Itec ITECNET SPIDERLINE 16 User manual

SPIDERLINE 16
MANUAL
VERSION 1.0, MAY 2013
Designed and Manufactured by
ITEC Tontechnik und
Industrieelektronik GesmbH
8200 Laßnitzthal 300
Austria / Europe

ITEC SPIDERLINE 16
2www.itec-audio.com
SPIDERLINE 16 - INTRODUCTION
Dear Customer,
The main focus of our research work is and always has been the development of practical devices that are
flexible, versatile, reliable, future-proof but still easy to handle. In close cooperation with electrical consultants,
system architects and operators of public address systems the ITECNET SpiderLine16 has emerged and
grown. In addition, all our know-how from many years of experience in the field of audio and digital technolo-
gy has been integrated into this product.
Unlike any other known device, it offers the possibility of building the largest and most complex audio systems,
with relatively simple and well arranged operation and configuration.
This manual describes the hardware of the SpiderLine16, shows the construction and the wiring of the
various audio and logic I/Os and thus serves the audio system designer / integrator in the conceptual design
phase respectively during the set-up process of audio networks. Numerous examples illustrate the optimum
usage and the professional installation of controls and other devices.
For knowing the entire system, all its possibilities and for executing the necessary configuration tasks the
software manual is required in addition. Please observe during the installation / operation of the ITEC
SpiderLine16 all listed safety instructions in this manual; furthermore data and examples provided ensuring
the optimum usage of the device.
Lots of joy and success - The ITEC Acoustics Team

ITEC SPIDERLINE 16 www.itec-audio.com 3
Safety instructions
When installing the device, the local connecting conditions, the required protective measures and all relevant
standards have to be observed.
The installation and configuration of the ITEC SpiderLine16 must be performed by trained personnel only. For
the configuration the original software ITEC NetDesign has to be used exclusively.
The power connection is carried out via the original power supply unit or directly to any existing 24 V DC
power supply (emergency current).
Please note that the ground connector of the device (audio ground and ground of all digital audio interfaces)
is electrically not connected to the negative pole of the DC supply.
Please observe during the installation, that no multiple connections between the ground connector of the
device and the 24 V negative pole are put in place (see also chapter „mass concept“).
When installed in switch cabinets, pre-cautions need to be taken to ensure sufficient air exchange to avoid
overheating of the device.
Due to the great depth of the housing, support rails are absolutely necessary for installation
in 19“ cabinets.
When connecting to other devices (e.g.: sound sources, computers), the exact pin configuration and the spe-
cifications of inputs and outputs need to be observed.
Only a connection to networks, which are compliant to IEEE 802.3 (Ethernet), is possible.
Never try to open the device by force or by unscrewing. The product does not contain parts that can be re-
paired by amateurs. Please contact the manufacturer or a local distributor.
Do not apply temperatures above 50 °C, humidity larger than 95% or rain to the device.
Caution: Before carrying out any modifications on the device (only by qualified personnel) the power supply
has to be disconnected.
The device is designed for installations in 19“ cabinets / rack / frame / housing. Improper installations in fur-
niture, cabinets or distribution systems, as well as free installation have to be avoided.
SPIDERLINE 16
The picture shows the installation in a 19“ cabinet with
support rails, Rittal system.

ITEC SPIDERLINE 16
4www.itec-audio.com
SPIDERLINE 16

ITEC SPIDERLINE 16 www.itec-audio.com 5
The audio network ITECNET
ITECNET is a decentralized, Ethernet-based audio network for the simultaneous transmission of up to 64
audio channels with the highest audio quality. At the same time, a huge number of system data, measure-
ment data and IOs are controlled and transmitted. With four audio inputs, four audio outputs, serial ports and
I/Os the SpiderLine16 is one of the most important system components.
SPIDERLINE 16

ITEC SPIDERLINE 16
6www.itec-audio.com
Made in Austria
DC 24V
POWER IN
D- D+ RX TX
RS 485 RS 232
CHASSIS
GROUND
SIGNAL
GROUND
Connectors on the rear panel
Operating and display elements on the front-panel
12 34
SIGNAL INPUT
12 34
SIGNAL OUTPUT
INFO
1
1 Indicator LED: green: normal operation, yellow = failure
2 Signal level indication for the 4 line/mic inputs
3 Signal level indication for the 4 line/mic outputs
4 Info button to switch display mode of the status indicators (see Figure 5)
1 24VDC power supply, power consumption depends on the load of the internal amplifier.
Up to 5A. max. Cable section 4 mm2
2 RS 485 (see chapter serial interfaces)
3 RS 232 (see chapter serial interfaces)
4 10 VDC power supply for external control devices (e.g remote ranel)
5 Logic Outputs (see chapter logic outputs)
6 Logic Inputs (see chapter logic inputs)
7 Fault relay (See chapter fault relay)
8 ground connections (See chapter mass concept)
max. cable section 4 mm2
SPIDERLINE 16
2 3 4
821 3 4 5 6 7

