ITW Simco-Ion ST-4 User manual

INST-10121514
Simco Worksurface Tester
Model ST-4
INSTRUCTIONS
Installation/Operation/Maintenance
CAUTION
It is important that these instructions be read and understood
before attempting to install or operate the equipment. Failure to
do so could result in serious personal injury and/or damage to
the equipment. At the end of this manual, a written warranty is
provided. This should be preserved carefully.
INST-10121514
Notes to users
WARNING
This equipment is not constructed for classified (hazardous) environment. It cannot be used
where it will be exposed to ignitable or corrosive materials and gases.
CAUTION
This equipment is intended for use in electrostatic processes that are free from water, oil,
solvent and other conductive contaminants. Exposure to such contaminants will cause failure
of the electrical insulation system in the product. Special care should be taken to ensure that
there is no dew formation. This equipment shouldbestoredorusedinaplacelessthan
60 %RH.
Please read this instructions carefully prior to attempting to operate.
This equipment should NOT be operated in an ambient with corrosive fumes of acid/alkali or
corrosive gases such as chlorine.
When not used, the switch should be OFF.
This equipment should be used as written in this operation manual.
This instrument contains delicate components and it is likely to be affected if dropped. Please
handle the instrument with care. In such an event, it should be carefully examined and any
necessary repairs be made by an authorized technician. This equipment also has chip
micro-computer inside so do not use under a radio wave noise.
Do not touch and hart the sensor of this equipment.
Do not weigh and/or push by finger on the LCD display.
This equipment was assembled and inspected at Simco Japan, Inc. Do not attempt to
disassemble or modify its construction. If you are not clear about its operation and
maintenance, call Simco Japan's authorized agent in your area.
This equipment has nickel-metal hydride battery. Thus if this equipment remain ON or OFF
condition longer than one-year, the battery would be in non-chargeable condition due to
discharge of electricity. Please turn off when not used and charge the battery frequently.
-page1-

INST-10121514
Thank you for buying Simco products. This equipment will meet your expectations and
provide safe operation when it is properly installed and maintained.
Receiptofequipment
Please carefully remove the equipment from the carton and inspect. Note any damage that
might have occurred during shipment. Empty the carton to ensure that small parts are not
discarded.
If any damage has occurred during shipment, the local carrier should be notified at once. A
report should be forwarded to SIMCO JAPAN, INC. The address and other relevant
information are written on the back cover page.
Packing articles and accessories
1 Worksurface Tester Model ST 4 ....................................................... 1 pc.() -
2 Probe Assembly cable .......................................................................... 1 pc.() Cable length 850 , banana plug alligator clip㎜、
3 Instructions / Warranty ....................................................................... 1 pc.()
Option:
1 USB Cable ........................................................................................... 1 pc.()
2 USB-AC ADAPTER ........................................................................... 1 pc.()
3 C ......................................................................................... 1 pc.() arrying case
Please check if any part is missing or does not
have satisfactory finish. Contact us or our agents
immediately in the event of such occurrence.
-page2-
INST-10121514
Contents
Notes to Users ......................................................................................... page 1
Receipt of equipment............................................................................... page 2
Packing articles and accessories.............................................................. page 2
Contents.................................................................................................... page 3
Section 1. Description ............................................................................. page 4
Section 2. Principle of measuremen ....................................................... page 4
Section 3. Specification ........................................................................... page 5
Section 4. Setup ....................................................................................... page 6
Section 5. Operation ................................................................................. page 7
Section 6. Exponnent less than a decimal point ..................................... page 8
Section 7. Probe Cleaning ........................................................................ page 8
Section 8. Dimensional drawings ............................................................ page 9
SIMCO EQUIPMENT REPAIR WARRANTY...................................... enclosed
Explanation of Symbols:
WARNING
ATTENTION / CAUTION
ELECTRIC SHOCK HAZARD
-page3-

INST-10121514
Section 1. Description
Simco Worksurface Tester Model ST 4 is a portable, easy-to-use instrument for use in-
evaluating a wide variety of ESD protective materials including table mats, floor mats, hard
laminates, conductive floors etc.
