Owner’s Manual

Inspired TEC4000

Air Purication System

1 Year Manufacturer’s Warranty

More Information Inside

Table of Contents

Introduction ..................................................................................... 3

Records / Specications........................................................................... 4

Warnings........................................................................................ 5

Features / Benets............................................................................. 6 - 7

Controls / Diagrams .......................................................................... 8 - 11

Setup / Operation........................................................................... 12 - 14

Disassembly / Assembly ...................................................................... 15 - 16

Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Troubleshooting ................................................................................. 18

Warranty....................................................................................... 19

Welcome to the joys of cleaner air and a healthier life. You are now the owner of one of the most technologically-advanced purication systems available—the IT4000.

e combination of four innovative technologies, Photo Catalytic Oxidation (PCO), Needlepoint Ionization, Scalable Purication and Electrostatic Filtration, sets the

IT4000 apart from similar air puriers on the market. e IT4000 uses these technologies to reduce particles and inactivate microbes in the output radius creating a

healthier living space with pristine air quality.

e IT4000 is designed to provide years of trouble-free service when it is properly maintained. Keep this manual. It will guide you through the steps to operate

your machine and the maintenance procedures which will keep your IT4000 in tip-top shape for years to come. Even when properly cared for, some parts

of the unit will need to be replaced periodically. Replacement parts can be purchased from your authorized distributor or directly from Inspired TEC

(www.inspiredtecllc.com).

We hope you enjoy your IT4000 and the overall healthier living environment it creates.

Introduction

Consumer Information

Inspired TEC declines all responsibility for all damages arising from improper

use of the unit or in case of tampering with the unit.

Specications

Unit

Size: 12” high x 9” wide x 12” deep

Weight: 10.2 lb.

Coverage: 250² to 3000² (23m² to 279m²) *

Power Cord

Fuyuang Switching Power Supply

Model: FY3803000

Input: 100-240VAC 50/60Hz 2.5A

Output: 38VDC 3A

See the power supply label for certications and warnings.

PCO Cell

Normal Mode Output: < 0.02 ppm ozone (ambient room concentration)

Purication Plate

High Mode Output: 25-360mg ozone per hour

Ionization Needle

24 to 30 KV, 20-30 Khz Ion Generation Pulsator

6 KV DC Needle Ion Generator

* Depending on variables such as the severity and frequency of pollution, ow

of air in the environment, humidity and temperature.

Records

Purchase Date: _________________________________________

Model Number: _________________________________________

Serial Number: __________________________________________

Distributor Name: _______________________________________

Distributor Phone: _______________________________________

Warnings

Review this list before use and performing any maintenance or cleaning of your unit.

WARNING: Never operate unit near heat source, open ame or ammable/combustible uids.

WARNING: Do not operate unit unless all parts (including PCO Cell, Purication Plate, Rear Filter Assembly and Rear Cover) are properly installed.

CAUTION: Directly viewing the lamp inside unit for an extended period (longer than 20 min.) may result in eye damage.

CAUTION: Never adjust setting to exceed square footage of ventilated space being treated.

CAUTION: Do not use AWAY MODE in occupied spaces. Short term exposure to ozone levels exceeding 0.5 ppm can cause temporary adverse reactions.

CAUTION: Unit should be powered OFF and Power Cord should be disconnected when Cleaning/Disassembling/Reassembling/Servicing.

Features / Benets

Benets

Unlike other air puriers, the IT4000 does more than simply lter the air in your space. Incorporating technology like photo catalytic oxidation, high level negative

ionization, scalable purication and electrostatic ltration allows the air purication system to provide tangible benets to your space by:

• Destroying pollution from the air, embedded in walls, ceilings, oors, carpets, furniture, etc.

• Reducing or eliminating odors such as cigarette smoke, mildew, food, etc.

• Contributing to the sanitization of all surfaces within the space.

e whisper quiet ve-speed fan disguises the power encapsulated in the advanced air purication system. Having the IT4000 in your space will not only improve the

quality of air, but, most importantly, it will improve the quality of life.

Ease of Use

e IT4000 is your hassle-free provider for clean air and healthy living. With proper care and maintenance (see “CLEANING” page 17), the IT4000 will operate with

the same robust power and eciency for several years beyond the date of purchase. With the push of a button the IT4000 starts working to eliminate the biological

contaminates and dangerous pathogens in your space. Enhancing your overall quality of life has never been this easy.

Availability of Support

is Owner’s Manual will provide comprehensive information regarding all aspects of your IT4000. If you experience any technical issues with your device, refer to

the Troubleshooting section of this booklet. e solution for many of the commonly reported problems is listed in detail in the Troubleshooting section (page 18).

If the problem you are experiencing is not listed in the Owner’s Manual and/or you need additional support, please feel free to email us at support@inspiredtecllc.com.

Four Technologies

Advanced Photo Catalytic Oxidation

e Photo Catalytic Oxidation (PCO) Technology in the IT4000 not only destroys

biological contaminates but also produces purifying plasma which eliminates

odors, mold, bacteria and viruses. PCO Cells have been proven to reduce

dangerous pathogens by more than 99% in less than 24 hours through a process

called molecular disassociation which actually breaks down the molecules instead

of simply covering up the source. e result at the end of the breakdown process:

harmless carbon dioxide and water vapor.

Needlepoint Ionization

e IT4000 generates a continuous stream of millions of negative ions that

circulate throughout the space. ese ions charge particles (such as dust, dander or

bacteria) causing them to attract other particles and clump together. As more and

more particles come together, they become heavier, making them easier to pull into

the space’s HVAC air lter or just fall to the oor to be vacuumed up. Unlike HEPA

lters that can only lter out particles of .5 microns or larger, the ionizer in the

IT4000 can reduce ultra-ne, even nano particles, that are much more dangerous

than the larger particles you can actually see.

Scalable Purication

e system allows for adjustable purication settings in order to accommodate

the specic needs of the user at the time. Using these settings will help your

machine provide optimum performance appropriate for its environment. In High

Mode, the purication plate generates activated oxygen to assist in breaking down

contaminates which cause odors. For faster cleanup, the machine can be set to

Away Mode which has a programmable auto-shuto timer feature. is allows the

machine to generate maximum output when the space is unoccupied.

Electrostatic Filtration

An advanced electrostatic lter is included with the IT4000 to help keep the purier

clean while at the same time lter out the clumped particles (See Needlepoint

Ionization). Several layers of media make up the lter. e friction created by these

layers and the particles ltering through them creates a negative charge further

attracting particles and directing them into the lter. Unlike expensive HEPA

lters, the electrostatic lter is washable and can be used over and over again.

(Unit)

Front of Unit Rear of unit Side of Unit

1 1 1

22 2

Diagrams

Ionization Needle

Front Grille

Control Panel

Rear Cover Screw

Rear Cover Clasps

Power Adapter Inlet

Rear Cover

Unit Rear

Unit Front

(Unit)

Rear of Unit (Rear Cover Removed) Rear of Unit (Filter Assembly Removed) Power Supply

1 1 1

2 2 2

33 3

4 4

Brass Thumbscrews

Filter Assembly

Filter Assembly Clasps

PCO Cell

PCO Cell Nuts

PCO Cell Connector

Purication Plate

Rear Cover

Unit Rear

Unit Front

Power Cord

Power Cord Plug

Power Adapter

Power Adapter Plug

(Controls)

Remote

Diagrams

Power Button

Fan Speed Control

Infrared Receiver

Reminder Reset Button

Power Button

Purication Level Control

Normal/High Mode Control

Away Mode Control

Fan Level Control

Sleep Mode Control

Purier Level Control

Away Mode Toggle

Normal/High Toggle

Control Panel

See Owner’s Manual for complete

operating instructions

PURIFIER FAN

POWER SLEEP

NORMAL

HIGH

AWAY

MODE

(Controls)

Control Panel Screen

HIGH

PURIFIER SETTING

MUST NOT EXCEED

SIZE OF AREA

NORMAL AWAY

PERFORM CLEANING

REPLACE PCO CELL

REPLACE PLATE

AREA MUST BE

UNOCCUPIED

Fan Speed Indicator

Mode Indicator

Purication Level Indicator

Maintenance Reminders

Purication Level Warning

Away Mode Warning

Mode Specic Display

Normal - Technology Indicator (PCO)

High - Square Footage Indicator

Away - Mode Duration Indicator (hours:minutes)

Mode Specic Display

AWAY

HRS

AREA MUST BE

UNOCCUPIED

Away

Mode

HIGH

PURIFIER SETTING

MUST NOT EXCEED

SIZE OF AREA

High

Mode

NORMAL

Normal

Mode

Setup / Operation

Initial Setup

Ideal Placement

There are several important factors to consider when selecting a location for

your IT4000:

• Make sure the location you choose is as far away from the HVAC air return

duct as possible. is will ensure that the purication produced by the IT4000

is optimally circulated.

