IWCS iriBridge IR-20-1060-01 User manual

USER MANUAL
COMMUNICATION CAN SAVE LIVES
IWCS
iriBridge
IRIBRIDGE
ANTENNA 1 ANTENNA 2
STATUS
2
STATUS
1
5VDC/(200mA) USB

CONGRATULATIONS ON YOUR NEW PRODUCT FROM
IRIDIUM WATERPROOF COMMUNICATION SYSTEMS
IWCS HOPE YOU WILL ENJOY THE BENEFITS OF TROUBLE FREE
HIGH QUALITY INTERCOM. PLEASE READ THESE INSTRUCTIONS
CAREFULLY BEFORE FIRST USE. IF INSTALLED, OPERATED AND
MAINTAINED ACCORDING TO THIS MANUAL, IRIBRIDGE WILL BE
A RELIABLE PARTNER IN MANY YEARS TO COME.
THOMAS B SVENNINGSEN
CO-FOUNDER OF IWCS
2
iriBridge
DUAL ACCESPOINT
COMMUNICATION CAN SAVE LIVES
IWCS

COMMUNICATION CAN SAVE LIVES
IWCS
CONTENT
CHAPTER 1 INTRODUCTION
1.1 Disclaimer Page 4
1.2 Copyright Page 4
1.3 Trademark Page 4
1.4 Safety Warning Page 5
CHAPTER 2 INSTALLATION
2.1 Unboxing Page 6
2.2 Tools Page 6
2.3 Installation Page 6
2.4 Drill Template Page 6
CHAPTER 3 OPERATION
3.1 Main Description Page 7
3.2 Setting Up Page 7
3.3 Pairings Page 7
CHAPTER 4 SERVICE AND MAINTENANCE
4.1 Troubleshoot Page 10
 4.2 Specications   Page11
Revision Date Description
1.0 03.02.2021 Release Rev. 1.0
2 3

COMMUNICATION CAN SAVE LIVES
IWCS
INTRODUCTION
1.1 DISCLAIMER
Any responsibility or liability for loss or damage in connection with the use of this product
and the accompanying documentation is disclaimed by IWCS. The information in this
manual is provided for information purposes only, is subject to change without notice and
may contain errors or inaccuracies.
Manuals issued by IWCS are periodically revised and updated. Anyone relying on this
information should acquire the most current version e.g. upon request at [email protected]
IWCS is not responsible for the content or accuracy of any translations or reproductions,
in the whole or in part, of this manual from any other source.
1.2 COPYRIGHT
2021 Iridium Waterproof Communication Systems ApS. All right reserved. Printed in
Denmark.
1.3 TRADEMARK ACKNOWLEDGEMENTS
iriBridge is a Trademark by Iridium Waterproof Communication Systems ApS
1.4 SAFETY WARNING
The following general safety precautions must be observed during all phases of operation,
service and repair of this equipment. Failure to comply with these precautions or with
specicwarningelsewhereinthismanualviolatessafetystandardsofdesign,manufac-
ture and intended use of the equipment. IWCS assumes no liability for the customer’s
failure to comply with these requirements.
1
4

COMMUNICATION CAN SAVE LIVES
IWCS
EMC / RF EXPOSURE
iriBridgeisCEcertiedasstatedintheDeclarationofConformitywhichisaccessibleon
request.
FIRE
Incaseofre,harmfulgasesandfumesmayoccur.Oneshouldimmediatelyleavethearea
and seek help. In case of suspected smoke in the lungs, a doctor should be consulted.
POWER LOSS
In the event of a power outage, iriBridge will turn off and will automatically restart when
power is restored.
IWCS is not responsible for any power outages or consequences thereof, of any kind
WARRANTY LIMITATIONS
IMPORTANT–Thisunitisasealed,waterproofunit(classiedIP67).TomeettheIP
classicationandtoensurecorrosionresistancewhenusedinavetand/orsaltyenviron-
ment, the end user must apply an environmentally applicable silicone sealant completely
covering the exposed metal base of the two antenna connectors after installing either
antennas or an optional antenna cable for remote antenna placement.
To create and maintain its waterproof integrity, the unit has been assembled in a con-
trolled environment using special equipment. This unit is NOT a user serviceable unit,
and under no circumstances should the unit be opened except by authorized personnel.
Unauthorized opening of the unit will invalidate the warranty.
INSTALLATION AND SERVICE
Installation and general service must be done by skilled service personnel only.
DISPOSAL
When disposing of iriBridge and related equipment, it must happen in accordance with
applicable national law or be returned to IWCS for proper recycling. There are no batte-
ries in iriBridge.
1
4 5

COMMUNICATION CAN SAVE LIVES
IWCS
INSTALLATION
2.1 UNBOXING
The following items are included in the delivery of your new iriBridge from IWCS
• iriBridge
• 2 Antennas
• Magnet
• User manual
2.2 TOOLS
The tools mentioned below are needed for installation
4,5 mm drill for machine screws or 3,2 mm drill for self tapping screws
Power drill
Screwdriverandspanner(dependingontypeofscrew)
4 x M4 machine screws, 4 x 4,0 mm washer, 4 x M4 nuts in stainless steel or
4 x M4 self tapping screws
2.3 INSTALLATION
MOUNTING IRIBRIDGE
FindaatsurfaceformountingyouririBridge.Makesurethattheantennasarenot
positionedclosetoreectingmetalsurfaces.
UsetheCuttingTemplate(Apendix),tosecuretheareaformounting.Fastenthetempla-
te, with tape, to the desired surface. Drill 4 x holes (4,5 mm or 3,2 mm depending on type
ofscrew).Mounttheselectedscrews.Ifmountedinaverybumpy/shakylocation,mount
iriBridgeonschockmounts(availablefromIWCSoryourlocaldealer).
Seal the holes with non-toxic industrial silicone.
2.4 DRILL TEMPLATE
Use seperate template.
2
6