Simply ST 4 will start measure by leave on the object you attempt to measure. ST 4 also has--
timer inside to avoid remaining/leaving ON condition although not used.
Additionally resistance to ground function of the same range is provided to permit resistance
measurements to be made from any points on the surface being tested to ground to indicate
total system resistance of the mat, ground lead and connection.
ST-4 accurately measures and displays surface resistivity in the range from
10 10 Ωsquare.
3
〜／
１３
Section 2. Principle of measurement
Worksurface Tester Model ST 4 has a built-in voltage source that places a potential difference-
(V) of 10V or 100V DC between the parallel conductive probes. The source can deliver up to
10mA or 1mA of current, and it is measurement of this current (I) that is used to determine
the surface resistivity. The resistance between the probes (R) is calculated automatically in the
tester using Ohm's Law
R=V/I
ST 4 has one-chip micro-processor and it can provide very precise measurement and-
wide-rage registancy. See below the diagram of ST 4.-
Low resistansy rubber covered probe (10 Ω/ or below) is attached on the surface to be-㎝
２
tested and the standard voltage (10V or 100V ) is charged to the surface to be tested thru
protective resistance inside.
The arrangement of the probes makes the resistance measurement in ohms equivalent to the
surface resistivity in ohms per squre. ST 4 tester displays the resistivity, after logarithmic-
conversion, as an exponent of LCD. a block diagram of the circuit is shown in fig.1
fig.1 Diagram of the circuit
−−page 4
INST-10121514
Section 3. Specification
１０ 〜１０ （ Ω）Surface Resistivity : Ω/sq. or
３１３
Mode : Standard Mode(Ohm per square, Surface Resistivity)①Mat surface - Mat resistance measurement Mode (Ohms, Resistivity to Ground)②(w/ cable)
IEC Standard measurement Mode③follow the IEC standard probe (surface + weight)
LCD display : Exponent display (one digit beyond the decimal point)
Remaining measurement time by bar-graph indicator
Remaining battery value
LED display : TEST①Green LED indicator: Standard Mode(Ohm per square, Surface Resistivity)
Red LED indicator: Mat Ground resistance measurement Mode-
(Ohms, Resistivity to Ground) and IEC standard measurement Mode
Measurement voltage (10V,100V)②Green LED indicator: 10V output
Red LED indicator: :100V output
Yellow LED indicator: Completed
CHARGE③Red LED indicator: in process of charging
Measurement time : 10sec, 30sec, 60sec
Range : Can be set up the max and min of measurement value (by 0.5 exponent)
（１０ ）Accuracy : ±0.5 decade ex.
８５±０５
..
Measurement volatage : Automatically adjust/chamge
Cube of 3 to 6 : 10V, 10mA max①Cube of 6 to 13 : 100V, 1mA max②
Source : Inside battery
External outlet : External probe connector①AC adaptor connector (battery charging USB mini type)②
Measurement are : 50mm probe length ×50mm (probe distance) (in measurement)（）
Probe material : Special conductive rubber (volume resistivity 0.02Ωmax.)･㎝
Environment : 15 25 under 60%R.H.℃〜 ℃，
Dimension : 114(W)×78(D)×69(H) max. (mm)
Case : Stainless
Weight : body 700g
cable 25g
−−page 5

INST-10121514
Section4.Setup
3.1 Battery
ST 4 can be charged from USB port at the side of the equipment. When turning ON-
power switch, LCD (at left bottom) shows the remaining battery charge with four steps
as below fig. When the battery charge is low, connect USB cable (mini-B-USB)to
AC/DC adopter or your PC's USB port to charge. Once charging starts, [CHARGE]
LED indicator is turn on RED during charging period.
