iWantit iHBTDAB14 User manual

wireless micro DAB Hi-Fi
iHBTDAB14
instruction manual

contents
safety warnings................................................................................................................................. 5
unpacking .......................................................................................................................................... 7
product overview ............................................................................................................................. 8
front view...................................................................................................................................................................... 8
rear view........................................................................................................................................................................ 9
top view......................................................................................................................................................................... 9
remote control ................................................................................................................................ 10
remove the plastic strip from the remote control.................................................................... 11
battery replacement for the remote control............................................................................. 11
remote control operation range.................................................................................................. 12
connections ..................................................................................................................................... 12
speaker connections...............................................................................................................................................12
using the AUX connection....................................................................................................................................13
connecting to the mains supply.........................................................................................................................13
charging from the USB CHARGING port ..........................................................................................................14
playing MP3 from a USB device..........................................................................................................................14
general operation........................................................................................................................... 15
powering ON/OFF....................................................................................................................................................15
selecting modes .......................................................................................................................................................15
adjusting the volume..............................................................................................................................................15
auto setting the clock.............................................................................................................................................15
manually setting the time.....................................................................................................................................15
setting the daily timer ............................................................................................................................................16
to cancel the daily timer........................................................................................................................................16
setting the sleep timer ...........................................................................................................................................16
EQ control ...................................................................................................................................................................17
system reset ...............................................................................................................................................................17
DAB operation................................................................................................................................. 18
full scan........................................................................................................................................................................18
manual tuning...........................................................................................................................................................18
secondary services...................................................................................................................................................18
preset stations...........................................................................................................................................................19
recalling a stored station.......................................................................................................................................19
DAB display modes..................................................................................................................................................20

FM operation ................................................................................................................................... 21
switching from DAB to FM mode .......................................................................................................................21
auto scan.....................................................................................................................................................................21
manual scan ...............................................................................................................................................................21
audio mode................................................................................................................................................................21
preset stations...........................................................................................................................................................21
recalling a stored station.......................................................................................................................................22
FM display modes ....................................................................................................................................................22
compatible disc types.................................................................................................................... 23
CD operation ................................................................................................................................... 23
playback ......................................................................................................................................................................23
to pause playback....................................................................................................................................................23
to stop playback .......................................................................................................................................................23
skipping to another track......................................................................................................................................23
repeat playback ........................................................................................................................................................24
random playback .....................................................................................................................................................24
programme setting .................................................................................................................................................24
programme cancel...................................................................................................................................................24
intro playback............................................................................................................................................................24
bluetooth® operation .................................................................................................................... 25
USB operation ................................................................................................................................. 25
AUX operation................................................................................................................................. 26
maintenance.................................................................................................................................... 27
cleaning the unit ......................................................................................................................................................27
handling discs ...........................................................................................................................................................27
cleaning discs ............................................................................................................................................................27
storing discs ...............................................................................................................................................................27
hints and tips................................................................................................................................... 28
specications................................................................................................................................... 29

• Read all the instructions carefully before
using the unit and keep them for future
reference.
• Retain the manual. If you pass the unit onto a
third party make sure to include this manual.
• Check that the voltage marked on the rating
label matches your mains voltage.
Damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you
are in any doubt about it working normally,
or if it is damaged in any way - switch o,
unplug from the mains socket and consult
your dealer.
Location of Unit
• The unit must be placed on a at stable
surface and should not be subjected to
vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the
unit and should be easily accessible.
• This unit is designed for indoor use only.
Temperature
• Avoid extreme degrees of temperature,
either hot or cold. Place the unit well away
from heat sources such as radiators or gas/
electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
Naked Flames
• Never place any type of candle or naked
ame on the top of or near the unit.
Moisture
• To reduce the risk of re, electric shock or
product damage, do not expose this unit
to rain, moisture, dripping or splashing. No
objects lled with liquids, such as vases,
should be placed on the unit.
• If you spill any liquid into the unit, it can
cause serious damage. Switch it o at the
mains immediately. Withdraw the mains
plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or re
hazard due to overheating, ensure that
curtains and other materials do not obstruct
the ventilation vents.
• Do not install or place this unit in a bookcase,
built-in cabinet or in another conned space.
Ensure the unit is well ventilated.
Safety
• Always disconnect the unit from the mains
supply before connecting/ disconnecting
other devices or moving the unit.
• Unplug the unit from the mains socket
before a lightning storm.
• In the interests of safety and to avoid
unnecessary energy consumption, never
leave the unit switched on while unattended
for long periods of time, e.g. overnight, while
on holiday or while out of the house. Switch
it o and disconnect the mains plug from
the mains socket.
Mains Cable
• Make sure the unit or the unit stand is not
resting on top of the mains cable, as the
weight of the unit may damage the cable
and create a safety hazard.
Interference
• Do not place the unit on or near appliances
which may cause electromagnetic
interference. If you do, it may adversely
aect the operating performance of the unit,
and cause distorted sound.
Batteries
• Batteries used in the remote control for this
unit are easily swallowed by young children
and this is dangerous.
• Keep loose batteries away from young
children and make sure that the battery
holder tray is secure in the remote control.
Seek medical advice if you believe a cell has
been swallowed.
• Please dispose of batteries correctly by
following the guidance in this manual.
• Do not expose the battery to direct sunlight
or sources of excessive heat.
safety warnings
5

