IVY DESIGN STANDARD User manual

MODEL
STANDARD

Warning
before you start unpacking and mounting your table make sure that no children are
around. Small parts as screws can be swallowed.
The table has to be fixed properly to the wall to avoid that anybody is hit by the parts
to mount.
Children are not allowed to fold up or down the table themselves!
When you fold up or down your table babies/children should be out of reach!
Maintenance
Check frequently if the screws and screw anchors are still secure and properly fixed
to the wall and the table. If screws are not properly fixed anymore don´t fold the table
up to the wall and let an expert check and renew your wall fixation.
Always turn the stainless steel block of the upper wall mount up and the same way
down again to fix the table at the wall. You risk that the fixation screw comes out of
the wooden block if you turn around 360 degrees several times.

Look for the right
place to mount your
table:
It is crucial to choose the right spot for mounting your table. The wall where you would
like to fix your table must be in a good condition and strong enough to hold your
tables weight. If you are not sure please ask an expert.
Choose the right screws and screw anchors depending of the condition of your wall.
For each type of wall (solid walls, drywalls,...) the right screw anchor must be used.
If you are not sure with any details of mounting please ask an expert!

Mounting
Montage

1
199 cmcenter
line
199 cm
75 cm
(same height as
table)
2 cm
3 cm
5 cm
Drill holes for the upper and lower mounts. Attach the lower wall
mount in a horizontal position to the wall and mark the drill holes.
Bohren Sie die Löcher für die obere und untere Wandhalterung. Hal-
ten Sie die untere Wandhalterung waagrecht an die Wand um die
Bohrlöcher zu markieren.

2
Screw the upper and lower wall mount with suitable screws
and anchor bolts to the wall.
Befestigen Sie mit passenden Schrauben und Dübeln
die obere und untere Wandhalterung.
center line

3
Merge the recess of the table top and the lower wall mount.
Screw in one bolt on each side. Allan key is required.
Fügen Sie Schlitze der Tischplatte mit den Laschen der
Wandhalterung zusammen. Fixieren Sie diese dann beidseitig
mit den mitgelieferten Bolzen. Ein Imbusschlüssel wird benötigt.

4
To lock the table legs insert the bolts on either side of the table.
The bolts will serve you as clothes hooks.
Um die Tischbeine zu arretieren, müssen die beiden Stahlstifte,
die als Kleiderhaken dienen, positioniert werden

5
Now your IvyDesign Model Standard is locked and ready to use.
IvyDesign Modell Standard ist gesichert und kann jetzt benützt werden.

Manual
Handhabung

6
Before folding up the table remove the bolts.
Bevor der Tisch nach oben geklappt wird, müssen die Stahlstifte
entfernt werden.

7
Lift up the table.
Heben Sie den Tisch an.

Lift the table until it‘s
parallel to the wall.
Heben Sie den Tisch bis die
Tischfläche parallel zur Wand positioniert ist. 8

9
Rotate the metal support into the hollow at the table edge.
Drehen Sie die Metallhalterung in die Führung an der Tischkante.

10
Turn the metal support in a vertical position.
Richten Sie die Metallhalterung vertikal aus.
Always turn the stainless
steel block of the upper
wall mount up and the
same way down again
to fix the table at the wall.
You risk that the fixation
screw comes out of the
wooden block if you turn
around 360 degrees
several times.

Ready to go!
Fertig! 11

Enjoy yourEnjoy your
IvyDesign folding tab-IvyDesign folding tab-
le Model Standardle Model Standard
Viel Freude mitViel Freude mit
deinem IvyDesigndeinem IvyDesign
Klapptisch ModelKlapptisch Model
StandardStandard
