Itouchless Bio-Matic BM001 User manual

INSTALLATION INSTRUCTIONS
: BM001/BM003
1. Preparation
(1.1) Due to the sliding cover of the Bio-Matic™, an
minimum clearance of 5” must exist a ove the lock
mounting hole.
(1.2) Check (Fig. 1) to determine if the lock lever direction
is corresponding to the door left-handed or right-handed.
(1.3) This Bio-Matic lock works on doors with a thickness
etween 1.5” to 2.36”.
2. Install Latch and Plate
In the package, you will find two Latch Backsets. The short
one is 2-3/8". The long one is 2-3/4".
(2.1) Determine the Backset y measuring the distance
from the edge of the door to the center of the hole.
(2.2) The end of the Backset should e in the center of the
hole when Backset is fitted from the side of the door.
(2.3) Insert Backset with angled side of olt facing outside.
Fasten with 2 Flat Head Screws.
(2.4) On the other side, use another 2 Flat Head Screws to
secure the Strikeplate on the wall.
3. Install Lock Units
(3.1) Remove the Cover of the Interior Lock Unit.
1. Loosen the ring with a “Y” Spanner y turning counter-
clockwise.
2. Remove oth the ring and the cover from the Lock Unit.
(3.2) Install the Interior and Exterior Lock Unit.
1. Unscrew the 2 Connection Screws to separate the
Interior and Exterior Lock Unit.
2. Insert the Exterior Lock Unit with protector and the ca le
through the door hole. Then hold tight.
3. With the cover removed, insert the Interior Lock Unit with
protector on the other side, with the attery compartment
on top.
4. The extension from the ack of the Exterior Lock Handle
should fit in a star shape hole at the ack of the Interior
Lock Handle.
5. Run the ca le through the hole under the attery
compartment.
(3.3) Insert atteries and connect the power ca le.
1. Insert 4 AA atteries into the attery compartment. Make
sure they are in the correct directions.
2. Plug in the ca le into the ottom of the attery
compartment.
3. Align and fasten 2 Connection Screws to secure the
Lock Units.
(3.4) Re-install the cover of the Interior Lock Unit.
1. Insert the cover and the ring ack to the Interior Lock
Unit.
2. Use the “Y” Spanner to tighten the ring y turning
clockwise.
4. Testin
(4.1) The handles should not lock the way of entrance or
when opening the doors.
(4.2) Slides open the protective cover. You should see a
lue light at the ackground of the scanner window.
Bio
-
Matic™ Fingerprint Door Lock
Single
-
Latch
User
Manual
DEFAULT MASTER CODE
:
A default master code is set when the Bio-Matic is
manufactured. The passcode is “11111111”. The master
code is always an 8-di it num er and you will need to use
the master code for all operations.
1. Modifyin Master Code:
1. Slide open front cover and press “0” then “*”
2. Enter Current Master Code
3. Enter New Master Code
4. Repeat New Master Code
5. Press “#” when finish
6. New Master code is accepted when you hear a
“BEEP”
7. If you hear 3 “BEEPS”, please repeat step 1 to 5, New
Master Code is NOT accepted
2. Reset Master Code
If for any reason you could not remem er the master
code, you can set it ack to the manufactured default
code “11111111” y following the steps elow
Note: This will erase all codes including User Numbers,
Fingerprints and Passcodes
1. Uninstall the Interior Lock Unit
2. Use the “Y” Spanner to remove the ring and the cover
of the Lock Unit y turning counter-clockwise
3. Disconnect the power ca le from the attery
compartment. Then press and hold oth “1” and “2” on
the key pad spontaneously while you reconnect the
power ca le. The default code is successfully set when
you hear a “BEEP”.
OPERATIONAL INSTRUCTIONS
:
1. Re isterin Fin erprints
(2.1) Register with User Number
1. Slide open front cover and press “1” then “#”
2. Enter Master Code
3. Enter 3-digit User Num er, then press “#” to confirm
4. Put finger tip on the center of the scanner when lue
light is on. Lay flat and hold firmly until you hear a
“BEEP”.
5. Repeat step 1 to 4 a ove to enter another user
6. If you hear 3 “BEEPS”, the fingerprint is not
recognized, please repeat step 1 to 4
To register user# 123 with de ault master code 11111111
Enter sequence on keypad: 1, #, 11111111, 123, #
When the scanner lights up, put finger on the scanner to
register the fingerprint for user# 123
(2.2) Register without User Number
1. Slide open front cover and press “1” then “#”
2. Enter master code
3. Press “#” to confirm
4. Put finger tip on the center of the scanner when lue
light is on. Lay flat and hold firmly until you hear a
“BEEP”.
5. Repeat step 1 to 4 a ove to enter another user
6. If you hear 3 “BEEPS”, your fingerprint is not
recognized, please repeat step 1 to 4
To register a user with de ault master code 11111111
Enter sequence on keypad: 1, #, 11111111, # When the
scanner lights up, put the FINGERPRINT to register.