Supervision
• Children should be supervised to ensure
that they do not play with the unit and the
remote control.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a
fatal electric shock.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the unit’s enclosure that may be of
sucient magnitude to constitute a risk of
electric shock.
The exclamation point within an
equilateral triangle is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the manual accompanying
the unit.
Service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose dangerous voltages.
Maintenance
• Ensure the unit is fully unplugged from the
power supply before cleaning.
• Do not use any type of abrasive pad or
abrasive cleaning solutions as these may
damage the unit’s surface.
• Do not use liquids to clean the unit.
6

unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit Speakers x 2 Remote Control
Quick Start Guide
Quick Start GuideInstruction Manual
Instruction
Manual
Thank you for purchasing your new iWantit wireless micro DAB Hi-Fi.
We recommend that you spend some time reading this instruction manual in order that you fully
understand all the operational features it oers. You will also nd some hints and tips to help you
resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future
reference.
AUDIO IN USB
5V 1A
MODE EQ
SCAN STOP
SKIP/
TUNE SEARCH
VOLUME
STANDBY
INFO MODE
STANDBY
MEMORY
CLOCK SHUFFLE
SELECT/
MONO/ST.
PRESET/FOLDER
TIMER
EQ INTRO SLEEP
––
–
MUTE VOLUME
REPEAT
SCAN
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
7

AUDIO IN USB
5V 1A
MODE EQ
SCAN STOP
SKIP/
TUNE SEARCH
VOLUME
STANDBY
3 4 5 6 7 8 9 1110
2
112
product overview
front view
1. STANDBY Button
Switch the unit between the ON and
STANDBY modes.
2. AUDIO IN Socket
Connects to an external audio device.
3. MODE Button
Switch between DAB, FM, CD, USB,
AUX and Bluetooth modes.
4. EQ Button
5. USB 5V 1A Charging Port
• For charging external devices.
• For MP3 playback.
6. SCAN/ Button
• Play/pause/resume playback.
• Auto-scan in DAB/FM mode.
7. Button
Stop playback.
8. SKIP/TUNE SEARCH Button
• Skip backwards to the beginning of
the track or to the previous track.
• Allow fast reversing of the current
track.
• Search for a radio station going
backwards through accessible radio
frequencies.
9. SKIP/TUNE SEARCH Button
• Skip forwards to the next track.
• Allow fast forwarding of the current
track.
• Search for a radio station going
forwards through accessible radio
frequencies.
10. Display
11. VOLUME +/– Dial
Increase or decrease the volume.
12. Remote Control Sensor
Receive signal from the remote control.
8

PUSH
OPEN/CLOSE
rear view
top view
1
23
3
1. Mains Cable
2. FM Aerial
1. OPEN/CLOSE Button
Open CD compartment.
3. SPEAKER (L/R) Sockets
9