• Place the unit on top of something tall such as a bookcase, a shelf or a mounting

bracket, leaving only 12 to 24 inches between the unit and the ceiling.

• To ensure the unit works properly, there should be as much space as possible in

front of your IT4000 so that it can eciently process the air in the area.

• Never place an operating unit on the oor.

Initial Settings

Before using the unit you will need to nd the area (or square footage) of the

environment. To do this accurately, take into account all connected rooms with

open doorways (the purication does not ow readily through closed doors).

e IT4000 can purify up to 3,000 square feet of space.

For example: Suppose you have a 2500 square foot house. e living room is attached

to the kitchen, three bedrooms, the den and a laundry room. e kitchen and three

bedrooms’ doors remain open the majority of the time but the laundry room and den

usually remain closed o from the rest of the house. Together, the laundry room and

den have a combined area of 500 square feet. e area of the environment you would

want to set your IT4000 and purify would be 2000 square feet.

Once you have determined an ideal location for your unit and calculated the area

of the environment:

1. Connect the Power Cord to the Power Adapter and the Power Adapter Plug

into the unit. (Check to be sure your power supply is properly assembled. e

Power Cord should be inserted far enough into the Power Adapter so that a

space of only about 1/8 in. is le between the widest part of the power cord

and the edge of the Power Adapter.)

2. Insert the Power Plug into the wall outlet.

3. Turn the unit on and set it to NORMAL mode (see CONTROLS)

4. Leave the unit on NORMAL mode for at least 24 hours to begin with.

5. After 24 hours, set the unit to HIGH mode and set the square footage to

250 square feet.

6. Gradually increase the square footage setting every 8-12 hours until you

reach the accurate square footage of your area which you calculated in the

beginning steps). Note: Using the purier at a setting less than the square

footage of the area being treated is acceptable and may be desirable in an

environment relatively free of pollutants.

Operating the Unit

Turning the Unit On/O

Press the Power Button on the Control Panel or Remote to turn the unit on. e unit will initially be set to Normal Mode. Press the Power Button once more to turn

the power o.

Using Normal Mode

Press Normal/High button until “Normal” is shown in the lower right of the Display.

• Square Footage not available in “Normal” (see “INITIAL SETUP: Initial Settings” page 12).

• To control the fan speed: Use Fan Up/Down buttons.

Using High Mode

Press the Normal/High button and verify that “High” is shown in the lower right of the Display.

• To set the square footage on the Display: Use Purier Up/Down buttons (See INITIAL SETUP: Initial Settings” page 12).

• To control the fan speed: Use Fan Up/Down buttons.

CAUTION: Never adjust setting to exceed square footage of ventilated space being treated.

Using Away Mode

Press the Away Mode button and verify that “Away” is shown in the lower right of the Display.

• To set the Away Mode Timer: press the Away Mode button. Each press of the Away Mode button adds two hours to the Away Mode Timer.

• Select 2:00, 4:00, 6:00 or 8:00 hours.

• Press Away Mode once more to switch the unit back to Normal Mode.

Setup / Operation

LCD Reminders

Replace Plate

When “Replace Plate” appears, the Purication Plate has reached the end of its useful life and must be replaced. To order a replacement, contact your distributor or

Inspired TEC (www.inspiredtecllc.com). Once a replacement has been obtained, follow the instructions in “DISASSEMBLY/ASSEMBLY” to replace your old Purication

Plate with your new one.

Replace PCO Cell

When “Replace PCO Cell” appears, the PCO Cell has reached the end of its useful life and must be replaced. Contact your distributor or Inspired TEC (www.

inspiredtecllc.com) to order a replacement. Once a replacement has been obtained, follow the instructions in “DISASSEMBLY/ASSEMBLY” to replace your old

PCO Cell with your new one.

Perform Cleaning

“Perform Cleaning” will display once the 30 day operation cycle between cleanings has passed and the unit requires a complete cleaning. Follow the instructions in

“CLEANING” (page 17) then see “Resetting Reminders” (below) to reset the reminders. e Perform Cleaning reminder will appear again aer 30 day of operation.