ITEC SPIDERLINE 16 www.itec-audio.com 7
SPEAKER LINES
13579111315
2 4 6 8 10 12 14 16
+-+
- +- +-+-+-+-+-
+-+-+-+-+-+-+-+-+-+-
AMP 3 AMP 4
++
--
+-+-
100V AMP IN
BACK-UP IN
AMP 1 AMP 2
++
--
LINE/MIC IN
T
+-
IN 1 IN 3
OUT 2 OUT 4
T
+-
T
+-
T
+-
T
+-
T
+-
T
+-
T
+-
LINE OUT
OUT 1 OUT 3
IN 2 IN 4
SPIDERLINE 16
SPIDERLINE 16
1 2 3 4 5 6 7 8 9 10 111213141516
SPEAKER LINE MONITORING
12
5speaker line indication:
Standard (mode 0): yellow= line-detection error on this line
red= voice alarm running on this line
Pressing the info button:
Mode 1: indicates line state (LED No.16 blinking yellow)
green= Line is active,
red= Line is active and PriorityOnly
Mode2: indicates station ID (LED15 blinking yellow)
Binary code indication, 12 Bit (1=LSB, 12=MSB)
Mode3: indicates back-up status (LED14 blinking yellow)
green= normal mode,
red= back-up mode (back-up amplifier)
5
131110
9
9 Mic/Line In (see chapter audio inputs)
10 Line Out (see chapter audio outputs)
11 Speaker lines: switched 100 Volt outputs connecting to the individual lines
12 100V line inputs of the amplifiers
13 100V line inputs of the back-up power amplifiers
Maximum cable section for all terminals 1.5 mm2- unless otherwise stated.

ITEC SPIDERLINE 16
8www.itec-audio.com
SPIDERLINE 16
Block diagram DSP 1 (Main)
DSP1
OUTPUT
UNIT 1 MIX
Volume
Priority
Volume
+
-
+
-
+
-
RS 485
A
B
Ethernet
PGA
+12V
LINE/MIC IN
Gain
+
-
Ethernet-Unit
Feed CH 1-256 Get CH 1-256
A/D-Converter
Input-Matrix
EQ
Delay
OUTPUT UNIT 2
EQ
Delay
OUTPUT UNIT 3
EQ
Delay
OUTPUT UNIT 4
D/A-Converter
EQ
Delay
24V DC IN
+
-
DC
DC
5V DSP
± 12V Analog
FAULT
+
-
+
-
+
-OUT 1
+
-
+
-
+
-
SD
OPERATE/FAULT
Pilot Amp,
Relais Matrix
MIC/LINE
PGA
+12V
Gain
A/D-Converter
+
-
+
-
MIC/LINE
PGA
+12V
Gain
A/D-Converter
+
-
+
-
MIC/LINE
PGA
+12V
Gain
A/D-Converter
+
-
+
-
MIC/LINE
RS 232
LINE OUT
OUT 2
OUT 3
OUT 4
IN 1
IN 2
IN 3
IN 4
Line Detection DSP
Main

ITEC SPIDERLINE 16 www.itec-audio.com 9
DSP2
SPIDERLINE 16
8 Logic Inputs
8 Logic Outputs
Front Panel LED-Board
Signal Processing
for Line Detection
Short Circuit,
End of Line
Earth fault
Detection
Control
Main DSP
A/D
V1
V8
M
U
L
T
I
P
L
E
X
Control
A/D
V9
V16
M
U
L
T
I
P
L
E
X
B1
B4
Control
A/D
I1
I8
M
U
L
T
I
P
L
E
X
Control
A/D
I9
I16
M
U
L
T
I
P
L
E
X
Relais Matrix
Signal
Generator D/A
Pilot Amp
Earth fault
Measurement
1 –16
Block diagram DSP 2
Line Detection, IOs
IO-Handling