IMPORTANT: If you have trouble installin the Bio
-
Matic
Door Lock or you have additional questions or concerns,
please contact iTouchless Customer Service at 1-800-
660-7978 Monday to Friday from 9:30am to 5:00pm PST.
DO NOT RETURN THIS ITEM TO THE STORE OR

OPERATIONAL INSTRUCTIONS
:
2. Deleting Fingerprints
(3.1) Deleting Individual Fingerprint with User Number
1. Slide open front cover and press “2” then “#”
2. Enter master code
3. Enter 3-digit User umber
4. Repeat 3-digit User number
5. Press “#” to confirm
6. You will hear a “BEEP” sound when fingerprints are
successfully deleted
To delete user# 123 with default master code 11111111
Enter sequence on keypad: 2, #, 11111111, 123, 123, #
Deletion succeeded when you hear a “BEEP” sound.
(3.2) Deleting Individual Fingerprint without User Number
1. Slide open front cover and press “2” then “#”
2. Enter master code
3. Press “#” to confirm
4. Put finger tip at the center of the scanner when blue light
is on. Lay flat and hold firmly until you hear a “BEEP”
sound
To delete a non assigned user number’s fingerprint with
default master code 11111111
Enter sequence on keypad: 2, #, 11111111, # When the
scanner lights up, put the FI GERPRI T on the scanner
firmly until you hear a “BEEP” sound to confirm the deletion
succeeded.
( 3.3) Deleting ALL Fingerprints
1. Slide open front cover and press “3” then “#”
2. Enter Master Code
3. Press “#” to confirm
4. You will hear a “BEEP” sound when all fingerprints are
successfully deleted
To delete fingerprints with default master code 11111111
Enter sequence on keypad: 3, #, 11111111, # When you
hear a “BEEP” sound, all memories are deleted
successfully.
3. Registering Passco es
The passcode is always an 8- igit number.
(4.1) Registering Passcode
1. Slide open front cover and press “1” then “*”
2. Enter Master Code
3. Enter 3-digit User umber
4. Enter Passcode
5. Repeat Passcode
6. Press “#” and you will hear a “BEEP” sound when
passcode is successfully registered.
To register user# 123 with default master code 11111111 &
passcode 02230223
Enter sequence on keypad: 1, *, 11111111, 123,
02230223, 02230223, #
If you hear 3 “BEEPS”, your passcode is not accepted.
Please repeat steps 1 to 6.
Reason: The User umber may be occupied. Try another
new User umber.
Bio
-
Matic™ Fingerprint Door Lock
Single
-
Latch
User
Manual
4.
Deleting/Mo ifying Passco es
(4.1) Deleting Individual Passcode with User number
1. Slide open front cover and press “2” then “*”
2. Enter Master Code
3. Enter 3-digit User umber
4. Repeat 3-digit User umber
5. Press “#” to confirm
6. You will hear a “BEEP” sound when passcode is
successfully deleted
To delete user# 123 with default master code 11111111
Enter sequence on keypad: 2, *, 11111111, 123, 123, #
(4.2) Deleting ALL Passcode
1. Slide open front cover and press “3” then “*”
2. Enter Master Code
3. Press “#” to confirm
4. You will hear a “BEEP” sound when all passcodes are
successfully deleted
To delete passcodes with default master code 11111111
Enter sequence on keypad: 3, *, 11111111, #
(4.3) Modifying Passcodes
1. Slide open front cover and press “0” then “*”
2. Enter Current Passcode
3. Enter ew Passcode
4. Repeat ew Passcode
5. Press “#” when finish
6. You will hear a “BEEP” sound when the passcode is
successfully modified
To modify current passcode 22222222 to 33333333
Enter sequence on keypad: 0, *, 22222222, 33333333,
33333333, #
5. Set the Bio-Matic Lock to Passage Mo e
Passage Mode enable users to keep the door unlock.
Users can access without using Fingerprints,
Passcodes or Keys. Just slide open the cover to open
the lock in Passage Mode.
(5.1) Set to Passage Mode
1. Slide open front cover
2. Press “*” two times
3. Enter Master Code
4. Press “#” to confirm
5. You will hear a “BEEP” sound when passage mode is
set.
(5.2) Deactivate Passage Mode
Repeat steps 1 to 4 on (5.1)
6. Unlocking the Bio-Matic Lock
(6.1) Unlock by using fingerprints
1. Slide open front cover and the scanner light will turn on
2. Firmly press finger tip at the center of the scanner
3. Door is unlock when you hear a “BEEP” sound
4. If you hear 3 “BEEPS”, your fingerprints is not
recognized. Repeat steps 1-3 again.
(6.2) Unlock by using passcodes
1. Slide open front cover
2. Enter 8-digit passcode to unlock
(6.3) Unlock by using backup key
1. Remove the keyhole cover by using the removal hook
which comes with the lock.
2. Use the backup key to unlock as you would normally
open a lock