Resetting Reminders

Aer replacing the Purication Plate or the PCO Cell, the corresponding reminders will reset themselves. Aer performing a cleaning of the unit (see “CLEANING” page

17) you should reset the reminders by holding down the Reset Reminders button on the Control Panel of the unit. e reminder has been reset when Perform Cleaning no

longer appears.

Disassembly/Assembly

Disassembly

Tools Required

You will need a #2 Phillips screwdriver.

Workspace Recommendations

A countertop or at surface is ideal for disassembling/assembling your unit. You

will need 2 . x 3. of clean, accessible workspace. It is recommended to use a small

bowl or cup to hold any screws so they are not lost during the disassembly process.

Disassembly Instructions

1. Turn the unit o.

2. Remove the Power Cord from the wall and rear of the unit.

3. Clean exterior of unit if necessary (see “CLEANING: Unit Exterior” page 17).

Removing the Rear Cover:

1. Using your screw driver, remove the Rear Cover Screw from the Rear Cover

(above the Power Cord Port). Place the Rear Cover Screw where you will

nd it easily during reassembly.

2. Squeeze the tabs on both sides of the Rear Cover (where the grooves are) until

they release and tilt the Rear Cover upwards until the top tab releases. Clean

with compressed air or a damp cloth. Set the Rear Cover aside.

Removing the Filter Assembly:

1. Remove Brass umbscrews from the top corners of the Filter Assembly.

Place Brass umbscrews where you will nd them easily during reassembly.

2. Grasp the top of the Filter Assembly and tilt away from the unit. Clean if

necessary (see “CLEANING: Filter Assembly” page 17) and set the Filter

Assembly aside.

3. Li tabs on either side of Filter Assembly to remove the rim and access the

separate honeycomb, foam and mesh layers.

Removing the Purication Plate:

Grasp the Purication Plate on the ceramic and gently pull it out of the grooves on

the sides. Clean (see “CLEANING: Purication Plate” page 17) and set the Purication

Plate aside.

Removing the PCO Cell:

1. Locate the PCO Cell Power Connector on the right of the rear of the unit

almost halfway up the unit (beside the Purication Plate slot). Squeeze the

tabs on the top and bottom of the PCO Cell Power Connector and pull gently

until free from the PCO Cell Power Connector Outlet.

2. Remove the umb Nuts from the Screw Posts on the right and le below the

PCO Cell. Place the umb Nuts where you will nd them easily during

reassembly.

3. Gently slide the PCO Cell out of the unit. Clean (see “CLEANING: PCO Cell”

page 17) and set the PCO Cell aside.

Clean the interior of the unit (see “CLEANING: Unit Interior” page 17).

Removing the Front Grille:

1. Locate the four Front Grille Screws in the four corners of the Front Grille.

Using your screw driver, carefully remove the four Front Grille Screws. Place

the Front Grille Screws where you will nd them easily during reassembly.

2. Remove the Front Grille carefully to ensure that the Ionization Needle(in the top

center of the front of the unit) is not damaged. Clean the Front Grille if necessary

(using compressed air, vacuum cleaner, damp cloth or warm soapy water)

and set the Front Grille aside.

3. Clean the Ionization Needle if necessary (see “CLEANING: Ionization Needle”).

Disassembly/Assembly

Assembly

Refer to Tools & Workspace from Disassembly Section

Installing the FRONT GRILLE:

1. Gently put the Front Grille in place on the front of the unit, being careful

not to damage the Ionization Needle at the top center of the front of the unit.

2. Insert the four Front Grille Screws one at a time until they are in place, but

not tight. Aer all four Front Grille Screws are in place, tighten them carefully.

Installing the PCO CELL:

1. Position the PCO Cell inside the unit so that the two tabs are on the bottom

(and interior side) of the PCO Cell. Ensure the holes in the two tabs t over

the two Screw Posts. Screw the umb Nuts onto the Screw Posts until they

are snug.

2. Align the PCO Cell Power Connector to the PCO Cell Power Connector Outlet

and insert gently until the tabs at the top and bottom of the PCO Cell Power

Connector snap into place, holding it in the PCO Cell Power Connector Outlet.

Installing the PURIFICATION PLATE:

1. Holding the Purication Plate by the ceramic, slowly insert it into the

Purication Plate Slot, ensuring that the Purication Plate is sliding into the

grooves on either side.

NOTE: About halfway in, the Purication Plate Connectors are parted.