ITEC SPIDERLINE 16
10 www.itec-audio.com
Signal-Routing
SPIDERLINE 16
OUT1 OUT2 OUT3 OUT4
116
PILOT-
AMP
Earth fault
1
2
3
External
Amplifiers
+-+-+-+-
+-+-
V V V V
4
24V
LS-BUS
BACK-UP 1
Earth fault
-
AMP 1 BACK-UP 2 AMP 2 BACK-UP 3 AMP 3 BACK-UP 4 AMP 4
V V
V1 V16
Short Circuit/EOL Short Circuit/EOL
I I
I1 I16
SPIDERLINE 16
+-
LINE OUT
SEAKER LINES
+-+-+-
B.Up1 B.Up2 B.Up3 B.Up4

ITEC SPIDERLINE 16 www.itec-audio.com 11
Audio outputs
The 4 outputs are balanced as well with XLR connectors on the rear cover.
The maximum output level is +15 dB
SPIDERLINE 16
DC 24V
POWER IN
DC
DC
24V 0V
Power supply 24 V DC
Audio inputs
The device features 4 balanced inputs, which are XLR connectors on the rear cover.
The maximum input gain is in line operation from -20 to +30 dB, in microphone operation
from +10 to +60 dB for each channel selectable.
Thus, all conventional microphones and media players can properly be adjusted.
Phantom power is switchable per channel (12V).
Connection is made to the included power adapter or an existing 24 V DC emergency power supply. The
ground connection of the device (audio ground and ground of all digital audio interfaces) is electrically not
connected to the negative pole of the DC supply. This is especially of importance, when a connection to
peripheral 24 V emergency supplies is made, as the audio grounds, linked to power amplifiers or playback
devices on site, are connected to the ground wire of the according sub-station. Due to the galvanic separation,
loops and shunts can effectively be prevented. A floating guidance of the 24 V supply voltage or to ground at
one spot, usually at the emergency power supply, is recommended.
T
+-
Signal Signal
T
+-
Signal Signal
SPIDERLINE 16

ITEC SPIDERLINE 16
12 www.itec-audio.com
The device has 8 digital inputs, which are primarily designed for the detection of low-level operating and fault
conditions. This includes the monitoring of fault signals of amplifiers, monitoring of cabinet temperature by
thermostats, etc. A remote control, that is, an output follows at any point of the system the input is also pos-
sible. Each input state can be inverted for further processing by the software. For a complete overview of all
features, see Software Manual „NetDesign“.
SPIDERLINE 16
Digital inputs
SPIDERLINE 16
DSP Inputs
Ri= 27 K
8 Logic Inputs
Logic 0.....UIN < 1,6 V
Logic 1.....UIN > 8 V
maximum voltage: UIN=36V
Digital outputs
SPIDERLINE 16
DSP Outputs
8 Logic Ouputs
Open Collector
UMAX = 36 V DC
IMAX = 200 mA per Channel
ITOTAL (∑Out1÷Out8) = 500 mA
max 36 V DC
+-
The device has 8 digital open collector transistor outputs. They are used for switching relays, lamps of lo-
wer power, etc. Typical applications are the display of faults, switching off other audio devices during an
announcement and more.
automatic fuses 0,2 A

ITEC SPIDERLINE 16 www.itec-audio.com 13
SPIDERLINE 16
The Serial interface
RS 232 and RS 485 are operated in parallel by the SpiderLine16. You may only connect one of the two
interfaces at the same time.
RS 232
SPIDERLINE 16
TXRX
The RS 232 interface is used to connect control devices with a maximum cable length of up to 25m, such
as media controls, management systems or indication systems, respectively for the export and logging of
data.
Operated in parallel with the RS 232 interface, to be used for up-mentioned functionalities, for distances of up
to 500 meters of cable. With the RS 485 interface up to 16 devices can be connected in parallel (e.g. ITEC UP
remote control panel).
RS 485
SPIDERLINE 16
+5 V
JP3
JP5
2-wire/half duplex
BA
D- D+

ITEC SPIDERLINE 16
14 www.itec-audio.com
Ethernet Interface
SPIDERLINE 16
Network
BA
Redundant Network
Ethernet Unit
The network connection is carried out via socket A by default. If a link to second redundant network is
planned, socket B is used. The LEDs on the RJ45 connector show the operating status of the network
connection:
Green LED on: Connected
Green LED flashing: Connected and network activity
Yellow LED on: valid connection (100Mbps full duplex)
SPIDERLINE 16
Fault relay
SPIDERLINE 16
Fault Relais
Fault Operating max 48 V
A potential-free relay contact used to display the operating status is available. In case the device is not
operating or during a fault condition, the relay is released, during normal operation it is activated.

ITEC SPIDERLINE 16 www.itec-audio.com 15
SPIDERLINE 16
Mass concept
SPIDERLINE 16
24V 0V CHASSIS
GROUND
SIGNAL
GROUND
24 V
24 V
Speaker
Lines
Relais
Matrix
Signal Ground
(Audio and digital GND)
0 V: The negative pole of the supply voltage should be grounded to avoid ground loops and leakage
currents at only one point with the system. The relevant standards and regulations must be observed.
Chasis Ground: is connected to the metal housing of the Spider16. Usually, this terminal should be
connected with the cabinet or the grounding terminal of the cabinet.
Signal Ground: This Mass refers to all digital inputs and outputs, to the audio in- and outputs (Mic/Line In,
Line Out) and the serial interfaces. Due to the internal use of DC/DC converters, audio transformers and
opto-couplers this mass is not connected to the negative terminal of the 24VDC supply and housing (Chas-
sis Ground).
Usually „Signal Ground“ gets the connection to the ground (earth) through the signal terminals of the
power amplifiers or by connection to other systems and must/should not be connected separately.
DC
DC
24 V
Pilot Amp
The SpiderLine 16 operates with three mass-potentials which might be referred to as one mass in a sense,
but they are not interconnected. Thus, it is up to the wiring concept of the system if and where this masses
are to be connected and/or are connected to the earth (ground) of the electric installation.
10V
Supply for
external devices
Power Supply IN
DSP,
analog Audio,
IOs
+–
Audio In/Out

GENERAL
EXTERNAL POWER SUPPLY 24 V DC (18 V < U < 32 V)
Current ca. 500 mA without pilot tone and without applied load on the 10 V DC Voltage .
With internal pilot-tone amplifier in operation, depending on impedance (power) of
the connected speakers, up to 5A.
OPERATING TEMPERATURE -5°C - +40°C
DIMENSIONS 482 x 44 x 357 mm (W x H x D), 19“ / 1 rack unit
WEIGHT 8,5 kg
AUDIO
AUDIO FREQUENCY RESPONSE 40 Hz-20 kHz/-1 dB
HARMONIC DISTORTION (of LINE-Outputs) <0,005 %
GENERAL DYNAMICS 103 dB
BALANCED INPUTS max. free selectable gain -20 dB to +60 dB
Phantom power +12 V
Input impedance 6,6 kOhm
BALANCED OUTPUTS max. output level +15 dB, output impedance 300 Ohm
SOUND PROCESSING
PER INPUT 2-band fully parametric equalizer ± 15 dB, Q=0.1-70
1 low/high pass 1st order
PER OUTPUT 4-band fully parametric equalizer ± 15 dB, delay: 0.023 ms-24.5 s
bandpassfilter: 1st – 4th order
Compressor/limiter
Filter quality selectable from 0.1 to 70
SERIAL INTERFACES
RS 232/RS 485 9600, 19200, 57600, 115.200 baud
DIGITAL INPUTS 8 schmitt-trigger inputs on plug in-terminal strip
INPUT VOLTAGE Low < 1,6 V / High > 8 V
MAX. ALLOWABLE VOLTAGE 36 V
INPUT CURRENT (@10 V) ca. 0,5 mA @ 12 V, ca. 1 mA @ 24 V
DIGITAL OUTPUTS 8 open-collector outputs on plug in-terminal strip
MAXIMUM VOLTAGE 36 V
MAXIMUM CURRENT 200 mA per output / total 500 mA (sum of all outputs switched))
ANALOG INPUTS 8 analog inputs on plug in-terminal strip
RANGE 0-10 V DC
RESOLUTION 8 Bit
INPUT CURRENT (@10 V) about 0,2 mA
DRY CONTACT ALARM RELAY
MAX. VOLTAGE / MAX. SWITCHING POWER 48 V AC/DC / 500 mA
NETWORK Ethernet 100 Base-TX, IEEE 802.3u
SPIDERLINE 16 - TECHNICAL SPECIFICATIONS
ITEC- Tontechnik und Industrieelektronik GesmbH, A-8200 Lassnitzthal 300
Tel.: [phone] / 3780-0, offi[email protected], www.itec-audio.com
44 mm
Depth: 357 mm
431 mm
482 mm
482
mm
No responsibility is taken for the correctness of this information - Specifications subject to change