1. STANDBY Button
Switch the unit between the ON and
STANDBY modes.
2. INFO Button
• Display soundtrack playback
information.
• Display current radio selection
information.
• ID3 On/O
3. REPEAT Button
Repeat a CD track or a music le.
4. Button
• Skip backwards to the beginning of
the track or to the previous track.
• Allow fast reversing of the current
track.
• Search for a radio station going
backwards through accessible radio
frequencies.
5. SELECT/MONO/ST. Button
Switch between mono or stereo in FM
mode.
6. PRESET/FOLDER Buttons
• Select a preset station in DAB or
FM mode.
• Select a folder in USB mode.
7. CLOCK Button
• Press to show the clock.
• Press and hold to enter clock setup
in Standby mode.
8. EQ Button
Select the EQ (Equaliser) mode.
9. MUTE Button
Silence the unit or restore the sound.
10. MODE Button
Switch between DAB, FM, CD, USB
AUX and Bluetooth modes.
11. MEMORY Button
• Press to show preset stations in DAB
or FM mode.
• Press to programme preset station
in DAB or FM mode.
• Press to programme tracks in CD
mode.
remote control
INFO MODE
STANDBY
MEMORY
CLOCK SHUFFLE
SELECT/
MONO/ST.
PRESET/FOLDER
TIMER
EQ INTRO SLEEP
––
–
MUTE VOLUME
REPEAT
SCAN
4
6
7
8
9
5
1
2
3
13
15
17
19
16
18
11
10
12
14
12. /SCAN Button
• Play/pause/resume playback.
• Auto-scan in DAB/FM mode.
13. Button
• Skip forwards to the next track.
• Allow fast forwarding of the current
track.
• Search for a radio station going
forwards through accessible radio
frequencies.
14. Button
Stop playback.
15. TIMER Button
Setup an alarm timer.
16. SHUFFLE Button
Random playback of CD tracks or music
les.
17. SLEEP Button
Select a sleep timer.
18. INTRO Button
Play soundtrack for 10 seconds.
19. VOLUME +/– Buttons
Increase or decrease the volume.
10

remove the plastic strip from the remote control
Remove the plastic strip from the battery if the battery is
being used for the rst time. It is located at the bottom rear
of the remote control.
2. Pull out the battery holder and remove the old
battery.
3. Replace with a new battery.
4. Insert the battery holder back into the remote
control.
battery replacement for the remote control
The remote control requires a CR2025, 3V Lithium battery.
1. Slide and hold the battery release tab in the
direction of the arrow.
Handling the Battery
• Improper or incorrect use of batteries may cause corrosion or battery leakage, which could
cause re, personal injury or damage to property.
• Install the battery correctly in the battery compartment. Normally the battery’s positive
polarity (+) will face up.
• Use only the battery type indicated in this manual.
• Do not dispose of the used battery as domestic waste. Dispose of it in accordance with
local regulations.
• Small button cell batteries such as the one used in the remote control are easily swallowed
by young children and this is dangerous. Keep loose button cells away from young children
and make sure that the battery is secure in the remote control. Seek medical advice if you
believe a battery cell has been swallowed.
11

remote control operation range
• The remote control sensor on the front unit is
sensitive to the remote control’s commands up
to a maximum of 4 metres away and within a
maximum of 60° arc.
• Please note that the operating distance may
vary depending on the brightness of the room.
AUDIO IN USB
5V 1A
MODE EQ
SCAN STOP
SKIP/
TUNE SEARCH
VOLUME
STANDBY
30° 30°
Max. 4 m
INFO MODE
STANDBY
MEMORY
CLOCK SHUFFLE
SELECT/
MONO/ST.
PRESET/FOLDER
TIMER
EQ INTRO SLEEP
––
–
MUTE VOLUME
REPEAT
SCAN
connections
speaker connections
Connect the speaker cables at the back of the speakers to the SPEAKER (L/R) Sockets at the
rear of the unit.
Handling the Remote Control
• Take care of your ngernails when you slide and pull the battery release tab.
• Do not drop the remote control.
• Do not allow anything to impact the remote control.
• Do not spill water or liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of excessive heat.
• Remove the battery from the remote control when not in use for a long period of time,
as corrosion or battery leakage may occur and result in physical injury, and/or property
damage, and/or re.
• When the battery is exhausted, the remote control will not function.
12

AUDIO IN USB
5V 1A
MODE EQ
SCAN STOP
SKIP/
TUNE SEARCH
VOLUME
STANDBY
AUDIO IN USB
5V 1A
MODE EQ
SCAN STOP
SKIP/
TUNE SEARCH
VOLUME
STANDBY
using the AUX connection
Use a 3.5mm to RCA stereo audio cable to connect the audio device’s audio output sockets
to the unit’s AUDIO IN socket.
3.5mm to RCA
stereo audio cable
(not included)
3.5mm to 3.5mm
stereo audio cable
(not included)
Mobile Device
Use a 3.5mm to 3.5mm stereo audio cable to connect the mobile device’s headphone
socket to the unit’s AUDIO IN socket.
AUDIO OUT
RRed
White
L
Audio device
connecting to the mains supply
• This unit is designed to operate with an AC power supply.
• Connecting the unit to any other power source may cause damage to the unit. Unwind
the mains cable to its full length. Connect the mains plug to a mains socket. Make sure
the mains plug is fully inserted into the mains socket. The unit is now connected and
ready to use.
• To switch the unit o completely, unplug the mains plug from the mains socket.
To the mains
socket
Ensure all connections are connected before connecting to the mains power socket.
13

charging from the USB CHARGING port
The USB 5V 1A charging port is designed only for charging mobile devices (e.g. MP3
player, mobile phone, etc). It supplies 5V DC at a charging current of up to 1000 mA (1A).
Use a USB cable (not included) to connect mobile device to the USB 5V 1A charging port
of the unit and the mobile device will start charging.
playing MP3 from a USB device
When a USB device is connected to the unit, press
MODE repeatedly on the unit or press MODE on
the remote control to select USB mode.
AUDIO IN USB
5V 1A
MODE EQ
SCAN STOP
SKIP/
TUNE SEARCH
VOLUME
STANDBY
AUDIO IN USB
5V 1A
MODE EQ
SCAN STOP
SKIP/
TUNE SEARCH
VOLUME
STANDBY
14

general operation
powering ON/OFF
When you rst connect the unit to the mains socket, display will show the “Scan Time
00:00:00” and synchronize to the current local time if you can receive a DAB signal in your
location. After approximate one minute, it will switch to STANDBY mode.
• Press STANDBY on the unit or the remote control to switch the unit to ON mode.
• Press STANDBY to switch the unit back to STANDBY mode.
• Disconnect the mains plug from the mains socket if you want to switch the unit o
completely.
• When the unit is idle for approximately 15 minutes, it will automatically switch to standby.
• Please turn the unit o completely to save energy when not in use.
selecting modes
Press MODE repeatedly to switch between DAB, FM, CD, USB,AUX and Bluetooth modes.
adjusting the volume
• Turn the VOLUME +/– dial on the unit or press VOLUME +/– on the remote control to
adjust the volume.
• If you wish to turn the sound o, press MUTE on the remote control. Press MUTE again
or press VOLUME +/– on the remote control or turn VOLUME +/– to resume normal
listening.
auto setting the clock
The clock can be updated automatically if you can receive a DAB signal in your location.
In order to synchronise to the current local time you must leave it on the DAB station for a
short period of time.
manually setting the time
1. During Standby mode, press and hold CLOCK on the remote control. The hour digits
ash on the display.
2. Press to adjust the hour digits, and then press CLOCK to conrm. The minute
digits will ash on the display.
3. Press to adjust the minute digits, and then press CLOCK to conrm.
4. The time is now set.
15

If you cannot received any DAB signal, you can manually set the time. Once DAB signal is
received, the time will be automatically updated.
setting the daily timer
1. Press and hold TIMER on the remote control until the
display shows“On Timer”, and the hour digits ash.
2. Press to adjust the hour digits, and then press
TIMER to conrm. The minute digits will ash on the
display.
3. Press to adjust the minute digits, and then press
TIMER to conrm.
4. When On Timer Clock set, the display will show “O Timer”
and the hour digits will ash.
5. Press to adjust the hour digits, and then press
TIMER to conrm. The minute digits will ash on the
display.
6. Press on the remote control to adjust the minute
digits, and then press TIMER to conrm.
7. Finally Press to select DAB, FM, DISC or USB mode,
then press TIMER to conrm. The display will show “VOL#”
and ash. Press to adjust the volume, and then
press TIMER to conrm.“ ” icon will show on the display to
indicator the timer is on.
8. The Timer setting is now complete.
to cancel the daily timer
Press TIMER on the remote control repeatedly to select Timer O mode. The “ ” indicator
will disappear from the display.
setting the sleep timer
Use the sleep timer to turn the system o after a certain number of minutes in play mode.
By setting the sleep timer, you can fall asleep to music and know that your system will turn
o by itself rather than play all night.
1. To set the sleep timer press SLEEP on the remote control repeatedly to view the
dierent timer settings. The number of minutes shown will display in this sequence:
90 80
OFF 10 20 30 40
70 60 50
2. The system is now set to turn o after the number of minutes you have set. The
display will show“SLEEP #”, e.g. “SLEEP 10”means the unit will switch itself o after
10 minutes, “SLEEP 20”means the unit will switch itself o after 20 minutes, and so on.
3. Press SLEEP to show the reminding time till the unit switches o minutes and return
back to previous screen.
16

4. To cancel the sleep timer press SLEEP repeatedly until “Sleep Timer OFF” shows on
the display.
EQ control
This system supports a variety of equalizers and sound eects.
During playback, press EQ on the remote control to select a desired music mode. Each time
EQ is pressed, the music mode will change to the next one as follows:
FLAT ROCKCLASSIC JAZZPOP
system reset
There may be times when you need to reset your unit back to the factory settings especially
when you have moved house. If you experience reception problems you may want to reset
and try again. If you move to another part of the country and pick up the local and national
DAB stations in that area, your previously tuned channels may no longer be available.
1. During DAB mode, open the CD door then press and hold
STOP on the unit until the display show “Restarting…
FACTORY RESET”.
2. When successful reset, it will back to DAB mode.
After the system reset, all the tuned stations, FM/DAB preset
stations will be erased.
17

DAB operation
If the unit is connected to the mains power and then switched on from standby for the rst
time, the unit will automatically enter into the DAB mode and perform auto scan function.
During the scan the display will show “SCANNING…”together with a slide bar that
indicates the progress of the scan and the amount of stations that have been found so far.
Once the scan has nished, the unit will select the rst alphanumerically found station. To
explore the found stations, press .
full scan
The full scan will search for the entire DAB Band III channels. After the scan has nished, the
rst alphanumerically found station will be automatically selected.
1. To activate auto scan, press /SCAN and the display will
show “SCANNING …” and a progressing slide bar.
2. All the stations that have been found will be stored
automatically. To explore and listen to the found stations,
press to select.
manual tuning
As well as the auto tune function, you can manually tune the receiver. This can help you
when aligning your aerial or when adding stations that were missed while auto tuning.
1. Press and hold SELECT/MONO/ST. to display the menu.
2. Press to cycle through the DAB channels, which are
numbered from 5A to 13F.
3. After your desired channel number is selected, press
SELECT/MONO/ST. to conrm. The display will show the
multiplex.
4. Press SELECT/MONO/ST. again to add selected channel to
station list.
secondary services
You may see a “>” symbol after the name of the station, this indicates that there are
secondary services available to that station. These secondary services contain extra
services that are related to the primary station. e.g. a sports station may want to add extra
commentaries. The secondary services are inserted directly after the primary station in the
station list.
To select the secondary station, press SELECT/MONO/ST. when the “>” appears in
the display before the station name. When the secondary service ends, the unit will
automatically switch back to the primary station.
18

preset stations
You can store up to 30 of your favourite stations to the memory. This will enable you to
access your favourite stations quickly and easily.
1. To store a preset, you must rst be listening to the station that you would like to save,
press and hold MEMORY. The display will show “Preset Store <#: (Empty)>”.
2. Press PRESET to select your desired preset station number.
3. The station will be stored in few seconds and the screen will then show “Preset #
Stored“.
recalling a stored station
1. Once you have saved a station to one of the preset buttons, you can recall it by pressing
MEMORY.
2. Press PRESET until your desired station show on the display; then it will play in few
seconds.
The stored stations will be saved into the memory and power o will not erase it. Storing a
new station into a preset location will erase the previously stored station in that location.
19

DAB display modes
Press INFO on the remote control, the display will switch through the following display
modes.
The information of each display mode is displayed on the lower segment of the display.
Ensemble
This displays the name of the multiplex that contains
the station you are listening to. A multiplex is a
collection of radio stations that are bundled and
transmitted on one frequency. There are national
and local multiplexes. Local ones contain stations
that are specic to that area.
DAB – unlike normal radio, groups together
several radio stations and transmits them on one
frequency.
Signal Strength
This shows a slide bar to indicate the signal strength,
the stronger the signal, the longer the bar will be
from left to right.
Time / Date
This displays the current time and date provided
automatically by the broadcaster.
DLS (Dynamic Label Segment)
Dynamic label segment is a scrolling message
that the broadcaster may include with their
transmissions. The message usually includes
information, such as programme details etc.
Programme Type
This describes the “style” or “genre”of the
programme that is being broadcast.
Audio Bit Rate
The display will show the digital audio bit rate being
received.
Frequency
This displays the frequency of the present station,
such as “11C 220.352MHz”.
Ensemble
Signal Strength
Frequency
Audio Bit Rate
Time / Date
DLS
Programme Type
20
