iTVGoggles FPView 3DHD User manual

FPView 3DHD
User Manual
A Revolution in Personal Entertainment
TM

WideView 3D Manual
iTVGoggles.com
CONGRATULATIONS ON YOUR NEW ITVGOGGLES.
You are about to experience the latest
in personal entertainment technology.
Before using your new device, please read this manual carefully. It includes
important safety information and instructions on how to correctly operate
your goggles to avoid unintentional mishaps or damages.
DO NOT use this device over the range of permitted temperatures (noted in the technical details. )
DO NOT drop, strike, or cause any portion of the product to be struck or shaken aggressively. Such actions may
damage the product and will void your warranty.
DO NOT use DC power adapters.
DO NOT disassemble the unit UNDER ANY CIRCUMSTANCES.
It is normal for the power adapter and the goggles to become warm during use and charging. However do not
use the goggles for extended periods of time, and allow a cool-down period every 30-60 minutes.
Do not use the goggles near water, high humidity or other potentially hazardous environments for electronics.
Take great care when connecting, disconnecting any of the plugs.
DO NOT put any restrain on the cables, connections and adapters.
Virtual screen size is an approximate estimation, which takes into account virtual distance and virtual viewing
angle.
Since this device will take over your audio/visual senses, please do not use in any potentially dangerous or risky
environments.
Stay seated while using the iTVGoggles.
IMPORTANT NOTES

FPView 3DHD User Manual
iTVGoggles.com Support.iTVGoggles.com
TABLE OF CONTENT
ONLINE RESOURCES 6
IN THE BOX 7
FEATURES OVERVIEW 8
SUPPORTED RESOLUTIONS 9
TECHNICAL SPECIFICATIONS 10
THE ANATOMY 11
CUSTOMISABLE ADJUSTMENTS 12
CONNECTING TO COMPUTER/LAPTOP 14
CONNECTING TO TABLETS/SMARPHONES 16
3D MODE 19
TROUBLESHOOTING 20
PRODUCT REGISTRATION 22
WARRANTY INFORMATION 23
SPREAD THE WORD. GET AWARDED. 24

7
6
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
IN THE BOX
HTTP://ITVGOGGLES.COM
HTTP://SUPPORT.ITVGOGGLES.COM
HTTP://FACEBOOK.COM/ITVGOGGLES
HTTP://TWITTER.COM/ITVGOGGLES
HTTP://YOUTUBE.COM/ITVGOGGLES
ONLINE
RESOURCES
FPView 3DHD Unit
Light Shield
Deluxe Carrying case
Cleaning Cloth
Stereo Earbuds
Male-To-Male HDMI Adapter
Mini/Micro HDMI Adapter

9
8
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
FEATURES OVERVIEW SUPPORTED RESOLUTIONS:
132”+ Virtual Screen Display (at approx. 10’-12’ virtual distance)
16:9 Wide-Screen
3D Support for Side-by-Side 3D movies & videos
HD Input Resolution support; up to 1920x1080 @60hrz
High Definition LCD Display - 1280×720 Display Resolution per eye
Radiation-Free LCD panels
Hi-fi Stereo Sound
Weight: under 100g (3.5oz) w/o wires
HDMI Input
Mini-HDMI, Micro-HDMI and MHL Adapters included

11
10
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
TECHNICAL SPECIFICATIONS
DisplayTechnology: TFT LCD
Virtual Display Size: 132” (at approximately 10’-12’ virtual distance)
Resolution: 720HD
Aspect Ratio: 16:9 Wide Screen
Color depth: 24-bit color for more than 16.7 million;
Video Input: HDMI
Audio: Hi-Fi Stereo
3D Format: Side by Side
Net Weight: 4oz (120g)
Power consumption: <1.1w
Working temperature: -5c~35c
Storage temperature: -5c~50c
Accessories: Hard shell carrying case, pouch, light-shield
Optional Accessories: Numerous adapters, WIFI display dongle and more;
THE ANATOMY

13
12
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
ADJUSTMENTS
FPView 3DHD comes with the freedome of several customizable adjustments to help deliver the best
viewing experience for each individual.
Diapter: Turn the ring around each lens untill it matches your prescription, or to the best position for
your eyes.
You can also move the lenses from side to side using the “Pupil Adjustment” slider bars under the unit.
This combination, along with adjusting the distance of the goggles from your eyes, using the Head-
band Dustance Adjust Botton, can lead to the most ideal experience for each user.
Pupil Adjustment
Diopter Adjustments
Pupil Adjustment
Distance djustments

15
14
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
CONNECTING TO COMPUTER/LAPTOP
1 - Make sure your screen resolution is set to a supported resolution (page 9)
2 - Connect the HDMI cable to the HDMI port on your computer
3 - Turn on the Goggles
Optional: Connect the USB plug to a USB port on your computer for power.
NOTE: SOME COMPUTERS MAY NOT HAVE HDMI OUTPUT. IN THIS CASE YOU WOULD
REQUIRE THE PROPER HDMI ADAPTER. FEEL FREE TO CONTACT US IF YOU NEED
ASSISTANCE IN CHOOSING THE RIGHT ADAPTER.

17
16
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
TABLETS, SMARTPHONES, CAMERAS, GAMING CONSOLES
1- Determine the type of DISPLAY/VIDEO OUT on your device (i.e. Mini-HDMI, Micro
HDMI, MHL, Lightning etc...)
2 - Connect the Goggles to your device via the HDMI connection end (using the
proper adapter if needed)
3 - Connect the USB end to a USB Power source such as a wall adapter, computer or
a portable battery bank
4 - Turn on your device or enable display if required, then the Goggles.
NOTE: You may need to adjust the resolution and/or other settings on your device
the supported specs by the goggles.
Some devices such as iPhones/iPads will require a Lightning Adapter (not included).
Feel free to contact our Support team if you need assistance.

19
18
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
3D MODE
FPView 3DHD supports Side-by-Side 3D content.
While watching a 3D video, movie or feed, press the switch on the 3D
button located at the bottom the goggles.
This mode will not work on regular 2D content. If you are seeing over-
lapping images, the chances are you have to tottgle this option.

21
20
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
TROUBLESHOOTING
The goggles do not turn on
- Please make sure your USB power source is working and has sufcient power output.
No Sound is coming from the headphones
- Make sure the earplugs are connected rmly
- Check if the volume on your device is turned down or on mute
- Make sure your device is set to output audio via HDMI
- If using any adapters, make sure they support audio
No video signal detected
- Check all the connections and cables
- Make sure you are using the proper adapters and connectors
- Check the resolution settings on your device
- Make sure your external device (i.e. Smartphone or PC) is setup correctly to output video
Picture appears blurry, out of focus, or distorted
- Follow instructions for adjusting the lenses to best t your vision (See “ADJUSTMENTS”)
- Please adjust the distance the goggles are from your eyes on your nose
- Adjust the pivot swivel point on the front of the goggles to point towards your eyes
- Make sure you are in the correct mode (2D or 3D)
I see two images overlapping
- Make sure you are in the correct mode (2D or 3D). Toggle the 2D/3D button.
For more assistance, tips and updates please visit our support center :
Support.iTVGoggles.com

23
22
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
PRODUCT REGISTRATION WARRANTY INFORMATION
We have made registering your product super easy.
Simply log on to http://Support.iTVGoggles.com to register your unit.
This device carries a 1-year limited manufacture warranty. This coverage starts from
the day of purchase, and requires your product to be registered. The warranty is not
transferable. This covers any defects clearly related to manufacturing procedures.
Due to the nature of this product it is highly recommended to exercise care while
handling and carrying this product. Physical damages, wear-and-tear, water
damage, or any other mishaps are not covered under the manufacture’s warranty.
Tampering with, attempting to open, interfering with the software or mishandling of
this product will automatically void this warranty. DO NOT attempt to open the casing
in any circumstances.
You may be able to purchase additional protection from your vendor.
If you feel like your unit has a manufacture’s defect please contact us or your vendor
immediately. Other restrictions may apply, and terms are subject to change. Please
visit iTVGoggles.com for more information.
REGISTER
ONLINE

25
24
FPView 3DHD User Manual
Support.iTVGoggles.com
iTVGoggles.com
LEARN ABOUT OUR AFFILIATE PROGRAM
10% PER SALE
EARN UP TO
Spread the word. Get awarded.
1 - Sign up and become an affiliate
2 - Talk about us on your Facebook page, blog, website, emails,
tweets and etc....
3 - Get commission for each sale coming from your referrals!
(paid in USD, via PayPal)
For terms and more information please visit itvgoggles.com
