ITW GSE 4400 User manual

OM2247 August 5, 2016
ITW GSE HOBART ●11001 Us Highway 41 North ●Palmetto, FL 34221 ●U.S.A
T: (toll free in US): 800-899-1841 ●T (International): + 1 941-721-1000 ●E: [e-mail]
Manual
ITW GSE 4400
60-90 kVA, 3 Phase, 115 Volt,
400 Hz Tier 4 Generator Set
Series no. 500106-500107
Type 4400
it’s all about connections

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Introduction
Page 1
Introduction
This manual contains operation and maintenance information for a diesel engine-generator manufactured by
ITW GSE, Palmetto, Florida 34221
This manual, including all information contained therein, is exclusive and confidential property of ITW
GSE. This manual is not to be copied, reproduced, or delivered or disclosed to others, in whole or in
part, except with express written permission of ITW GSE.
This manual is not intended to be a textbook on electricity or electronics. Its primary purpose is to provide
information and instructions to experienced operators, electricians, and mechanics that have never operated
this equipment. It is the intent of this manual to guide and assist operators and maintenance personnel in the
proper use and care of the equipment.
Use of the manual should not be put off until trouble or a need for help develops. Read the instructions before
starting the unit. Learn to use the manual and to locate information contained in it. Its style and arrangement
are very similar to commercial aircraft manuals.
The manual is divided into five chapters plus appendices. Each chapter is divided into as many sections as
required. Each new section starts with page 1. Each page is identified by chapter, section and page number,
which are located in the lower, outside corner.
When information located in another portion of the manual is referred to, a chapter, section, and paragraph or
figure number identify its location. For example: “(see Section 2-3, Paragraph 1.a.)” refers to information
located in Chapter 2, Section 3, Paragraph 1.a. If a chapter and section are not indicated in a reference, the
referenced material is located in the same section as the reference, for example: “(see Paragraph 1.a.).”
In addition to operation and maintenance instructions, the manual contains an illustrated parts list in Chapter
4 and a collection of manufacturer’s literature and supplemental information in Chapter 5.
Contents of the manual are arranged as follows:
Chapter 1 Description/Operation
Chapter 2 Servicing/Troubleshooting
Chapter 3 Illustrated Parts List
Chapter 4 Manufacturer’s Literature
Appendix A ARU
Appendix B Options
Appendix C Wet Stacking
Appendix D Operation in Unusual Service Conditions
Appendix E Software Installation Procedures
Appendix F Product Data sheet
Appendix G Schematics

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Introduction
Page 2
If you have any questions concerning your ITW GSE equipment, immediately contact our Service Department
by mail, telephone, FAX, or E-Mail.
Write: ITW GSE
Service Department
11001 US Highway 41, North
Palmetto, FL 34221
U.S.A.
Call Inside U.S.A.: [phone] (Parts)
[phone] (Service)
Call From Foreign Countries: [phone] (Technical Support)
[phone] (Spare Parts)
FAX inside U.S.A. [phone]
FAX From Foreign Countries: [phone]
E-Mail: [e-mail]
[e-mail]
Web Page: www.itwgse.com

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Safety Warnings
Page 1
Safety Warnings and
Cautions.
WARNING
ELECTRIC SHOCK can KILL. Do not touch live electrical parts.
ELECTRIC ARC FLASH can injure eyes, burn skin, cause equipment damage, and
ignite combustible material. DO NOT use power cables to break load. Prevent tools
from causing short circuits.
IMPROPER PHASE CONNECTION, PARALLELING, OR USE can damage this and
attached equipment.
IMPORTANT
Protect all operating personnel. Read, understand, and follow all instructions in the
Operating/Instruction Manual before installing, operating, or servicing the equipment.
Keep the manual available for future use by all operators.
WARNING
CALIFORNIA PROPOSITION 65 - DIESEL ENGINES. Diesel engine exhaust and
some of its constituents are known to cause cancer, birth defects and other illnesses.
1) General
Equipment that supplies electrical power can cause serious injury or death, damage to other equipment or
property. The operator must strictly observe all safety rules and take precautionary actions. Safe practices
have been developed from past experience in the use of power source equipment. While certain practices
below apply only to electrically powered equipment, other practices apply to engine-driven equipment, and
some practices to both.
2) Shock Prevention
Bare conductors, terminals in the output circuit, or ungrounded, electrically live equipment can fatally shock a
person. Have a certified electrician verify that the equipment is adequately grounded and learn what
terminals and parts are electrically HOT. Avoid hot spots on machine. Use proper safety clothing,
procedures and test equipment.
The electrical resistance of the body is decreased when wet, permitting dangerous currents to flow through it.
When inspecting or servicing the equipment, do not work in damp areas. Stand on a dry rubber mat or dry
wood, and use insulating gloves when dampness or sweat cannot be avoided. Keep clothing dry, and never
work alone.
a) Output Cables and Terminals
Inspect cables frequently for damage to the insulation and the connectors. Replace or repair cracked
or worn cables immediately. Do not overload cables. Do not touch output terminal while equipment
is energized.

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Safety Warnings
Page 2
3) Service and Maintenance
This equipment must be maintained in good electrical condition to avoid hazards stemming from
disrepair. Report any equipment defect or safety hazard to the supervisor and discontinue use of the
equipment until its safety has been assured. Repairs should be made by qualified personnel only.
Before inspecting or servicing this equipment, take the following precautions:
a) Shut off all power at the battery disconnect before inspecting or servicing the equipment.
b) Lockout the equipment at the battery disconnect switch if it is out of service.
c) If troubleshooting must be done with the unit energized, have another person present who is trained
in turning off the equipment and providing or calling for first aid.
4) Fire and Explosion Prevention.
Fire and explosion are caused by electrical short circuits, combustible material near engine exhaust pipes,
misuse of batteries and fuel, or unsafe operating or fueling conditions.
a) Electrical Short Circuits and Overloads.
Overloaded or shorted equipment can become hot enough to cause fires by self-destruction or by
causing nearby combustibles to ignite.
b) Batteries.
Batteries may explode and/or give off flammable hydrogen gas. Acid and arcing from a ruptured
battery can cause fires and additional failures. When servicing, do not smoke, cause sparking, or use
open flame near the battery.
c) Engine Fuel.
Use only approved fuel container or fueling system. Fires and explosions can occur if the fuel tank is
not grounded prior to or during fuel transfer. Shut unit DOWN before opening fuel tank cap. DO NOT
completely fill tank, because heat from the equipment may cause fuel expansion overflow. Remove
all spilled fuel IMMEDIATELY, including any that penetrates the unit. After clean-up, open equipment
doors and blow fumes away with compressed air.
5) Toxic Fume Prevention.
Carbon monoxide - Engine exhaust fumes can kill and cause health problems. Pipe or vent the exhaust
fumes to a suitable exhaust duct or outdoors. Never locate engine exhausts near intake ducts of air
conditioners.
6) Bodily Injury Prevention.
Serious injury can result from contact with fans or hot spots inside some equipment. Shut DOWN such
equipment for inspection and routine maintenance. When equipment is in operation, use extreme care in
doing necessary troubleshooting and adjustment. Do not remove guards while equipment is operating.

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Safety Warnings
Page 3
7) Medical and First Aid Treatment.
First aid facilities and a qualified first aid person should be available for each shift for immediate treatment
of all injury victims. Electric shock victims should be checked by a physician and taken to a hospital
immediately if any abnormal signs are observed.
EMERGENCY
FIRST AID
. SEEK ADDITIONAL ASSISTANCE. Use First Aid techniques recommended by
American Red Cross until medical help arrives.
IF BREATHING IS DIFFICULT, give oxygen, if available, and have victim lie down.
FOR ELECTRICAL SHOCK, turn off power. Remove victim; if not breathing, begin
artificial respiration, preferably mouth-to-mouth. If no detectable pulse, begin external
heart massage.
8) Equipment Precautionary Labels
Inspect all precautionary labels on the equipment monthly. Order and replace all labels that cannot be
easily read.

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Safety Warnings
Page 4
This page is intentionally left blank.

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4F Generator Set
August 5, 2016
Table of Contents
Page 1
Table of Contents
Chapter 1
Description/Operation
Chapter-Section/Page#
Section 1
Description
1-1/1
1) General
1-1/1
2) Optional Equipment - Appendix A and B
1-1/1
3) Component Locations
1-1/2
Figure 1-1-1: General Assembly of Generator Set
1-1/2
Figure 1-1-2: Main Components of Generator Set (Right Side)
1-1/3
Figure 1-1-3: Main Components of Generator Set (Left Side)
1-1/4
Figure 1-1-4: Main Components of Generator Set (Bottom)
1-1/5
4) Specifications
1-1/5
5) Special Features
1-1/8
6) Canopy
1-1/8
7) Engine and Generator
1-1/8
8) Operator Controls
1-1/12
8.1)Parameters – Menu Structure
1-1/15
9) Power Module Assembly
1-1/16
10) Cold Weather Start System
1-1/17
11) Active Rectifier Unit (ARU)
1-1/18
Section 2
Preparation for Use, Storage or Shipping
1-2/1
1) Preparation For Use after receipt of unit
1-2/1
2) Preparation for Storage
1-2/5
3) Preparation for Shipment
1-2/6
Section 3
Operation
1-3/1
1) General
1-3/1
2) 400 Hz. Operating Procedure
1-3/1
3) Active Rectifier Unit (ARU) – 28.5 VDC Power Supply
1-3/5
4) Icon Menu
1-3/8
4.0.1) View Parameters Menu
1-3/9
4.0.2) Setup Menu
1-3/10
4.1) Output Voltage
1-3/15
4.2) Output 1 Compensation
1-3/15
4.3) Output 2 Compensation
1-3/15
4.4) Output Mode
1-3/15
4.5) 400 Hz EF Interlock
1-3/16
4.6) 28V Interlock
1-3/16

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4F Generator Set
August 5, 2016
Table of Contents
Page 2
4.7) EF Interlock Ripple Level
1-3/16
4.8) EF Interlock Delay
1-3/17
4.9) Aircraft Connector Insertion
1-3/17
4.10) Cable Temperature
1-3/17
4.11) Allow Engine Idle
1-3/17
4.12) Automatic Engine Shutdown
1-3/18
4.13) Real Time Clock Setup
1-3/18
4.14) Date/Time Format
1-3/18
4.15) Ethernet Configuration
1-3/18
4.16) Modbus Slave Address
1-3/18
4.17) LED Brightness
1-3/19
4.18) Unit of Measure
1-3/19
4.19) 28V Voltage
1-3/19
4.20) 28V Compensation
1-3/19
4.21) Current Limit Step Size
1-3/19
4.22) Diagnostic Mode
1-3/20
4.23) Menu Lock Bypass
1-3/20
4.24) Confirm Battery Replaced
1-3/20
4.25) Tier IV Regeneration
1-3/21
4.26) Language
1-3/21
4.3) Black Box
1-3/22
4.4) Power Log
1-3/23
4.5) Update/Save Log Menu
1-3/24
Section 1
Maintenance Inspection/Check
2-1/1
1) General
2-1/1
2) Maintenance Schedule
2-1/1
Figure 2-1-1 Maintenance Schedule Check Sheet
2-1/2
3) Inspection / Checks
2-1/4
a) General
2-1/4
b) “AR” Checks and Operations (As Required)
2-1/4
c) “BR” Checks and Operations (Break-In Period)
2-1/4
d) “A” Checks and Operations (10 Hours or Daily)
2-1/5
e) “B” Checks and Operations (250 Hours or 3 Months)
2-1/8
f) “C” Checks and Operations (500 Hours or 6 Months)
2-1/9
g) “D” Checks and Operations (1000 Hours or 1 Year)
2-1/10
h) “E” Checks and Operations (1500 Hours or 1.5 Years)
2-1/11
i) Seasonal Maintenance Checks Spring/Fall (Engine)
2-1/12
j) “F” Checks and Operations (2000 Hours or 2 Years)
2-1/12
Chapter 2
Servicing / Troubleshooting
Chapter-Section/Page#

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4F Generator Set
August 5, 2016
Table of Contents
Page 3
k) “G Checks and Operations (5000 Hours or 4 Years)
2-1/12
l) Lamps and Fuses
2-1/13
Section 2
Maintenance Procedures
2-2/1
1) General
2-2/1
2) Engine Lubrication
2-2/2
a) General
2-2/2
b) Oil Specification
2-2/2
Figure 2-2-2 Lubrication Specifications
2-2/2
c) Changing Engine Oil
2-2/3
Figure 2-2-2 Oil Fill and Check Locations
2-2/3
d) Engine Accessories Lubrication
2-2/5
e) Trailer Lubrication
2-2/5
3) Servicing the Air Cleaner
2-2/6
a) Inspecting the Air Cleaner
2-2/6
Figure 2-2-3 Air Cleaner Assembly
2-2/6
b) Changing the Air Filter
2-2/6
c) Disposal
2-2/7
4) Engine Fuel
2-2/7
a) How to Select Fuel - Quality
2-2/7
b) Cold Weather Operation
2-2/7
5) Engine Fuel System
2-2/8
a) Fuel Tank
2-2/8
b) Fuel Water Separator or Lubricity Additive Filter
2-2/8
c) Primary Fuel Filter
2-2/9
Figure 2-2-5 Primary Fuel Filter
2-2/9
d) Fuel Pump
2-2/10
e) Fuel Return
2-2/10
f) Fuel Level Indicators
2-2/10
6) Engine Cooling System
2-2/11
a) General
2-2/11
b) Radiator Cap
2-2/11
c) Coolant
2-2/11
d) Draining the Cooling System
2-2/12
e) Flushing the Cooling System
2-2/12
f) Cleaning the Radiator Core
2-2/13
g) Filling the Cooling System
2-2/13
h) Thermostat
2-2/13
7) Engine Drive Belt
2-2/14
8) Generator Maintenance
2-2/14
9) Preventive Maintenance
2-2/15

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4F Generator Set
August 5, 2016
Table of Contents
Page 4
Section 3
Troubleshooting Procedures
2-3/1
1) General
2-3/1
2) Equipment for Troubleshooting
2-3/1
3) Parts Replacement
2-3/1
4) Normal Operational Parameters
2-3/1
5) Check Connections and Leads
2-3/1
6) Engine Troubleshooting
2-3/2
7) GPU Control Monitoring
2-3/2
8) Cummins Engine Fault Codes & Troubleshooting
2-3/3
9) Fuses
2-3/3
Troubleshooting Charts
2-3/5
…Error Code Chart
2-3/5
…Engine Controls Diagnostic Checks
2-3/9
…Generator Diagnostic Checks
2-3/12
…Load Contactor Operating Circuits Diagnostic Checks
2-3/14
…Protective Circuit Diagnostic Checks
2-3/15
Chapter 3
Illustrated Parts List
Chapter-Section/Page#
Section 1
Introduction
3-1/1
1) General
3-1/1
2) Purpose
3-1/1
3) Arrangement
3-1/1
4) Explanation of Parts List
3-1/1
5) Numerical Index
3-1/3
6) Explanation of Numerical Index
3-1/3
Section 2
Illustrated Parts List
3-2/1
Explanation of Parts List Arrangement
3-2/1
Symbols and Abbreviations
3-2/1
Hierarchy
3-2/1
Figure 3-1. 4400, 60/90 kVA,3-Phase 115 Volt Generator Set
3-2/6
Figure 3-2. Assembly Chassis/Running Gear 60-90 kVA T-4
3-2/9
Figure 3-3. Genset/Fuel Tank Installation, 60-90 kVA
3-2/12
Figure 3-4. Genset Assembly, 60-90 kVA
3-2/16

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4F Generator Set
August 5, 2016
Table of Contents
Page 5
Figure 3-5. Fuel Tank Composite Assembly
3-2/19
Figure 3-6. Radiator/After-Treatment Installation 60-90 kVA T-4
3-2/23
Figure 3-7. Coolpack, Radiator Assy 60-90 kVA
3-2/26
Figure 3-9. Output Table Assembly, Single Output
3-2/29
Figure 3-10. Output Table Assembly, Single Output w/ 28 VDC ARU
3-2/31
Figure 3-11. Output Table Assembly, Dual Output
3-2/33
Figure 3-12. Output Table Assembly, Dual Output w/28 VDC ARU
3-2/35
Figure 3-13. Control Box Module Assembly
3-2/37
Figure 3-14. Cable Tray Assembly, Left Side
3-2/39
Figure 3-15. Cable Tray Assembly, Right Side
3-2/41
Figure 3-16. Top Canopy Composite Assembly
3-2/43
Chapter 4
Manufacturer's Literature
Appendices
Appendix A – Active Rectifier Unit (ARU)
Appendix B – Options
Appendix C – Wet Stacking
Appendix D – Unusual Service Conditions
Appendix E – Software Installation Procedure
Appendix F – Product Data Sheet
Appendix G – Schematics
Section 2
Numerical Index
3-3/1

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Chapter 1-1
Page 1
Chapter 1
Description/Operation
1) General
The basic generator sets covered in this manual, manufactured by ITW GSE Group, are rated at 60kVA
and 90kVA they are designed to produce and deliver 115/200-volt, 400 Hz, 3-phase AC power to a
parked aircraft or other load. Some generator models with the Active Rectified Unit (ARU) option also
provide 28.5 volts DC for aircraft having those requirements. A comprehensive review of the 28VDC
output Active Rectifier Unit (ARU) is located in Appendix A.
This version of the manual reflects firmware changes to the operating system through version F. (The
firmware version of the unit is found on the unit information screen in the View Parameters Menu. Section
4.0.1). These changes include new setup menu items and changing the order of several screens.
Model Number kVA Mounting Engine Certification Outputs 28.5 DC Output
ACE44xxSTT4 xx
Trailer
Tier 4 US Labeled Single 400Hz No
ACE44xxS28TT4
xx
Trailer
Tier 4 US Labeled Single 400Hz Yes
ACE44xxDTT4
xx
Trailer Tier 4 US Labeled Dual 400Hz No
ACE44xxD28TT4
xx
Trailer Tier 4 US Labeled Dual 400Hz Yes
xx – 60, 90, (i.e. ACE4460STT4 is rated for 60 kVA full load single output)
Table 1-1-1: ITW GSE 4400 Series Tier 4 Generator Set Part Number Descriptions
2) Optional Equipment - Appendix A and B
Chapters 1 through 4 of this Operation and Maintenance Manual identify only the basic version of the ITW
GSE 4400 Tier 4 generator set. Appendix A describes the Active Rectifier Unit (28.5 VDC) option.
Appendix B contains a list of the rest of the optional equipment that can be ordered with the unit. Each
item has a brief description of the optional equipment.
Section 1
Description

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Chapter 1-1
Page 2
3) Component Locations
For purpose of orientation when designating RIGHT and LEFT throughout this manual, the radiator is
considered to be at the FRONT of the unit and the generator is at the REAR. RIGHT and LEFT are
determined by standing at the REAR facing the machine. As an example, the control panel is mounted
on the RIGHT FRONT side of the unit.
1. Fuel Filler Neck / Manual Gauge
2. Operator Control Panel
3. Composite Output Cable Trays
4. Fifth Wheel Assembly
5. Rear Axle Assembly
6. Emergency Stop Switch
7. Sliding/Removable Canopy
8. Clearance Lights (Option)
9. Radiator End
10. Generator End
11. Forklift Pockets
12. Low Fuel Beacon (Option)
13. Operating Beacon (Option)
14. Canopy Locking Latch
Figure 1-1-1: General Assembly of Generator Set
2
3
4
1
5
6
7
8
9
11
10
3
12
13
14

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Chapter 1-1
Page 3
1. Cummins QSB4.5 T4 Engine
2. Control Module Assembly
3. Batteries (inside tray pockets)
4. Battery Disconnect
5. After Treatment Shielding
6. Generator
7. 28.5 VDC ARU (Option)
8. Engine Alternator
9. Output Contactors
10. Air Filter Assembly
Figure 1-1-2: Main Components of Generator Set (Right Side)
1
2
3
10
6
8
7
9
4

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Chapter 1-1
Page 4
1. Coolant fill access cover
2. Lubricity Additive Fuel Pre-Filter
3. Fuel Filter
4. Engine Oil Filter
5. Engine Control Module (ECM)
6. Engine Oil Fill Tube
7. Charge-Air-Cooler Piping
8. Engine Air Filter
9. Tow Bar/Brake Release Lever
10. DEF Tank Fill Tube
Figure 1-1-3: Main Components of Generator Set (Left Side)
1
2
3
4
5
7
8
9
6
10

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Chapter 1-1
Page 5
1. Oil Drain Valve
2. Tie Down Rings (Option)
3. DOC Diesel Oxidation Catalyst
4. SRC Selective Catalytic Reduction
5. DEF Fluid Holding Tank
6. DEF Dosing Module
Figure 1-1-4: Main Components of Generator Set (Bottom)
4) Specifications
a) Standards
These units have been designed to be in compliance with the following standards:
US EPA Tier 4F/CARB Tier 4F
EU Stage IV
US MIL-STD-704F, SAE ARP5015
1
2
3
4
5
6

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Chapter 1-1
Page 6
b) Physical Specifications
Length
112.1 in. (2847 mm) w/ towbar
up
Width 66.7 in. (1694 mm)
Height 63.9 in. (1622 mm)
Weight (dry) 4000 lb. (1814 kg.)
Weight with 28.5 VDC ARU 4300 lb. (1950 kg.)
Operating temperatures
-25°F* to +125°F
-32°C to +52°C
*Low temperature option -
Battery blanket & Block Heater
-40°F/C
c) AC Generator Specifications
Output power rating
60 kVA (48 kW)
90 kVA (72 kW)
Output voltage
115 / 200 VAC
115 / 200 VAC
Rated load capacity
173 Amps
260 Amps
Frequency
400 Hz.
400 Hz.
Power factor
0.8
0.8
Duty Cycle
100%
100%
Operating speed
2000 RPM
2000 RPM
Overload capacity
125% rated load
216 Amps
325 Amps
Output cable size
2/0 – if banded
2/0 – if banded
Insulation Class
H
H
d) AC Generator Protective System Specifications
Condition
Time Delay
Over voltage
250 milliseconds
15 milliseconds
Under voltage
500 milliseconds
Over frequency
1 second
immediate
Under frequency
5 seconds
60 kVA & 90 kVA
Output overload
80% load at PF 0.8 to 1.0
Continuous
100% load at PF 0.7 to 0.8
Continuous
100% to 125% load
10 minutes
125% to 150% load
10 seconds
150% to 175% load
2 seconds

OM-2247 / Operation and Maintenance Manual
ITW GSE 4400 / 400 Hz. Tier 4 Generator Set
August 5, 2016
Chapter 1-1
Page 7
e) DC Output Specifications (with optional TR unit)
Output Power Rating
17.1 kW
Output Voltage
28.5 VDC
Load Capacity (Continuous)
600 A
Current Limiting Capability
300 to 2000 A in selectable steps
(50/100/200/300A)
Peak/Starting Load Capacity
2000 A for 5 seconds
Output cable size
4/0 for continuous loads up to 400A
2x 4/0 for continuous loads up to 600A
f) DC Protective System Specifications
Condition
Trip Point
Time Delay
Over Voltage
32 - 40 VDC
Over 40 VDC
4 seconds
150 ms
Output Overload
2000 A
5 seconds
1800 A
10 seconds
1200 A
30 seconds
800 A
30 seconds
g) Engine Specifications
Manufacturer and Model
Cummins Engine Company / QSB4.5
Type
4 cylinder, 4 cycle diesel, electronic controlled
Bore and Stroke
4.21 in. x 4.88 in. (107 mm x 124 mm)
Displacement
272 in3(4.5 L)
Horsepower
155 hp (115 kW)
Idle speed
1000 ± 50 rpm
Normal governed speed
2000 rpm
Firing Order
1-3-4-2
Electrical system
24 VDC
Lubricating oil capacity (w/ filter)
11.6 quarts (11 liters)
Coolant capacity system
20 quarts (18.9 liters)
Fuel tank capacity
53 gallons (200 liters)
DEF Tank capacity
5 gallons (18.9 liters)
h) Normal Operating Characteristics
Engine oil pressure (warm and at rated speed 2000 RPM)
65 to 75 PSI (448 to 517 kPa).
Engine coolant temperature (normal operation)
180 to 203º F (82 to 95º C).
