USE AND MAINTENANCE
USO E MANUTENZIONE
UTILISATION ET ENTRETIEN
BETRIEB UND WARTUNG
USO Y MANTENIMIENTO
NEF SERIES
E LECTRONIC INJECTION SYSTEM
Publication edited by
Marketing - Adv. & Promotion
Print L31900018 - 10/06
MARINE ENGINES

1
ENGLISH
NEF SERIES
ELECTRONIC INJECTION
SYSTEM
N40 ENT M25
N60 ENT M37
N60 ENT M40
N67 ENT M45
USE AND MAINTENANCE
INTRODUCTION
We would like to thank you for buying an IVECO MOTORS product,
and compliment you on your choice of engine.
Before you carry out any operation involving the engine or its fittings,
please read the contents of this manual carefully; compliance with the
instructions provided in the manual is the best way to guarantee trouble-
free, long term operation of the engine.
The contents of this manual refer to the standard configuration of the
engine, and the illustrations are purely indicative. Some instructions are
provided by giving the sequence of operations to be carried out in order
to allow the engine and/or its fittings to perform in a certain way. In
some cases they will be dependent on the configuration of the
commands and the set-up of the vessel on which the engine is installed;
for any points that differ from the contents of this manual, please consult
the instructions provided by the Boatbuilder or a specific manual.
The information provided below was current at the date of publication.
The Manufacturer reserves the right to make modifications at any time
without prior notice, for technical or commercial reasons or to update
the engines to comply with legal requirements in the various Countries.
The Manufacturer declines all liability for any errors or omissions.
Please remember that the IVECO MOTORS Technical Service
Network is available to offer you its experience and professional skills,
wherever you may be.

2
CONTENTS Page
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Engine technical data N40 ENT M25. . . . . . . . . . . . . . . . . . . . . . . .4
Engine technical data N60 ENT M37/M40 . . . . . . . . . . . . . . . . . . .6
Engine technical data N40 ENT M25. . . . . . . . . . . . . . . . . . . . . . . .8
Signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
USE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Preliminary checks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Starting and stopping the engine . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Starting and stopping the engine from
the analogue control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Recognising alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Starting and stopping the engine from
the digital control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Recognising alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Managing the engine from the Relay box . . . . . . . . . . . . . . . . . . .21
Proper use of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Special warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Running in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
CONTROLS AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . .25
Maintenance personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Accident prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
How to proceed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Moving the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Disposal of waste . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Page
LONG PERIODS OF INACTIVITY . . . . . . . . . . . . . . . . . . . . . . .36
Preparing the engine for a long period of inactivity . . . . . . . . . . .36
Restarting the engine after a long period of inactivity . . . . . . . . .37
ENGINE MALFUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
EMERGENCIES ON BOARD . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
IN APPENDIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil viscosity level according to surrounding temperatures . . . . . . .

3
ENGLISH
GENERAL INFORMATION
GUARANTEE
In order to ensure that your engine gives the best possible performance
and to take advantage of the IVECO MOTORS guarantee, you must
follow the indications provided in this publication with great care; failure
to do so may result in invalidation of the guarantee.
SPARE PARTS
Always use Original IVECO MOTORS Spare parts. This is essential to
keep the engine in original running order.
The use of non-original spare parts will not only invalidate the guarantee,
but will mean that IVECO MOTORS will not be considered liable in any
way during the whole working life of the engine.
LIABILITY
The Manufacturer will only be considered liable subject to performance
of the control and maintenance operations indicated and described in
this manual; to this effect, proof that these operations have been
performed must be provided. Any special maintenance operations that
may be necessary must be carried out by qualified technicians from
authorised Workshops in the IVECO MOTORS Network, using the
instruments and equipment provided for the purpose.
SAFETY
The following information is intended to encourage caution when using
the engine, so as to avoid damage to persons or property as a result of
improper or incorrect behaviour.
The engines must only be used for the purposes indicated by the
Manufacturer.
Any tampering, modification and use of non-original spare parts
may compromise proper operation of the engine and safe
navigation;
never, under any circumstances make
modifications to the
wiring and to the units equipping the engine,
or connect them to other power systems.
Pay particular attention to moving parts of the engine, to high
temperature components and to circuits containing pressurised
fluids; its electrical equipment houses electrical currents and
voltage.
The exhaust fumes produced by the engine are bad for your health.
The engine must only be moved using suitable lifting tackle, making
use of the U-bolts provided on the engine for that purpose.
The engine must not be started up and used until the vessel in
which it installed has satisfied all necessary safety requirements, or
until the vessel has been guaranteed to comply with local laws and
regulations.
The operations required to guarantee the best possible use and
preservation of the engine must only be carried out by persons of
proven experience, equipment with tools considered suitable by
IVECO MOTORS.
For the purpose of safety, further recommendations are given in the
chapter CONTROLS AND MAINTENANCE.

4
ENGINE TECHNICAL DATA N40 ENT M25
The technical code and serial number are indicated on a plate, which is
located on different parts of the engine, according to the model: flywheel
casing, tappet cover, coolant tank.
(*)Net power to the flywheel in compliance with ISO 3046-1. Test
conditions: T 25 °C; atmospheric pressure 100 kPa; relative
humidity 30%.
Code N40 ENT M25
Engine family F4
Cycle 4-stroke diesel
Number and arrangement
of cylinders 4, in line
Bore x stroke 102 x 120 mm
Total displacement 3.900 cm3
Air system Supercharged aftercooled
(TCA or TAA)
Injection type Direct/Common rail
electronically managed
Engine direction of rotation Anticlockwise
(seen from flywheel side)
Dry weight 490 kg
Electrical system 12 V (24 V on request)
Accumulator/s
- capacity 180 Ah or above
- discharge current 800 A or above
Available settings (*) N40 ENT M25
A1 184 kW (250 CV) @ 2800 rpm
B 147
kW (200 CV) @ 2800 rpm
C 125 kW (170 CV) @ 2800 rpm
WARNING
Any alteration of the above mentioned characteristics, in particular
modification of the data stored in the injection system electronic
units or the characteristics of the engine and its fittings, is strictly
prohibited, penalty invalidation of the guarantee and absence of
all liability on the part of IVECO MOTORS.

5
ENGLISH
Engine NEF N40 ENT M25
1. Exhaust gas and sea water discharge - 2. Turbocharger - 3. Engine
coolant-sea water heat exchanger - 4. Coolant outlet manifold from
engine - 5. Oil filter - 6. Lifting U-bolt - 7. Coolant filler cap -
8. Thermostat valve location - 9. Alternator - 10. Manifold
connecting the cooling circuit to the coolant tank - 11. Coolant
infeed to engine - 12. Water-heater system tap or plug -
13. Connection to battery positive terminal - 14. Coolant discharge
plug - 15. Electrical starter motor - 16. Removable anode.
Engine NEF N40 ENT M25
1. Coolant expansion tank - 2. Oil extraction pump - 3. Oil dipstick -
4. Oil filler cap - 5. Common rail divider - 6. Sea water pump inlet -
7. Lifting U-bolt - 8. Oil vapour filter - 9. Sea water circuit connector
pipe - 10. Air filter - 11. High-pressure pump for common rail system -
12. Fuel inlet from tank - 13. Fuel outlet to tank - 14. Fuel filter -
15. Removable anode - 16. Accelerator voltage divider lever - 17. Sea
water discharge plug - 18. Auxiliary member pulley casing.
    
  
 
 

04_363_N
      
  
04_364_N

6
ENGINE TECHNICAL DATA N60 ENT M37 / M40
The technical code and serial number are indicated on a plate, which is
located on different parts of the engine, according to the model: flywheel
casing, tappet cover, coolant tank.
(*)Net power to the flywheel in compliance with ISO 3046-1. Test
conditions: T 25 °C; atmospheric pressure 100 kPa; relative
humidity 30%.
Code N60 ENT M37 / M40
Engine family F4
Cycle 4-stroke diesel
Number and arrangement
of cylinders 6, in line
Bore x stroke 102 x 120 mm
Total displacement 5.900 cm3
Air system Supercharged aftercooled
(TCA or TAA)
Injection type Direct/Common rail
electronically managed
Engine direction of rotation Anticlockwise
(seen from flywheel side)
Dry weight 595 kg
Electrical system 12 V (24 V on request)
Accumulator/s
- capacity 180 Ah or above
- discharge current 800 A or above
Available settings (*) N60 ENT M37
A1 272 kW (370 CV) @ 2800 rpm
B
243 kW (330 CV) @ 2800 rpm
C 199 kW (270 CV) @ 2800 rpm
Available settings (*) N60 ENT M40
A1 294 kW (400 CV) @ 3000 rpm
A2 272 kW (370 CV) @ 3000 rpm
B
243 kW (330 CV) @ 3000 rpm
C 199 kW (270 CV) @ 3000 rpm
WARNING
Any alteration of the above mentioned characteristics, in particular
modification of the data stored in the injection system electronic
units or the characteristics of the engine and its fittings, is strictly
prohibited, penalty invalidation of the guarantee and absence of
all liability on the part of IVECO MOTORS.

7
ENGLISH
Engine NEF N60 ENT M37/M40
1. Exhaust gas and sea water discharge - 2. Turbocharger - 3. Engine
coolant-sea water heat exchanger - 4. Coolant outlet manifold from
engine - 5. Oil filter - 6. Lifting U-bolt - 7. Coolant filler cap -
8. Thermostat valve location - 9. Alternator - 10. Manifold
connecting the cooling circuit to the coolant tank - 11. Coolant
infeed to engine - 12. Water-heater system tap or plug - 13. Coolant
discharge plug - 14. Connection to battery positive terminal -
15. Electrical starter motor - 16. Removable anode.
Engine NEF N60 ENT M37/M40
1. Coolant expansion tank - 2. Oil extraction pump - 3. Oil filler cap -
4. Oil dipstick - 5. Common rail divider - 6. Sea water pump inlet -
7. Lifting U-bolt - 8. Oil vapour filter - 9. Sea water circuit connector
pipe - 10. Air filter - 11. High-pressure pump for common rail system -
12. Fuel inlet from tank - 13. Fuel outlet to tank - 14. Fuel filter -
15. Removable anode - 16. Accelerator voltage divider lever - 17. Sea
water discharge plug - 18. Auxiliary member pulley casing.
2 3 54 6 9
11 1015 14
7 8
1216 13
1
04_352_N
1 32 4 75 6 8 109
1114 12131518 1617
04_353_N

8
ENGINE TECHNICAL DATA N67 ENT M45
The technical code and serial number are indicated on a plate, which is
located on different parts of the engine, according to the model: flywheel
casing, tappet cover, coolant tank.
(*)Net power to the flywheel in compliance with ISO 3046-1. Test
conditions: T 25 °C; atmospheric pressure 100 kPa; relative
humidity 30%.
Code N67 ENT M45
Engine family F4
Cycle 4-stroke diesel
Number and arrangement
of cylinders 6, in line
Bore x stroke 102 x 120 mm
Total displacement 5.900 cm3
Air system Supercharged aftercooled
(TCA or TAA)
Injection type Direct/Common rail
electronically managed
Engine direction of rotation Anticlockwise
(seen from flywheel side)
Dry weight 595 kg
Electrical system 12 V (24 V on request)
Accumulator/s
- capacity 180 Ah or above
- discharge current 800 A or above
Available settings (*) N67 ENT M45
A1 331 kW (450 CV) @ 3000 rpm
A2 309 kW (420 CV) @ 3000 rpm
B
272 kW (370 CV) @ 3000 rpm
C 258 kW (350 CV) @ 3000 rpm
WARNING
Any alteration of the above mentioned characteristics, in particular
modification of the data stored in the injection system electronic
units or the characteristics of the engine and its fittings, is strictly
prohibited, penalty invalidation of the guarantee and absence of
all liability on the part of IVECO MOTORS.

9
ENGLISH
Engine NEF N67 ENT M45
1. Exhaust gas and sea water discharge - 2. Turbocharger - 3. Engine
coolant-sea water heat exchanger - 4. Coolant outlet manifold from
engine - 5. Oil filter - 6. Lifting U-bolt - 7. Coolant filler cap -
8. Thermostat valve location - 9. Alternator - 10. Manifold
connecting the cooling circuit to the coolant tank - 11. Coolant
infeed to engine - 12. Water-heater system tap or plug - 13. Coolant
discharge plug - 14. Connection to battery positive terminal -
15. Electrical starter motor - 16. Removable anode.
Engine NEF N67 ENT M45
1. Coolant expansion tank - 2. Oil extraction pump - 3. Oil filler cap -
4. Oil dipstick - 5. Common rail divider - 6. Sea water pump inlet -
7. Lifting U-bolt - 8. Oil vapour filter - 9. Sea water circuit connector
pipe - 10. Air filter - 11. High-pressure pump for common rail system -
12. Fuel inlet from tank - 13. Fuel outlet to tank - 14. Fuel filter -
15. Removable anode - 16. Accelerator voltage divider lever - 17. Sea
water discharge plug - 18. Auxiliary member pulley casing.
2 3 54 6 9
11 1015 14
7 8
1216 13
1
04_352_N
1 32 4 75 6 8 109
1114 12131518 1617
04_353_N

10
SIGNS
Certain warning signs are affixed to the engine, and their meanings are
indicated below.
NOTE: The signs with an exclamation mark on them underline a
potential danger.
Lifting point (engine only).
Fuel Cap
(on the fuel tank, if there is one).
Oil Cap.
Oil dipstick.
Danger of burning:
Expulsion of hot water under pressure.
Danger of burning:
Presence of high temperature parts.
Danger of fire:
Fuel present.
Danger of impact or catching
on moving parts:
Presence of fans, pulleys, belts or the like.

11
ENGLISH
USE
PRELIMINARY CHECKS
Before starting the engine each time:
Make sure that the sea-water inlet valve is open. Operation of the
sea water pump without water would cause irreparable damage to
the internal rotor within a very few seconds.
Check the level of technical fluids (fuel, engine oil and coolant).
STARTING AND STOPPING THE ENGINE
For vessels equipped with instrument panels that
are not manufactured by IVECO MOTORS
The start-up and shut-down operations described below apply to an on-
board control panel manufactured by IVECO MOTORS; if the vessel is
fitted with an instrument panel that has been customised by the
Boatbuilder or Fitter, these operations may vary according to the various
choices made during construction. In these cases, follow the start-up/
shut-down sequence and use the instrument panel description provided
by the Boatbuilder on specific documentation.
CAUTION!
Before starting the engine, make sure that no
combustible vapours or gasses are present in the
engineroom.

12
STARTING AND STOPPING THE ENGINE
FROM THE ANALOGUE CONTROL PANEL
Procedure for start-up from the main IVECO
MOTORS control panel (supplied on demand)
Make sure that the electrical switch indicating ENGINE ROOM -
BRIDGE on the Relay Box unit (normally located in the engine room) is
in the BRIDGE position, then proceed as follows:
1. Lift the protective cover over the key switch (8), insert the key and
turn it to the right to position 8B.
2. Make sure that the analogue instruments are showing values that
conform with the relevant physical parameters (temperature,
battery voltage and oil pressure).
3. Wait for the beeper to stop sounding and for the alarm indicator
lights on the indicator module (5) to switch off, with the exception
of the “alternator recharge” and “low oil pressure” indicators. At
the same time, check that the indicator test has been performed
successfully (information on how to interpret this test and
indications on the module are given in the relevant paragraph).
4. Turn the key to position 8C; once the engine has started, release
the key and do not accelerate.
5. Make sure that the analogue instruments are showing values that
conform with the relevant physical parameters (temperature,
battery voltage and oil pressure).
6. If the engine does not start, after releasing the key it will only be
possible to turn it back to the start position after first returning the
switch to the rest position 8A.
1. Coolant temperature indicator - 2. Rev counter and hour counter -
3. Voltmeter - 4. Beeper - 5. Indicator and alarm module - 6. Engine oil
pressure indicator - 7. Control panel instrument light switch - 8. Key
switch to start/stop the engine - 9. Button to stop the engine -
10. Button to disable the beeper.
1
2
3
4
5
6
7
89
10
04_354_N
8A
8B
8C
04_356_N
Detail of the key switch

13
ENGLISH
Procedure for start-up from IVECO MOTORS
secondary or fly-bridge control panel (supplied on
demand)
1. Enable the secondary control panel, by turning the key
switch on the main panel to position 8B (see warnings and
procedure given in previous paragraph).
2. Wait for the beeper to stop sounding and for the alarm indicators
on the indicator module (3) to switch off, with the exception of the
“alternator recharge” and “low oil pressure” indicators. At the same
time, check that the indicator test has been performed successfully
(information on how to interpret this test and indications on the
module are given in the relevant paragraph).
3. Press the green button (5) and release it when the engine has
started.
4. Check that the rev indicator shows a plausible value. 1. Rev counter and hour counter - 2. Beeper - 3. Indicator and alarm
module - 4. Button to disable the beeper - 5. Engine start button -
6. Engine stop button.
5
1 3
2
6
4
04_355_N

14
Stopping the engine
Before stopping the engine it is recommended you run it for a few
minutes at minimum speed with no load; this will allow the temperature
to drop evenly and will avoid harmful thermal shocks.
A. The engine is normally stopped from the main IVECO MOTORS
control panel by turning the key switch to the rest position 8A or
by turning a similar command on the customised control panel.
B. The IVECO MOTORS secondary control panel is stopped by
pressing the red button (6) on the control panel.
The main IVECO MOTORS control panel for engines equipped with an
“excited” device (on request or as prescribed by the Certification
Body), is stopped by pressing the red button (9).
To re-start the engine from the main control panel:
1. Return the key switch to the rest position 8A to reset all the on-
board control panel functions.
2. Proceed as indicated.
To re-start the engine from the secondary control panel:
1. Make sure that the panel has been enabled (key switch on the main
control panel turned to position 8B).
2. Press the green button (5) and release it when the engine has
started, making sure that the rev indicator is showing a plausible
reading.

15
ENGLISH
RECOGNISING ALARMS
IVECO MOTORS on-board control panels with analogue instruments
are fitted with an electronic module that includes the indicator lights and
the interface, timer and alarm storage circuits.
The figure illustrates the dial and the key indicates the meaning of the
alarm signals sent by all the indicator lights; some types of engine and
relevant equipment only make some of the above mentioned functions
available.
If the Boatyard uses different technical options there may also be
changes to the above.
Operation
When the key switch is turned to position 8B the signals and alarms
module will perform an efficiency test on all the indicator lights, lasting 5
seconds, with the exception of the “Pre-lubrication”, “Pre-post heating”,
“EDG system malfunction” indicators, and simultaneously the beeper
sounds.
It is possible to stop the beeper before the end of the test, by pressing
the relevant button.
During start-up and for the following 15 seconds, all alarm functions are
disabled; after this period, each alarm detected by the sensors provided
on the engine will result in the relevant indicator flashing and a
simultaneous warning sound from the beeper. If the beeper is disabled
by pressing the relevant button, the indicator light will turn on without
flashing and the alarm will be stored until the engine is next stopped.
1. Maximum allowed rotation speed exceeded (on request) - 2. Water
in the fuel pre-filter - *3. Engine coolant level low - 4. Alternator
malfunction - *5. Oil filter blocked - * 6. Oil vapour filter blocked -
*7. Pre-lubrication in progress - 8. Air filter blocked - *9. Fuel filter
blocked - 10. Coolant temperature high - 11. Oil pressure low -
*12. Pre-post heating - 13. Malfunction in EDC electronic injection
system.
*Alarm functions not available with standard setup.
12 12
11101334
5 6 8 9
7
04_234_N

16
STARTING AND STOPPING THE ENGINE
FROM THE DIGITAL CONTROL PANEL
Procedure for start-up from the main IVECO
MOTORS control panel (supplied on demand)
Make sure that the electrical switch indicating ENGINE ROOM -
BRIDGE on the Relay Box unit (normally located in the engine room) is
in the BRIDGE position, then proceed as follows:
1. Lift the protective cover over the key switch (8), insert the key and
turn it to the right to position 8B.
2. Make sure that the instruments with analogue displays are showing
values that conform with the relevant physical parameters.
3. Wait for the beeper to stop sounding and for the alarm indicator
lights to switch off, with the exception of the “Alternator
malfunction” and “Low oil pressure” indicators. At the same time,
check that the indicator test has been performed successfully (see
the section on RECOGNIZING ALARMS).
4. Turn the key to position 8C; once the engine has started, release
the key and do not accelerate.
5. Make sure that the instruments with analogue displays are showing
values that conform with the relevant physical parameters
(temperature, battery voltage and oil pressure).
6. If the engine does not start, after releasing the key it will only be
possible to turn it back to the start position after first returning the
switch to the rest position 8A.
1. Engine coolant temperature indicator - 2. Lubrication circuit pressure
indicator - 3. Service and alarm signals - 4. Rev counter - 5. Supercharged
air pressure indicator - 6. Voltmeter - 7. Alpha-numeric display - 8. Key
switch to start/stop the engine - 9. Accessory function programming
button - 10. Button used to scroll through and select additional
information - 11. Button to reset the “planned maintenance” indicator -
12. Button to disable the beeper- 13. Beeper.
1
2
4
6
5
8
91112
13
3 3
10
7
04_357_N
8A
8B
8C
04_356_N
Detail of the key switch