Remaining battery indicator
ATTENION
ST 4 battery remaining indicator may not match exactly same as real remainning-
battery charge. Thus it may show sharp drop upon the remaining and usage
condition.
3.2 Measurement
ST 4 can set up the measurement time and max/min of the resistivity.-
Push [SET] button under LCD (see the picture below) with tiny pin (approx 1mm
diameter). [SE01] show up first, then the reserved measurement time comes up. You
can set upthe measurement time with UP/DOWN button with tiny pin. Once you
complete set up and push again [SET] button, [SE02] comes up and the reserved
maximum measurement time will be indicated. The measurement time can be changed
by 0.5 with UP/DOWN button. After you complete setting up the maximum, please
push [SET] button. Next you can see [SE03] and the reserved minimum measurement
time. Same as setting up the maximum, you can set up with UP/DOWN button by 0.5.
After you complete, push [SET] again, then the mode is back to normal measurement
mode.
3.2.1 Set up the measurement time
The four measurement time can be set up.
LCD : Measurement time : Bar indicator
15 : 15 sec : 1 sec/ 1 bar
30 : 30 sec : 2 sec/ 1 bar
60 : 60 sec : 4 sec/ 1 bar
(default set up is [15])
3.2.2 The maximum set
If the resistance is over the maximum, the indicator will be blinking and show
）[+] beside. (default set is [13.5]
3.2.3 The minimum set
If the resistance is under the minimum, the indicator will be blinking and show
-）[ ] beside. (default set is [2.5] −−page 6
INST-10121514
Section 5. Operation
4.1 Surface resistivity check
1) Turn on switch ON
2) Place ST-4 Tester on the surface to be tested gently
3) Push [START] button, then the measurement starts. During surface resistivity check,
LED in TEST is lighted Green (Ohms per square Surface Resistivity). Also，
LED in OUT is lighted Green first, then lighted Red once hitting over 6 square.
4) During the measurement, LCD just shows (no value) and the「−−−」
measurement progress by bar graph at right top corner.
5) After the measurement time is up, LED in OUT is lighted Yellow and the
registivity value shows. the exponent measurement value shows beyond one decimal
（、 ）point on LCD ex. 10 the value shows as 8.4
８４
.
6) If the test is outside of the operating range of ST-4 (10 Ω/sq below or 10 Ω/sq
３１３
above), the value indicator is blinking and shows [ ] (below the minimum) or [+]-
(above the maximum) left the value. If you set your own max/min range (refer to
Section 3 Set up)and outside of the range, it shows same.
7) If another measurement is desired, push [START] button again.
8) When measurements are completed, turn OFF the switch.
4.2 Resistance to Ground Check
1) Attach a ground lead to RESISTANCE TO GROUND jack on the side of the tester
and its mode automatically change to ground check between the lead end and ST 4-
probe. LED in TEST is lighted Red (Ohms, Resistance to Ground).
2) Connect the other end of the ground to a common point grounding block or to
another known nearby ground.
3) Place ST 4 tester on the surface to be tested.-
4) Push [START} button and start measurement. Also LED in OUT is lighted Green
first, then lighted Red once hitting over 6 square.
5) During the measurement, LCD just shows (no value) and the measurement｢---｣
progress by bar graph at right top corner.
6) After the measurement time is up, LED in OUT is lighted Yellow and the registivity
value shows. The exponent measurement value shows beyond one decimal point on
LCD (ex. 10 the value shows as 8.4)
８４
.
、
7) If the test is outside of the operating range of ST 4 (10 Ωbelow or-
３
10 Ωabove), the value indicator is blinking and shows [ ] (below the minimum)
１３
-
or [+] (above the maximum) left the value. If you set your own max/min range
(refer to Section 3 Set up)and outside of the range, it shows same.
8) If another measurement is desired, push [START] button again.