COMMUNICATION CAN SAVE LIVES
IWCS
6 7
OPERATION
3.1 MAIN DESCRIPTION
DUAL DIGITAL ACCESPOINT
iriBridge is the digital Audio link between two wireless Bluetooth headsets, like iriComm
headsetsor3rdpartyheadsets/earpieces.
3.2 SETTING UP
INITIAL STARTUP
• Mount the two included antennas on iriBridge. Operating iriBridge without sui-
table antennas attached may damage the unit.
• ConnecttheUSBpowercablestoasuitable5V/0.5AUSBoutlet.iriBridgeturnson
automaticallyandafterafewsecondsbothindicatorLEDswillbeashinggreen.
3.3 PAIRINGS
PAIRING (of two headseets)
Before you can use your iriBridge, you must setup pairing with two suitable Bluetooth
headsets-oneatatime.Preferably,theheadset(s)shouldallowlocalvolumecontrolas
iriBridge does not perform any volume control.
PAIRING 1:
• PutyourheadsetintoBluetoothpairing(byowingtheinstructionsforthechosen
headset).
• Placethebluemagnetinfrontofthe(*)markforchannel1.TheLEDindicatorwill
changefromaashinggreentoasteadybluelight.Removethemagnetassoon
astheindicatorLEDchangestogreen.TheLEDindicatorwillnowbefast-ashing
blue indicating that iriBridge is in pairing mode.
• WaitfortheheadsetandiriBridgetondeachotherandconnect.Thiscantake
anywhere from a few seconds to a about a minute.
3

PAIRING 2:
• Repeat the same procedure as indicated above for channel 2.
Your two headset devices will now both be paired to iriBridge and bi-directional audio
will be passed between the two headsets. Adjust volume on the individual headset as
required.
After use, simply turn off the power to iriBridge and turn off both headsets. Next time
you turn on iriBridge and the headsets, they will automatically reconnect. No additional
pairing procedures are required.
ADVANCED SETUP
iriBridge also has the feature of acting as a wireless link between e.g. two vessels each
equipped with an iriBridge. In this case, channel 2 on each iriBridge is used for connecting
to the other iriBridge.
PAIRING WITH ANOTHER iriBridge
PAIRING:
Placethebluemagnetinfrontofthe markforchannel2ontherstiriBridge.TheLED
indicatorwillchangefromaashinggreentoasteadybluelight.Removethemagnetas
soonastheindicatorLEDchangestogreen.TheLEDindicatorwillnowbefast-ashing
blue indicating that iriBridge is in pairing mode.
On the second iriBridge, place the blue magnet in front of the mark for channel 2. The
LEDindicatorwillchangefromaashinggreentoasteadybluelight.WaitfortheLED
to change from steady blue to steady green and then back to steady blue again. Remove
the magnet as soon as the indicator LED changes to blue. The LED indicator will now be
fast-ashingblueindicatingthatiriBridgeisinpairingmode.
WaitforthetwoiriBridgeunitstondeachotherandconnect.Thiscantakeanywhere
from a few seconds to a about a minute.
For pairing of a headset to channel 1 on each iriBridge, follow the instructions under
“PAIRING(oftwoheadsets).
COMMUNICATION CAN SAVE LIVES
IWCS
3
8

COMMUNICATION CAN SAVE LIVES
IWCS
IRIBRIDGE
ANTENNA 1 ANTENNA 2
STATUS
2
STATUS
1
5VDC/(200mA) USB
Indicates Power ON
Place and hold the magnet until steady blue light turns green - remove immidiately
Indicates that Channel 1 is in pairing mode
Connection established
3
8 9
FOLLOW THE SAME STEPS ON CHANNEL 2

COMMUNICATION CAN SAVE LIVES
IWCS
4.1 TROUBLESHOOT
Action
Problem Cause
No light in LED Indicators Power cable not plugged in,
Cable defective,
iriBridge is defect
Replace iriBridge
RED light indication Other failure Restart the system
No Audio Paired device too far away,
iriBridge defect
Move paired device closer,
Replace iriBridge
For other troubles - contact your local dealer support.
SERVICE AND MAINTENANCE
4
10

COMMUNICATION CAN SAVE LIVES
IWCS
4.2 SPECIFICATIONS
Specications iriConnect
Model
Width
Depth
Height-woantennas/cables
Weight
Temp. range
IP Rating
Bluetooth Class
Power
Release - Revision
120/150mm
37 mm
100 mm
452 g
-20 to +65
IP67 (see comments in the section
“WARRANTYLIMITATIONS”)
Class II
5VDC/(200mA)USB
CLEANING / MAINTENANCE
Do not use chemicals or solvents to clean your iriBridge. Use only fresh water. Pressure,
friction, sharp objects, etc. can damage the product and the warranty may be void.
WARRANTY
iriBridgeiscoveredbyalimitedtwo(2)yearwarranty.
DECLARATION OF CONFORMITY
Refer to relevant section on www.iwcs.eu
4
Height - w standard 3dBi antennas 270 mm
03.02.2021 Rev. 1.0
10 11
IR-20-1060-01
Antenna connector RP-TNC

COMMUNICATION CAN SAVE LIVES
IWCS
iriBridge is developed, designed and manufactured by
IWCS ApS
Porthusvej 7A
3490 Kvistgaard
Denmark
[phone]
[email protected]
www.iwcs.eu
