USER MANUAL
EN 2HD IP
284001
ENCODER / STREAMER TWIN
V03

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
EN 2HD-IP USER MANUAL
INDEX
INTRODUCTION: ..................................................................................................................................................................................................................3
Description:.........................................................................................................................................................................................................................3
Main features: ...................................................................................................................................................................................................................3
Packaging Contents: .................................................................................................................................................................................................3
CONNECTIONS AND INTERFACES: .................................................................................................................................................................4
INSTALLATION RECOMMENDATIONS: ........................................................................................................................................................4
2HD IP CONFIGURATION: ..........................................................................................................................................................................................5
System status: ..................................................................................................................................................................................................................5
NETWORK: ...........................................................................................................................................................................................................................5
Account: .................................................................................................................................................................................................................................6
System parameters:...................................................................................................................................................................................................6
Configuration of Channel 1 or Channel 2: ........................................................................................................................................... 7
INSTALLATION SCHEMES:.......................................................................................................................................................................................10
Local Network Installation:...............................................................................................................................................................................10

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
3
EN 2HD-IP USER MANUAL
INTRODUCTION:
Description:
Encoder streamer with 2 HDMI inputs. Multicast IP output / HLS / RTMP for local or public
network (internet) of online content.
In the case of WebTV, the user will browse, from any web browser, a dedicated web page from
where you can select any of the two available services.
Up to 25 concurrent users.
Main features:
•2 HDMI inputs up to 1080.
•Video Code: H.264.
•Audio encoding: AAC.
•SPTS
•RJ45 100/1000 Mbps output port
•Management Web Interface
Packaging Contents:
•EN 2HD-IP, code 284001.
•Power supply 12V/2Amp.

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
4
EN 2HD-IP USER MANUAL
CONNECTIONS AND INTERFACES:
1 2 3 4 5
1.- Grounding.
2.- DC 12V/2A input.
3. - HDMI-1 in.
4.- HDMI-2 in.
5.- LAN connection.
1 2 7
3 4
5 6
1.- ALARM:
2.- ENCODE:
3.- RUN:
led flashes in
proper operation.
4.- HD1: HDMI-1 signal.
5.- POWER: equipment
connected to mains.
6.- HD2: signal in HDMI-2.
7.- RESET.
INSTALLATION RECOMMENDATIONS:
1.- Install the equipment vertically in a properly ventilated place, making sure that the
maximum recommended operating temperature values will not be exceeded.
2.- Leave between 15cm and 20cm free of obstacles around the equipment to ensure
compliance with point no.1.
3.- Connect the earth.
4.- Connect the input and output cables.
5.- Connect the power cable.
6.- Configure the equipment.

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
5
EN 2HD-IP USER MANUAL
2HD IP CONFIGURATION:
System status:
This first page shows us the status of the equipment showing serial no, CPU temperature, HW
and SW versions and CPU usage.
Then it shows us which HDMI inputs have signal, in green, and its resolution.
NETWORK:
The IP address, user and password by default are those that are indicated on the label of the
device, on its back side.
The NETWORK tab page will allow us to change the IP, mask and gateway.

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
6
EN 2HD-IP USER MANUAL
Account:
The IP address, user and password by default are those that are indicated on the label of the
device, on its back side.
The page of the ACCOUNT tab will allow us to change the username and password of the device.
System parameters:
In this menu we can update the FW, reset to factory settings or Restart.

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
7
EN 2HD-IP USER MANUAL
Configuration of Channel 1 or Channel 2:
This menu consists of two sub-menu. In the first we will configure the TS and the Output. Also,
in the list of programs, we will have the URL generated for each type of output that we
configure.
In the second sub-menu we can configure a subtitle and an image that will be superimposed
on the image of that channel.

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
8
EN 2HD-IP USER MANUAL
Web Player:
Copying, the marked address, in a browser
it will play a page served from encoder with two buttons where we can select any of the two
HDMI channels of the input. In this way we can play any of the two channels on any device
equipped with a browser.
In the event that you intend to play this page from a device outside our network, you will have
to redirect the relevant ports, port 80, on the Router correctly.

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
9
EN 2HD-IP USER MANUAL

ITS Partner O.B.S S.L · Of. Cerdanyola 79-81 Local C
08172 San Cugat of the Vallès · Barcelona (Spain)
Phone: [phone] · [e-mail] · www.ek.plus
10
EN 2HD-IP USER MANUAL
INSTALLATION SCHEMES:
Local Network Installation:
Installation for transmission to the internet:
