hand
Hour Hand
Crown
Time indicator
a: Normal position
b: First click (Not used)
c: Second click
12 o'clock position
6 o'clock position

24
25
TO PRESERVE THE QUALITY OF YOUR WATCH
PRECAUTIONS ON WEARING YOUR WATCH
• In case you tumble, fall or bump into others with the watch worn on your
wrist, you may be injured because you are wearing the watch.
• When you come into contact with children, especially with infants, they may
get injured or develop a rash caused by an allergic reaction.
• Your watch may damage property or malfunction depending on your
actions when wearing it. Special care should be taken.
• When clasping and unclasping the band, you may damage your nail,
depending on the type of clasp used with the band.
CARING FOR YOUR WATCH
• The case and bracelet contact the skin directly just like underwear. If they
are left dirty, the edge of a sleeve may be stained with rust or those who
have delicate skin may develop a rash.
• After removing the watch from your wrist, wipe off perspiration or moisture
with a soft cloth. This will prevent the watch from being soiled, which will



ADJUSTING THE LEATHER BAND
(1) Push the buttons on both sides of the buckle to
open the clasp.
(2) Push the buttons again and pull the stopper on
the back of the buckle.
(3) Gently and slowly remove the stopper hook
from the band hole. Then, adjust the band
length to your arm while sliding the band.
Failure to gently and slowly remove the hook
might result in band hole damage.
(4) Pull down the stopper so as to pass its hook
through the hole of the band.

Buckle

26
27
RASHES AND ALLERGIES
• Adjust the bracelet or band so that there is little clearance between the
bracelet or band and your wrist to prevent perspiration from accumulating.
• If you are constitutionally predisposed to rash, the band may cause you to
develop a rash or disorder depending on your physical condition.
• The possible causes of the rash are as follows:
1. Allergy to metals or leathers
2. Rust, dust or perspiration on the watch or band
• If you develop any skin reactions, take off the watch and consult a doctor
immediately.
WATER RESISTANCE
• NEVER WEAR a 10-bar water-resistant watch during saturated diving or air
diving.
• After immersing a 10-bar water-resistant watch in water, remove salt, etc.
as soon as possible. If not, the watch may rust. If you rinse the watch under
running water, excessive water pressure applies to the watch, possibly
causing a failure in its water resistance. Always rinse the watch in a pot or
bowl and be careful not to apply excessive water pressure to the watch.
• If a leather band gets wet, its durability may be affected.



prolong the life of the gasket.
• Your watch is extremely sensitive to chemicals, including benzene, thinner,
alcohol, detergent and other organic solvents. Keep your watch away from
chemicals and avoid chemical reactions with your watch. If not, it may
degrade.
<Leather band>
When removing moisture from a leather band, do not rub the band with
the cloth as this may discolor it or reduce its gloss. Be sure to blot up the
moisture using a soft dry cloth. (If a leather band gets wet, its durability may
be adversely affected.)
<Metal band>
Clean the watchband with a soft toothbrush dipped in water or soapy
water, and be sure to blot up the moisture using a soft dry cloth. If your
watch is not water-resistant, be careful not to get the case wet when
cleaning.
<Soft plastic band>
If your watch has a soft plastic band such as urethane, do not leave the
watch under a fluorescent lamp or direct sunlight for a long period of
time, or do not leave the band soiled. Otherwise, the band may discolor,
harden or break. Also, do not keep the watch in places where exposed to
high humidity, and do not leave the band wet with perspiration or water.
Otherwise, the band may discolor in a very short time. When the band is
soiled, rinse it in soapy water. Do no use solvents for cleaning as some
solvents may degrade the band. If your watch has a semitransparent
urethane band, which is easily discolored, special care should be taken to
keep it clean. Depending on the condition of use, the semitransparent band
may discolor after several months of use.

28
29
PERIODIC CHECK
• We suggest that you have your watch checked every 2 or 3 years by the
retailer from whom you purchased the watch. Depending on how the watch
is used, the lubrication of the watch mechanism may become insufficient,
parts may become worn due to impurities in the lubricating oil, or the
watch may be running noticeably fast or late. Seals, etc., may also become
worn and the watch may stop being waterproof. Take your watch to the
retailer from whom you purchased it for inspection and adjustment through
disassembly/cleaning.
• When replacing the parts, please specify “GENUINE PARTS”.
• It is recommended that the gasket and the push-pin be also replaced with
new ones.
PLACES TO KEEP YOUR WATCH
When not in use, the watch may be damaged, degraded or broken in any of
the following cases.
• If the watch is exposed to a temperature below -5°C or above +50°C for
a long period of time, its performance may be impaired or it may stop
operating.
• If the watch is exposed to direct sunlight, high temperatures or low
temperatures for a long period of time, it may gain or lose time.
• If the watch is exposed to magnetic leakage from TV sets, speakers, mobile
phones, magnetic necklaces, etc., it may gain or lose time.
• If the watch is exposed to strong vibrations, it may be broken or gain or
lose time.
• If the watch is exposed to chemicals or chemical steam, it may degrade or
break.
Examples of chemicals: Benzene, thinner, nail polish, cosmetic sprays,
cleaners, toilet solvents, adhesive agents, mercury, iodized disinfectants,
insect repellents, etc.
• If the watch is exposed to hot spring water or other special environment or
put in a box containing insect-killer, it may degrade.
• It is recommended that the watch be put in a clean box or case and stored
in a well-ventilated place.

30
31
TROUBLE SHOOTING
The watch gains/loses time.
[Possible cause]
• It was left in extremely high or low temperature.
➔ This condition will be corrected when the watch temperature returns to
normal.
[Possible cause]
• The watch was brought into close contact with a magnetic objects.
➔ This condition will be corrected when the watch is kept away from close
contact with the magnetic source. If the condition is not corrected,
contact the retailer from whom the watch was purchased.
[Possible cause]
• You dropped the watch, hit it against a hard surface or wore it while playing
active sports.
• The watch was exposed to strong vibration.
➔ The accuracy cannot be restored to its original level. Contact the retailer
from whom the watch was purchased.
[Possible cause]
• The watch was not taken in for inspection and adjustment through
disassembly/cleaning for a long time exceeding 3 years.
➔ Contact the retailer from whom the watch was purchased.
REMARKS ON THE REPLACEMENT PARTS
(Replacement parts are those which are essential to maintaining the functional
integrity of the watch.)
• The number of years that a watch is considered repairable may vary
greatly depending on the conditions under which it was used, and normal
accuracy may not be achieved in some cases. We recommend, therefore,
that you consult the shop from whom the watch was purchased when
having the repair your watch.
• The case, dial, hands glass and band, or parts thereof may be replaced
with substitutes if the originals are not available.

32
33
The watch stops operating.
[Possible cause]
• The mainspring is not wound.
➔ Swinging the watch from side to side will get it moving again. If this fails,
contact the retailer from whom the watch was purchased.
The surface of the glass is foggy.
[Possible cause]
• Water entered the watch through a deteriorated packing.
• The crown was turned or pulled out when the watch was wet.
➔ Contact the retailer from whom the watch was purchased.
* For the solution of troubles other than above, contact the retailer from
whom the watch was purchased.
ACCURACY OF MECHANICAL WATCHES
Mobile accuracy and static accuracy
• “Mechanical watch accuracy” has two meanings. In this manual, “mobile
accuracy” refers to accuracy expressing weekly time gain/loss in a watch
worn under given conditions as a daily average.
• On the other hand, mechanical watch inspections generally measure time
gain/loss in a static state in which movements are subjected to a number of
orientation and temperature conditions. This is called “static accuracy.”
Daily rate
The accuracy of mechanical watches is called the “daily rate.”
The accuracy of mechanical watches varies slightly from day to day and
usually is not fixed. Thus, the gain/loss of a watch that is worn is not judged
on a single-day basis and instead a weekly average is used. Depending on the
number of hours the watch is used, the usage environment, etc., the accuracy
range indicated In this manual may be exceeded.
Accuracy variation due to temperature
Metal is used in the parts that contribute to the accuracy of mechanical
watches. A well-known characteristic of metals is their tendency to expand
and contract as the result of changes in temperature. This in turn affects
the accuracy of a watch. Mechanical watches tend to run slow at high
temperatures, and run fast at low temperatures.

34
35
SPECIFICATIONS
Time indication: Two hands (hour, minute)
Vibrations per hour: 21,600/h
Loss/gain: Day rate +25 seconds to -15 seconds
at normal temperatures of between 5°C and 35°C
Driving system: Mainspring winding
(automatic winding and self-winding)
Jewels used: 23 jewels
* Due to the mechanism of mechanical watches, actual loss/gain may not
fall within the range of time accuracy specified above, depending on the
conditions of use, such as the length of time during which the watch is
worn on the wrist, life style (whether much arm movement is involved or
not), etc.
* The vibration per hour represents the vibration of the balance.
The above specifications are subject to change without notice.
Mainspring tension and accuracy
Supplying a regular amount of energy to the balance wheel that controls the
speed of the wheels is an important aspect of raising the accuracy.
The mainspring, which is the power source of the mechanical clock, has a
different amount of force depending on whether it is tightly wound or on the
verge of becoming totally unwound. The less it is wound, the weaker its force.
A relatively stable accuracy can be obtained by fully winding the mainspring at
a fixed time every day.