9) When measurements are completed, turn switch OFF , then disconnect the ground
cable from the common point grounding block or other known nearby ground. Then
disconnect plug of the cable carefully.
−-page 7

INST-10121514
Section 6. Exponent less than a decimal point
ST 4 displays decade values to one digit beyond the decimal Exponent Real number-0.1 1.3point. 0.2 1.6Thus ST 4 can measure more accurate compared to the relative-0.3 2.0value of resistance. 0.4 2.5
0.5 3.2Please refer the table right 0.6 4.0
0.7 5.0For example, when the instrument gives a decade value of 0.8 6.35.8, table can be used to add additional precision to the 0.9 7.9measurement as below
５８ ５＋０８ ０８ ５
10 10 10 × 10
...
＝＝
≒＝(Ω)6.3 × 10 0.63M
５
Other example, in case of 8.2
≒＝(Ω)10 1.6 × 10 160M
８２ ８
.
Section 7. Probe cleaning
The insulated part of the probe is fluorocarbon polymer so this is high resistance and
preventive from dirt. You can test using an insulating object ( fluorine resin, 10 Ω/sq or
１３
above) or metal object. If the probes and the surfaces are clean each test should illuminate
[OUT OF RANGE] Attention: If the probe is not clean enough, the value showed on LCD
may be lower than real value.(in particular high resistance object measurement Also you）
can test using clean surface metal object ( 10 Ω/sq or below). LCD should show [OUT OF
３
RANGE]. Attention: If the probe rubber is not clean enough, the value showed on LCD may
）be higher than real value.(in particular low resistance object measurement
In case of [OUT OF RANGE], the probe has dirt on it. Thus remove accumulations of dust,
dirt, and oils using pure isopropyl alcohol on a lightly moistened swab. Allow probe
assembly to air dry prior using. After dry, please perform same test again.
Even after cleaning, if the equipment test does not show properly, it may has
function/mechanical problems. Thus please contact SIMCO Japan Inc. or Simco Japan's
authorized agent in you r area.
ELECTRIC SHOCK HAZARD
Please clean the electrode part after turning off the power switch without fail.
−−page 8
INST-10121514
Section 7. Dimensional drawings
--page 9

INST-10121514
SIMCO EQUIPMENT
REPAIR WARRANTY
Simco equipment has been carefully tested and inspected at the factory and
is warranted to be free from any defects in materials or workmanship.
Simco Japan, Inc. will, under this warranty, repair or replace any
equipment, which proves upon their examination, to have become defective
within the Warranty period from the date of shipment. A one year Warranty
applies to all Simco equipment. The equipment is to be returned by the
purchaser to Simco Japan, Inc. or authorized agent of Simco, transportation
prepaid and insured for its full purchase price. Prior to returning any goods
for any reason, contact Simco Japan, Inc. or authorized agent for a Return
Authorization Number. This number must accompany all returns.
The Warranty does not apply when the equipment has been tampered with,
misused, improperly installed, altered, has received damage through abuse,
carelessness, accident, connected to improper line voltage, or has been
serviced by anyone other than an authorized factory representative. The
warranty does not apply when Simco parts and equipment have been
energized by other than appropriate Simco Power unit or generator, or when
Simco Power unit or generator has been used to energize other than Simco
parts and equipment.
Simco Japan, Inc. makes no Warranty, expressed or implied, nor accepts
any obligation, liabilities or responsibility in connection with the use of this
product other than the repair or replacement of parts as stated herein.
Simco Worksurface TesterProduct
ＳＴ−４ Name
AoneyearDelivery Product's serial number contains Warranty WarrantyDate information on the shipping date. Period
INST-10121514
SIMCO JAPAN, INC.
1-2-4, Minatojima-Nakamachi,
Chuo-ku, Kobe, 650-0046, Japan
Phone: [phone] Fax: [phone]
WEB: http://www.simcoion.jp/
INQUIRY e-mail: [email protected]