Continue sliding the Purication Plate into the Purication Plate Slot until there

is approximately one inch of the Purication Plate remaining outside of the

Purication Plate Slot and signicant resistance is met. Be careful not to force

the Purication Plate further into the Purication Plate Slot as this could seriously

damage your unit.

Installing the FILTER ASSEMBLY:

1. Hold the Filter Assembly with the larger at side (where the honeycomb

layer of the lter is visible) facing the interior of the unit. A sticker reading,

“Caution: Reinstall Filter Aer Cleaning,” is located on the opposite side

of the Filter Assembly. is sticker should be visible when you install the

Filter Assembly.

2. Insert the bottom of the Filter Assembly into the tabs on the rear of the unit

and then seat the Filter Assembly on the rear of the unit. (NOTE: If the user

fails to insert the Filter Assembly into the tabs appropriately, disassembling

the unit in the future could be extremely dicult.)

3. Screw the two Brass Thumbscrews into their holes at the top corners of

the Filter Assembly.

Installing the Rear Cover:

1. Place the tab at the top of the Rear Cover into the hole at the top of the Filter

Assembly then lay the Rear Cover at against the rear of the unit until the tabs

on the sides of the Rear Cover click into place on the unit.

2. Carefully insert the Rear Cover Screw into its hole on the Rear Cover (above

the Power Cord Port) and tighten.

Installing the POWER CORD:

1. Insert the Power Adapter Plug into the rear of the unit.

2. Ensure the Power Cord is properly connected to the Power Adapter.

3. Insert the Power Plug into a wall outlet.

Turning the unit on:

1. Press the power button.

2. e unit will be set to Normal Mode once again. Ensure that the unit’s settings are

adjusted to suit the environment (see “Operations” on page 13).

Cleaning

Your unit should be cleaned monthly to be kept running at peak performance, but depending upon the pollution or odor levels present during

initial setup, it is advisable to clean the unit more frequently (weekly or bi-weekly) until the environment has been treated.

Cleaning the Unit (Exterior):

Wipe down the exterior with a damp cloth or use compressed air or a vacuum cleaner to remove dust. Use an alcohol-based cleaning product to clean the surfaces of your unit.

Cleaning the Filter Assembly

You may use clean water or compressed air to clean your Filter Assembly once it has been disassembled (see “Disassembly: Removing the Filter Assembly”). Aer disassembling

your unit, the three lters (mesh, foam and honeycomb) should be removed and cleaned separately. If using water, you must allow the lters to dry separately before

reassembly. When reassembling, the Honeycomb Filter goes in rst, then the Foam Filter, and nally the thin Mesh Filter. Lastly, reattach the rim to the Filter Assembly.

Cleaning the Ionization Needle

Using a cotton applicator (Q-tip), apply a small amount of clear alcohol-based cleaner (or rubbing alcohol) to the Ionization Needle. You may also use compressed air to

blow o any dust that may accumulate near the ionization needle.

Cleaning the PCO Cell

Using a compressed air or a vacuum cleaner, blow and/or vacuum the dust out of the PCO Cell. Do not use any liquid to clean the PCO Cell.

Cleaning the Purication Plate

Using a 50/50 mix of warm water and clear ammonia (100% white vinegar can be used in place of water and ammonia), soak the Purication Plate for 8-10 hours but do not

exceed 12 hours. Using a so-bristle brush, scrub the wire mesh to remove debris lodged inside the mesh. Rinse thoroughly. Allow the purication plate to dry completely

before reinstalling. Aer reinstalling, use a so cloth and rubbing alcohol to clean the contacts on the interior of the unit that touch the Purication Plate.

Cleaning the Unit (Interior)

Using a damp cloth, a clear alcohol-based cleaner, compressed air or a vacuum cleaner, carefully clean the walls and components inside of the unit only aer completing

the Disassembly procedures.

Troubleshooting

e Unit Fails to Turn On

1. Verify that the Power Plug is plugged into an operational wall outlet.

2. Ensure that the Power Cord is fully inserted (leaving less than an 1/8”) to the Power Adapter.

3. Ensure that the Power Adapter Plug is fully seated in the receptacle on the back of the unit.

4. Verify the Power Button has been activated on the Control Panel.

5. If the Power Button on the Control Panel fails, use the Power Button on the Remote Control. If the Control Panel fails, contact your distributor of Inspired TEC (www.inspiredtecllc.com).

e Unit is Operating in High Mode or Away Mode, but No Noticeable Purication is Being Produced

1. Ensure that the Purication Plate is clean (see “CLEANING: Purication Plate” page 17).

2. e Purication Plate may not be working because it needs to be replaced. Try installing a new Purication Plate.

