KJ750F-T02 Instruction Manual
Read instructions before operating. Retain for future references.
EnVure
Air Purification System

Air Outlet
Product Panels
Four-Side Air Inlets
Combined Filter (Internal)
Control Panel
Power Cord Connection
Laser Dust Sensor/
Humidity & Temperature Sensor/
TVOC Odour Sensor (Internal)
General Introduction

Power cord
1
Unpack the product, and remove
the power cord.
3
Filter installation
2
Installation
Powering up
Open air purifier’s rear cap, slide filter holder to the left to unlock and remove filter
cartridge.
Remove filter from packaging and place filter cartridge on filter seat.
Slide filter holder to the right to raise chassis to their original place. Close the rear
cap of filter. (Press and hold sleep button for 3 seconds to reset filter operation time).
Connect the power cord to the power
supply connection at the bottom, and plug
the other end into a power source.
LOCKUNLOCK

Screen Display Introduction
Light Strips Reflecting Air Quality
(if flashing it is time to replace the filter)
Air Quality Reading Temperature
Humidity Level
PM2.5 Inspection/ Anion Function/
APP Connection
Air Quality Level
Fan Speed
Start Button: When purifier is powered up, “Start” button
will turn red (standby-mode). Press the “Start” button to
start. Power consumption is less than 2W on standby
mode. System will shut down completely once power is
turned off.
Smart Button: During start up, air purifier works in Smart
Mode by default, and will automatically control fan speed
according to air quality (TVOC level) of the surrounding
area. To exit Smart Mode, manually press any button (Sleep
or Fan Speed).
Anion Button: Press “ON ANION” button on the remote
control to activate ANION function which produces
negative ion to precipitate fine dust particles. To deactivate,
press “OFF ANION” button once.
Fan Speed Button: Press Fan “Speed” button on the
control panel or remote controller to set fan speed. When a
certain speed is chosen, the corresponding indicator light
will show.
Sleep Mode: Press “Sleep” button on control panel or
remote control, the air purifier will enter Sleep mode and
electrical motor will run at their lowest speed. Only “Sleep”
button will be lighted on the control panel. Press other
buttons (except Start button) to exit Sleep mode.
WIFI (Enable Remote Control via Mobile APP):
• Download “Envure” app from App Store/Google Play
• Run the downloaded app and register a user account
• Connect your mobile to home/office WIFI
• Turn off purifier for 5 seconds and then on again.
• Press and hold SMART button for 3 seconds (or press WIFI button on remote
control) to turn the unit into pairing mode. You will see “WIFI” flashing on
purifier panel.
• Select “Add Device” on the APP and choose “Air Purifier” icon from the list.
• Click “Finished Network Configuration”.
• Key in your WIFI password and press OK to continue the set up.
• The APP will register your unit once installation is completed.
• If installation fails, repeat the above processes. The purifier is unable to
connect if there is a firewall, please disable firewall and try again.
• You can observe air quality reading, power on/off or select fan speed
from the APP.
NOTE: If WIFI button on the remote control is pressed again, the remote control via mobile
APP needs to be set up again.

