IVY DESIGN Picture/Mirror Table Classic User manual

MANUAL
Picture/Mirror Table
Classic

Warning
before you start unpacking and mounting your table make sure that no children are
around. Small parts as screws can be swallowed.
The table has to be fixed properly to the wall to avoid that anybody is hit by the parts
to mount.
Children are not allowed to fold up or down the table themselves!
When you fold up or down your table babies/children should be out of reach!
Maintenance
Check frequently if the screws and screw anchors are still secure and properly fixed
to the wall and the table. If screws are not properly fixed anymore don´t fold the table
up to the wall and let an expert check and renew your wall fixation.
Always turn the stainless steel block of the upper wall mount up and the same way
down again to fix the table at the wall. You risk that the fixation screw comes out of
the wooden block if you turn around 360 degrees several times.

Look for the right
place to mount your
table:
It is crucial to choose the right spot for mounting your table. The wall where you would
like to fix your table must be in a good condition and strong enough to hold your
tables weight. If you are not sure please ask an expert.
Choose the right screws and screw anchors depending of the condition of your wall.
For each type of wall (solid walls, drywalls,...) the right screw anchor must be used.
If you are not sure with any details of mounting please ask an expert!

Mounting
Montage

Drill holes at the green marked spots: 4 holes for the lower wall mount,
2 holes for the upper wall mount. Use the wall mounts to mark the drill
holes. Bohren Sie Löcher an den grün markierten Stellen: 4 Löcher für
die untere und 2 Löcher für die obere Wandbefestigung. 1
199 cm
78,4 inch
center line
199 cm
78,4 inch
75 cm
29,5 inch
2 cm
0,79 inch
3 cm 1,18 inch
5 cm 1,97 inch

2
Screw the upper and lower wall mounts with suitable screws and
anchor bolts to the wall.
Befestigen Sie die obere und untere Wandhalterungen mit
passenden Schrauben und Dübeln.
center line

3
Fix the legs, lift the table up, slide the grooves on the
table surface into the metal support on the wall. Turn the bolts with an
Allen key on both sides in the table.
Schieben Sie die Schlitze an der Tischoberfläche in die Metallbefesti-
gung. Befestigen Sie den Tisch mit beiden Bolzen. Ein Imbusschlüssels
wird benötigt.

4
Lift the table up and assure that the upper metal wall mount is in
a horizontal position.
Klappen Sie den Tisch nach oben nachdem die obere
Wandbefestigung in horizontale Position gebracht ist.

Manual
Handhabung

Lift the table until it
is parallel to the wall.
Heben Sie ihn bis die Tischfläche parallel zur Wand steht. 5
Now the metal support must stay in
horizontal position!

6
Turn the metal support in the slit on the table edge.
Drehen Sie die Metallhalterung in die Führung an der Tischkante.

7
Turn the metal support in a vertical position.
Richten Sie die Metallhalterung vertikal aus.
Always turn the stainless
steel block of the upper
wall mount up and the
same way down again
to fix the table at the wall.
You risk that the fixation
screw comes out of the
wooden block if you turn
around 360 degrees
several times.

8
Turn the wooden rectangle 90 degrees.
Drehen Sie das rechteckige Holzplättchen um 90 Grad.

9
Let the leg down to close the picture frame.
Führen Sie das Tischbein nach unten und schließen Sie den
Bilderrahmen.

Close the frame.
Schließen Sie den Rahmen. 10

For Model Classic with plexiglass:For Model Classic with plexiglass:
Exchange the PosterExchange the Poster
Für Modell Classic mit Plexiglas:Für Modell Classic mit Plexiglas:
Austausch des PostersAustausch des Posters

11
Move the short wooden bar on the left side downwords.
Ziehen Sie den kurzen Rahmenteil auf der linken Seite
nach unten.

12
Push the left bar of the frame towards the left side in order to take
the
plexiglass off and exchange the poster/photo.
Drücken Sie den linken unteren Rahmenteil nach links um danach
das Plexiglas herausziehen und das Poster/Foto austauschen
zu können.

13
Drag the plexiglass out and insert your own individual poster.
Ziehen Sie die Plexiglasplatte heraus und fügen Sie ihr individuelles Poster
ein.

14
Put the short wooden bar back to the original position.
Bringen Sie den Balken wieder in die ursprüngliche Position.