3. Check the electrical contact arms which touch the plate to ensure that they are making proper contact with the metal weave on the Purication Plate.

4. Ensure the electrical contact arms which touch the plate are clean. Clean them with a so cloth and rubbing alcohol.

5. Turn the lights o in the room and look through the Front Grille at the Purication Plate. If it is operating properly, it will produce a dim purple glow.

e Purication Plate Generates an Electrical Arc, an Arcing Noise or a Burning Odor

1. is means the Purication Plate is damaged and must be replaced. e unit may or may not display the Replace Plate LCD reminder. To order a replacement, contact your distributor or

Inspired TEC (www.inspiredtecllc.com).

e PCO Cell is Not Lighting Up:

1. Ensure the PCO Cell Power Connector is properly seated in the PCO Cell Power Connector Outlet (see “DISASSEMBLY/ASSEMBLY” pages 15-16).

2. If the PCO still fails to operate, it needs to be replaced. Contact your distributor or Inspired TEC (www.inspiredtecllc.com).

e Ionization Needle Creates an Electrical Arc:

1. e Ionization Needle needs to be cleaned (see “CLEANING: Ionization Needle” page 17). Be sure to complete all of the cleaning procedures (see “CLEANING” page 17)

every 30 days of operation.

e Fan Does Not Operate Properly:

1. Try adjusting the fan speed using the Control Panel or Remote Control.

2. Remove the Front Grille (see “DISASSEMBLY/ASSEMBLY” pages 15-16) to ensure there are no obstructions to the movement of the fan.

3. If the Fan continues to operate improperly or not at all, contact your distributor of Inspired TEC (www.inspiredtecllc.com).

e Unit Makes a Rattling Noise When Taken Out of Packaging

1. Remove the back panel of the unit (see “DISASSEMBLY/ASSEMBLY” pages 15-16). Check to ensure the two brass umb Screws holding the Filter Assembly are in their proper place. If

they are properly installed, remove the umb Screws and Filter Assembly (see “DISASSEMBLY/ASSEMBLY” pages 15-16) and check the PCO Cell to ensure the two brass umb Screws

securing the PCO Cell are installed properly

Your IT4000 Air Purier is warranted to be free from all defects in material and workmanship in normal household use for a period of (1) year from date of purchase.

e warranty is granted only to the original purchaser and members of his or her immediate household. e warranty is subject to the following provisions.

is warranty does not cover parts of the Air Purier that require replacement under normal use. is includes the purier plate and rear lter assembly. Although the PCO cell requires

periodic replacement, the cell is warranted for the same 1 year period as the purier. Any damages or malfunctions caused by negligence, abuse, or use not in accordance with the Owner’s

Manual are not covered by this warranty. Likewise, any defects or damages caused by unauthorized service or the use of other than Genuine Inspired TEC parts are not covered.

Inspired TEC will, at its option, repair or replace a defective Air Purier or part(s) for the Air Purier that is covered by this warranty. As a matter of warranty policy, Inspired TEC will not

refund the customer’s purchase price.

To obtain warranty service you must return the defective Air Purier or Air Purier parts along with proof of purchase to the Inspired TEC Authorized Warranty Station. All transportation

charges on parts, or units, submitted under this Warranty shall be borne by purchaser. Unless this Warranty is expressly renewed or extended by Inspired TEC, any repaired or replaced part

of unit shall be warranted to the original purchaser only for the length of the unexpired portion of the original warranty. For the location of the nearest Inspired TEC Authorized Warranty

Station or for service information in the United States or Canada, please visit us online at:

www.inspiredtecllc.com

Further Limitations And Exclusions Are As Follows

Any warranty that may be implied in connection with your purchase or use of the Air Purier, including any warranty of merchantability or any warranty for Fitness For A Particular

Purpose is limited to the duration of this warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you.

Your relief for the breach of this warranty is limited to the relief expressly provided above. In no event shall Inspired TEC be liable for any consequential or incidental damages you may

incur in connection with your purchase or use of the Air Purier. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or

exclusion may not apply to you.

is Warranty gives you specic legal rights, and you may also have other rights which vary from state to state.

Registration

Please register your new Inspired TEC Air Purication product within 10 days of purchase by lling out and returning the enclosed warranty registration card. Registering your new