Filter replacement alert/instruction:
During Start-up, the air purifier will automatically calculate running
duration of the filter according to machine’s programmed algorithm.
Durability of the machine depends on the operating condition. The light
strips on control panel will flash when filter requires replacement.
Restart air purifier after replacement. Press and hold the Sleep button
for 3 seconds to reset the flashing of light strips; the corresponding
indicator light will turn off and time memory will reset. Air purifier will
automatically shows the default Particulate Matter (PM) 2.5 condition on
its control panel.
Timer Setting:
A series of numbers “0-1-2-3-4-5-6-7-8-9” will be shown after pressing
Timer button. Air purifier will exit Timer mode with Timer button light
going off when “0” is selected. If no other operations are carried out or
no other buttons are pressed within 10 seconds after choosing the time
length, air purifier will switch to display mode automatically.
Child Lock:
To activate “Child-lock” mode, press and hold “TIMING” button on the
control panel for 3 seconds and red light will lit. During this mode, all
other buttons on the panel is LOCKED. Press and hold this button for 3
seconds again to exit “Child-Lock” mode.
Fall Prevention:
When the air purifier is placed in a wrong position (example if it tilts at a
90-degree angle), the machine will power off automatically. The machine
enters standby mode by default when it is returned to an upright
position.
Users’ Guide Technical Specifications
Model KJ750F-T02
Service Area up to 90 m2
Power Requirement 220 Vac / 50Hz / 65W (standby > 2W)
CADR (Particulate) 750 m3/hr
CADR (Formaldehyde) 225 m3/hr
Filter type 3 in 1 compact (Pre-lter, True HEPA, Activated Carbon)
Filter dimension 235mm dia x 42mm (Thk) x 400mm (H)
Filter Replacement 8 – 12 months (alert by lter replacement indicator)
Noise Level < 70 dB(A) @ max fan speed
Body Material Anodized Aluminium Alloy (Black Color)
Control Method Touch Panel, Remote & WIFI Apps
Certicates CB / CE / FCC / KC / RoHS
Build in Sensors PM 2.5, TVOC, Humidity, Temperature & Light Sensor
Operation Mode Manual, SMART, Sleep & Timer
Fan Speed Setting Level 1-2-3-4
Fan Motor DC Brushless (Nidec)
Fan Type Multiple Blade Centrifugal
Safety Operation AUTO Off (lter door open or Purifer tilted)
Product Dimension 330mm(L) x 330mm(W) x 806mm(H)
Packing Size 425mm(L) x 425mm(W) x 1010mm(H)
Casters Wheel Four (4) pieces with locking mechanism
Other Function Night Mode, ANION & Child Lock
Other Features Compact Design, Low Noise & Low Power Consumption
Packing Type Double Layer Corrugated Carton
Net Weight 16 kg
Gross Weight 19 kg

Installation
Air purifier cannot work if filter cover plate is not installed correctly;
Air inlet should always be kept more than 20 cm away from obstacles
to airflow, such as walls.
•
•
AC Power Cord
Do not excessively twist, pinch, bend or turn back the power cord,
otherwise the wire core will be exposed to air or break off;
Do not drag or pull power cord when unplugging;
Do not use AC socket that is not compatible;
Do not use the provided power cord in other devices.
•
•
•
•
Product Care
Immediately stop the air purifier if you experience anything unusual
such as abnormal sounds, strange smells, high-temperature, and fan’s
irregular rotation;
Do not put your finger or any object into air inlet and outlet;
Do not place anything (e.g. hair, fabric etc) close to the air purifier in
case they are sucked into the machine or block the air inlet and outlet;
Do not sit/stand on or tilt air purifier;
Do not spill any liquid or water into the purifier.
•
•
•
•
•
Filters and Cautions
CO2 Filter
EO2 Filter
Power
WIFI
Anion On
Child-Lock
Timer
Auto
Anion Off
Unlock Child-Lock
Sleep
Fan Speed

Common Problems
Foul smell from air filter outlet
High reading of PM2.5 value and red
light strips permanently lit
Low reading of PM2.5 value and red
light strips flashing
Mild static charge from top part of
purifier
Loud noise from purifier
Purifier unable to turn ON
Purifier unable to connect with
mobile app
Possible Causes
Dirty or contaminated filter due to high
humidity and purifier constantly operating at
low fan speed
Dirty sensors
New filter needed
Build up of static electric charge if the purifier
operates at low humidity environment
Foreign material present in fan compartment
No power supply, filter is not installed correctly
or filter lock is not closed properly
Internet connection is too slow or firewall block
present
Counter Measure
Remove the filter, sun dry for 2-4 hour and
remove any dirt on filter surface
Occasionally operate the filter with level 2 or
level 3 fan speed
Use a hair dryer with cold air mode to blow the
sensor port located on the left side of purifier
Replace new filter, press and hold ‘SLEEP”
mode button for 3 seconds
Turn off the ANION function or restart the
purifier again
Inspect and remove any foreign material
present
Check incoming power supply and ensure the
filter is installed correctly
Disable the firewall and ensure the WIFI is
2.4Ghz
Troubleshooting

This product is warranted to the original purchaser to be free from defective materials and workmanship
under normal use, and any such defects will be repaired through Authorised Service Stations/Dealers.
Warranty
User Address:
Product Model:
User Name:
Contact Information:
Date of Purchase:
Date of Repair:
Malfunction Information:
Repair Progress:
Document No.:
Supplier: Envilab Sdn Bhd.
Official Website: www.its-envilab.com
Service Hotline: [phone]
Official Distributor:
