8
2.2 - POSITIONING
Position the pallet, with the dough
mixer, on a flat surface and unscrew (a)
the screws that fix the machine to the
pallet (Fig. n°12).
At this point, with care, turn the
machine over onto one side and
unscrew the screws to remove the
anchoring plates (b). Fixed the screws
removed onto the bottom cover.
Position the dough mixer in the pre-
destined place.
The surface on which the dough mixer
is to be positioned must take into
consideration the dimensions indicated
in Tab. 1 (based on the model)
therefore the support surfaces must be
wide enough to contain it (Fig. n°13)
and must be well levelled and dry away
from water and heat sources with
suitable ventilation and lighting in
relation to the space necessary for its
use and safe keeping.
(The machine must also be positioned
in a non saline room with a maximum
humidity of 75% and a temperature
included between +5°C and +35°C;
however in rooms that can not cause
malfunctioning of the machine.
Fig. n°13
Fig. n°14
a
Fig. n°12
b
mt 2
mt 1,5
= =
≥mt 0,5
21
CHAP. 5 - USING THE MACHINE
5.1 - STARTING UP THE MACHINE
For 1st use strictly follow the
following instructions:
- check that installation has been
carried out correctly as indicated in
chapter 2;
- lift the tank’s lid (Fig. 35) and pour
inside the tank all of the water and
other liquids necessary for the dough;
- add about 50% of the flour and the
other solid ingredients (Fig. 36);
- close the lid by lowering it up to
slightly touching the tank;
- check before any other operation that
the main switch is ON;
- before switch on, check the voltage of
the distribution network by means of
switch on of the “NETWORK” warning
light (Fig. 37);
- press the “START” button to start the
machine that will start the work cycle;
- after 2-3 minutes stop the machine by
pressing the “STOP” button;
- lift the lid and insert the remaining
flour;
- close the lid and start the machine
that will blend all ingredients,
transforming it into a homogeneous
dough;
- a thermal overload protection circuit
breaker stops the machine in case of a
motor jamming. After removing its
cause, you can reset the protection
and restart the machine in few
minutes.
Fig. n°37
Fig. n° 35
Fig. n°36
“NETWORK”
