iVina FS-0913B User manual

iVina
M40
Portable Photo Scanner
User Manual
Regulatory model: FS-0913B

ii
Trademarks
Microsoft is a U.S. registered trademark of Microsoft Corporation.
Windows and MS-DOS are trademarks of Microsoft Corporation.
IBM, IBM PC are registered trademarks of International Business Machines Corp.
ENERGY STAR®is a U.S. registered mark.
Other brands and product names herein are trademarks or registered trademarks of their
respective holders.
Copyright
All rights reserved. No part of this publication may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language or computer language, in any
form or by any means, electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise, without the prior written permission of iVina Inc.
Material scanned by this product may be protected by governmental laws and other
regulations, such as copyright laws, the customer is solely responsible for complying with
all such laws and regulations.
Warranty
The information contained in this document is subject to change without notice.
iVina makes no warranty of any kind with regard to this material, including, but not
limited to, the implied warranties of fitness for a particular purpose.
iVina shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material.

iii
FCC Radio Frequency Interference Statement
This product has been tested and found to comply with the limits for a class B digital
device, pursuant to Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation. The FCC Class B limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult your point of purchase or service representative for additional suggestions.
CE Warning
This product satisfies the Class B limits of EN55022, EN55024 and safety requirements of
EN 60950.
Disposal of Waste Equipment by Users in Private Union
This symbol on the product or on its packaging indicates that the product can not be
disposed of with your other household waste. Instead it should be sent to appropriate
facilities for recovery and recycling in an effort to protect human health and the
environment. Fore more information about where you can drop off your waste equipment
for recycling, please contact your local city office, your household waste disposal service or
the shop where you purchased the product.
System Requirements

Microsoft Windows XP/Vista/7
1.2 GHz CPU or greater
512 MB RAM for Windows XP (2+ GB RAM recommended)
1 GB RAM for Windows Vista and 7 (2+ GB RAM recommended)
500 MB available on the Hard Drive for complete software installation
USB 2.0 Port
CD-Rom drive
Display supporting full color (32 bit) at 800 x 600

iv
Table of Contents
1. Introduction .......................................................................................................1-1
2. Scanner Overview ...........................................................................................2-1
2.1 Scanner View..................................................................................... 2-1
3. Installation & Operation ................................................................................3-1
3.1Initial setup ....................................................................................... 3-2
3.2 Scan an original ................................................................................. 3-3
3.3 Using Plastic sheaths .......................................................................... 3-4
3.4 Scan dark or night pictures.................................................................. 3-5
3.5 Power off the scanner ......................................................................... 3-6
4. Connecting to a Computer.............................................................................4-1
4.1 How to connect to a computer ............................................................. 4-1
4.2 Disconnecting the scanner from a computer .......................................... 4-3
5. Scanning To PC Manager ...............................................................................5-1
5.1 Starting the Scan To PC Manager ......................................................... 5-1
5.2 Uninstalling the Scan To PC Manager .................................................... 5-2
6. Maintenance.......................................................................................................6-1
6.1 Cleaning the roller .............................................................................. 6-1
6.2 Calibrating the scanner ....................................................................... 6-2
6.3 Cleaning the image sensor .................................................................. 6-3
7. Troubleshooting................................................................................................7-1
7.1Frequently asked questions ................................................................. 7-1
7.2 The indicator light pattern ................................................................... 7-2
8. Specifications..................................................................................................... 8-1

1-1
1. Introduction
Congratulations on your purchase of the BulletScan M40 scanner. Now you
can scan and store your printed photos directly to your memory card or USB
flash drive without connecting to any computer.
Simply insert a memory card or USB flash drive into the scanner, and power
it on. When the scanner is ready, feed your printed photo into the scanner
and your images will be stored in the memory card or USB flash drive. If you
want to store your photos directly into your computer, just plug in a USB
cable and use the supplied Scan To PC utility.
Before you install and operate the product, please take a few minutes to read
through this manual. It provides proper instructions for you to install,
operate and maintain the product.
The following figure indicates the package contents. Please check all the
items against your checklist. If you do not receive all the items, please
contact your authorized local dealer immediately.

1-2
1. Scanner
2. Sensor Cleaning Swab
3. Roller Cleaning Tool
4. Calibration Chart
5. Power Adapter
6. USB Cable
7. Black Plastic Sheath/White Plastic Sheath
Note:
1. Only use the BulletScan Type 5 AC adapter (DSA-12PFA-05 FUS
050200 DEE VAN) included in the box. Using other AC adapters may
damage the scanner and void the warranty.
2. Please unpack the packing carefully, and check the contents against the
checklist. If any items are missing or damaged, please contact your
dealer immediately.
1
2
3
4
5
6
7

2-1
2. Scanner Overview
2.1 Scanner View
No.
Name
Function/ Description
1
Indicator light
Indicates the operating status of the
scanner.
2
Feeding Slot
Insert an original to begin scanning.
1
1
2

2-2
No.
Name
Function / Description
3
Power connector
To power on the scanner, connect the
supplied power adapter to the scanner.
To power off the scanner, disconnect the
supplied power adapter from the
scanner.
4
Mini USB
connector
For connecting to a computer via a USB
cable.
5
Flash drive slot
For connecting a USB flash drive.
6
Memory card slot
For SD cards and Micro SD cards using
the supplied adapter.
7
Function Button
Press to start cleaning the scanner‟s
roller (Refer to the Cleaning the roller
section on page 6-1).
Press to eject paper during paper jam
condition. (Refer to the 2-blink
description of The indicator light
pattern section on page 7-2).
Press until the indicator light starts
blinking to calibrate the scanner. (Refer
to the Calibrating the scanner section
on page 6-2).
3
4
5
6
7

3-1
3. Installation & Operation
Precautions
Keep the product out of direct sunlight. Direct exposure to the sun or
excessive heat may cause damage to the unit.
Do not install the product in a humid or dusty place.
Be sure to use the proper AC power source.
Place the product securely on an even, flat surface. Tilted or uneven
surfaces may cause mechanical or paper-feeding problems.
Retain the product box and packing materials for shipping purposes.

3-2
3.1 Initial setup
1. Connect the plug on the power adapter cable to the power connector on
the scanner.
2. Plug the power adapter into a power outlet. Wait until the indicator light
on the scanner stops blinking and stays on steady, indicating the scanner
is ready.
3. Insert a memory card into the memory card slot or a USB flash drive into
the USB Port. (If you connect a memory card and a USB flash drive to the
product at the same time, the scanned image will be stored in the
memory card.)
Connect a USB flash drive into the USB Port.
Insert a memory card into the memory card slot.

3-3
3.2 Scan an original
1. Insert your photo into the plastic sheath supplied with the scanner.
(The detailed usage of the plastic sheath is described in the next page.)
2. With the side to be scanned facing upward and in correct orientation,
place the left edge of the original against the left edge of the feeding slot.
3. Simply let go the original when it begins to feed into the slot.
4. When the scan is completed, the scanner will automatically create a folder
titled “Photo1” on your memory card or flash card, which will hold the
first 9999 scans. Then “Photo2” folder will be created for the next 9999
scans, and so on.
(Each scanned image is given a file name with the prefix img followed by
a 4- digit sequential number in the order the images are stored. For
example, img0001.jpg, img0002.jpg, etc.)
Note:
Do not remove the memory card or disconnect the power supply while the
scanner is processing an image and the lights are blinking.
This scanner only supports output images in JPEG (.jpg) format.
If the memory card is near full (lower than 1MB), the indicator light blinks.
Use another card or delete some files on it if necessary.
Insert only one item at a time, and insert the next original only when the
previous one is done and the blinking has stopped.
Remove any items attached to the photo, such as staples, paper clips, and
paper sticky notes before feeding it into the scanner due to possible
damage to the scanner.

3-4
3.3 Using Plastic sheaths
Always use the clear plastic sheath (included) when scanning photos to ensure
the best scanning results. The sheath helps eliminate the possibility of de-
focusing due to the uneven surface of curled photos.
1. Insert the photo into the plastic sheath as shown below.
2. Insert the plastic sheath, flat and level, into the scanner‟s feeding slot,
folded side first, image facing up.
Note:
Keeping the original flat and level when feeding prevents possible
jamming.
Keep originals free from finger prints, oil, dirt, and dust for optimum
scanned image quality.
Remove photos from the plastic sheath after scanning to prevent the
sheath from sticking to the photos over time.
If the plastic sheaths are not in use, store them in a safe place and keep
them protected from accumulating dust.
Curled photo

3-5
3.4 Scanning dark or night pictures
When you need to scan very dark or night pictures, be sure to use the white
plastic sheath to avoid an incomplete scanned image. However, using the white
plastic sheath will disable the auto crop (automatically cropping your image
according to your photo size) and deskew (auto straighten) functions. You may
need to use a 3rd party graphic editing program to perform the cropping and
straightening.
.
The scanned image using white plastic sheath

3-6
3.5 Power off the scanner
After all originals are scanned, disconnect the supplied power adapter from the
scanner. Now the scanner has been safely powered off.
Important:
(1) Insert only one photo at a time, and insert the next one only when the
previous one is done. Otherwise, the scanner may malfunction.
(2) The paper detector is quite sensitive. Please do not push your photo or
card into the feeding slot or the top of your image will be cut. Simply
let go the photo (card) when it begins to feed into the slot.
(3) The acceptable original size is 2”x 2”~ 4”x 8”.
(4) Do not use the following types of originals for scanning; otherwise the
scanner may malfunction or cause the original to jam in the slot.
Originals thicker than 0.5mm
Originals with either side shorter than 2” (55mm)
Originals with lots of black or dark colors*
Originals with dark colors surrounding the edges*
Newspaper clippings*
Soft and thin materials (thin paper, cloth, etc.)*
Originals that exceed the acceptable size
Torn or folded originals*
Post-it®type “Sticky Notes”*
Carbon copies*
*Without the clear plastic sheath

3-7
(5) The scanner has a built-in cropping function that is capable to detect
and crop the edges of an original. The max cropping size is 1.5mm per
edge, as illustrated below:
(6) If the photo is very crooked, you will see black edges like in the picture
below:
Max. 1.5mm
Max. 1.5mm

4-1
4. Connecting to a Computer
By connecting the scanner to a computer, you can access the pictures and
other files on the memory card directly allowing you to freely copy, paste or
delete files to and from the memory card using the computer.
4.1 How to connect to a computer
1. Connect the plug on the power adapter cable to the power connector on
the scanner.
2. Plug the power adapter into a power outlet. Wait until the indicator light
on the scanner stops blinking and stays on steady, indicating the scanner
is ready.
3. Insert a memory card into the memory card slot or a USB flash drive into
the USB port.
Insert a USB flash drive into the USB port.
Insert a memory card into the memory card slot.

4-2
4. Connect the mini end of the USB cable (included with scanner) to the Mini
USB connector on the scanner.
5. Power on your PC, and then connect the large end of the USB cable to a
USB port on your PC.
6. When the scanner connects successfully with a computer, a Removable
Disk (F:) (F: represents the removable drive letter) will be shown in
Windows Explorer or Finder. If a memory card or USB flash drive is
inserted to the scanner, the Removable Disk will be replaced with the
name of the memory card or USB flash drive.
7. After your scan, a folder titled PHOTO1 is added to the memory card or
USB flash drive and the scanned image will be saved in JPEG file format.
Each scanned image is given a file name with the prefix scan followed by
a 4- digit sequential number in the order the images are stored. For
example, img0001.jpg, img0002.jpg. If the file name reaches
img9999.jpg in the Photo1 folder, a new folder titled Photo2 will
automatically be created to store subsequent new files, and so on.
8. You can now view or edit the files on the memory card or USB flash drive
using your own graphic editing software.

4-3
4.2 Disconnecting the scanner from a computer
1. On the Windows System Tray, click the hardware removal icon.
2. Click the „Safely remove USB mass Storage device‟ message with the
corresponding Drive.
3. When the „Safe to Remove Hardware‟ message appears, you can safely
remove the scanner‟s USB cable.