17
ENGLISH
Procedure for start-up from IVECO MOTORS
secondary or fly-bridge control panel (supplied on
demand)
1. Enable the secondary control panel, by turning the key switch
on the main panel to position 8B (requirements and procedure
given in previous paragraph).
2. Wait for the beeper to stop sounding and for the alarm indicator
lights to switch off, with the exception of the “Alarm malfunction”
and “Low oil pressure” indicators. At the same time, check that the
indicator test has been performed successfully (see the section on
RECOGNIZING ALARMS).
3. Press the green START button (11) and release it when the engine
has started, making sure that the instruments with analogue displays
are showing values that conform with the new physical parameters.
1. Engine coolant temperature indicator - 2. Lubrication circuit pressure
indicator - 3. Service and alarm signals - 4. Rev counter - 5. Supercharged
air pressure indicator - 6. Voltmeter - 7. Alpha-numeric display -
8. Button to stop the engine - 9. Button used to scroll through and select
additional information - 10. Button to disable the beeper- 11. Engine
start button.
1
2
6
5
3 3
4
7
1011 9 8
04_358_N

18
Stopping the engine
Before stopping the engine it is recommended you run it for a few
minutes at minimum speed with no load; this will allow the temperature
to drop evenly and will avoid harmful thermal shocks.
A. From the main IVECO MOTORS control panel: turn the
key switch to the rest position 8A.
B. From the secondary IVECO MOTORS control panel:
press the red STOP button (8).
To re-start the engine from the main control panel:
1. Return the key switch to the rest position 8A to reset all the on-
board control panel functions.
2. Proceed as indicated in the relevant paragraph.
To re-start the engine from the secondary control panel:
1. Make sure that the panel has been enabled (key switch on the main
control panel turned to position 8B).
2. START button (11) and release it when the engine has started,
making sure that the instruments with analogue displays are
showing plausible values.
RECOGNISING ALARMS
The following shows the meaning of the symbols associated with each
of the indicator lights on the main and secondary control panels some
types of engine and relevant equipment only make some of the above
mentioned functions available. If the Boatyard uses different technical
options there may also be changes to the above.
* Alarm functions not available with standard setup
04_359_N
* Oil vapour filter
blocked
Alternator
malfunction
Oil pressure low
Coolant
temperature high
Over-revs
* Coolant level low
EDC engine control
system malfunction
* Air filter
blocked
Maintenance
interval expired
* Oil filter
blocked
* Pre-lubrication
in progress
* Pre-post
heating
* Fuel filter
blocked
Water in the
fuel filter

19
ENGLISH
Operation
When the key switch is turned to position 8B an efficiency test will be
performed on all the indicator lights, lasting 5 seconds, with the
exception of the “Pre-lubrication”, “Pre-post heating”, “EDC electronic
injection system malfunction” indicators, and simultaneously the beeper
sounds; It is possible to stop the beeper before the end of the test, by
pressing the relevant button.
During start-up and for the following 15 seconds, all alarm functions are
disabled; after this period, each alarm detected by the sensors provided
on the engine will result in the relevant indicator flashing and a
simultaneous warning sound from the beeper. If the beeper is disabled
by pressing the relevant button, the indicator light will turn on without
flashing and the alarm will be stored until the engine is stopped.
Alpha-numeric display
This provides the following information:
• engine running speed
• total running hours (see note A)
• exhaust gas temperature (on request)
• instant fuel consumption (see note B)
The information required is selected by pressing the “Scroll select”
button on both the control panels, main and secondary.
Detail of the main control panel
7. Alpha-numeric display - 9. Accessory function programming button -
10. Button used to scroll through and select additional information -
11. Button to reset the “planned maintenance” indicator - 12. Button
to disable the beeper.
(A)The control panel's internal electronics are programmed to count
the working hours and issue warnings when the time limit for
ordinary maintenance operations expires; this function requires
that the counter be reset after each maintenance operation, which
is carried out from the main control panel as follows:
- Pressing and holding the “Prog” (9) and “Scroll select” buttons (10),
turn the key switch from position 8A to position 8B and wait for
the display to show the pre-set value (e.g: 600 hours). Release the
buttons and press the “Prog” (9) button again once only to start
the new count.
912 11 10
04_360_N
7
