Beforeyoubegin
•IntheboxareZAURAStartersandMasters.
•DonotyetinsertbatteriesintheMasters.
•Decidewhichconfigurationyouprefer:
–EasiestConfiguration,forNon‐Dimmingsystems(recom‐
mended):beginwithStepOne,overthereontheright. →
–CustomConfiguration,forsystemswithDimmers:refertothe
nextpage.
–ForsystemsthatwillincludeRangeExtenders,orforassistance,
seetheZAURARFWirelessLightingControlInstallationGuide
(UM0229),availableonwww.zilog.com.
•Assembleyourtools.
•Seethewww.zaura.comwebsitefor:
–Troubleshootinginfo
–Supportmaterials,videosanddocumentation
–Replacementpartsorderinginfo
LocalContactInfo
LessEnergyBV
AnthonettaKuijlstraat47
3066GSRotterdam
+31107144844
c.hermes@less‐energy.nl
www.less‐energy.nl
InstallingaSystemwithoutDimmingControls
StepOne
A. ReplacetheexistingstarterswiththeZAURAstarters.
B. Turnonthelightswitch(alllightsshouldbeilluminated).
StepTwo
A. InsertabatteryintheMaster.
B. Wait1minute.
C. PresstheAssociateNon‐Dimmerbuttononceandrelease.
D. Wait30secondstoallowtheassociationtocomplete.
StepThree
A. MountthebaseoftheMasterinthecenteroftheroomusingthe
screwsorthestickytapeprovided.
B. AttachtheMastertothebase.
StepFour
A. Exittheroom.Yourlightsshouldextinguishwithinafewminutes.
B. Reentertheroom.Yourlightsshouldilluminate.
ZAURA™RFWirelessLightingControl
QuickStartGuide

QS008101‐0211 www.zilog.com Copyright©2011Zilog
®
,Inc.Allrightsreserved.
InstallingaSystemwithDimmingControls
StepOne
A. Identifytheluminariesthatyouwanttobenon‐dimmingand
replacetheirexistingstarterswiththeZAURAstarters.
B. Turnonthelightswitch(alllightsshouldbeilluminated).
StepTwo
A. InsertabatteryintheMaster.
B. Wait1minute.
C. PresstheAssociateNon‐Dimmerbuttononceandrelease.
D. Wait30secondstoallowtheassociationtocomplete.
StepThree
A. Identifytheluminariesforwhichyouwantdimmingcapability
andreplacetheirexistingstarterswiththeZAURAstarters.
B. Turnonthelightswitch(alllightsshouldbeilluminated).
StepFour
A. PresstheAssociateDimmerbuttononceandrelease.
B. Wait30secondstoallowtheassociationtocomplete.
StepFive
A. MountthebaseoftheMasterinthecenteroftheroomusingthe
screwsorthestickytapeprovided.
B. AttachtheMastertothebase.
StepSix
A. Exittheroom.Yourlightsshouldextinguishwithinafewminutes.
B. Reentertheroom.Yourlightsshouldilluminate.
